Specification
n SPEAKER SECTION
Type
Woofer
Sound pressure level
Frequency range (with amp)
n AMPLIFIER SECTION
Output power
Input sensitivity/Input Impedance
Phase switching
Low pass filter
CONTENTS
1 Safety Precautions
1.1. GENERAL GUIDELINES
2 Caution for AC Mains Lead
3 Handling the Lead-free Solder
1 way 2 speaker system Bass-
reflex type
17 cm cone type x 2
83 dB/W (1.0 m)
28-300 Hz (at -16 dB)
32-250 Hz (at -10 dB)
100 W (6 Ω) x 2 (THD 0.9%)
300 mV/33 kΩ (RCA jack)
NORMAL/REVERSE
50-200 Hz Variable
Page
Active Subwoofer System
SB-WA800E
SB-WA800EB
Colour
(M)... Wood Grain Type
n GENERAL
Power supply
Power consumption
Dimensions (W x H x D)
Mass
Note :
Specifications are subject to change without notice.
Mass and dimensions are approximate.
3
3.1. About lead free solder (PbF)
3
4 Before Repair and Adjustment
4
5 Protection Circuitry
5
6 Accessories
© 2004 Matsushita Electric Industrial Co., Ltd. All
rights
distribution is a violation of law.
ORDER NO. MD0410487C2
AC 230-240 V, 50Hz (EB)
AC 230 V, 50Hz (E)
255 mm x 462.5 mm x 467 mm
reserved.
Unauthorized
165 W
(with the stand)
21 kg
Page
5
5
5
6
copying
and
Advertisement
Related Manuals for Panasonic SB-WA800E
Summary of Contents for Panasonic SB-WA800E
- Page 1 ORDER NO. MD0410487C2 Active Subwoofer System SB-WA800E SB-WA800EB Colour (M)... Wood Grain Type Specification n SPEAKER SECTION Type 1 way 2 speaker system Bass- n GENERAL reflex type Power supply AC 230-240 V, 50Hz (EB) Woofer 17 cm cone type x 2...
- Page 2 SB-WA800E / SB-WA800EB 7 Connection of the Speaker Cables 12.1. Power P.C.B. and LED P.C.B. 8 Disassembly Procedure 12.2. Level Control P.C.B. and LED P.C.B. 8.1. Disassembly flow chart 12.3. AC Inlet P.C.B. and Transformer P.C.B. 8.2. Disassembly of the Speaker Unit and checking of the 13 Wiring Connection Diagram P.C.B.
- Page 3 SB-WA800E / SB-WA800EB 1 Safety Precautions 1.1. GENERAL GUIDELINES 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
- Page 4 SB-WA800E / SB-WA800EB 2 Caution for AC Mains Lead...
- Page 5 SB-WA800E / SB-WA800EB 3 Handling the Lead-free Solder 3.1. About lead free solder (PbF) Distinction of PbF P.C.B. : P.C.B.s (manufactured) using lead free solder will have a PbF stamp on the P.C.B. Caution: · Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 - 70°F (30 - 40°C) higher.
- Page 6 SB-WA800E / SB-WA800EB 6 Accessories AC cord (For EB only)..1 pc AC cord (For E only)..1 pc RCA cord..1 pc...
- Page 7 SB-WA800E / SB-WA800EB 7 Connection of the Speaker Cables Connect to a receiver or amplifier (a) with a pin-type output terminal for an active subwoofer. · Before connection, turn off the other equipment. Do not connect the AC mains lead until all other cables and cords are connected.
- Page 8 SB-WA800E / SB-WA800EB 8 Disassembly Procedure “ATTENTION SERVICER” Some chassis components may have sharp edges. Be careful when disassembling and servicing. 1. This section describes procedures for checking the operation of the major printed circuit boards and replacing the main components.
- Page 9 SB-WA800E / SB-WA800EB 8.2. Disassembly of the Speaker Unit and checking of the P.C.B. 8.2.1. Disassembly of the Woofer Unit (Front) Step 1: Detach the net frame as arrow shown. (Be careful of the bosses attached to the unit). 8.2.2.
- Page 10 SB-WA800E / SB-WA800EB Step 3: Detach the (+) and (-) wires from the woofer speaker. Step 2: Remove 6 screws. Step 3: Remove the control panel unit from the front panel 8.2.3. Disassembly and Checking of assembly as arrow shown.
- Page 11 SB-WA800E / SB-WA800EB Step 4: Remove 2 screws. Step 5: Remove the barrier. Step 9: Remove both volume knobs and nuts. Step 6: Remove 2 screws. Step 10: Cover with a soft cloth and pull out the selector knob as arrow shown.
- Page 12 SB-WA800E / SB-WA800EB Step 15: Remove the volume angle as arrow shown. Step 12: Pull out the control panel as arrow shown. Step 16: Reconnect the connectors CN502B and CN101B to Step 13: Remove the protection foam from the bottom of the check the LED P.C.B.
- Page 13 SB-WA800E / SB-WA800EB 8.2.5. Disassembly of the Amp Unit · Follow Step (1) described in Item 8.2.4 Step 1: Remove 8 screws from the bottom of the cabinet. Step 4: Disconnect the connectors (CN601, CN602, CN502A and CN101A). Step 2: Remove 2 screws from the rear panel.
- Page 14 SB-WA800E / SB-WA800EB 8.2.6. Disassembly of the Rear Panel · Follow Step (1) described in Item 8.2.4 · Follow Step (1) to Step (5) described in Item 8.2.5 Step 1: Remove 5 screws from the rear panel. Step 2: Lay the rear panel and remove the fan unit as arrow shown.
- Page 15 SB-WA800E / SB-WA800EB Step 6: Remove 4 screws. Step 2: Detach the connector CP603. Step 3: Lift up the AC Inlet P.C.B. as arrow shown. Step 7: Reconnect the Power P.C.B., Transformer P.C.B. and AC Inlet P.C.B. for checking. Steps 4 & 5: Remove 4 screws.
- Page 16 SB-WA800E / SB-WA800EB Step 2: Remove 2 screws from the IC601.
- Page 17 SB-WA800E / SB-WA800EB 9 Block Diagram IC101 C0AABB000086 DUAL OP AMP JK101 Q703 Q702,Q704 INPUTS SUPPLY CONTROL, REGULATOR SUPPLY SWITCH S501 Q701 VR501 Q603 REGULATOR D613 SYNC D702 SWITCH D703, D704, D706, D707 TRANSFORMER T702 D406~D409 T701 Q409 REGULATOR D602,D603,...
- Page 18 SB-WA800E / SB-WA800EB 10 Notes of Schematic Diagram (All schematic diagrams may be modified at any time with the development of the new technology) Note: · The voltage value and waveforms are the reference voltage of this unit measured by DC electronic voltmeter (high impedance) and oscilloscope on the basis of chassis.
- Page 19 SB-WA800E / SB-WA800EB 11 Schematic Diagram 11.1. Power Circuit, Level Control Circuit and LED Circuit SCHEMATIC DIAGRAM - 1 LEVEL CONTROL : -B SIGNAL LINE CIRCUIT POWER CIRCUIT : MAIN SIGNAL LINE : +B SIGNAL LINE R108 C501 D101 16V10...
- Page 20 SB-WA800E / SB-WA800EB SCHEMATIC DIAGRAM - 2 : -B SIGNAL LINE LED CIRCUIT : MAIN SIGNAL LINE : +B SIGNAL LINE S501 K0F124A00053 R503 R505 R506 Q501 VR502 W501 W501 D501 2.7K 2.7K B3AKA0000006 R507 R504 VR502 C507 R509 C506...
- Page 21 SB-WA800E / SB-WA800EB 11.2. AC Inlet Circuit and Transformer Circuit SCHEMATIC DIAGRAM - 3 : -B SIGNAL LINE : +B SIGNAL LINE AC INLET CIRCUIT LEVEL CONTROL CIRCUIT (CN502B) ON SCHEMATIC DIAGRAM-2 CN502A Q701,Q703 Q702 Q704 2SD0592ARA 2SA1175KEF 2SB0621AHA REGULATOR...
- Page 22 SB-WA800E / SB-WA800EB 12 Printed Circuit Board 12.1. Power P.C.B. and LED P.C.B. POWER P.C.B (REPV0047B)...E (REPV0047C)...EB E601 J110 Q603 Q602 CP603 D612 R628 D613 C304 R309 R305 R312 R306 Q302 Q301 J102 IC301 C110 CN101A C106 JK101 C109 J103...
- Page 23 SB-WA800E / SB-WA800EB Q409 D407 J112 C410 D409 D408 J106 D406 D612 R628 C304 R309 J209 R305 R312 CN604 J607 Q302 Q301 J606 C613 J713 J701 J702 C305 J303 R211 J308 Q202 R619 J404 J117 J506 R212 R203 C614 R206...
- Page 24 SB-WA800E / SB-WA800EB 12.2. Level Control P.C.B. and LED P.C.B. LEVEL CONTROL P.C.B (REPV0048A) LOW PASS POWER PHASE FILTER VOLUME VR501 VR502 W501 S502 S501 R508 R507 Q501 IC502 R503 CN502B C505 R504 Q502 CN101B LED P.C.B (REPV0048A) W501 D501...
- Page 25 SB-WA800E / SB-WA800EB 12.3. AC Inlet P.C.B. and Transformer P.C.B. AC INLET P.C.B (REPV0047B)...E (REPV0047C)...EB CN502A 250V T2.5AL C703 RLY701 FC701 FC702 T702 (SUB-TRANSFORMER) JK701 Q701 J130 L701 C702 J131 R701 AC IN Q703 230V 50Hz...E J132 Q702 C707 D701...
- Page 26 SB-WA800E / SB-WA800EB 13 Wiring Connection Diagram LEVEL CONTROL P.C.B. LOW PASS POWER PHASE FILTER VOLUME VR502 VR501 W501 S502 4 5 6 1 2 3 1 2 3 LED P.C.B. S501 CN502B W501 3 2 1 CN101B 7 6 5 4 3 2 1 POWER P.C.B.
- Page 27 SB-WA800E / SB-WA800EB 14 Illustration of ICs, Transistors and Diodes C0AABB000086 RSN313H25-P 2SB0621AHA KTC3199GRTA 2SC3940ARA 2SD0592ARA KRA102MTA 2SA1175KEF KRA119MTA B0AACK000004 MA2C700A0F KRC102MTA Cathode Cathode Anode Anode MTZJ13BTA B0EAMM000038 B3AKA0000006 B0EAKM000122 MTZJ18CTA Cathde B0BA7R900004 Cathode B0BA6R800007 Anode Cathode B0BA01100004 Anode Cathode...
- Page 28 SB-WA800E / SB-WA800EB 15 Parts Location and Replacement Parts List Notes: · Important safety notice: Components identified by mark have special characteristics important for safety. Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low noise (resistors), etc are used.
- Page 29 SB-WA800E / SB-WA800EB 15.1. Cabinet 15.1.1. Cabinet Parts Location...
- Page 30 SB-WA800E / SB-WA800EB...
- Page 31 SB-WA800E / SB-WA800EB 15.1.2. Cabinet Parts List Ref. Part No. Part Name & Description Remarks CABINET AND CHASSIS RFKGBWA800M FRONT PANEL ASS’Y RMN0802 CATCHER XTB3+16AFZ SCREW RGP1299-K CONTROL PANEL RGU2182A-K POWER KNOB RGW0397A-K VOLUME KNOB RGU2183-AK SELECTOR KNOB RHN90001 M9 NUT...
- Page 32 SB-WA800E / SB-WA800EB 15.2. Electrical Parts List Ref. Part No. Part Name & Description Remarks D610 B0EAMM000038 DIODE Ref. Part No. Part Name & Description Remarks D611 B0AACK000004 DIODE D612 B0EAKM000122 DIODE PRINTED CIRCUIT BOARD D613 MTZJ18CTA DIODE D701 B0AACK000004...
- Page 33 SB-WA800E / SB-WA800EB Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks R501 D0AE101JA048 100 1/4W JACKS R502 D0AE103JA048 10K 1/4W R503 D0AE103JA048 10K 1/4W JK101 K2HA102B0073 JK RCA R504 D0AE103JA048 10K 1/4W...
- Page 34 SB-WA800E / SB-WA800EB Ref. Part No. Part Name & Description Remarks C407 ECA1CAK470XB 47 16V C408 F1E1H1030001 0.01 50V C409 ECA1EAM331XB 330 25V C410 F1E1H1030001 0.01 50V C501 ECA1CAK100XB 10 16V C502 ECA1CAK100XB 10 16V C503 F1E1H1030001 0.01 50V C505 F1E1H1030001 0.01 50V...
- Page 35 SB-WA800E / SB-WA800EB 15.3. Packing Materials & Accessories Parts List Ref. Part No. Part Name & Description Remarks Ref. Part No. Part Name & Description Remarks PACKING MATERIALS ACCESSORIES RPG7377 PACKING CASE [M]E RJA0019-2K AC CORD (SF) [M]E RPG7378 PACKING CASE...
