  • Page 1 BELKA LED DERBY PAR INSTRUKCJA OBSŁUGI USER MANUAL...
  • Page 2 POLSKI Dziękujemy za wybór naszego urządzenia. Przed rozpoczęciem użytkowania sugerujemy zapoznanie się z tą instrukcją. Zawiera ona ważne informacje na temat bezpieczeństwa oraz ułatwia użytkowanie. UWAGA! DLA WŁASNEGO BEZPIECZEŃSTWA ZAPOZNAJ SIĘ Z TĄ INSTRUKCJĄ PRZED PIERWSZYM WŁĄCZENIEM URZĄDZENIA. Po otrzymaniu przesyłki ostrożnie odpakuj produkt i sprawdź zawartość opakowania. Sprawdź czy urzą- dzenie oraz opakowanie nie zostało uszkodzone podczas transportu.
  • Page 3 Nie narażaj bezpieczeństwa swojego i innych, nieprawidłowa instalacja może zagrozić zdrowiu lub ży- ciu, oraz może spowodować uszkodzenie mienia. BELKA LED DERBY PAR – WPROWADZENIE Kompaktowy zestaw oświetleniowy, w całości mieszczący się w jednym opakowaniu. W zestawie znaj- duje się wytrzymały statyw, wygodna torba, pilot bezprzewodowy, 2 wielokolorowe reflektory oraz dwa efekty oświetleniowe podłączone na stałe do belki z zasilaniem.
  • Page 4 Uwaga wykres poglądowy, rzeczywisty wygląd może się różnić. STRUKTURA MENU...
  • Page 5 TRYB DMX Użytkowanie tego trybu daje użytkownikowi dużą elastyczność pod względem ustawiania własnych kolorów i tworzenia własnego show. W tym trybie sterować możesz całą belką, lub każdym urządze- niem z osobna. Aby przejść do ustawień adresu DMX wciśnij przycisk „MENU” z tyłu urządzenia aż na wyświetlaczu pojawi się...
  • Page 6 TRYB 6 KANAŁÓW Kanał Wartość Funkcja 000-255 Czerwony 000-255 Zielony 000-255 Niebieski 000-255 Biały 000-255 Stroboskop 000-255 Szybkość TRYB 15 KANAŁÓW KANAŁ WARTOŚĆ FUNKCJA 000-255 Czerwony 000-255 Zielony 000-255 Niebieski Efekt 1 000-255 Biały 000-255 Ruchy 000-255 Czerwony 000-255 Zielony PAR 1 i 2 000-255 Niebieski...
  • Page 7 Tryb SOUND Aby wejść do trybu sterowania dźwiękiem wciskaj przycisk „MENU” aż na wyświetlaczu pojawi się ko- munikat „Sou”. Wciśnij przycisk „ENTER” i wybierz przyciskami „UP” i „DOWN” odpowiedni efekt SouP (PAR sound), SouF (efekt sound), Soun (PAR i efekt sound). Zatwierdź przyciskiem „ENTER” i przejdź do wyboru sterowanego programu SP/SF/Sn.
  • Page 8 Protokół DMX Protokół DMX512 to międzynarodowy standard pozwalający na połączenia i sterowanie inteligentnymi oprawami oświetleniowymi. W połączeniu DMX występuje 512 kanałów, które mogą być przypisane w dowolnej kolejności. Urządzenie kompatybilne z protokołem DMX512 wymaga jednego lub kilku kolej- nych kanałów. Użytkownik musi przypisać początkowy adres DMX, który będzie pierwszym kanałem sterowanym przez kontroler.
  • Page 9 INFORMACJA O ZUŻYTYM SPRZĘCIE ELEKTRYCZNYM I ELEKTRONICZNYM UWAGA! URZĄDZENIA NIE WOLNO WYRZUCAĆ DO ODPADÓW DOMOWYCH. To oznaczenie oznacza, że produkt nie może być wyrzucany razem z odpadami domowymi w całej UE. W celu zapobiegnięcia potencjalnym szkodom dla środowiska lub zdrowia, zużyty produkt należy poddać...
  • Page 10 ENGLISH Thank you for choosing our device. Before using it, we suggest you read this manual. It contains im- portant safety information and makes it easy to use. WARNING! FOR YOUR OWN SAFETY, READ THIS MANUAL BEFORE TURNING ON THE DE- VICE FOR THE FIRST TIME.
  • Page 11 Do not jeopardize the safety of yourself and others, improper instal- lation may endanger health or life, and may cause damage to property. BELKA LED DERBY PAR – INTRODUCTION Compact lighting kit that fits entirely in one package. The set includes a sturdy stand, a convenient bag, a wireless remote, 2 multicolor spotlights and two lighting effects permanently connected to a pow- ered bar.
  • Page 12 Note: illustrative graphic, the actual appearance may vary. MENU STRUCTURE...
  • Page 13 DMX MODE Using this mode gives the user a lot of flexibility in terms of setting your own colors and creating your own show. In this mode you can control the entire bar, or each device individually. To go to the DMX address setting, press the "MENU" button on the back of the unit until "dnH" appears on the display.
  • Page 14 6-CHANNEL MODE Channel Value Function 000-255 000-255 Green 000-255 Blue 000-255 White 000-255 Strobe 000-255 Speed 15-CHANNEL MODE Channel Value Function 000-255 Effect 1 000-255 Green 000-255 Blue 000-255 White 000-255 Movements 000-255 PAR 1 i 2 000-255 Green 000-255 Blue 000-255 White...
  • Page 15 SOUND mode To enter the sound control mode, press the "MENU" button until "Sou" appears on the display. Press the "ENTER" button and select the desired effect SouP (PAR sound), SouF (sound effect), Soun (PAR and sound effect) with the "UP" and "DOWN" buttons. Confirm with the "ENTER" button and proceed to the selection of the controlled SP/SF/Sn program.
  • Page 16 DMX protocol The DMX512 protocol is an international standard that allows connections and control of intelligent lighting fixtures. There are 512 channels in a DMX connection, which can be assigned in any order. A DMX512 protocol-compatible device requires one or more consecutive channels. The user must as- sign an initial DMX address, which will be the first channel controlled by the controller.
  • Page 17 INFORMATION ABOUT USED ELECTRICAL AND ELECTRONIC EQUIPMENT WARNING! THE DEVICE MUST NOT BE DISPOSED OF WITH HOUSEHOLD WASTE. This symbol indicates that this product must not be disposed of with household waste, according to the EU and your national law. In order to prevent potential damage to the environment or health, the used product must be recycled.
