Summary of Contents for Summerset TRLPB2
- Page 1 POWER BURNERS USER MANUAL...
- Page 2 Table of Contents...
- Page 3 TRLPB2 SIZPROPB ALTPB2 Safety Warnings & Codes .........5 Safety & Installation Instructions ......7 Where To Install The Power Burner ......12 Gas Safety Requirements ........14 Cleaning & Maintenance ........20 Operating Instructions ...........22 Sizzler Pro Power Burner Parts List ......24 TRL Power Burner Parts List ........26...
- Page 4 Natural gas & liquid propane configurations THANK YOU Thank you for your purchase. We’d like to welcome you to the Summerset family of luxury outdoor kitchen products and look forward to being a part your home for years to come. As a family business with over 30 years of industry experience, we aim to deliver exceptional quality and personal service.
- Page 5 Safety Warnings & Codes...
- Page 6 IF YOU SMELL GAS 1. Shut off the gas to the appliance. 2. Extinguish any open flame. 3. Open lid to vent. 4. If odor continues, keep away from the appliance, and immediately call your gas supplier or fire department. INSTALLATION CODE AND SUPPLY REQUIREMENTS This power burner must be installed in accordance with local codes and ordinances,...
- Page 7 Safety & Installation Instructions...
- Page 8 GENERAL SAFET Y REQUIREMENTS WARNING! WARNING! The installation of this appliance must conform with local codes To Reduce the risk of fire, electrical shock, or or, in the absence of local codes, Either the National Fuel Gas injury, read and follow these basic precautions Code, ANZI Z223.1/NFPA 54, or CAN/CGAB149.1, Natural Gas before operating your gas power burner.
- Page 9 23. The Summerset Power Burner is not designed/certified for foot traffic pa erns. Position your Power Burner so and cannot be installed in or on recreational vehicles, portable the prevailing wind blows into the front control panel trailers, boats or any other mobile vehicle.
- Page 10 IMPORTANT: THIS POWER BURNER IS FOR OUTDOORS USE ONLY. WARNING! The power burner must be installed in masonry or other type of fireproof surround. The unit is not insulated and therefore must be installed or placed with 16” – 18” of side and back clearance from unprotected combustible materials such as wood, Plastic, or stucco with wood framing.
- Page 11 75% recommended. of the support grid surface with pans or griddles. BURNER BTUS Note: The 1” (2.5 cm) front air space allows access to the drip tray. MODEL SIZPROPB TRLPB2 ALTPB2 24,000 24,000 24,000 INNER 36,000 36,000...
- Page 12 Where to Install the Power Burner...
- Page 13 GAS SAFET Y REQUIREMENTS NOTE! Each appliance is set and tested at the factory for the We recommend you build the enclosure for the type of gas supply to be used. Identify the type of gas, either natural gas or LP (Liquid Propane) gas and make power burner 6"-12"...
- Page 14 Gas Safety Requirements...
- Page 15 It must be provided with a shut-off valve terminating in gas tank valve outlet. It must include a collar to protect the cylinder valve. The cylinder supply system must be arranged for vapor withdrawal. Do not operate the gas Power Burner indoors or in any enclosed area.
- Page 16 FILLING AND REFILLING LP GAS CYLINDERS All purging and refilling of LP gas cylinders must be performed by qualified personnel in the LP gas industry. Never store a spare LP gas cylinder under or near this appliance. Never fill the LP gas cylinder beyond 80 percent full. Failure to follow these instructions may result in explosion, personal injury or death.
- Page 17 LIQUID PROPANE A dented or rusty LP cylinder may be hazardous and INSTALLATION NOTE: should be avoided. If in doubt, have it checked by your LP supplier. Always check for leaks a er every LP cylinder Ventilation is required in the enclosure on opposite change.
- Page 18 NATURAL GAS INSTALLATION The installation must conform with local codes or, in the absence of local codes, with either The national Fuel Gas Code, ANSI Z223.1/NFPA 54, or CAN/CGA-B149.1, Natural Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code. 1. This gas appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at To prevent fire or explosion hazard, DO NOT use or...
- Page 19 Power Burner above cooking surface to non- combustible construction is required. A minimum of 1” clearance to the sides of the Power Burner above cooking surface to noncombustible TRLPB2 construction is recommended. NOTE! DO NOT USE THIS APPLIANCE UNDER OVERHEAD COMBUSTIBLE SURFACES...
- Page 20 Cleaning & Maintenance...
- Page 21 SPIDER AND INSECT WARNING POWER BURNER GRATE MAINTENANCE Spiders and other insects can nest in the burner of this and any other Power Burner, which causes the gas The easiest way to clean the grates is to scrub them to flow from the front of the burner. This dangerous with a barbeque brush immediately a er cooking is “condition”...
- Page 22 Operating Instructions...
- Page 23 BEFORE LIGHTING THE POWER MATCH/BBQ LIGHTER BURNER LIGHTING INSTRUCTIONS: 1. DO NOT ATTEMPT TO LIGHT THE POWER BURNER IF 1. Push and turn the knob counter-clock-wise past the YOU SMELL GAS. “CLICK” position. Hold the knob pushed in for 2-3 seconds.
- Page 24 SIZZLER PRO Power Burner Parts List...
- Page 26 Power Burner Parts List...
- Page 27 TRL POWER BURNER PARTS LIST BUMPER INNER GRATE OUTER GRATE BODY DRIP TRAY TRACK OIL DRIP TUBE BASIN BACK BASIN FRAME LEFT SIDE BOARD FIXING PANEL CHANNEL BURNER RIGHT SIDE PANEL IGNITER PIN ORIFICE BURNER BASE RIGHT ANGLE IGNITER FITTING BURNER BASE BRACKET DRIP TRAY...
- Page 28 ALTURI Power Burner Parts List...
- Page 30 Warranty...
- Page 32 14520 Delta Ln Suite 105 Huntington Beach, CA 92647 ( 800 ) 966 8126 SUMMERSETGRILLS.COM VER. 042823...
