Installation Guide
VIGI Solar System Controller
© 2024 TP-Link 7106511595 REV1.0.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VIGI PS90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TP-Link VIGI PS90

  • Page 1 Installation Guide VIGI Solar System Controller © 2024 TP-Link 7106511595 REV1.0.1...
  • Page 2 Contents Chapter 1 Overview ———————————— 1 Chapter 2 Installation ——————————— 3 Package Contents ..........3 Safety Precautions ..........3 Installation ...............4 Chapter 3 Configuration —————————— 15 Appendix FAQ ——————————————— 16...
  • Page 3 Chapter 1 Overview The VIGI Solar System Controller should work with VIGI 180W Solar Mount, and VIGI Solar Panels. Open the waterproof box with the provided key and the solar system controller is shown as below. Note: Keep the key in a safe place for future use. Modular Battery*3 Controller LED Explosion-proof Valve: Used to help discharge the exhaust gas in the waterproof box when the...
  • Page 4 • Controller LED Indication On: The system is working and the load is enabled Flashing: The system is working and the load is disabled. Off: The system is not working. On: The RJ45 interface is connected. Flashing: Data is being transferred. Off: The RJ45 interface is not connected.
  • Page 5 Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items are damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from what is depicted.
  • Page 6 Installation Step 1. Prepare all components The VIGI Solar System Controller should work with VIGI 180W Solar Mount, and VIGI Solar Panels. Step 2. Install the solar mount D: Thickness of the pole φ: Diameter of the pole H: Recommended Mounting Height M8*16 M5*20 M10*120 Kit...
  • Page 7 M8*16...
  • Page 8 Suitable for poles: φ ≥ 100 mm Suitable for poles: φ <100 mm M10*220 Kit Step 3. Install the solar panel Solar panel Junction box Four-pin male connector for connecting solar system controller...
  • Page 9 M8*20 Kit M8*16 M8*20 Kit M8*20 Kit...
  • Page 10 The arrow should point toward the panel's junction box. M8*16 Keep the arrow pointing up. M10*120 Kit Recommended solar panel inclination angles (the following inclination angles correspond to the holes on the mount): Latitude Recommended Range Inclination 0-5° 5° 5-15° 15°...
  • Page 11 Step 4. Install the solar system controller M8*16 M8*16...
  • Page 12 M8*16 M10*220 Kit...
  • Page 13 M8*16...
  • Page 14 Step 5. Install the cameras M4*20 M5*20 Use the screws that came with your camera. M4*20 Note: If the product is used in a windy area, it is recommended to tie VIGI 5-Series cameras directly to the pole to reduce the impact of strong wind on the image quality of the camera.
  • Page 15 Step 6. Connect the cables Connect modular battery Connect solar panel Connect cameras...
  • Page 16 Step 7. Waterproof cables 1. After connecting the camera to the load interface, wrap the connection with over two layers of waterproof tape (not included). Note: When using waterproof tape, wrap the first layer, then cut. Apply a second layer, ensuring no gaps between the connection and tape for secure waterproofing.
  • Page 17 (such as access points, bridges, and 4G cameras). 2. Download and install the latest TP-Link VIGI app. 3. Open the app and log in with your TP-Link ID. If you don’t have an account, sign up first. 4. Tap the + button on the top right and follow the app instructions to add the VIGI solar system contrroller.
  • Page 18 Appendix FAQ Q1. The controller LED status is abnormal. • SYS LED is off: It may be out of power or the system board is damaged. • LAN LED is off: There is no connection. Check whether the RJ45 interface is firmly connected to the network device.
  • Page 19 Risk of fire or explosion if the battery is replaced by an incorrect type. EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863.
  • Page 20 For technical support, user guides and other information, please visit https://www.tp-link.com/support/...
