INSTALLATION MANUAL GAS COOKTOP Please read this guide thoroughly before installation. LSCG366ST LSCG306ST www.lg.com...
Page 2
I N S TA L L AT I O N I N S T RU C T I O N S INSTALLATION SAFETY INSTRUCTIONS BEFORE YOU BEGIN Read these instructions completely Note to Installer: Leave these instructions with the appliance after installation is completed. and carefully.
Page 3
I N S TA L L AT I O N I N S T RU C T I O N S READ ALL INSTRUCTIONS BEFORE INSTALLATION IN THE COMMONWEALTH OF MASSACHUSETTS • This product must be installed by a licensed •...
Page 4
I N S TA L L AT I O N I N S T RU C T I O N S INSTALLATION SAFETY INSTRUCTIONS BEFORE YOU BEGIN Remove all tape and packing materials before using the cooktop. Dispose all plastic bags after unpacking the cooktop.
Page 5
I N S TA L L AT I O N I N S T RU C T I O N S INSTALLATION SAFETY INSTRUCTIONS (continued) • The ventilating hood must be constructed of sheet • The vertical distance from the plane of the cooking metal not less than 0.0122”...
Page 6
I N S TA L L AT I O N I N S T RU C T I O N S DIMENSIONS AND CLEARANCES Provide enough clearances between the cooktop and The cooktop may be placed with 2 3/4” clearance to adjacent combustible surfaces.
Page 7
I N S TA L L AT I O N I N S T RU C T I O N S INSTALLING THE COOKTOP UNIT 1. LOCATE ELECTRICAL OUTLET 4. INSTALL THE RETAINER BRACKETS AND GAS SHUT-OFF VALVE Install the retainer brackets to the bottom BENEATH CABINET of the cooktop unit.
Page 8
I N S TA L L AT I O N I N S T RU C T I O N S 1. PROVIDE ADEQUATE GAS SUPPLY This cooktop is designed to operate at a pressure of For LP gas, the pressure supplied must be between 5”...
Page 9
I N S TA L L AT I O N I N S T RU C T I O N S FLEXIBLE CONNECTOR HOOKUP Pressure regulator Adapter Gas Flow into Range Flex connector (6 ft. max.) Adapter Installer: Inform the consumer of the shut-off valve 1/2”...
Page 10
I N S TA L L AT I O N I N S T RU C T I O N S 3. ELECTRICAL CONNECTIONS ELECTRICAL REQUIREMENTS 120 Volt, 60 Hertz, properly grounded dedicated The power cord of this appliance should be equipped circuit protected by a 15 A or 20 A circuit breaker or with a three-prong (grounding) plug which mates with time delay fuse.
Page 11
I N S TA L L AT I O N I N S T RU C T I O N S 3. ELECTRICAL CONNECTIONS (continued) CAUTION The installation of appliances designed for mobile home installation should conform with the Manufactured Home Construction and Safety The customer should have the circuit checked by a Standard, Title 24 CFR, Part 3280 (formerly the qualified technician to make sure the receptacle is...
Page 12
I N S TA L L AT I O N I N S T RU C T I O N S 5. ASSEMBLE THE SURFACE BURNERS Make sure the hole in the burner head is positioned CAUTION over the electrode. DO NOT operate the burners without all parts in place.
Page 13
I N S TA L L AT I O N I N S T RU C T I O N S 7. ADJUST THE SURFACE BURNER LOW FLAME (SIMMER) SETTING For all surface burners except for the center 7. Position center burner head, center burner cap, center grate, and center knob.
Page 14
I N S TA L L AT I O N I N S T RU C T I O N S WHEN ALL HOOKUPS ARE COMPLETE Make sure all controls are left in the off position. Make sure the flow of combustion and ventilation air to the cooktop is unobstructed.
