CONEN LITE-K CCELW-AFK Series Assembly Instruction Manual

Electrical height adjustable mount for 55" - 86" displays

Advertisement

Quick Links

MONTAGEANLEITUNG
ASSEMBLY INSTRUCTION
LITE-K SERIES
Elektrisch höhenverstellbare
Halterung für 55" - 86" Displays
Electrical height adjustable
mount for 55" - 86" displays
S Y S T E M S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LITE-K CCELW-AFK Series and is the answer not in the manual?

Questions and answers

Summary of Contents for CONEN LITE-K CCELW-AFK Series

  • Page 1 S Y S T E M S LITE-K SERIES Elektrisch höhenverstellbare Halterung für 55" - 86" Displays Electrical height adjustable MONTAGEANLEITUNG mount for 55" - 86" displays ASSEMBLY INSTRUCTION...
  • Page 2: Table Of Contents

    Inhaltsverzeichnis / Table of Content Seite / Page Rechtliche Informationen / Legal & Regulatory information Sicherheitshinweise / Safety information Technische Informationen / Technical information Montageanleitung / Assembly instructions Erhältliches Zubehör / Available accessories Gebrauchsanweisung / User instructions Checkliste / Checklist...
  • Page 3 WANDMONTIERT / WALL MOUNTED 14 18 Packungsinhalt / Package contents 15 18 Montageanleitung / Assembly instruction FREISTEHEND / FREESTANDING 20 23 Packungsinhalt / Package contents 21 23 Montageanleitung / Assembly instruction MOBIL / MOBILE 24 27 Packungsinhalt / Package contents 25 27 Montageanleitung / Assembly instruction WEITERES / OTHER...
  • Page 4: Rechtliche Informationen / Legal & Regulatory Information

    Dokument enthaltenen Informationen. Bilder, Diagramme, Abbildungen und alle anderen Informationen im Folgenden. dienen lediglich der Erläuterung und Beschreibung. In keinem Fall haftet Conen für besondere, mittelbare, zufällige oder Folgeschäden, einschließlich u.a. Schäden aus entgangenem Gewinn oder Betriebsunterbrechung, unabhängig davon, ob diese auf Vertragsbruch, unerlaubter Handlung (einschließlich Fahrlässigkeit), Produkthaftung oder...
  • Page 5: Legal & Regulatory Information

    (including negligence), product liability, or otherwise, in connection with the use of the product, even if Conen has been advised of the possibility of such damage or loss.
  • Page 6 Komponente angehängt ist. Die Halterung kann entweder an der Wand, freistehend oder mobil sein. Zubehör: Ein Zubehör ist das sekundäre Conen-Produkt, das an ein primäres Conen-Produkt angehängt wird. An das Zubehör kann eine Komponente angebracht werden oder drauf gestellt werden.
  • Page 7: Safety Instructions

    The mount could be either wall mounted, freestanding or mobile. Accessory: An accessory is the secondary Conen product which is attached to a primary Conen product. The accessory may have a component attached to or sitting on.
  • Page 8: Wichtige Montagehinweise

    Schäden am Gerät oder zum Erlöschen der Werksgarantie führen. Bewahren Sie diese Anweisungen zum späteren Nachschlagen auf. Conen ist nicht verantwortlich für Verletzungen oder Schäden, die durch unsachgemäße Instal- lation, unsachgemäße Verwendung oder Nichtbeachtung der Anweisungen verursacht werden. WARNUNG: Es liegt in der Verantwortung des Installateurs, sicherzustellen, dass alle Montage- systeme und alle Zubehörteile und/oder Komponenten ordnungsgemäß...
  • Page 9: Important Installation Instructions

    Save these instructions for future reference. Conen is not responsible for injury or damage caused by improper installation, improper usage or failure to follow the instructions. WARNING: It is the installer´s responsibility to make sure that all mounting systems and...
  • Page 10: Mechanische Sicherheit

    Sicherheitsinformationen MECHANISCHE SICHERHEIT WARNUNG: Überschreiten Sie niemals die maximale Gewichtsbelastung. Es liegt in der Verantwortung des Installateurs, sicherzustellen, dass das Gesamtgewicht aller Zubehör- teile und Komponenten, die am Montagesystem befestigt sind, geringer ist als die angege- bene maximale Gewichtsbelastung. Siehe Tabelle oben unter „Max. Gewichtsbelastung“. WARNUNG: Lassen Sie Kinder das Befestigungssystem nicht bedienen oder auf die Bedienelemente zugreifen.
  • Page 11: Mechanical Safety

    Safety information MECHANICAL SAFETY WARNING: Never exceed the maximum weight load. It is the installer‘s responsibility to make sure that the combined weight of all accessories and components attached to the mounting system is less than the specifi ed maximum weight load. See table above under “Max.
  • Page 12: Technische Informationen / Technical Information

    Technische Informationen / Technical information CCELW AFK WANDMONTIERT / WALL MOUNTED SCETALIK FREISTEHEND / FREESTANDING...
  • Page 13 SCETAVLIB MOBIL / MOBILE...
  • Page 14 Packungsinhalt / Package contents Packungsinhalt / Package contents Packungsinhalt / Package contents 2 x M8 x 85 2 x M6 x 30 2 x M8 x 85 2 x M6 x 30 2 x M8 4 x M8 x 16 4 x M6 x 16 2 x M8 4 x M8 x 16...
  • Page 15: Montageanleitung / Assembly Instructions

    WANDMONTIERT / WALL MOUNTED Montageanleitung / Assembly instruction 100 mm / 4.0" Düble und Schraube müssen eine Ausreißkraft von 500N standhalten Plug and screw must withstand a pull-out force of 500N 150 mm /5.9" Wandmontagematerial enthalten (keine Wandschrauben und Dübel). Wandbeschaffenheit kann zusätzliches Montagematerial nötig machen.
  • Page 16 Montageanleitung / Assembly instruction Position beachten! Langlöcher müssen nach oben zeigen. / Note position! Oblong holes must point upwards. Position beachten! Langlöcher müssen nach unten zeigen. / Note position! Oblong holes must point downwards.
  • Page 17 WANDMONTIERT / WALL MOUNTED VESA VERTIKAL / VESA VERTICAL Federverschluß muss nach außen zeigen / Spring lock must point outwards 10/11 10/11 VESA HORIZONTAL...
  • Page 18 WANDMONTIERT / WALL MOUNTED Montageanleitung / Assembly instruction KOLLISIONSSCHUTZ / COLLISION PROTECTION 16.1 16.2...
  • Page 20 Packungsinhalt / Package contents Packungsinhalt / Package contents FREISTEHEND / FREESTANDING Packungsinhalt / Package contents 2 x M8 x 85 2 x M6 x 30 2 x M6 x 30 2 x M8 x 85 2 x M8 4 x M8 x 16 4 x M6 x 16 2 x M8 4 x M8 x 16...
  • Page 21 Montageanleitung / Assembly instruction Position beachten! Langlöcher müssen nach oben zeigen. / Note position! Oblong holes must point upwards. Position beachten! Langlöcher müssen nach unten zeigen. / Note position! Oblong holes must point downwards. VESA VERTIKAL / VESA VERTICAL Federverschluß muss nach außen zeigen / Spring lock must point outwards...
  • Page 22 FREISTEHEND / FREESTANDING VESA HORIZONTAL...
  • Page 23 Montageanleitung / Assembly instruction KOLLISIONSSCHUTZ / COLLISION PROTECTION 16.1 16.2...
  • Page 24 Packungsinhalt / Package contents Packungsinhalt / Package contents Packungsinhalt / Package contents Packungsinhalt / Package contents 2 x M8 x 85 2 x M6 x 30 2 x M8 x 85 2 x M6 x 30 2 x M8 4 x M8 x 16 4 x M6 x 16 2 x M8 x 85 2 x M6 x 30...
  • Page 25 MOBIL / MOBILE Montageanleitung / Assembly instruction Position beachten! Langlöcher müssen nach oben zeigen. / Note position! Oblong holes must point upwards. Position beachten! Langlöcher müssen nach unten zeigen. / Note position! Oblong holes must point downwards. VESA VERTIKAL / VESA VERTICAL Federverschluß...
  • Page 26 Montageanleitung / Assembly instruction VESA HORIZONTAL...
  • Page 27 MOBIL / MOBILE KOLLISIONSSCHUTZ / COLLISION PROTECTION 16.1 16.2...
  • Page 29 Bedienteile / Control panels HOCH RUNTER UP DOWN Zur Höhenverstellung die Tasten oder Bedieneinheit gedückt halten. Beim Loslassen stoppt die Bewegung sofort. Im Gefahrenfall da- her lediglich die Bedieneinheit loslassen (Tot- mannschaltung). To adjust the height, press and hold the button on the remote.
  • Page 30: Erhältliches Zubehör / Available Accessories

    WEITERES / OTHER Erhältliches Zubehör / Available accessories ABLAGEN / SHELVES Vordere Ablage zur Befestigung an der Pylonensäule FSH-SMLI Front shelf for attachment to the pylon column Tastaturablage AFSCETAKBLI Keyboard tray Soundbar Halterung SMPRSO Soundbar mount BODENPLATTEN / FLOOR STANDS Bodenplatte - groß...
  • Page 31 Erhältliches Zubehör / Available accessories WANDMONTAGE / WALL MOUNTINGS Set aus zwei Z-Winkeln zur Wandmontage, 11 cm CCZ11-LI Set of two Z-brackets for wall mounting, 11 cm U-Wandhalterung H 28,5 cm, inkl. Montageraster mit 9 Löchern WMB-SCETSLI U-shaped wall bracket H 28.5 cm, incl. mounting grid with 9 holes Wandmontagesatz- zwei Stahlrohre L120 cm zur Lastverteilung...
  • Page 33: Gebrauchsanweisung / User Instructions

    Gebrauchsanweisung / User instructions STELLEN SIE KEINE GEGENSTÄNDE MAXIMALE BELASTUNG / UNTER DAS SYSTEM / DO NOT PLACE MAXIMUM WEIGHT LOAD OBJECTS UNDER OR ABOVE THE SYSTEM Max. 136 kg Max. 300 lbs. LASSEN SIE KINDER NICHT UNBEAUFSICHTIGT MIT DEM SYSTEM / DO NOT LEAVE CHILDREN UNSUPERVISED WITH THE SYSTEM ERLAUBEN SIE KINDERN UNTER 16 JAHREN NICHT, MOBILE SYSTEME ZU BEWEGEN.
  • Page 34 Checkliste CHECKLISTE FÜR BENUTZER MOTORISIERTES DISPLAY MONTAGESYSTEM Prüfen Sie, ob das maximale Gesamtgewicht von Display, Zubehör und anderen Komponenten die angegebene maximale Gewichtsbelastung nicht überschreitet. Prüfen Sie, ob alle Kabel sauber verlegt und verdeckt sind. Stellen Sie sicher, dass sich die Kabel nicht verheddern oder beschädigt werden können, wenn das Montagesystem nach oben oder unten bewegt wird.
  • Page 35 Checklist USER CHECKLIST MOTORIZED DISPLAY MOUNTING SYSTEM Check whether the maximum total weight of display, accessories and any other components does not exceed the listed max. weight load. Check whether all cables are neatly run and concealed. Make sure that when the mounting system is moved up or down, cables cannot get tangled or damaged.
  • Page 36 S Y S T E M S Conen Systems GmbH Conenstr. 4 54497 Morbach-Gonzerath Germany T +49 5251 50012-0 E sales@conen-systems.com www.conen-systems.com AI-0027_V2 DISPLAY STAND E496872 © Copyright: Conen Systems GmbH...
