  • Page 1 Lenovo N27p User Guide...
  • Page 2 Version 1 (April 2024) All rights reserved Lenovo 2024 LENOVO products, data, computer software, and services are developed on earmarked funds and are sold to government agencies as commodities as defined in 48 C.F.R. 2.101, with limited restricted rights of use, duplication, and disclosure granted to the government agencies.
  • Page 3 Contents ������������������������������ ����� � Safety Matters ����������������������������� � General Safety Principles ���������������� ���� ������� Chapter 1. New Member Guide ��������������������������� ����....Items List ���������������������������� ��� Precautions For Use ������������������������������...� Product Overview ������������������������� �����.�. Set Up the Display ������������������ ���.� Chapter 2. Adjusting and Using the Display ���������������������...
  • Page 4 Safety Matters General Safety Principles For tips on safe computer use, please go to: http://www.lenovo.com/safety Before installing this product, please read the safety matters. Danger To avoid collision dangers: • Do not remove the cover. • Do not use the product without the base installed.
  • Page 5 This user guide provides detailed operation instructions. For Quick overview instructions, see the Quick Start Guide for brief information. N27p Supports Lenovo Accessories and Display Manager- Artery. Items List The following items should be included in the package of this product: ■Quick Start Guide...
  • Page 6 Precautions For Use To set up your display, please refer to the following illustration. Note: Do not touch the screen area of the display. The screen area is a glass product and can be easily damaged by friction or pressure. 1.
  • Page 7 Height Adjustment Pivot Before the display is shown in the vertical direction, it should be fully lift up and fully tilted to avoid collisions. Chapter 1. New Member Guide 1-3...
  • Page 8 Swivel With the built-in base, you can tilt and rotate the display to get the best viewing angle. Display Control Different functions can be used through the key controls on the panel frame. For information on how to use these key controls, see "Adjusting the Display Image" on pages 2-3. Chapter 1.
  • Page 9 Kensington anti-theft lock Your display is equipped with a Kensington anti-theft lock, which is located on the back of the display. Chapter 1. New Member Guide 1-5...
  • Page 10 Set Up the Display This section describes how to set up the display. Connecting and Powering on the Display Note: Before performing this procedure, be sure to read the "Safety Matters" on page iv. 1. Turn off the power to the computer and all connected devices, and then unplug the computer's power cord.
  • Page 11 4. For computers with DP connections. 5. For computers with USB-C connections. Chapter 1. New Member Guide 1-7...
  • Page 12 6. For computers with USB-A connections. 7. Connect the audio cable of the speaker and the audio jack of the monitor to transmit the audio source from HDMI. Note: HDMI mode audio output. Chapter 1. New Member Guide 1-8...
  • Page 13 8. Plug the power cord into the display, and then plug the display power cord and computer cord into a grounded power outlet. Note: A certified power cord must be used for this equipment. The installation and/o r equipment regulations of the country concerned should be taken into account. The certified power cable used should not be lighter than the normal PVC cable (marked H05VV-F 3G 0.75mm or H05VVH2-F2 3G 0.75mm...
  • Page 14 10. Turn on the power to the display and computer. 11. When you install the display driver, download the driver that corresponds to your display model from the Lenovo website at http://support.lenovo.com.cn/ . To install the driver, see the "Manually Install the Driver for the Display" section on pages 3-5.
  • Page 15 Chapter 2. Adjusting and Using the Display This section describes how to adjust and use this display. Comfort and Assistance Functions Good ergonomic designs are important for the comfortable use of your personal computer. Your workplace and the equipment you use should be arranged appropriately for your personal needs and the type of work you do.
  • Page 16 Here are some additional tips for comfortable viewing of your display: • Use adequate lighting for the type of work you do. • Use display brightness, contrast, and image controls (if available) to optimize the image on the screen for your visual needs. •...
  • Page 17 Adjusting the Display Image This section describes the functions of the user controls used to adjust the display image. Using Direct Access Controls When On Screen Display (OSD) is not displayed, you can use direct access controls. Icon Control Description Power Power on/off...
  • Page 18 Use the On-Screen Display (OSD) Control When adjusting the settings, you can view the user controls through the OSD. N27p Brightness Basic Settings Contrast Off Color Settings Standard Display Mode Auto Audio Settings Full Screen Scaling Mode Normal Over Drive...
  • Page 19 Table 2-1. OSD Functions Main Menu Submenu Description Controls and Adjustment Brightness Adjust the overall brightness of the screen Contrast Adjust the screen contrast Power consumption Changing this setting will Off increase the power consumption. Change/Cancle Display Mode Standard Game Movie Picture Basic Settings...
  • Page 20 Input Signal HDMI2 HDMI1 USB Charging Port Settings Off USB 3.2 USB Select USB 2.0 DP 1.2 DP Select DP 1.4 Model Name: N27p Refresh Rate: 60Hz Firmware: Information Scaler L1.0 8.20 USB Hub 1.00 Serial Number: UMA00001 English Français Italiano 简体中文...
  • Page 21 Menu Vertical Position 0-100 Transparency 0-100 DDC/CI Off Factory Reset Reset Low Blue Light Concerns about the effects of blue light on eye health have been growing for years. The wavelength of blue light is between 300 nanometers and 500 nanometers. This display reduces the emission of blue light in the default setting mode.
  • Page 22 Select Supported Display Modes The display mode used by the display is controlled by the computer. Therefore, you should refer to the computer's documentation for detailed information on how to change the display mode. When the display mode is changed, the image size, position, and shape may change. This is normal and the image can be readjusted using the automatic image settings and image controls.
  • Page 23 Understanding Power Management The power management function is activated when the computer detects that the mouse or keyboard has not been used for a user-defined time interval. There are several states as described in the table below. For best performance, it is best to turn off the display at the end of the day, or when it is not in use for a longer period during the day.
  • Page 24 Maintaining the Display Always turn off the power to the display before performing any maintenance work on the display. Do not: • Let water or liquids spill onto the display. • Use solvents or abrasive substances. • Use flammable cleaning materials to clean the display or any other electronic device. •...
  • Page 25 Step 3: Remove the base and stand from the display, see "Removing the Display Base and Support Arm" on pages 2-10. Step 4: Install the assembly bracket for the VESA compatible wall mount (100mm x 100mm distance), VESA assembly screws M4 x 10 mm. Step 5: Mount the LCD to the wall following the instructions for the wall mount.
  • Page 26 Chapter 3. Reference Information This section provides display specifications, instructions for manual installation of the display driver, and troubleshooting information. Display Specifications Table 3-1. Display Specifications - Model H24270UN0 Size Depth 228.9 mm（9.01 in.） Height 533.1~413.1 mm (20.99~16.26 in.) Width 615.0 mm (24.21 in.) Support Arm Tilt...
  • Page 27 USB-C Input signal USB-C Horizontal addressing capability 3840 pixels (max) Vertical addressing capability 2160 pixels (max) Clock frequency 594 MHz (max) Communication VESA DDC/CI Supported display Horizontal frequency 63.75 kHz - 138.9 kHz modes Vertical frequency 40 Hz - 62 Hz Self-resolution 3840 x 2160 @ 60 Hz Temperature...
  • Page 28 Troubleshooting If you encounter problems setting up or using your display, you may be able to solve the problem. Before contacting your dealer or Lenovo, please try the following suggested actions depending on the problem you are experiencing. Table 3-2. Troubleshooting...
  • Page 29 Problem Possible Causes Recommended Operations Refer to •Image settings are not Adjust the system's resolution "Adjusting the Display •Blurred lines or images in text optimized setting to the resolution of this Image" on pages 2-3. •Horizontal or vertical lines are •The system's display display: 3840 x 2160 @ 60 Hz.
  • Page 30 3840 x 2160 @ 60 Hz refresh rate. Get further help If you are still unable to resolve the issue, please contact Lenovo Support. For more information on contacting the Support Center, see "Appendix A. Service and Support" on page A-1.
  • Page 31 The Customer Support Center will continue to provide installation and netting support for 90 days after the option is removed from the market. After this time, Lenovo will, at its discretion, no longer provide support or provide paid support. Other support services are charged at the published cost.
  • Page 32 Finland Warranty service and support: +358-800-1-4260 (Finnish) France Warranty service and support: 0810-631-213 (hardware) (French) Germany Warranty service and support: 0800-500-4618 (toll-free) (German) Greece Lenovo Business Partner (Greek) Guatemala Dial 999-9190, wait for operator, and request to reach 877-404-9661 (Spanish)
  • Page 33 ThinkCentre and ThinkPad: 352-360-385-222 (French) 1-800-88-0013 Malaysia 03-7724-8023 (Standard Charges Apply) (English) 356-21-445-566 Malta (English, Italian, Maltese Arabic) 001-866-434-2080 Mexico (Spanish) 020-513-3939 Netherlands (Dutch) 0508-770-506 New Zealand (English) 001-800-220-2282 Nicaragua (Spanish) 8152-1550 Norway (Norwegian) Lenovo Customer Support Center: 001-866-434 (toll-free) Panama (Spanish)
  • Page 34 0-800-50-866 OPCION 2 Peru (Spanish) 1-800-8908-6454 (GLOBE subscribers) Philippines 1-800-1441-0719 (PLDT subscribers) (Tagalog, English) Laptops and tablets branded with logo Think: 48-22-273-9777 Poland ThinkStation and ThinkServer: 48-22-878-6999 (Polish, English) 808-225-115 (Standard Charges Apply) Portugal (Portuguese) 4-021-224-4015 Romania (Romanian) +7-499-705-6204 Russia +7-495-240-8558 (Standard Charges Apply) (Russian) 1-800-415-5529 Singapore...
  • Page 35 Lenovo may own or be applying for patents on the items mentioned in this document. The distribution of this document does not give you a license to use these patents. You may make inquiries in writing by sending a license to the following address: Lenovo (United States), Inc.
  • Page 36 Collect and Recycle Used Lenovo Computers or Displays If you are a company employee and need to dispose of a Lenovo computer or display that is a company asset, it must be disposed of following the requirements of the Resource Efficient Use Promotion Act.
  • Page 37 Power Cord Only the power cord provided by the product manufacturer should be used. Do not use AC power cords from other devices. Appendix B. Declaration B-3...
