Washing Machine

WF0794W7-02875N_EN.indd 1

user manual

imagine

the possibilities

Thank you for purchasing this Samsung product.

To receive a more complete service, please

www.samsung.com/register

WF0794W7(E/N/S/V/W)

WF0792W7(E/N/S/V/W)

WF0794Y7(E/N/S/V/W)

WF0792Y7(E/N/S/V/W)

2010-10-05

3:54:21

Need help?

Do you have a question about the WF0794W7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung WF0794W7

Page 1 WF0794W7(E/N/S/V/W) WF0792W7(E/N/S/V/W) WF0794Y7(E/N/S/V/W) WF0792Y7(E/N/S/V/W) Washing Machine user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WF0794W7-02875N_EN.indd 1 2010-10-05 3:54:21...
Page 2 No time to waste! Quick Wash program can help your busy life - now you can wash your favorite clothes (up to 2Kg) in 15 minutes! • Quiet Drive Motor Samsung’s unique Quiet Drive Motor works without belts or gears, reducing vibration and making the washer quieter and more durable. • Eco Drum Clean Using Ecol Drum Clean helps to keep washing machine clean even without any chemical detergent or bleach.
Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
Page 4 Congratulations on your new Samsung washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefits and features.
Page 5 For washing machines with ventilation openings in the base, ensure that the opening is not obstructed by carpet or any other obstacles. Use the new hose-sets and old hose-sets should not be reused. safety information _5 WF0794W7-02875N_EN.indd 5 2010-10-05 3:54:23...
Page 6 Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in electric shock or fire. Do not pull or excessively bend the power cord. Do not twist or tie the power cord. 6_ safety information WF0794W7-02875N_EN.indd 6 2010-10-05 3:54:23...
Page 7 - If trapped inside, the child may become trapped and suffocate to death. Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washer before using it. safety information _7 WF0794W7-02875N_EN.indd 7 2010-10-05 3:54:23...
Page 8 Unplug the power plug when the appliance is not being used for long periods of time or during a thunder/lightning storm. - Failure to do so may result in electric shock or fire. 8_ safety information WF0794W7-02875N_EN.indd 8 2010-10-05 3:54:23...
Page 9 Open the Water Tap and check if the water supply hose connector is firmly tightened and that there is no water leaking before using the product. - If the screws or the water supply hose connector are loose, it may result in water leakage. safety information _9 WF0794W7-02875N_EN.indd 9 2010-10-05 3:54:23...
Page 10 - This may result in spontaneous combustion or ignition due to the heat of the oxidation of the oil. Do not use hot water from water cooling/heating devices. - This may result in problems with the washer. 10_ safety information WF0794W7-02875N_EN.indd 10 2010-10-05 3:54:23...
Page 11 - This may result in discolouration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failure to do so may result in electric shock or fire. safety information _11 WF0794W7-02875N_EN.indd 11 2010-10-05 3:54:23...
Page 12 Repairing a frozen washing machine Storing your washing machine TROUbleshOOTING ANd Check these points if your washing machine... INfORmATION COdes Information codes CyCle ChART Cycle chart AppeNdIx Fabric care chart Protecting the environment Declaration of conformity Specifications 12_ contents WF0794W7-02875N_EN.indd 12 2010-10-05 3:54:23...
Page 13 Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Work top...
Page 14 You can reduce the risk of leaks and water damage by: • Making water taps easily accessible. • Turning off taps when the washing machine is not in use. • Periodically checking for leaks at water inlet hose fittings. Before using your washing machine for the first time, check all connections at the water valve and taps for leaks. WarninG 14_ setting up your washing machine WF0794W7-02875N_EN.indd 14 2010-10-05 3:54:25...
Page 15 Drain Samsung recommends a standpipe height of 65cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.
Page 16 4. Store the shipping bolts away safely in case you have to move the washing machine in the future. Packaging materials can be dangerous to children; keep all packaging material (plastic bags, polystyrene, etc.) well out of the reach of children. WarninG 16_ setting up your washing machine WF0794W7-02875N_EN.indd 16 2010-10-05 3:54:25...
Page 17 2. Connect the other end of the hot water supply hose to your sink’s hot water tap and tighten it by hand. 3. Use a Y-piece if you only want to use cold water. setting up your washing machine _17 WF0794W7-02875N_EN.indd 17 2010-10-05 3:54:26...
Page 18 5. Connect the other end of the water supply hose to the inlet water valve at the rear of the washing machine. Screw the option hose clockwise all the way in. 18_ setting up your washing machine WF0794W7-02875N_EN.indd 18 2010-10-05 3:54:27...
Page 19 It is attached to the water supply hose and automatically cuts off the water flow if the hose is damaged. It also displays a warning indicator. • Connect the water supply hose to the tap as shown. setting up your washing machine _19 WF0794W7-02875N_EN.indd 19 2010-10-05 3:54:28...
Page 20 Plug the power cord into a wall sockets, an AC 220-240V / 60Hz approved electrical outlet protected by a fuse or circuit breaker. (For more information on electrical and grounding requirements, see page 14.) 20_ setting up your washing machine WF0794W7-02875N_EN.indd 20 2010-10-05 3:54:29...
Page 21 With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WaSHinG for tHE firSt tiME Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry).
Page 22 Fabrics include functional technology finishes and fibers such as spandex, stretch, and micro-fiber. Baby Care - High temperature wash and extra rinses ensure that no washing powder remains to mark your thin clothes. 22_ washing a load of laundry WF0794W7-02875N_EN.indd 22 2010-10-05 3:54:30...
Page 23 Cotton, Synthetics, Denim, Bedding, Daily Wash, Baby Care. “Intensive”: Press this button when the laundry is heavily soiled and needs to be washed intensively. The cycle time is increased for each cycle. washing a load of laundry _23 WF0794W7-02875N_EN.indd 23 2010-10-05 3:54:31...
Page 24 Press it once to turn your washing machine on, press it again to turn your washing machine off. pOWeR bUTTON If the washing machine is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. 24_ washing a load of laundry WF0794W7-02875N_EN.indd 24 2010-10-05 3:54:31...
Page 25 If you want to activate or deactivate the Sound Off function, press the spin and Option buttons at the same time for 3 seconds. The “Sound Off ” will be lit when this feature is activated. 3 SEC. washing a load of laundry _25 WF0794W7-02875N_EN.indd 25 2010-10-05 3:54:32...
Page 26 If you press My Cycle and release it within 3 seconds, the previously saved course and options appear. If you press and hold My Cycle for 3 second or longer, the currently set course and options are saved and the LED blinks for 3 seconds. 26_ washing a load of laundry WF0794W7-02875N_EN.indd 26 2010-10-05 3:54:33...
Page 27 • Once a washing machine operation begins, you cannot add or select the bubble function. • Enough bubbles are generated with the specified amount of detergent. • Please clean the Debris filter frequently. Periodic cleaning helps generate sufficient bubbles. • Depending on the detergent and the laundry, the bubbles may be absorbed and seem like a small quantity. • Although bubbles are generated once the wash begins, it may take several minutes for users to see them. washing a load of laundry _27 WF0794W7-02875N_EN.indd 27 2010-10-05 3:54:33...
Page 28 Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap.
Page 29 Your new washing machine, combined with modern detergents, will give perfect washing results, thus saving energy, time, water and detergent. However, if your cotton is particularly dirty, prewash with a protein-based detergent. washing a load of laundry _29 WF0794W7-02875N_EN.indd 29 2010-10-05 3:54:34...
Page 30 Do not use detergent that has hardended or solidified as the detergent may remain in the rinse cycle. It may cause your washing machine to not rinse properly or result in the overflow becoming blocked. 30_ washing a load of laundry WF0794W7-02875N_EN.indd 30 2010-10-05 3:54:34...
Page 31 • DO NOT fill above the MAX line. Liquid • When using powdered detergent, remove the liquid detergent box detergent box from the detergent drawer. Powdered detergent will not dispense with liquid detergent box. • After a wash, some liquid may remain in the detergent drawer. washing a load of laundry _31 WF0794W7-02875N_EN.indd 31 2010-10-05 3:54:35...
Page 32 • Powder-type cleansing agent: Use a [powder-type bleaching agent] or a [cleansing agent for drum cleaning only]. • Liquid-type cleansing agent: Use a [liquid-type oxygen bleaching agent] or a [cleansing agent for drum cleaning only]. 32_ cleaning and maintaining your washing machine WF0794W7-02875N_EN.indd 32 2010-10-05 3:54:36...
Page 33 5. Allow all the water to flow into a bowl. Remain water maybe more than you expected. Prepare larger bowl. 6. Reinsert the emergency drain cap and the drain tube. 7. Replace the filter-cover. cleaning and maintaining your washing machine _33 WF0794W7-02875N_EN.indd 33 2010-10-05 3:54:37...
Page 34 1. Wipe the washing machine surfaces, including the control panel, with a soft cloth using a nonabrasive household detergent. 2. Use a soft cloth to dry the surfaces. 3. Do not pour water onto the washing machine. 34_ cleaning and maintaining your washing machine WF0794W7-02875N_EN.indd 34 2010-10-05 3:54:37...
Page 35 Also clean inside and outside the threaded connector. 4. Push the filter back into place. 5. Screw the hose back onto the washing machine. 6. Make sure the connections are watertight and turn on the tap. cleaning and maintaining your washing machine _35 WF0794W7-02875N_EN.indd 35 2010-10-05 3:54:41...
Page 36 If your washing machine has been stored in below-freezing temperatures, allow time for any leftover water in your washing machine to thaw out before using it. 36_ cleaning and maintaining your washing machine WF0794W7-02875N_EN.indd 36 2010-10-05 3:54:41...
Page 37 • Make sure the debris filter is not clogged. • The door will not open until 3 minutes after the machine stops or the Door is locked shut or will not open. power turns off. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _37 WF0794W7-02875N_EN.indd 37 2010-10-05 3:54:41...
Page 38 • Call the after-sales service. ce/3e/Uc For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer. 38_ troubleshooting and information codes WF0794W7-02875N_EN.indd 38...
Page 39 5. Course time in individual homes may differ from the values given in the table due to variations in the pressure and temperature of the water supply, the load and the type of laundry. 6. When the Intensive Wash function is selected, the cycle time is increased for each cycle. cycle chart _39 WF0794W7-02875N_EN.indd 39 2010-10-05 3:54:41...
Page 40 • Use stain removal products and bleaches before the wash cycle only when strictly necessary. • Save water and electricity by only washing full loads (the exact amount depends upon the program used). DECLaration of ConforMity This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. 40_ appendix WF0794W7-02875N_EN.indd 40 2010-10-05 3:54:46...
Page 41 WF0794 / WF0792 paCkaGE WEiGHt PAPER 2.5 kg PLASTIC 2.5 kg MODEL WF0794 WF0792 Spin rEVoLutionS 1400 1200 The appearance and specifications of the product are subject to change without prior notice for purposes of product enhancement. appendix _41 WF0794W7-02875N_EN.indd 41 2010-10-05 3:54:46...
Page 42 WF0794W7-02875N_EN.indd 42 2010-10-05 3:54:46...
Page 43 WF0794W7-02875N_EN.indd 43 2010-10-05 3:54:46...
Page 44 QUESTIONS OR COMMENTS? Country CAll OR VIsIT Us ONlINe AT 1-800-10-SAMSUNG(726-7864) 1-800-3-SAMSUNG(726-7864) PHILIPPINES www.samsung.com 1-800-8-SAMSUNG(726-7864) 02-5805777 Code No. DC68-02875N_EN WF0794W7-02875N_EN.indd 44 2010-10-05 3:54:46...
