- Page 1 JT4300P LTE Outdoor CPE Administrator User Manual...
-
Page 2: Table Of Contents
Table of Contents OVERVIEW ..............................3 NTERFACE PECIFICATION ...................... 3 GETTING STARTED ..........................3 EVICE OGIC CONNECTION ......................4 SIM C ..........................5 NSERT (ODU) – C ..................5 NSTALLING UTDOOR LAMP LED DISPLAY ............................6 RF S ... -
Page 3: Overview
1. Overview JT4300P is highly advanced LTE outdoor data unit specially designed to meet the most challenging demands of today’s high speed wireless backhaul and fixed wireless access deployments by the 4G service operators. The unit can support multiple TDD/FDD band operations. -
Page 4: Device Logic Connection
Power cord Clamp PC Ethernet Cable If you find any of the items is missing, please contact our local distributor immediately. 2) Installing the Equipment Device Logic connection For outdoor CPE product, it is suggested that the CPE device be installed in a shaded area to avoid direct sun light exposure which may cause over heat in certain extreme weather condition. -
Page 5: Insert Sim Card
Insert SIM Card Installing Outdoor Unit (ODU) – Clamp 5 / 27... -
Page 6: Led Display
3. LED Display Type Function Description Solid green – Device is power on. Power indicator OFF – NO wireless network access. WAN port status Solid Green – WAN data transmission in progress Light is on – SIM card state is ready. SIM card indicator Blinking Green –... -
Page 7: Managing Your Device
4. Managing Your Device WEB Login It is recommended that you log in to the device by using a web browser from a PC that’s connected to the device’s LAN port. To log in, open a web browser and type http://192.168.0.1 in the address bar. -
Page 8: Device Statistics
Device Statistics The menu shows the CPE device traffic statistics and memory usage information. LTE Interface The menu shows the LTE Connection status and LTE interface info. 8 / 27... -
Page 9: Wan Interface
WAN Interface The menu shows the WAN status and LTE APN interface info. User Interface The menu shows LAN status and device list. Maintenance / Update This menu allows user to perform firmware upgrade via WEG GUI with option to reset to factory setting. -
Page 10: Wireless Configuration
5. Wireless Configuration LTE Settings The LTE radio can be enabled or disabled via 4G Radio setting. The radio can also be reset via Reconnect. PLMN Settings The user can add and configure the PLMN list to restrict the CPE to attach. The CPE will attach to network according to the PLMN priority assigned. - Page 11 Cell Selection The cell selection menu is used to configure how CPE will select the best cell. APN Settings This menu is used to configure the operator APN profile. You can configure single or multiple APNs for the operator network. The below shows an example of two APN configuration.
-
Page 12: Sim Management
SIM Management This menu is used to view the SIM card status and perform PIN code management for SIM card. You disable or enable the SIM card PIN check on the CPE to bind the SIM card inserted. 12 / 27... -
Page 13: Advanced Options
Advanced Options In this menu, you can configure advanced options for the CPE operation. Fast scan & cell selection will allow you to quickly connect to good cell when they are first found instead of search the best cell. QAM64 setting will allow the CPE enable Uplink QAM64 support. -
Page 14: Lan Networking
LAN Networking The LAN setting allows user to specify the device LAN IP, DHCP server setting, Local DNS etc. When Router mode is selected, the DHCP server should be enabled by default. User is advised to leave the default setting unchanged for quick configuration and smooth device operation. -
Page 15: Ipv6 Settings
IPv6 Settings On this page, user configure the IPv6 operation setting for the CPE device. DDNS Settings This section allows user to configure VPN service for selected connection mode. This section allows user to configure DDNS service. VPN Service This section allows user to configure VPN service for selected connection mode. -
Page 16: Firewall Control
6. Firewall Control Firewall Control This allows to configure firewall protection. ALG Setting This allows to configure ALG options. 16 / 27... - Page 17 MAC Filtering This allows user to create MAC filter to control the client access. 17 / 27...
- Page 18 IP Filtering This allows user to create IP filter to control the client access. URL Filtering This allows user to create URL filter to control the client access. 18 / 27...
-
Page 19: Ccess Estriction
Access Restriction This allows user to configure access restriction. Port Forwarding This menu allows user to configure the port forwarding rules for the CPE in router mode. 19 / 27... -
Page 20: Dmz Setting
DMZ Setting This menu allows user to configure the DMZ setting for CPE in router mode. Web server, Telnet/SSH and Ping Service port can be exempted from DMZ mapping if required. By enabling DMZ option will make the specified local LAN host (DMZ IP) exposed to Internet. -
Page 21: N P Setting
UPnP Setting This menu allows user to configure the UPnP application for on-demand “DMZ” support. The current forwarding rules created can be viewed and cleared if required. DoS This menu allows user to configure DoS setting. 21 / 27... -
Page 22: Management
7. Management Date & Time The menu allows user to configure the NTP setting for the CPE device. 22 / 27... -
Page 23: Account
Account The menu allows user to configure the WEB GUI login password TR069 The menu allows user to configure the necessary setting for TR069 management of the CPE device. 23 / 27... -
Page 24: Snmp
SNMP The menu allows user to configure the SNMP setting. Maintenance The menu allows user to configure the CPE reboot, factory reset and download or upload configuration file. 24 / 27... -
Page 25: Access Management
Access management The menu allows user to configure the device management options. 8. Diagnosis Tools Ping This menu allows user to perform PING tests using WEB GUI interface. Both IPv4 and IPv6 can be supported. 25 / 27... -
Page 26: Route
Trace Route This menu allows user to configure traceroute testing Iperf This menu allows user to configure iPerf testing using WEB GUI interface. Both TCP and UDP tests can be supported. Remote iPerf server is required to conduct the tests. -
Page 27: Command Shell
Command Shell This menu allows user to command for get CPE status. 27 / 27...
