- Page 1 All manuals and user guides at all-guides.com Fujitsu Microelectronics Europe FMEMCU-UG-960011-10 User Guide F²MC-16FX FAMILY ADAPTER BOARD ADA-16FX-ETHERNET USER GUIDE...
- Page 2 All manuals and user guides at all-guides.com ADA-16FX-ETHERNET Revision History Revision History Date Issue 11.01.2008 V1.0, TKi, First Release This document contains 14 pages. UG-960011-10 - 2 - © Fujitsu Microelectronics Europe GmbH...
- Page 3 Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in original packing and without further defects resulting from the customer’s use or the transport.
- Page 4 5 CONNECTORS......................10 Ethernet connector (X1) ..................10 Edge Connectors (X2, X3, X11) ................10 6 SILK-PLOT OF THE BOARD ..................11 7 RELATED PRODUCTS ....................12 8 INFORMATION IN THE WWW..................13 UG-960011-10 - 4 - © Fujitsu Microelectronics Europe GmbH...
- Page 5 < All 100 pins routed to pin-header < On-board 5V and 3V voltage regulators, Power-LED < USB power-supply (external power supply possible) This board must only be used for test applications in an evaluation laboratory environment. © Fujitsu Microelectronics Europe GmbH - 5 - UG-960011-10...
- Page 6 Attach the adapter board to the evaluation board as shown below. The Ethernet jack has to face to the outer edge. Ethernet jack Note: Make sure to jumper the board to 5V before connecting the ADA-16FX-ETHERNET. UG-960011-10 - 6 - © Fujitsu Microelectronics Europe GmbH...
- Page 7 JP 3pol. Select center tap B of Ethernet jack solder JP 3pol. Please refer to the documentation of the evaluation board for detailed information about the jumper settings for the SK-16FX-EUROSCOPE (SK-16FX-100PMC). © Fujitsu Microelectronics Europe GmbH - 7 - UG-960011-10...
- Page 8 By default the pins 4 and 5 of the assembled Ethernet jack are used as center tap pin. This setting depends on the type and manufacturer of the used Ethernet jack (see chapter 5.1). UG-960011-10 - 8 - © Fujitsu Microelectronics Europe GmbH...
- Page 9 These LEDs display the status of the Ethernet interface. Colour Description LINK Green Indicates that a link is established Yellow Indicates activity on the Ethernet By default the LINK LED should light directly after connected to a network. © Fujitsu Microelectronics Europe GmbH - 9 - UG-960011-10...
- Page 10 MCU Pins X2 (1 – 20) 1 – 20 X3 (71 – 100) 71 – 100 X11 (51 – 70) 51 – 70 The adapter board is powered via the edge connectors. UG-960011-10 - 10 - © Fujitsu Microelectronics Europe GmbH...
- Page 11 All manuals and user guides at all-guides.com ADA-16FX-ETHERNET Chapter 6 Silk-Plot of the Board 6 Silk-Plot of the Board Ethernet connector Latch Cirrus CS8900A Latch © Fujitsu Microelectronics Europe GmbH - 11 - UG-960011-10...
- Page 12 All manuals and user guides at all-guides.com ADA-16FX-ETHERNET Chapter 7 Related Products 7 Related Products SK-16FX-EUROSCOPE Evaluation board with MB96F348HS < FPT-100P-M20 package ADA-16FX-ETHERNET Adapterboard for SK-16FX-EUROSCOPE < (SK-16FX-100PMC) MB96F348HS MB96340 Series Flash MCU < UG-960011-10 - 12 - © Fujitsu Microelectronics Europe GmbH...
- Page 13 Datasheets and Hardware Manuals, Support Tools (Hard- and Software) http://mcu.emea.fujitsu.com Linear Products: Power Management, A/D and D/A Converters http://www.fujitsu.com/emea/services/microelectronics/linears/ Media Products: SAW filters, acoustic resonators and VCOs http://www.fujitsu.com/emea/services/microelectronics/saw/ For more information about FUJITSU MICROELECTRONICS http://www.fujitsu.com/emea/services/microelectronics/ © Fujitsu Microelectronics Europe GmbH - 13 - UG-960011-10...
- Page 14 According to the European WEEE-Directive and its implementation into national laws we take this device back. For disposal please send the device to the following address: Fujitsu Microelectronics Europe GmbH Warehouse/Disposal Monzastraße 4a D-63225 Langen Germany UG-960011-10 - 14 - © Fujitsu Microelectronics Europe GmbH...
