- Page 1 EN User Manual | Dishwasher FSB42907Z aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................5 4. PRODUCT DESCRIPTION................7 5.
- Page 3 • Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •...
- Page 4 • If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.
- Page 5 parts related to door assemblies, printed WARNING! circuit boards, electronic displays, pressure switches, thermostats and Dangerous voltage. sensors, software and firmware including reset software. The following spare parts 2.4 Use are available for at least 10 years after the • Do not put flammable products or items model has been discontinued: door hinge that are wet with flammable products in, and seals, other seals, spray arms, drain...
- Page 6 Authorized Service Centre to replace it with the new one. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux 60 cm Sliding Door Dishwasher 3.2 Safety caps If the furniture panel is not installed, open the appliance door carefully to avoid the risk of injury.
- Page 7 4. PRODUCT DESCRIPTION Ceiling spray arm Lower basket Upper spray arm Upper basket Lower spray arm Cutlery drawer Filters Rating plate The graphic is a general overview. For Salt container more details, refer to other chapters or documents provided with the appliance. Air vent Rinse aid dispenser Detergent dispenser...
- Page 8 ExtraPower option button AUTO Sense program button 5.1 Indicators Indicator Description ECO programme indicator. It indicates the most environmentally friendly programme selec‐ tion for a normally soiled load. Refer to "Programme selection". Rinse aid indicator. It is on when the rinse aid dispenser needs refilling. Refer to "Before first use".
- Page 9 6.4 Programmes overview Programme Dishwasher Degree of soil Programme phases Options load 30min Crockery, cutlery Fresh • Dishwashing 50 °C • ExtraPower • Intermediate rinse • Final rinse 45 °C • AirDry 90min Crockery, cutlery, Normal, lightly • Dishwashing 60 °C •...
- Page 10 In your request, include the product number Information for test institutes code (PNC) from the rating plate. To receive the necessary information for For any other questions regarding your conducting performance tests (e.g. according dishwasher, refer to the service book to: EN60436 ), send an email to: provided with your appliance.
- Page 11 • The indicator related to the setting is • The other indicators are off. • The light related to indicates the current setting value. 3. Press Previous or Next to change the value. 4. Press OK to confirm the setting. •...
- Page 12 German de‐ French de‐ mmol/l mg/l (ppm) Clarke de‐ Water softener grees (°dH) grees (°fH) grees level 11 - 14 19 - 25 1.9 - 2.5 185 - 254 13 - 17 4 - 10 7 - 18 0.7 - 1.8 70 - 184 5 - 12 <4...
- Page 13 tablets only, you can deactivate the AirDry is automatically activated with all notification for refilling the rinse aid. However, programmes. for best drying performance, always use rinse The duration of the drying phase and the door aid. opening time vary depending on the selected If standard detergent or multi-tablets without programme and options.
- Page 14 8.2 How to fill the rinse aid The salt is used to recharge the resin in the dispenser water softener and to assure good washing results in daily use. How to fill the salt container 1. Turn the cap of the salt container counterclockwise and remove it.
- Page 15 9.3 How to activate ExtraPower 8. Close the water tap when the programme is complete. 1. Select a programme using MY TIME 9.1 Using the detergent selection bar. 2. Press The light related to the button is on. ExtraPower is not a permanent option and must be activated every time before you start a programme.
- Page 16 Press and hold for about 3 seconds. The appliance returns to the programme If the door is opened for more than 30 selection. seconds during the drying phase, the running programme ends. It does not happen if the door is opened by AirDry If you cancel the delay start, you have to function.
- Page 17 – Make sure that the current level of the 3. Start the 30min programme. Do not add water softener agrees with the detergent and do not put dishes in the hardness of the water supply. baskets. – Follow the instructions in the chapter 4.
- Page 18 10.6 Unloading the baskets 1. Let the tableware cool down before you After the programme is completed, water remove it from the appliance. Hot items can still remain on the inside surfaces of can be easily damaged. the appliance. 2. First remove items from the lower basket, then from the upper basket.
- Page 19 11.4 External cleaning • Clean the appliance with a moist soft cloth. • Only use neutral detergents. • Do not use abrasive products, abrasive cleaning pads or solvents. 11.5 Cleaning the filters 4. Wash the filters. The filter system is made of 3 parts. 5.
- Page 20 CAUTION! 3. To install the spray arm back, press it An incorrect position of the filters can downwards. cause bad washing results and damage to the appliance. 11.6 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes.
- Page 21 element (B) counterclockwise and pull the spray arm downwards. 4. Wash the spray arm under running water. Use a thin pointed tool, e.g. a toothpick, to remove particles of soil from the holes. Run the water through the holes to wash soil particles away from the inside.
- Page 22 Problem and alarm code Possible cause and solution You cannot activate the appliance. • Make sure that the mains plug is connected to the mains socket. • Make sure that there is no damaged fuse in the fuse box. The programme does not start. •...
- Page 23 Problem and alarm code Possible cause and solution The temperature of the water inside • Make sure that the temperature of the inlet water does not exceed the appliance is too high or malfunc‐ 60°C. tion of the temperature sensor oc‐ •...
- Page 24 Once you have checked the appliance, WARNING! deactivate and activate the appliance. If the problem occurs again, contact an Authorised We do not recommend using the Service Centre. appliance until the problem has been completely fixed. Unplug the appliance For alarm codes not described in the table, and do not plug it in again until you are contact an Authorised Service Centre.
- Page 25 Problem Possible cause and solution There are residues of detergent in the • The detergent tablet was stuck in the dispenser and was not washed dispenser at the end of the pro‐ away by water. gramme. • Water cannot wash away the detergent from the dispenser. Make sure that the spray arms are not blocked or clogged.
- Page 26 13.1 Link to the EU EPREL database database using the link https:// eprel.ec.europa.eu and the model name and The QR code on the energy label supplied product number that you can find on the with the appliance provides a web link to the rating plate of the appliance.
- Page 28 156826110-A-502023...
