- Page 1 Endeavor 5 - 10KVA Step Down Transformer User's Manual Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN - 34000473 R2...
-
Page 2: Table Of Contents
Table Of Contents Introduction Rear Panels Installation Operation Obtaining Service Specifications Limited Product Warranty A1. Declaration of Conformity... -
Page 3: Introduction
WARNING: Qualified Service Personnel ONLY must perform the Installa- the Standard for the Protection of Electronic Computer/Data Processing Equip- tion and Servicing of these ED-XFR. MINUTEMAN accepts no liabilities and is ment ANSI/NFPA 75. The AC inputs of these Step Down Transformers are not limited to: injury to the Service Personnel, or damages to;... - Page 4 CAUTION! To de-energize the outputs of the ED-XFR: 1. Turn off the Load breakers on the rear panel of the ED-XFR. 2. If the UPS is on press and release the On/Off/Test button after the sec- ond beep. 2. Turn off the input circuit breaker on the rear panel of the UPS. 3.
-
Page 5: Rear Panels
Chapter 2: Rear Panels 1. The Load 4 circuit breaker will trip in the event the load exceeds the power rating. 2. Load 4: 120V output receptacles (3 - 5-15/20R). 3. The Load 3 circuit breaker will trip in the event the load exceeds the power rating. -
Page 6: Installation
RACKMOUNT CONFIGURATION Chapter 3: Installation Use the included rackmount brackets and screws to mount the ED-XFR in a rack by following the steps below. INSTALLATION PLACEMENT USE CAUTION: The ED-XFR is extremely heavy. Use the appropriate number of personnel when installing the UPS system. CAUTION! DO NOT USE THE MOUNTING BRACKETS TO LIFT THE STEP DOWN TRANSFORMER. - Page 7 TOWER CONFIGURATION CONNECTING THE STEP DOWN TRANSFORMER TO THE UPS The tower configuration allows the user to install the ED-XFR in the up-right WARNING: Qualified Service Personnel ONLY must perform the Installa- position. The tower stands are provided with the UPS. The tower stand ex- tion and Servicing of these ED-XFR.
- Page 8 The ED8000RT-XFR and ED10000RT-XFR come with an #6 AWG input power 2. Input / Output cable selection: cable in the box. The pins for the input cable are included. Connect one end Temperature Rating 5/6KVA 8/10KVA of the input power cable to the input terminal block on the ED-XFR. Connect 60°C / 75°C #10 AWG (Cu) #6 AWG (Cu)
-
Page 9: Operation
1. Turn on the input breaker on the rear panel of the UPS. The fans will turn Connect the green wire labeled G on the input power cable to the ED- XFR AC input terminal block ground terminal and secure. on, the AC normal icon will flash off/on and the LCD will display ‘bPS’. -
Page 10: Obtaining Service
802 x 620 x 230 mm 780 x 600 x 276 mm Weight - Shipping 196.2 lbs / 89.0 Kgs 123.5 lbs / 56.0 Kgs Para Systems Inc. MINUTEMAN UPS REGULATORY COMPLIANCE 1809 W. Frankford Road, Suite 150 Safety and Approvals cTUVus Carrollton, TX 75007 ATTN: RMA # _______ (Conforms to UL60950-1:2007 R12.11, CSA-C22.2 No.60950-1-07-A1:2011) -
Page 11: Limited Product Warranty
United States and Canada, Para Systems only covers faulty parts. Para Systems products that are depot repaired or replaced pursuant to this warranty shall only be Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) warranted for the unexpired portion of the warranty applying to the original product. This warranty applies only to the original purchaser who must have properly registered the product within 10 days of purchase. - Page 12 Notes: Notes:...
