- Page 1 RPM-LCD (Remote Power Manager) User’s Manual...
- Page 2 Table of Contents 1. Important Safety Instructions ....................2 2. Introduction ..........................4 3. Package Contents ........................5 4. Functions ..........................6 5. Installation ..........................7 6. Web Interface ........................... 8 7. Specifications ......................... 28 8. Obtaining Service ........................30 9.
- Page 3 1. IMPORTANT SAFETY INSTRUCTIONS This manual contains important instructions that should be followed during the installation and the operation of the Remote Power Manager (RPM). SAVE THESE INSTRUCTIONS An Important Notice To ensure safety a Qualified Service Personnel should perform the installation. ...
- Page 4 The packing materials that your RPM was shipped in are carefully designed to minimize any shipping damage. In the unlikely case that the RPM needs to be returned to MINUTEMAN, please use the original packing material. Since MINUTEMAN is not responsible for shipping damage incurred when the system is returned, the original packing material is inexpensive insurance.
- Page 5 2. Introduction The RPM is an Internet ready device designed and equipped with an intelligent current meter (True RMS) that will indicate the total power consumption of the RPM. Features: Built-in Web Server to support Remote Power Management. Local LCD displays Amps, IP Address, Temperature or Humidity.
- Page 6 3. Package Contents The standard RPM package contains a Remote Power Manager unit with supporting hardware. The contents of the package are: Remote Power Manager Unit Power Cord Rackmount Brackets Quick Install Instructions CD-ROM, which contains: ...
- Page 7 4. Functions Functions Description Circuit Breaker Overload protection. ON / OFF (green) LEDs: On means the outlet is active. Off means the outlet is not active. LED Indicators Circuit Status (red) LED: On means the RPM is Overloaded. ...
- Page 8 5. Installation This RPM series is ONLY intended to be installed in an indoor temperature-controlled environment that is free of conductive contaminants. DO NOT operate the RPM in: extremely dusty and/or unclean areas, locations near heating devices, water, or excessive humidity, or where the RPM is exposed to direct sunlight. Select a location, which will always provide good air circulation for the RPM.
- Page 9 6. Web Interface Login: Enter the IP address of the RPM in a web browser. Note: The default setting for the IP address is DHCP enabled. If the RPM cannot get the IP from the DHCP server, the IP address will remain at the default IP address 192.168.0.216 The default Username is snmp.
- Page 10 Information: Overview This section shows the information about the RPM Power, the temperature/humidity (when using the temp/hum probe), the last five events that have occurred, and the status of the individual outlets.
- Page 11 Information: Power This section shows the information about the current draw, the voltage, the frequency, the power, and the energy. Information: System This section shows the information about the System (RPM), Network and SNMP:...
- Page 12 Information: Event Log This table lists all the events that have occurred. The existing values are overwritten when the maximum number of entries (5000) has been reached. You can filter the log based on specific dates and times. The event logs can be downloaded and saved for future reference.
- Page 13 Information Chart The chart shows the saved power and environmental data, then displays it in graphical form.
- Page 14 Management: Control This allows the specified users to control the outlets. Select the outlet by checking the box and then click the ON, the OFF, or the Restart button to control the outlet. ON: Click the ON button to turn on the selected outlets. OFF: Click the OFF button to turn off the selected outlets.
- Page 15 Management: Schedule This allows the administrator to schedule turning OFF/ON the RPM’s outlets. Outlet: Assign the outlet and/or group to be controlled in this schedule. Outlet Action: Select the action you want to occur. Date: When selecting the Once option, a specific date must be entered. When selecting the ‘Every’ option you can set the schedule for an outlet using an assigned weekly day, or every day.
- Page 16 Management: Ping Action This allows the administrator to Ping the device that is connected to a specific outlet and if there is no response the RPM will automatically cycle power to a locked device connected to the specified outlet by rebooting the outlet.
- Page 17 Management: Event Action This allows the administrator to setup specific actions based on a selected event. The RPM can also receive SNMP traps from a specified device and then perform the selected action. Event Device: When the current for entire RPM exceeds the Warning or Overload thresholds the RPM will perform the selected Action.
- Page 18 Management: Device This allows the administrator to configure the outlet name, the delay time and select different users for specific outlets. Outlet Configuration Outlet Name: Rename the outlet. Delay ON: Set the delay time in seconds for the power on sequence. Delay OFF: Set the delay time in seconds for the power off sequence.
- Page 19 Management: Threshold This allows the administrator to configure the thresholds for the Temp/Hum probe, the entire RPM, and each individual outlet. Device Threshold Configuration: Set the warning and overload thresholds for entire RPM then click Modify to change the settings. Once these thresholds are set see the management Event Actions to configure the actions based on these thresholds.
- Page 20 Configuration: Network This allows the administrator to configure the network settings. TCP/IP Settings for IPv4 Host Name: The host name of the RPM. DHCP Client: Enable/Disable DHCP to get the IP address from a DHCP server. The default setting for DHCP is enabled.
- Page 21 Configuration: Security This allows the administrator to configure the security settings to prevent unauthorized users from accessing the RPM. HTTP Configuration Server: Enabling or disabling the HTTP connection with the RPM. SSL: Enable or Disable the SSL function. The user may configure HTTPS protocol to use a port number other than standard HTTPS port (443).
- Page 22 Configuration: User This allows the administrator to add users and give them specific rights. No.: This is the number of users. The maximum number of users is eight. User: This is the user’s login name. The default administrator’s name is snmp. Password: This is the user’s login password.
- Page 23 Configuration: Mail This allows the administrator to setup the email notification. When an event occurs, the RPM can send out email messages to the predefined accounts. Email Server: Enter the Hostname or IP address of the SMTP Mail Server that will be used to send emails. If entering a Hostname, you are also required to enter the DNS Address, see the Configuration Network tab.
- Page 24 Configuration: SNMP The RPM supports the SNMPv1, v2c and v3 traps to satisfy most of the user’s environment. This allows the administrator to setup the SNMP Traps. When an event occurs, the RPM can send out SNMP Traps to predefined targets. Once the SNMP configuration is complete click the Apply button to save the settings.
- Page 25 Configuration: Time This allows the administrator to setup the system time for the scheduled events. Time Configuration: To use the Simple Network Time Protocol (SNTP), Activate the SNTP and then setup the Timeserver. Click the Apply button to save the settings. To setup the date and time manually, Inactive the SNTP.
- Page 26 Configuration: Radius This allows the administrator to configure the RADIUS parameters. Remote Authentication Dial-In User Service (RADIUS) is a widely deployed protocol enabling centralized authentication, authorization, and accounting for network access. RADIUS: Enable or Disable the RADIUS function. Primary Server: Input the Primary RADIUS Server's IP address. Shared Secret: Input the Password of Primary Server.
- Page 27 Configuration: Log This allows the administrator to setup the log information. Export Data Configuration: Export the log files in csv format. Syslog Configuration: Configure the RPM to send Systems logs. Data Log Configuration: Set the time interval to record the data logs. Heartbeat Interval: Enable or Disable the Heartbeat Trap and set the interval time.
- Page 28 Configuration: System This allows the administrator to configure the system. System Configuration: Configure one RPM, then its configuration file can be saved and then uploaded to another RPM. Firmware Upgrade: The firmware can be upgraded via the web page. Reset System: Reset the system back to the factory default setting. Hardware Reset Button Definition: Configure how the reset button functions.
- Page 29 7. Specifications Model Number RPM158N1LCD-15P RPM208N1LCD-20P RPM2024N1LCD-20P RPM3024N1LCD-L30P RPM3024N1LCD-HW Load Capacity 12Amps 16Amps 24Amps (Max) INPUT PARAMETERS Number of Phases Single (12W +G) Nominal Voltage 100-127VAC Frequency 50/60Hz Input Protection Re-settable circuit breaker OUTPUT PARAMETERS Nominal Voltage 100-127VAC Frequency 50/60Hz Branch Circuit 62368-1 Protection...
- Page 30 Specifications (Cont.) Model Number RPM208I2LCD-L20P RPM308I2LCD-L30P RPM308I2LCD-HW RPM3016I2LCD-L30P RPM3016I2LCD-HW Load Capacity 16Amps 24Amps 24Amps 24Amps 24Amps (Max) INPUT PARAMETERS Number of Phases Single (12W +G) Nominal Voltage 200-240VAC Frequency 50/60Hz Input Protection Re-settable circuit breaker OUTPUT PARAMETERS Nominal Voltage 200-240VAC Frequency 50/60Hz Branch Circuit...
- Page 31 4. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside of the package. 5. Return the unit by insured prepaid carrier to: Para Systems Inc. MINUTEMAN UPS 1809 W. Frankford Road, Suite 150 Carrollton, TX 75007 ATTN: RMA # _______...
- Page 32 9. Limited Product Warranty Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three (3) years from the date of purchase. For equipment sites within the United States and Canada, this warranty covers depot repair or replacement of defective equipment at the discretion of Para Systems.
