- Page 1 OWNER’S MANUAL BUILT-IN SXS REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. LSSB2691** www.lg.com...
- Page 2 Table of contents Introduction Model/Serial record Basic safety precautions Parts and Features Operation Starting Adjusting the temperatures and functions Adjusting the temperatures and display Operating the dispenser Setting the functions Shelf Freezer door bin Dairy corner Adjustable door bin Refrigerator gallon bin Refrigerator/Freezer drawers Refrigerator/Freezer Drawer cover Upper/Lower How to replace the water filter...
- Page 3 Introduction Model/Serial record The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.
- Page 4 Introduction WARNING TIP-OVER HAZARD Use two or more people to move and install the refrigerator. To prevent the refrigerator from tipping over, install anti-tip brackets (provided). Failure to follow the refrigerator installation instructions can result in serious injury or death. WARNING This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
- Page 5 Introduction Unplug the power cord or turn off the power when cleaning or moving the refrigerator. • It may cause electric shock or injury. • Press the POWER button for 3 second to turn off the power at display panel. Do not pull out the cord or touch the power plug with wet hands.
- Page 6 Introduction 2. When using the refrigerator Do not place heavy or dangerous objects on the refrigerator. It may fall and cause injury, fire, electric shock when opening or closing the door. Do not install the refrigerator in a damp place or a place where water drips or splashes, like near a sink or a downspout.
- Page 7 Introduction Do not use combustible sprays (including cooking sprays, oils and other aerosol products) on or near the refrigerator. It may cause fire. Do not install the refrigerator near a gas stove, water heater or other sources of ignition that may possibly leak gas.
- Page 8 Introduction When disposing the refrigerator, remove the packing materials from the door or take off the doors but leave the shelves in place so that children may not easily climb inside. Child entrapment generally results in death by suffocation. This appliance is not intended for use by persons (including children) with reduced physical, sensory, mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 9 Introduction Do not touch food or containers in the freezer with wet hands. It may cause frostbite. Do not put ice in a thin crystal cup or ceramic ware. The glass may shatter and present a hazard. When the electricity is off, remove ice from the ice bucket. If the power is off long enough, the ice will melt and the water will run onto the floor.
- Page 10 Introduction Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner.
- Page 11 Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions LED Function display board Dispenser Display Board Dispenser Lamp (hidden)
- Page 12 Operation LED Function display board POWER Power on/off. Press and hold the POWER button for 3 seconds to turn the power on or off. And you can turn on the refrigerator with same way. QUICK FREEZING When the QUICK FREEZING button is pressed, the display will indicate the selected function has been activated.
- Page 13 Operation Adjusting the temperatures and display Adjust freezer To adjust the temperature in the freezer compartment, press the FRZ.TEMP. button to temperature cycle through the range of available settings. Adjust refrigerator To adjust the temperature in the refrigerator temperature compartment, press the REF.TEMP. button to cycle through the range of available settings.
- Page 14 Operation Operating the dispenser Dispensing Press the DISPERNSER SELECTION button repeatedly until the crushed ice icon illuminates. crushed ice Press the Dispenser Push Switch with a glass or other container to dispense crushed ice. Press the DISPERNSER SELECTION button repeatedly until Dispensing the cubed ice icon illuminates.
- Page 15 Operation Setting the functions Press the button for the desired function to view and select other settings. Setting Press and hold the CHILD LOCK button for three seconds to the Child Lock lock the dispenser and all of the other control panel functions. Press and hold again for 3 seconds to unlock.
- Page 16 Operation Power on/off The POWER button will turn off all electrical power to the unit. Press and hold the POWER button for 3 seconds to turn off the power. When the power is off, the indicator light is off. It means you don’t have to turn off power at the circuit breaker or wall receptacle.
- Page 17 Operation When icemaker Ice is lumped together does not operate When ice is lumped together, take the ice lumps out of the ice storage bin, smoothly break them into small pieces, and then place them into the ice storage bin again.
- Page 18 Operation Throw away the first few batches of ice (about 24 cubes) and water CAUTION (about 7 glasses) first made after refrigerator installation. The first ice and water may include particles or odor from the feed water pipe or feed water box. This is also necessary if the refrigerator has not been used for a long time.
- Page 19 Operation Shelf How to use The shelves in your refrigerator are adjustable to meet your individual storage needs. How to 1. Hold the front part of the shelf and lift it up disassemble slightly. 2. While holding the shelf, tilt the shelf to pull it out. How to Tilt the front of the shelf up and guide the shelf reassemble...
- Page 20 Operation Dairy corner How to use You can store dairy goods like butter, cheese etc. How to To remove the dairy corner, simply lift it up and pull straight out. disassemble If you close the refrigerator door with the dairy corner left open on the door side, the refrigerator door may not close properly.
- Page 21 Operation Refrigerator gallon bin How to use For storing larger containers, such as gallons of milk. How to Hold the bin with both hands, lift up and pull out. disassemble How to Hold the bin with both hands and click it reassemble into place, one side at a time.
- Page 22 Operation Refrigerator/Freezer Drawer cover Upper/Lower How to 1. Hold the front part of the cover and lift it up slightly. disassemble 2. While holding the cover, tilt the shelf to pull it out strongly. 3. Turn the cover over 45°, pull it out from appliance. * The cover can be reassembled in the reverse order.
- Page 23 To purchase a replacement water filter: • - Visit your local dealer or distributor - Web: Find Parts & Accessories from Support section of lg.com - Call : 1-800-243-0000 (USA) , 1-888-542-2623 (Canada) Part number of the replacement water filter: ADQ36006101...
- Page 24 Suggestion on food storage Food storage guide (Refer to identification of parts) Freezer Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc. compartment shelf Store small packed frozen food. Freezer compartment Temperature is likely to increase as door opens. The temperature in the door racks is likely to increase as the door bin door opens;...
- Page 25 Suggestion on food storage Food storage guide Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food that spoils quickly, such as bananas and melons, at low temperatures.
- Page 26 When LED lamp Check to make sure that the LED lamp is turned on. doesn't light up - LED lamp is not a user-serviceable item. If the LED array fails, contact LG for service.
- Page 27 Care and maintenance Cleaning It is important that your refrigerator be kept clean to prevent undesirable odors. Spilled food should be wiped up immediately, since it may acidify and stain plastic surfaces if allowed to settle. Exterior Use a lukewarm solution of mild soap or detergent to clean the durable finish of your refrigerator.
- Page 28 If you experience problems with your refrigerator, call 1-800-243-0000. Only use the Smart Diagnosis feature when instructed to do so by the LG call center agent. The transmission sounds that you will hear are normal and sound similar to a fax machine.
- Page 29 Care and maintenance Troubleshooting guide COOLING Before conducting troubleshooting, make sure that the following basic requirements are met: Service Flow 0.5 gpm (1.9 lpm) Water Supply Potable Water Water Pressure 40-120 psi (138 - 827 kPa) Operating Ambient Temperature Limits 55°F - 100°F Electrical Ratings 115 Volts, 60 Hz, AC only, and fused...
- Page 30 Care and maintenance Problem Possible Causes Solutions Cooling System Refrigerator is replacing an older Modern refrigerators require more runs too much. model. operating time but use less energy due to more efficient technology. Refrigerator was recently plugged The refrigerator will take up to 24 hours to in or power restored.
- Page 31 Care and maintenance Problem Possible Causes Solutions Refrigerator or Refrigerator was recently installed. It may take up to 24 hours for each Freezer section is compartment to reach the desired too warm. temperature. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 32 Care and maintenance Problem Possible Causes Solutions Interior moisture Doors are opened often or for long When the doors are opened often or for buildup. periods of time. long periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 33 Care and maintenance COOLING/ICE & WATER Problem Possible Causes Solutions Food is freezing Food with high water content was Rearrange items with high water content in the refrigerator placed near an air vent. away from air vents. compartment. Refrigerator temperature control is If the temperature is too cold, adjust the set incorrectly.
- Page 34 Care and maintenance Problem Possible Causes Solutions Icemaker is not Demand exceeds ice storage The icemaker will produce approximately making enough capacity. 100 cubes in a 24 hour period. ice. House water supply is not Connect the refrigerator to a cold water connected, valve is not turned on supply with adequate pressure and turn fully, or valve is clogged.
- Page 35 Care and maintenance ICE & WATER Problem Possible Causes Solutions Icemaker is not Doors are opened often or for long If the doors of the unit are opened often, making enough periods of time. ambient air will warm the refrigerator ice (continued).
- Page 36 Care and maintenance Problem Possible Causes Solutions Not dispensing Doors are not closed completely. Ice will not dispense if any of the ice. refrigerator doors are left open. Infrequent use of the dispenser. Infrequent use of the ice dispenser will cause the cubes to stick together over time, which will prevent them from properly dispensing.
- Page 37 Care and maintenance Problem Possible Causes Solutions Icemaker is not Refrigerator was recently installed It may take up to 24 hours for each making ice. or icemaker recently connected. compartment to reach the desired temperature and for the icemaker to begin making ice.
- Page 38 Care and maintenance Problem Possible Causes Solutions Not dispensing New installation or water line Dispense 2.5 gallons of water (flush for water. recently connected. approximately 5 minutes) to remove trapped air and contaminates from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 39 Care and maintenance Problem Possible Causes Solutions Ice has bad taste Water supply contains minerals A water filter may need to be installed to or odor. such as sulfur. eliminate taste and odor problems. NOTE: In some cases, a filter may not help.
- Page 40 Care and maintenance Problem Possible Causes Solutions Water has bad Water supply contains minerals A water filter may need to be installed to taste or odor. such as sulfur. eliminate taste and odor problems. Water filter has been exhausted. It is recommended that you replace the water filter: •...
- Page 41 Care and maintenance NOISE Problem Possible Causes Solutions Clicking The defrost control will click when Normal Operation the automatic defrost cycle begins and ends. The thermostat control (or refrigerator control on some models) will also click when cycling on and off. Rattling Rattling noises may come from the Normal Operation...
- Page 42 Care and maintenance Problem Possible Causes Solutions Vibrating If the side or back of the refrigerator To eliminate the noise, make sure that the is touching a cabinet or wall, some of sides and back cannot vibrate against any the normal vibrations may make an wall or cabinet.
- Page 43 Care and maintenance PARTS & FEATURES Problem Possible Causes Solutions Doors will not Food packages are blocking the door Rearrange food containers to clear the door close correctly or open. and door shelves. pop open. Ice bin, crisper cover, pans, shelves, Push bins all the way in and put crisper door bins, or baskets are out of cover, pans, shelves and baskets into their...
- Page 44 Care and maintenance It is Normal... The following occurrences are normal. Occurrence Solution Noise When you hear Tick or Click This is the sound of various parts expanding/contracting sound or various control devices operating depending on the temperature change within the refrigerator. When you hear This is the count of compressor or fan operating when the operation of the refrigerator is starting or ending.
- Page 45 Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States including U.S.
- Page 46 WARRANTY: Should your LG Refrigerator ("Product") fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the Product upon receipt of proof of original retail purchase.
- Page 47 LG Customer Information Center For inquires or comments, visit www.lg.com or call; 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User 1-888-542-2623 CANADA Register your product Online! www.lg.com...
