FAURE HERMAN FH8500 User Manual

Hide thumbs

Advertisement

Quick Links

FH 8 5 0 0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the FH8500 and is the answer not in the manual?

Questions and answers

Related Manuals for FAURE HERMAN FH8500

Summary of Contents for FAURE HERMAN FH8500

  • Page 1 FH 8 5 0 0...
  • Page 3 Faure Herman Faure Herman Meter 1 1 1 1...
  • Page 4 FH 8 5 0 0 Attention! This manual contains important instructions and important warnings. It is essential to read and apply it before commencing installation, connection, and commissioning work. Failure to observe these instructions and warnings may damage the flowmeter and endanger persons.
  • Page 5 For prolonged storage, arrangements to protect from damp may be necessary. Return Before any return, contact Faure Herman. If the flowmeter has been used with hazardous, corrosive, or toxic substances, the operator must make sure that it has been correctly rinsed, cleaned, and decontaminated before being returned to Faure Herman.
  • Page 6 FH 8 5 0 0 4 4 4 4 TEC 05.03.09 / 412522 Revision index I 09/07/2013...

  • Page 7: Table Of Contents

    General contents General contents ATEX recommendations Chapter 1: General overview Chapter 2: Commissioning procedure Chapter 3: Using the FH8500 remote control device 35 Chapter 4: Spare parts and Maintenance Chapter 5: Modbus transmission tables Appendix I Appendix II Appendix III...
  • Page 8 FH 8 5 0 0 Detailed contents Personal notes 6 6 6 6 TEC 05.03.09 / 412522 Revision index I 09/07/2013...

  • Page 9: General Contents

    ATEX recommendations ATEX recommendations ATEX recommendations ATEX recommendations Recommandations ATEX Recommandations ATEX Recommandations ATEX Recommandations ATEX Raccomandazioni ATEX Raccomandazioni ATEX Raccomandazioni ATEX Raccomandazioni ATEX ATEX recommendations ATEX recommendations ATEX recommendations ATEX recommendations ATEX ATEX anbefalinger ATEX ATEX anbefalinger anbefalinger anbefalinger Recomendaciones ATEX Recomendaciones ATEX Recomendaciones ATEX...
  • Page 10 FH 8 5 0 0 ATEX ATEX ATEX ATEX anbefalinger anbefalinger anbefalinger anbefalinger ATEX ATEX richtlijnen ATEX ATEX richtlijnen richtlijnen richtlijnen Zalecenia Zalecenia Zalecenia Zalecenia ATEX ATEX ATEX ATEX ATEX ATEX Empfehlungen ATEX ATEX Empfehlungen Empfehlungen Empfehlungen ATEX-S S S S uositukset uositukset uositukset uositukset...

  • Page 11: Atex Recommendations

    ATEX recommendations Συστάσεισ Συστάσεισ Συστάσεισ Συστάσεισ περί περί περί ATEX περί ATEX ATEX ATEX 9 9 9 9...
  • Page 12 FH 8 5 0 0 Protection hazardous area • • • • • Remark: The FH8500 is delivered with ATEX certificates and corresponding elements. TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 13 ATEX recommendations ATEX recommendations for FH8500 transducer Equipment nameplate Refer to the equipment nameplate for operating field specifications. Company name: FAURE HERMAN Company address: Route de Bonnétable 72400 La Ferté Bernard – France Model: USTT Serial number S/N… Manufacturing year:...
  • Page 14 FH 8 5 0 0 Installation WARNING: CAUTION: WARNING: WARNING: WARNING: Maintenance WARNING: WARNING: WARNING: Don’t forget to give us your equipment serial number. TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 15 ATEX recommendations ATEX recommendations for FH8500 electronic enclosure Equipment nameplate Refer to the equipment nameplate for operating field specifications. Company name: FAURE HERMAN Company address: Route de Bonnétable 72400 La Ferté Bernard – France Model: ADS8500 Serial number S/N… Manufacturing year:...
  • Page 16 FH 8 5 0 0 Installation WARNING: CAUTION: WARNING: WARNING: WARNING: Maintenance WARNING: WARNING: WARNING: Don’t forget to give us your equipment serial number. TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 17 Chapter 1: General overview overview overview Remark: The FH8500 is delivered with an individual calibration certificate. Measuring principle Note: The figure shows only the transducer seatings. (1) The API recommendations are more restrictive than the OIML's ones, which recommends an 0,2 % – class 3 error.
  • Page 18 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...

  • Page 19: Chapter 1: General Overview

    Chapter 1: General overview upstream transducer (A) direction of flow downstream transducer (B) ⋅ − ⋅ Remark: The expression above is independent of the velocity of sound inside the product flowing in the pipe. This velocity can be computed by the meter by using the following expression: ...
  • Page 20 FH 8 5 0 0 Sizes and Flowrates Standard K-factors FH8500 diameter Pulses / m3 Pulses / barrel Remark: For a given size, the recommended K-factor has been adjusted to provide the best repetability of the measurement. Working modes •...
  • Page 21 Chapter 1: General overview • Constitutive parts of the FH8500 • • • Important • • Remark...
  • Page 22 FH 8 5 0 0 Enclosure containing the electronics The connection 4x20 character enclosure is behind display Casings protecting the transducers FH8500 inputs-outputs • π • − − • TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 23 Chapter 1: General overview • • Data logger and Event logger Remark: The total recording duration depends on the selected period. The table below gives the recording duration for several period values. Recording period Total available recording duration ≈ ≈ ≈...
  • Page 24 Remark: Refer to Appendix V for pressure temperature rating as a function of body material (ASME B16.5-2003 – Tables 2-1.1, 2-1.2, 2-2.2). Pressure drop Using the FH8500 in a vertical pipe Power supply TEC 05.03.09 / 412522 Revision index I...
  • Page 25 (See the 5.8 chapter of the MPMS) • • • • • • Remark For all the FH8500 models, the body is made by casting. • • • • • − − −...
  • Page 26 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 27 Chapter 2: Chapter 2: Chapter 2: Chapter 2: Commissioning Commissioning procedure Commissioning Commissioning procedure procedure procedure FH8500 handling • • Important Reception and storage...
  • Page 28 FH 8 5 0 0 Choice of the FH8500 location on the pipe Installing the FH8500 Erreur ! Signet non défini.Erreur ! Signet non défini. Remark: Both flanges have a slightly conical edge allowing to correct a difference of thickness (schedule) or alignment between the pipe and the meter.

  • Page 29: Chapter 2: Commissioning Procedure

    Chapter 2: Commissioning procedure Cabling the FH8500 • • • Important Remark: The cabling enclosure includes three glands: two 1/2 " glands for the instrumentation cables and one 1/4 " gland for the power supply cable.
  • Page 30 FH 8 5 0 0 Cabling the RS 485 link + transmission – transmission Cabling the 4-20 mA ouputs + output #1 – output #1 + output #2 – output #2 + output #3 – output #3 Cabling the temperature input + temperature –...
  • Page 31 Chapter 2: Commissioning procedure Wiring the alarms Alarm #1 Alarm #1 Alarm #2 alarm #2 For both polarity Selection of the pulse outputs working mode output n° 2 output n° 1 • −...
  • Page 32 FH 8 5 0 0 Remarks: 1) Removing a jumper leads to the disconnection of the corresponding output. 2) On delivery, the pulse outputs are set according to the customer demand. By default, the pulse outputs are set in the TTL mode. Connecting scheme for a pulse output External resistor between 480 and 2000...
  • Page 33 Live wire (110 ou 220 V) Remarks: 1) The power supply cable must be a 0,6mm /1 kV cable = AWG 19. 2) The FH8500 is protected by a 5x20mm 500 mA delay fuse located in the enclosure containing the electronic boards.
  • Page 34 FH 8 5 0 0 Wiring the shielding Shielding Earthing of the meter to the pipe TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 35 Chapter 2: Commissioning procedure Setting the FH8500's parameters Commissioning of the plant...
  • Page 36 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 37 Reminder: The custody mode allows to set the only parameters which have no influence on the measurement. The non fiscal mode allows to stop the meter and modify all the parameters except the ones set by Faure Herman (inside diameter and calibration coefficients).
  • Page 38 FH 8 5 0 0 Remote control device's keypad 10 figures and decimal point moving a digit right or left selection of a menu, a sub- menu, a parameter validation key Information displayed in measure mode • • • • •...

  • Page 39: Chapter 3: Using The Fh8500 Remote Control Device

    Chapter 3: Using the FH8500 remote control device General parameter setting procedure ↑ ↓ → ↓ ↑ Remark: Each parameter setting screen includes an "Exit" line and a "Stop" / "Start" line. (The "Stop" / "Start" line is displayed only when the FH8500 is in non custody transfer mode.)
  • Page 40 FH 8 5 0 0 Important Menus and sub-menus structure "1 Settings" • • Remark: It is possible to define separately the display units and the units used for 4-20 mA outputs and the alarms. • • • • • •...
  • Page 41 Chapter 3: Using the FH8500 remote control device "5 Configuration" • • "6 Zeroing" Selection of units Display unit for the flow rate − Display unit for the temperature Display unit for the pressure Display unit for the totalizer...
  • Page 42 FH 8 5 0 0 Display unit for the velocity of sound Transmission unit for the velocity of sound Transmission unit for the velocity of flow Transmission unit for the flow rate Transmission unit for the totalizer Transmission unit for the pressure TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 43 Chapter 3: Using the FH8500 remote control device Transmission unit for the temperature Setting the analog outputs Allocation of the output n° 1 − − − − − − − Calibration of 4 and 20 mA limits of the analog output n° 1...
  • Page 44 FH 8 5 0 0 Setting of the analog output n° 3 Setting the temperature input Setting the pressure input Setting the alarms Allocation of the alarm n° 1 − − − − − − − − TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 45 Chapter 3: Using the FH8500 remote control device Switching mode of the alarm n° 1 Threshold of the alarm n° 1 Summary of the alarm n° 1 Setting of the alarm n° 2 Setting the serial link Selection of the link protocol...
  • Page 46 Setting the data logger and resetting both loggers Choosing the data logger storage period Resetting the Data Logger Resetting the Event logger Setting FH8500 date and time Setting the date Remark: Day, month and year must be validated separately. TEC 05.03.09 / 412522...
  • Page 47 Chapter 3: Using the FH8500 remote control device Setting the time Setting the back-light − − − Resetting the totalizer Display of the temperature corrected inside diameter Display of the serial number Time constant of the floating average filter...
  • Page 48 FH 8 5 0 0 Factory set parameters Setting the K-factor K-factor unit Value of the K-factor Zeroing TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 49 Chapter Chapter 4 4 4 4 : : : : Chapter Chapter Spare Spare parts Spare Spare parts parts parts and and Maintenance Maintenance Maintenance Maintenance Warning Spare parts • • Important...
  • Page 50 FH 8 5 0 0 1. Replacing the converter's electronics Removing the electronics Turn off the power supply. TEC 05.03.09 / 412522 Revision index I 09/07/2013...

  • Page 51: Chapter 4: Spare Parts And Maintenance

    Chapter 4: Spare parts and Maintenance...
  • Page 52 FH 8 5 0 0 Installing a new converter's electronics TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 53 Chapter 4: Spare parts and Maintenance 2. Removing and replacing the transducers Removing a transducer Erreur ! Signet non défini.Erreur ! Signet non défini. Reminder: One path corresponds to two transducers. Turn off the power supply.
  • Page 54 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 55 Chapter 4: Spare parts and Maintenance • • •...
  • Page 56 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 57 Chapter 4: Spare parts and Maintenance Installing a new transducer...
  • Page 58 FH 8 5 0 0 3. Performing a zeroing procedure TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 59 Chapter Chapter 5 5 5 5 : : : : Chapter Chapter Modbus Modbus transmission tables Modbus Modbus transmission tables transmission tables transmission tables Avalaible tables • Table n° 1 − − − − − − − − • Table n° 2 −...
  • Page 60 FH 8 5 0 0 • Table n° 3 − − − − − − • Table n° 4 − − − − • Table n° 5 − − − • Table n° 6 • Table n° 7 − − −...

  • Page 61: Chapter 5: Modbus Transmission Tables

    Chapter 5: Modbus transmission tables • Table n° 8 − − − Main characteristics of the transmission • • • • • • • • Transmission formats • • • 31 30 23 22 sign Exponent on 8 Mantissa on 23 bits...
  • Page 62 FH 8 5 0 0   − = −  ⋅  ) 1 1   Example: Given the value 40.21.80.40h 0 0 0 0 0 0 0 0 1 0 0 0 0 1 1 0 0 0 0 0 0 0 0 1 0 0 0 0 0 0 ...
  • Page 63 Chapter 5: Modbus transmission tables Framework for the writing of n Modbus words (1≤ n ≤ 123) Request Slave Function Address Number Nb of Value of Value of CRC16 number code of the of words bytes in the 1st the last control (16) 1st word...
  • Page 64 FH 8 5 0 0 Structure of the table n°1 Modbus Format Access Name and description address CM NCM Remark : 0 if temperature sensor not wired Remark : 0 if pressure sensor not wired TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 65 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 66 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 67 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM Remark: This word is reset to 0 when the totalizer reset is over.
  • Page 68 FH 8 5 0 0 Structure of the table n° 2 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 69 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 70 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 71 Chapter 5: Modbus transmission tables Structure of the table n° 3 Modbus Format Access Name and description address CM NCM Remark : The value is equal to 0 if the path is not valid. Remark : The value is equal to 0 if the path is not valid.
  • Page 72 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 73 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 74 FH 8 5 0 0 Structure of the table n° 4 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 75 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 76 FH 8 5 0 0 Structure of the table n° 5 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 77 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 78 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 79 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 80 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 81 Chapter 5: Modbus transmission tables Structure of the table n° 6 Modbus Format Access Name and description address CM NCM...
  • Page 82 FH 8 5 0 0 Structure of the table n° 7 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 83 Chapter 5: Modbus transmission tables Structure of a Data logger record Modbus Format Access Name and description address CM NCM...
  • Page 84 FH 8 5 0 0 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 85 Chapter 5: Modbus transmission tables Modbus Format Access Name and description address CM NCM...
  • Page 86 FH 8 5 0 0 Structure of the table n° 8 Modbus Format Access Name and description address CM NCM TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 87 Chapter 5: Modbus transmission tables Structure of an Event logger record Modbus Format Access Name and description address CM NCM...
  • Page 88 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 89 Appendix Appendix Appendix Appendix I I I I Dimensions, weight, maximal flow rate vs meter size Diameter Min flow rate Max flow rate Weight (1 m/s) (15 m/s) 3 /h 3 /h inches Bbl/h Bbl/h...
  • Page 90 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 91 Appendix Appendix Appendix Appendix II II II II Lifting Arrangement Drawing...
  • Page 92 FH 8 5 0 0 Lifting Arrangement Drawing TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 93 Appendix Appendix II II II III I I I Appendix Appendix FH8X00 HART Commands list Unniversal Commands Command 0 Read unique identifer Command 1 Read primary variable Command 2 Read loop current and percent of range Command 3 Read dynamic variables and loopd current Command 6 Write polling address Command 7...
  • Page 94 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 95 Appendix Appendix IV IV IV IV Appendix Appendix FH8X00 HART Menu Tree Meter type Device config ─── Device info ─── Distributor Manufacturer Model Dev id Date Write protect Descriptor Message Final asmbly num HART 6 Max Number Of Devices Variables ───...
  • Page 96 FH 8 5 0 0 Temperature unit ─── ° C ° F Pressure unit ─── Totalizer unit ─── US gal Configuration Diameter Damping Factory settings ─── Coefficient 1 Coefficient 2 Coefficient 3 Coefficient 4 Coefficient 5 Coefficient 6 Coefficient 7 Coefficient 8 Coefficient 9 Coefficient 10...
  • Page 97 Appendix IV ↓ ↓ 4/20mA inputs ─── Temperature input ─── 4mA value 20mA value Pressure input ─── 4mA value 20mA value Alarms ─── Alarm n1 ─── Variable ─── Velocity of sound Velocity of fluid Flowrate Totalizer Pressure Temperature Signal Limit alarm active when >...
  • Page 98 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 99 Appendix pendix pendix pendix V V V V Pipe Flanges and flanged fitting ASME B16.5-2003 Table 2-1.1 Pressure – Temperature ratings for Group 1.1 Materials...
  • Page 100 FH 8 5 0 0 Appendix Appendix Appendix Appendix V V V V Pipe Flanges and flanged fitting ASME B16.5-2003 Table 2-1.2 Pressure – Temperature ratings for Group 1.2 Materials TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 101 Appendix V Appendix Appendix Appendix Appendix V V V V Pipe Flanges and flanged fitting ASME B16.5-2003 Table 2-2.2 Pressure – Temperature ratings for Group 2.2 Materials...
  • Page 102 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 103 Appendix Appendix V V V V I I I I Appendix Appendix Operating restrictions – Special recommendations • • • Remark: When the operating temperature is higher than the indicated value the maximum authorized pressure shall be reduced, in strict application of the NF EN 1759-1 Standard.
  • Page 104 FH 8 5 0 0 Gasket Flange bolting Tightening torque Recommended tightening torque for Klingersil gasket type TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 105 Appendix VI Equipment installation...
  • Page 106 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 107 Appendix VI Equipment disassembly Important The equipment is a measuring instrument and shall be used as such. The equipment body of the associated components (flowstraightener, bosses …) are designed to support stresses in reasonably foreseeable operating conditions. They are not designed to be used as supports, equipment carry means or step.
  • Page 108 WEEE Directive. The disposal of the used Electronic Board should be either sent back to Faure Herman who will take care of its disposal, or dispose by the customer according to the EPA rules of its country.
  • Page 109 Detailed contents Detailed contents Detailed contents Detailed contents General contents ATEX recommendations Chapter 1: General overview Chapter 2: Commissioning procedure...
  • Page 110 FH 8 5 0 0 Chapter 3: Using the FH8500 remote control device 35 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 111 Detailed contents Chapter 4: Spare parts and Maintenance Chapter 5: Modbus transmission tables ≤ ≤...
  • Page 112 FH 8 5 0 0 Appendix I Appendix II Appendix III Appendix IV Appendix V TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 113 Detailed contents Appendix VI Detailed contents Personal notes...
  • Page 114 FH 8 5 0 0 TEC 05.03.09 / 412522 Revision index I 09/07/2013...
  • Page 115 Personal Personal notes Personal Personal notes notes notes...
