OXO PixyLine 300 GFX User Instruction

Hide thumbs

Advertisement

Quick Links

Download this manual
PixyLine 300 GFX
INSTRUCTION MANUAL
MODE D'EMPLOI
FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL
CAREFULLY BEFORE YOU INITIALLY START-UP
POUR VOTRE SÉCURITÉ, MERCI DE LIRE ATTENTIVEMENT
CE MODE D'EMPLOI AVANT D'UTILISER VOTRE PRODUIT
V1.0 06/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the PixyLine 300 GFX and is the answer not in the manual?

Questions and answers

Related Manuals for OXO PixyLine 300 GFX

Summary of Contents for OXO PixyLine 300 GFX

  • Page 1 PixyLine 300 GFX INSTRUCTION MANUAL MODE D’EMPLOI FOR YOUR OWN SAFETY, PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE YOU INITIALLY START-UP POUR VOTRE SÉCURITÉ, MERCI DE LIRE ATTENTIVEMENT CE MODE D’EMPLOI AVANT D’UTILISER VOTRE PRODUIT V1.0 06/2024...
  • Page 3 ENGLISH PIXYLINE 300 GFX - USER INSTRUCTION Page 1. In the box 2. Instructions 3. Overview 4. Operation guide 5. Installation 6. Technical data 7. Dimensions FRANÇAIS PIXYLINE 300 GFX - MODE D’EMPLOI Page 1. Dans la boîte 2. Instructions 3.
  • Page 4 • If in doubt, DON’T use it and contact an authorized dealer. • This unit must only be operated by adults. DO NOT allow children to tamper or play with it. User Manual - PIXYLINE 300 GFX V1.0 06/2024 4/72...
  • Page 5 4. Touch button «Mode / Up / Down / Enter» to navigate and change value in Menu 5. Display 6. Power supply OUT (PowerCON TRUE 1) 7. DMX OUT (XLR5) 8. Connection system User Manual - PIXYLINE 300 GFX V1.0 06/2024 5/72...
  • Page 6 MANUAL B- Menu To navigate thru menu use «up» and «down» button. To validate use «enter». To enter and get out menu use «mode». 1-DMX ADDR Change DMX Address value 001-512 User Manual - PIXYLINE 300 GFX V1.0 06/2024 6/72...
  • Page 7 See at the end of manual for details DIMMER EFFECT MACRO 000-255 SPEED See at the end of manual for details BLIND STROBE 000-255 See at the end of manual for details FROST 000-255 BACK COLOR DIMMER 000-255 User Manual - PIXYLINE 300 GFX V1.0 06/2024 7/72...
  • Page 8 See at the end of manual for details BACK EFFECT MACRO SPEED 000-255 See at the end of manual for details BACK STROBE 000-255 See at the end of manual for details User Manual - PIXYLINE 300 GFX V1.0 06/2024 8/72...
  • Page 9 To unlock : push MODE + ENTER during 5s DIMMER CURVE Linear / Exponential / Logarithmic / S-Curve DIMMER RESPONSE LED / HALOGEN DISPLAY REVERSE To return display ON/OFF ON : upside OFF : downside User Manual - PIXYLINE 300 GFX V1.0 06/2024 9/72...
  • Page 10 : 9116 to go inside MENU 01 thru 12 and ALL WHITE 050-255 R UP 050-255 G UP 050-255 B UP 050-255 R DOWN 050-255 G DOWN 050-255 B DOWN 050-255 User Manual - PIXYLINE 300 GFX V1.0 06/2024 10/72...
  • Page 11 RESET CALIBRATION Get back to all default calibration value 7-INFO SOFTWARE V1.00 Software version TEMP INFO 39°C Product temperature OPERATE TIME 507 h Time of use RDM info RDM info User Manual - PIXYLINE 300 GFX V1.0 06/2024 11/72...
  • Page 12 Intensity 0 to 100% BACK COLOR ALL B 000 - 255 Intensity 0 to 100% BLIND DIMMER (White) 000 - 255 Intensity 0 to 100% FROST 000 - 255 Frost 0 or 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 12/72...
  • Page 13 BACK COLOR ALL B 000 - 255 Intensity 0 to 100% BACK COLOR MACRO 000 - 255 See Macro in Macro list BACK COLOR MACRO SPEED 000 - 255 from Slow to Fast User Manual - PIXYLINE 300 GFX V1.0 06/2024 13/72...
  • Page 14 Intensity 0 to 100% BLIND 3 000 - 255 Intensity 0 to 100% BLIND 3 FINE 000 - 255 Intensity 0 to 100% BLIND 4 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 14/72...
  • Page 15 Intensity 0 to 100% BLIND 11 000 - 255 Intensity 0 to 100% BLIND 11 FINE 000 - 255 Intensity 0 to 100% BLIND 12 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 15/72...
  • Page 16 BACK COLOR R 1 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 1 000 - 255 Intensity 0 to 100% BACK COLOR G 1 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 16/72...
  • Page 17 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 1 G 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 1 B 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 17/72...
  • Page 18 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 5 G 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 5 B 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 18/72...
  • Page 19 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 9 G 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 9 B 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 19/72...
  • Page 20 BACK and FRONT COLOR 12 B 000 - 255 Intensity 0 to 100% BLIND DIMMER 12 (White) 000 - 255 Intensity 0 to 100% FROST 000 - 255 Frost 0 or 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 20/72...
  • Page 21 Intensity 0 to 100% BLIND 7 FINE 000 - 255 Intensity 0 to 100% BLIND 8 000 - 255 Intensity 0 to 100% BLIND 8 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 21/72...
  • Page 22 Ramdom Lighting Strobe : Slow to Fast 200 - 224 Ramdom solo Strobe : Slow to Fast 224 - 255 Ramdom Solo lighting Strobe : Slow to Fast FROST 000 - 255 Frost 0 or 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 22/72...
  • Page 23 BACK COLOR B 2 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 3 000 - 255 Intensity 0 to 100% BACK COLOR R 3 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 23/72...
  • Page 24 BACK COLOR G 5 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 5 000 - 255 Intensity 0 to 100% BACK COLOR B 5 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 24/72...
  • Page 25 BACK COLOR R 8 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 8 000 - 255 Intensity 0 to 100% BACK COLOR G 8 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 25/72...
  • Page 26 BACK COLOR B 10 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 11 000 - 255 Intensity 0 to 100% BACK COLOR R 11 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 26/72...
  • Page 27 BACK COLOR G 1 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 1 000 - 255 Intensity 0 to 100% BACK COLOR B 1 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 27/72...
  • Page 28 BACK COLOR R 4 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 4 000 - 255 Intensity 0 to 100% BACK COLOR G 4 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 28/72...
  • Page 29 BACK COLOR B 6 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 7 000 - 255 Intensity 0 to 100% BACK COLOR R 7 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 29/72...
  • Page 30 BACK COLOR G 9 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 9 000 - 255 Intensity 0 to 100% BACK COLOR B 9 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 30/72...
  • Page 31 BACK COLOR R 12 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 12 000 - 255 Intensity 0 to 100% BACK COLOR G 12 FINE 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 31/72...
  • Page 32 Ramdom Lighting Strobe : Slow to Fast 200 - 224 Ramdom solo Strobe : Slow to Fast 224 - 255 Ramdom Solo lighting Strobe : Slow to Fast 000 - 255 Intensity 0 to 100% User Manual - PIXYLINE 300 GFX V1.0 06/2024 32/72...
  • Page 33 Zenith Blue 195 084-087 Elysian Blue 714 088-091 Just Blue 079 092-095 Sky Blue 68 096-099 Medium Blue 132 100-103 Glacier Blue 352 104-108 Steel Blue 117 109-111 Lagon Blue 172 User Manual - PIXYLINE 300 GFX V1.0 06/2024 33/72...
  • Page 34 Fade macro 13 to 18 204-207 Fade macro 19 to 29 208-211 Fade macro 30 to 34 212-215 Fade macro 35 to 41 216-219 Fade macro 42 to 47 220-255 Reserved User Manual - PIXYLINE 300 GFX V1.0 06/2024 34/72...
  • Page 35 150- 159 9- Double drop chase IN 160- 169 10- Double half drop chase IN oppose 170- 179 11- Sinus snake wave 180- 189 12- Sinus long snake wave 190-255 Reserved User Manual - PIXYLINE 300 GFX V1.0 06/2024 35/72...
  • Page 36 Screw the couplers via M12 screws and self-locking nuts onto the Omega brackets. Insert the quick-lock fasteners of the Omega brackets into the respective holes on the back side of the device. Tighten the quick-lock fasteners fully clockwise. User Manual - PIXYLINE 300 GFX V1.0 06/2024 36/72...
  • Page 37 0°- 40°C Product dimension 1017 x 85 x 119 mm Product weight 9,00 kg Box Pack Size 1075 x 185 x 180 mm Box weight 10,60 kg 7. Dimensions 1017 mm User Manual - PIXYLINE 300 GFX V1.0 06/2024 37/72...
  • Page 38 • En cas de doute, ne l’utilisez pas et contactez un revendeur agréé. • Cet appareil ne doit être utilisé que par des adultes. NE PAS permettre aux enfants de le manipuler ou de jouer avec. Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 38/72...
  • Page 39 4. Touch button «Mode / Up / Down / Enter» to navigate and change value in Menu 5. Display 6. Power supply OUT (PowerCON TRUE 1) 7. DMX OUT (XLR5) 8. Connection system Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 39/72...
  • Page 40 24 CH RUN MODE Si SLAVE MODE : afficher SLAVE MODE SLAVE RUN MODE Si MASTER MODE : afficher MASTER MODE MASTER RUN MODE Si MANUAL MODE : afficher MANUEL MODE MANUAL Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 40/72...
  • Page 41 Pour choisir les valeurs du MODE MANUEL 01 jusqu’à 12 et ALL BLIND DIMMER 000-255 DIMMER EFFECT MACRO 000-255 Voir détail à la fin du manuel DIMMER EFFECT MACRO 000-255 SPEED Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 41/72...
  • Page 42 10s / 30s / 1min / 5min / JAMAIS L’écran s’éteint et le produit se vérrouille après la durée DISPLAY LOCK sélectionnée Pour déverrouiller : appuyer sur MODE + ENTER pendant Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 42/72...
  • Page 43 Reprend toutes les valeurs par défaut, NE MODIFIE PAS les valeurs d’étalonnage 6-CALIBRATION CALIBRATION Code : 9116 pour entrer dans le menu 01 jusqu’à 12 et ALL WHITE 050-255 R UP 050-255 G UP 050-255 Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 43/72...
  • Page 44 B DOWN 050-255 RESSET CALIBRATION Restaure les valeurs par défaut 7-INFO SOFTWARE V1.00 Version du logiciel TEMP INFO 39°C Température du produit OPERATE TIME 507 h Durée d’utilisation RDM info Info RDM Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 44/72...
  • Page 45 Intensity 0 to 100% BACK COLOR ALL B 000 - 255 Intensity 0 to 100% BLIND DIMMER (White) 000 - 255 Intensity 0 to 100% FROST 000 - 255 Frost 0 or 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 45/72...
  • Page 46 BACK COLOR ALL B 000 - 255 Intensity 0 to 100% BACK COLOR MACRO 000 - 255 See Macro in Macro list BACK COLOR MACRO SPEED 000 - 255 from Slow to Fast Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 46/72...
  • Page 47 Intensity 0 to 100% BLIND 3 000 - 255 Intensity 0 to 100% BLIND 3 FINE 000 - 255 Intensity 0 to 100% BLIND 4 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 47/72...
  • Page 48 Intensity 0 to 100% BLIND 11 000 - 255 Intensity 0 to 100% BLIND 11 FINE 000 - 255 Intensity 0 to 100% BLIND 12 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 48/72...
  • Page 49 BACK COLOR G 1 000 - 255 Intensity 0 to 100% BACK COLOR G 1 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 1 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 49/72...
  • Page 50 Intensity 0 to 100% BACK and FRONT COLOR 1 B 000 - 255 Intensity 0 to 100% BLIND DIMMER 1 (White) 000 - 255 Intensity 0 to 100% with Tungsten mode Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 50/72...
  • Page 51 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 5 B 000 - 255 Intensity 0 to 100% BLIND DIMMER 5 (White) 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 51/72...
  • Page 52 000 - 255 Intensity 0 to 100% BACK and FRONT COLOR 9 B 000 - 255 Intensity 0 to 100% BLIND DIMMER 9 (White) 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 52/72...
  • Page 53 BACK and FRONT COLOR 12 B 000 - 255 Intensity 0 to 100% BLIND DIMMER 12 (White) 000 - 255 Intensity 0 to 100% FROST 000 - 255 Frost 0 or 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 53/72...
  • Page 54 Intensity 0 to 100% BLIND 7 FINE 000 - 255 Intensity 0 to 100% BLIND 8 000 - 255 Intensity 0 to 100% BLIND 8 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 54/72...
  • Page 55 Ramdom Lighting Strobe : Slow to Fast 200 - 224 Ramdom solo Strobe : Slow to Fast 224 - 255 Ramdom Solo lighting Strobe : Slow to Fast FROST 000 - 255 Frost 0 or 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 55/72...
  • Page 56 BACK COLOR B 2 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 3 000 - 255 Intensity 0 to 100% BACK COLOR R 3 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 56/72...
  • Page 57 BACK COLOR G 5 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 5 000 - 255 Intensity 0 to 100% BACK COLOR B 5 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 57/72...
  • Page 58 BACK COLOR R 8 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 8 000 - 255 Intensity 0 to 100% BACK COLOR G 8 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 58/72...
  • Page 59 BACK COLOR B 10 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 11 000 - 255 Intensity 0 to 100% BACK COLOR R 11 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 59/72...
  • Page 60 BACK COLOR G 1 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 1 000 - 255 Intensity 0 to 100% BACK COLOR B 1 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 60/72...
  • Page 61 BACK COLOR R 4 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 4 000 - 255 Intensity 0 to 100% BACK COLOR G 4 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 61/72...
  • Page 62 BACK COLOR B 6 FINE 000 - 255 Intensity 0 to 100% BACK COLOR R 7 000 - 255 Intensity 0 to 100% BACK COLOR R 7 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 62/72...
  • Page 63 BACK COLOR G 9 FINE 000 - 255 Intensity 0 to 100% BACK COLOR B 9 000 - 255 Intensity 0 to 100% BACK COLOR B 9 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 63/72...
  • Page 64 BACK COLOR R 12 FINE 000 - 255 Intensity 0 to 100% BACK COLOR G 12 000 - 255 Intensity 0 to 100% BACK COLOR G 12 FINE 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 64/72...
  • Page 65 Ramdom Lighting Strobe : Slow to Fast 200 - 224 Ramdom solo Strobe : Slow to Fast 224 - 255 Ramdom Solo lighting Strobe : Slow to Fast 000 - 255 Intensity 0 to 100% Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 65/72...
  • Page 66 Elysian Blue 714 088-091 Just Blue 079 092-095 Sky Blue 68 096-099 Medium Blue 132 100-103 Glacier Blue 352 104-108 Steel Blue 117 109-111 Lagon Blue 172 112-115 Peacock Blue 115 Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 66/72...
  • Page 67 Fade macro 13 to 18 204-207 Fade macro 19 to 29 208-211 Fade macro 30 to 34 212-215 Fade macro 35 to 41 216-219 Fade macro 42 to 47 220-255 Reserved Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 67/72...
  • Page 68 150- 159 9- Double drop chase IN 160- 169 10- Double half drop chase IN oppose 170- 179 11- Sinus snake wave 180- 189 12- Sinus long snake wave 190-255 Reserved Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 68/72...
  • Page 69 Visser les coupleurs à l’aide de vis M12 et d’écrous autobloquants sur les supports Omega. Insérer les attaches rapides des supports Omega dans les trous correspondants sur la face arrière de l’appareil. Serrer les attaches rapides à fond dans le sens des aiguilles d’une montre Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 69/72...
  • Page 70 CE, UKCA Température de fonctionnement 0°- 40°C Dimensions produit 1017 x 85 x 119mm Poids produit 9,00kg Dimensions carton 1075 x 185 x 180mm Poids carton 10,60kg 7. Dimensions 1017 mm Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 70/72...
  • Page 71 Mode d’emploi - PIXYLINE 300 GFX V1.0 06/2024 71/72...
