KGK JET JPT2700 Series Instruction Manual

Continuous ink jet printer for industrial use
Hide thumbs

Advertisement

Quick Links

Download this manual
JPT2700
Continuous ink jet printer for industrial use
Instruction manual
Introduction
Thank you for purchasing our continuous ink jet printer for industrial use.
In order to properly use this unit, carefully read this instruction manual.
Please keep this instruction manual on hand so that you can consult it whenever any
question and/or trouble arise while in use.
Subsidiary of Kishu Giken Kogyo, Japan

Advertisement

loading
Need help?

Need help?

Do you have a question about the JET JPT2700 Series and is the answer not in the manual?

Questions and answers

piyush shukla
January 31, 2025

how create rs sign in every fount size like 7*5 ,9*8 etc

0
1 comments:
Mr. Anderson
February 10, 2025

The KGK JET JPT2700 Series supports multiple font sizes for character printing. To create an "RS" sign in different font sizes, follow these steps:

1. Select the Font Size: The printer supports various font sizes, including:
- 32x32, 32x24, 24x24, 24x18, 16x16, 16x12, 12x10, 10x8, 9x9, 9x7, 7x8, 7x5, 5x5.

2. Choose the Character Type: The printer supports alphanumeric characters in Gothic and Original fonts.

3. Set the Print Position: The number of vertical dots allows positioning at specific lines, such as:
- 1st line (0th dot) for 32x32 or less.
- 2nd line (16th dot) for 16x16 or less.
- 3rd line (20th dot) for 10x8 or less.

4. Input the "RS" Sign: Use the printer's interface to enter "RS" and assign the desired font size.

5. Print and Adjust: Execute a test print and adjust positioning or font size as needed.

By following these steps, you can create an "RS" sign in different font sizes using the KGK JET JPT2700 Series printer.

This answer is automatically generated

0

Related Manuals for KGK JET JPT2700 Series

Summary of Contents for KGK JET JPT2700 Series

  • Page 1 JPT2700 Continuous ink jet printer for industrial use Instruction manual Introduction Thank you for purchasing our continuous ink jet printer for industrial use. In order to properly use this unit, carefully read this instruction manual. Please keep this instruction manual on hand so that you can consult it whenever any question and/or trouble arise while in use.
  • Page 2 "Instruction manual - [ Communication ]" along with this manual. About this manual This manual is intended only for the KGK JET JPT2700 series. This manual shall not be reproduced in part or in whole without our permission. Every effort has been made to prepare this manual.
  • Page 3 Safety precautions Before use, thoroughly read the "Safety precautions" in this manual, and properly use this product to obtain its best performance. This manual indicates the safety precautions as follows in order to prevent personal injury and/or property damage. Description of the indication Indicates that improper handling in disregard of this indication may result in death Danger or severe injury.
  • Page 4 Introduction Danger Avoid installing the equipment in a place subject to frequent vibration or in an unstable place. Avoid installing the equipment in a place where vibration is directly transmitted to it or in an Prohibit unstable place such as a wobbly place. Otherwise, the equipment may fall, causing personal injury.
  • Page 5 Caution Avoid tying power lines and other wires together in a bundle. Prohibit Air purging in the printhead with dry air Air purging in the printhead is recommended. Be sure to do that, especially in the case of use in humid surroundings or using pigment inks.
  • Page 6 Introduction Caution Prohibited connection/disconnection of the power cables while power is turned on Prohibit Do no connect/disconnect the power cables while power is turned on. Failure to observe this may damage the equipment. When you install or transport this product, open the cover, or connect with any equipment, be sure to connect or disconnect the cables according to the following procedures.
  • Page 7 In case of emergency Danger When the equipment emits smoke If the equipment emits smoke or gives off an unusual odor, immediately turn off the power, and Direction disconnect the power plug. Then, contact us. Further use in this condition may cause fire. When foreign material enters the equipment If foreign material (water, dust, etc.) enters the equipment, i mmediately turn off...
  • Page 8 Introduction Precautions for using organic solvents, etc. Precautions for handling * Be sure to close the lid of any organic solvent containers when it is not in use. * Avoid bringing more than the amounts of organic solvents, etc. needed directly for the day's work into the workplace.
  • Page 9 Locations of warning seals Caution Be careful about the use of flames because a highly flammable solvent is used. No. Name Description Caution label about Be careful about the use of flames because a highly flammable solvent is ignition used. Caution label about Be careful not to get your fingers or hands caught in the rotating parts.
  • Page 10 Contents Introduction Safety precautions ____________________________ 3 Description of the indication___________________ 3 Installation place ___________________________ 3 Power supply _____________ _________________ 5 Checking _________________________________ 6 In case of emergency _______________________ 7 Precautions for handling _____________________ 7 Precautions for using organic solvents, etc. ______ 8 Locations of warning seals ___________________ 9 Contents Before use...
  • Page 11 Set printing conditions ______________________ 34 Switch the printhead to the stop mode _________ 36 Turn off the power _ ________________________ 37 Operation screen 2-1 Precautions for the touch panel _____________ 38 2-2 Description of the main screen, the menu screen, and the icon buttons.38 Main screen ________________ ______________ 38 Menu screen _____________________________ 40 Icon buttons ______________________________ 41...
  • Page 12 Before use 1-1 Features of the product This product is a continuous ink jet printer for industrial use, which can print high-quality characters with 36 vertical dots. Major features are as follows. Nozzle capping system The auto nozzle capping system seals the nozzle at the end of operation to prevent nozzle clogging arising from solidified ink at the nozzle section.
  • Page 13 Design with consideration given to safety The enclosure is equipped with a waterproof mechanism (equivalent to IP54) and a high-voltage safety circuit, and has been designed with consideration given to safety. Improvement in the variety of connections with external devices This product is equipped with a USB port and possible to copy or back up data using USB media Improvement in the ease of operation The advanced settings of each function can be individually made, and the display items can be customized...
  • Page 14 Before use 1-2 Product configuration and supplied items Product configuration This product is composed of the main unit, the printhead, and the operation panel. The printhead and the operation panel are individually connected to the main unit with cables, and cannot be disconnected.
  • Page 15 Checking of supplied items Supplied items including this product and its instruction manual. JPT2700 Instruction manual Set of maintenance tools * Washing bottle * Container * Dryer * Safety goggles * Phillips screwdrivers * Flat-blade screwdriver (No.0, No.1, No.2) * Manual pump * Set of wrenches * Spanners (8mm, 11mm)
  • Page 16 Before use * Clearance gauge * Kaydry * Tweezers * Stirring rod * * Gun unit fixture * Stirring rod is supplied item only for the pigment model with agitation mechanism. Spare parts of replacement Above is the spare parts of replacement only for using the specific dye ink or pigment ink. Name Remarks Quantity...
  • Page 17 Name Remarks Quantity Replacement parts for the pump Diaphragm unit Spare parts of (only for using the specific dye ink or the replacement or Diaphragm set pigment ink)
  • Page 18 Before use Options The following options are not included with this product, but a re useful in improving print quality, maintenance, etc. Name Description For the print direction, side-surface printing or top-surface printing can be selected. Self-supporting stand For the mounting method, a self-supporting type or a supported type can be selected.
  • Page 19 1-3 Name of each section Main unit (front side and right side) Name Description Main power switch of this product. This is used to turn ON/OFF the main Main switch power. Front door Open this door at the time of ink refilling, maintenance, etc. Knob Turn this knob to open the front door.
  • Page 20 Before use Main unit (rear side and left side) No. Name Description Cable for connecting the main unit to the printhead. The length is 3.5 m. This cable Head cable cannot be disconnected from the printhead. (Minimum bending radius: 35 mm) Prevents foreign bodies such as dust from entering the inside.
  • Page 21 Main unit (inside) Name Description Ink reservoir Reservoir that holds ink Solvent reservoir Reservoir that holds an solvent Main reservoir Measures and adjusts the viscosity of ink Regulator Regulates the pressure of ink Valve unit Valve for controllin g the flow of ink Ink discharge Plug for discharging ink Ink filter...
  • Page 22 Before use Operation panel ぉ互ゞ 策 4261 覗4261 ㍽ 况 Name Description Touch panel for selecting items, inputting values and characters, and Operation screen displaying information This switch is used to boot and shutdown the system. It is lit in green when Standby switch the system is in action, and it is lit in red during standby.
  • Page 23 Head (appearance and inside) Name Description Printhead cover Upper cover of the printhead When the head cover will not open due to the solidified ink, you can take this out for cleaning with the solvent. Head cover tip cap When attach the cap into the head cover, note the orientation of the cap. If attach the cap in the opposite orientation, can not mount the head cover correctly.
  • Page 24 Before use 1-4 Installation and connection Installation Power and environment Rated power supply voltage 90 to 265 VAC, 47 to 63 Hz Power supply Power consumption 80 W Grounding Class D ground Ambient operating temperature 0 to 40 [°C] Ambient operating humidity 10 to 85 [%] (non-condensing) Main unit - Flat place...
  • Page 25 400 mm or more 200 mm 200 mm or more or more 500 mm or more 200 mm or more Detaching and reattaching the operation panel To detach the operation panel from the main unit, pull up the lever on the back of the panel to detach it in the direction pointed by the (white) arrow.
  • Page 26 Before use Installation of the printhead Install the main unit according to the operating environment. Memo If you want to move the printhead to perform printing, contact us. Installation direction The printhead can be installed in any direction. Positional relationship with the main unit Install the printhead within 1.5 m above and 1.0 m below the bottom of the main unit.
  • Page 27 Example of connection with external devices Signal lamp Main Unit Printhead Encoder Workpiece Conveyor This product receives input signals from an encoder, a photocell sensor, etc. to make settings for printing. It receives an input signal as a trigger from a photocell sensor, calculates the timing of printing, and prints characters on a workpiece.
  • Page 28 Before use 1-5 From startup to termination This section shows a sequence of operations from turning on the power to turning off the power. Operational flowchart Turn on the power. Select message data. Create message data. Set printing conditions. Switch the printhead to the running mode.
  • Page 29 Turn on the power Check that various kinds of cables including the photocell sensor signal cable are correctly connected. Turn on the main switch on the right side of the main unit. Memo * If emergency accident is occurred, turn off the main switch.
  • Page 30 Before use Create or select message data In this section, create characters "ABCDE" as a sample. Press the [Select] button on the main screen. Select a message data field to be created (No. 001 in this example), and press the button.
  • Page 31 Create or select a text module to be placed in message data. Press the button, and press the preview area. ② ① Select a module data field to be created (No. 001 in this example), and press the button. ② Directly press a displayed module data field or move the cursor to module data to be selected using the ①...
  • Page 32 Before use Press the button to register the text module. When "Set?" appears, press the [Yes] button to enter. Select the created text module, and press the [Select] button. ① ② The text module is displayed in the preview area of the "Msg edit select"...
  • Page 33 When "Set?" appears, press the [Yes] button to enter. The data "ABCDE," which has been created this time, is displayed in the preview area of the main screen.
  • Page 34 Before use Set printing conditions Press the [Condition] button on the main screen. Press the [Condition] tab. Memo The number of tabs displayed and the number of items displayed in the tabs depend on the setting of each item in [Menu]-[System setting]-[Function]- [Printing].
  • Page 35 Press the button to register the editing contents When "Set?" appears, press the [Yes] button to enter. Switch the printhead to the running mode Check that the “Head heating complete” icon is displayed and the head heater temperature exceeded the “Operational temperature”. And then, press the [Run] button on the main screen.
  • Page 36 Before use When preparation for printing is completed, the Ready lamp lights up Perform printing When a workpiece flows and a print command is received, the specified printing content is printed. Memo Test printing can be performed by pressing the [Test print] button on the menu screen.
  • Page 37 Turn off the power Press the [Quit] button to exit the system. Memo Once the power is turned off, it takes a long time to start printing because the unit performs the bleed process upon the next startup. If you only stop operation for several hours, keep the printhead suspended (stop mode) without turning off...
  • Page 38 Operation screen 2-1 Precautions for the touch panel This product is operated by making an entry or a selection with the touch panel. Caution Note that the following operations may damage the screen. * Do not operate the unit by touching the screen with a sharp-pointed object (such as a pen tip and tweezers).
  • Page 39 Name Description Switches to the Condition screen. [Condition] button For details, refer to "1-4. Setting the printing conditions" in the separate Instruction manual: "Operation/Maintenance." Refresh button For details, refer to "Icon buttons" on page 41. Zoom button For details, refer to "Icon buttons" on page 41. Previews the content of the currently selected message data.
  • Page 40 Operation screen Menu screen Memo The number of buttons displayed on the menu screen and the number of setting items displayed on each setting screen can be customized depending on the user's application. The instruction manual describes the screen display using the "Full" option of the "Set all defaults collectively"...
  • Page 41 Icon buttons Frequently used buttons are displayed as icons on each setting screen. Name Description Confirmation button Confirms settings and returns to the previous screen. Apply button Confirms settings and does not return to the previous screen. Cancel button Cancels settings and returns to the previous screen. Clear button Clears display contents.
  • Page 42 Operation screen Name Description Switches to the registration/selection screen for a 2D code 2D code module select button module. Bit image module select Switches to the selection screen for an bit image module. button Switches to the registration/selection screen for an interval Interval module select button module.
  • Page 43 Status icon The status icons indicate the current status. Name Description Indicates that the printhead is in the stop mode. Indicates that the printhead is in the running mode and can perform printing. Indicates that the printhead is in transition between the running Printhead cover status icon mode and the stop mode.
  • Page 44 Operation screen 2-3 Screen transition This section describes the transition of the operation screens. Print setting System setting Message selection Function Reset print counter Main screen Msg edit (Select) Environment Communication Msg edit (Edit) Head/ink Menu screen Condition System clock Operation level Module Operation level change...
  • Page 45 Maintenance Current state Unit information Test printing Print counter Work log I/O monitor Bleed Unit log System state Main unit maintenance Backup Current numbering value Measurement log Data initialization Consumables state Memo The number of buttons displayed on the menu screen and the number of setting items displayed on each setting screen can be customized depending on the user's application.
  • Page 46 Ink and solvent 3-1 Compatibility of ink, solvent, and cleaning solution There are a wide variety of ink types and colors available for this product so that it can be used for various applications. For the list of solvents and cleaning solutions compatible with each ink, refer to the "ink compatibility table."...
  • Page 47 3-3 Remaining amounts of ink and solvent The remaining amounts of ink and solvent in their reservoirs are controlled in two alarm levels. * Warning screen If the level of ink or solvent (or both) falls below the required level (Dye type ink reservoir/Solvent reservoir : 150ml, Pigment type ink reservoir : 210ml, Magnetic stirrer type ink reservoir : 320ml), the warning screen appears, and the "Supply"...
  • Page 48 Ink and solvent Viscosity measurement Ink and solvent are blended in the equipment so that the viscosity is suitable for printing. A Zahn cup is used to measure the viscosity. * Principles With a Zahn cup, ink is supplied to the top of a cylindrical reservoir, and the time taken for ink to drop from a tiny hole at the bottom is measured to determine the viscosity.
  • Page 49 Ink refilling operation in the equipment Refilling operation starts when the liquid level sensor turns off. Based on the drop time measured by the Zahn cup and the intrinsic viscosity standard value of each ink, it is determined whether ink or solvent should be supplied. Judgment of measurement Process Status...
  • Page 50 Specifications 4-1 Product specifications Model Dye machine Pigment machine Model name JPT2700-P60 JPT2700-P40 JPT2700-D50 JPT2700-D40 Type Print method Continuous system (charge control system) Compatible ink For details, refer to "Ink Dye ink, and some of pigment ink Pigment ink compatibility table". Dust- and water-proof IP65 CE marking...
  • Page 51 Model Dye machine Pigment machine Model name JPT2700-P60 JPT2700-P40 JPT2700-D50 JPT2700-D40 Type Operating environment 0 to 40 °C 10 to 85% (non-condensing) (temperature, humidity) * For details, refer to "Ink compatibility table". Power 100-240V, 50/60Hz, 0.9-0.5A Weight 25 kg Grounding Class D ground...
  • Page 52 Specifications Character/printing specifications Standard font The standard fonts installed in this product are as follows. Character type 32 x32 32x24 24 x24 24 x18 16 x16 16 x12 12x10 Alphanumeric characters Gothic Original Gothic Original Gothic Original Original and symbols Mincho Mincho Mincho...
  • Page 53 Multiple lines printing In the case of using the module of placing the character transversely, multiple lines printing can be performed. And multiple lines printing can be performed even if fonts with different numbers of dots are mixed. Multiple lines printing allows the use of various formats based on the settings of Condition (vertical dots, font size, and arrangement).
  • Page 54 Specifications Number of vertical dots: 32 Lines Print position Font sizes that can be registered Image 1st line (0th dot) 32x32 or less (all character directions) 1st line (0th dot) 16x16 or less (all character directions) 2nd line (16th dot) 1st line (0th dot) 12x10 (horizontal), 2nd line (10th dot)
  • Page 55 Number of vertical dots: 26 Lines Print position Font sizes that can be registered Image 1st line (0th dot) 32x24 (horizontal), 24x24 or less (all character directions) 1st line (0th dot) 16x12 (horizontal), 2nd line (13th dot) 12x10 or less (all character directions) 1st line (0th dot) 10x8 (horizontal), 9x7 (horizontal), 2nd line (8th dot)
  • Page 56 Specifications Number of vertical dots: 20 Lines Print position Font sizes that can be registered Image 1st line (0th dot) 24x18 (horizontal), 16x16 or less (all character directions) 1st line (0th dot) 12x10 (horizontal), 2nd line (10th dot) 10x8 or less (all character directions) 1st line (0th dot) 7x5 (horizontal), 5xN (vertical), 2nd line (6th dot)
  • Page 57 Number of vertical dots: 11 Lines Print position Font sizes that can be registered Image 1st line (0th dot) 12x10 (horizontal), 10x8 or less (all character directions) 1st line (0th dot) 7x5 (horizontal), 5xN (vertical), 2nd line (6th dot) 5x5 (all character directions) Number of vertical dots: 10 Lines Print position...
  • Page 58 Specifications ̈ Samples for arbitrary print position settings Limits of positioning the lowest dot of each font dot in the case of fixed width fonts. Vertical Character 32 x32 32x24 24x24 24x18 16x16 16x12 12x10 10x8 dots direction Vertical 0-12 0-12 0-20 0-20...
  • Page 59 Vertical Character dots direction Vertical 0-27 0-27 0-29 0-29 0-29 0-31 0-31 0-27 0-29 0-26 0-28 0-31 0-28 0-31 Horizontal Vertical 0-23 0-23 0-25 0-25 0-25 0-27 0-27 Horizontal 0-23 0-25 0-22 0-24 0-27 0-24 0-27 Vertical 0-19 0-19 0-21 0-21 0-21 0-23...
  • Page 60 Dimensional outline drawing 5-1 Main unit Unit: [mm]...
  • Page 61 5-2 Printhead Unit: [mm] (140) (59.4)
  • Page 62 KGK Jet India Private Limited Head Office / Works Plot No: A-29, SIPCOT Industrial Growth Center, Oragadam, Sriperumbuthur, Kancheepuram, Tamil Nadu 602105, India è marketing@kgkjetindia.com è info@kgkjetindia.com è www.kgkjetindia.com TEC2774ZAA (November, 2024) Subsidiary of Kishu Giken Kogyo, Japan...
