Qilin double pendulum industrial welding system user manual
V 40 control box + BWT 40 welding head
Guangdong Qilin Laser Technology Co., Ltd
Address: Room 901, Building E1, SongshanLake Intelligent Valley,Yanhe North Road No.9, Liaobu
Town,Dongguan City,Guangdong China
Tel.: 0755-27999931
mail:
address:www.qilinlaser.com
Be sure to read the manual before using the system
This manual is the user manual of double
pendulum industrial welding system
Read the manual carefully first to ensure the
correct electrical connection
BWT40

Advertisement

loading
Need help?

Need help?

Do you have a question about the BWT40 and is the answer not in the manual?

Questions and answers

Related Manuals for Qilin Laser Application Technology BWT40

Summary of Contents for Qilin Laser Application Technology BWT40

  • Page 1  Read the manual carefully first to ensure the correct electrical connection BWT40 Qilin double pendulum industrial welding system user manual V 40 control box + BWT 40 welding head Guangdong Qilin Laser Technology Co., Ltd Address: Room 901, Building E1, SongshanLake Intelligent Valley,Yanhe North Road No.9, Liaobu...
  • Page 2 BWH30 Qilin double pendulum light industrial independent welding head Copyright Statement Guangdong Qilin Laser Technology Co., Ltd. (hereinafter referred to as Qilin Laser) reserves all powers. Qilin Laser has the patent copyright and intellectual property rights of this product. Without the authorization and permission of Qilin Laser, it shall not directly or indirectly copy, manufacture, process and use the product and its related parts, otherwise Qilin Laser will be investigated for relevant legal liabilities according to law.
  • Page 3 BWH30 Qilin double pendulum light industrial independent welding head BWH30 Qilin double pendulum light industrial independent welding head Certification statement The CE Certification Statement This product has passed the European Union CE (Communate Europpene) safety, certification, has passed the corresponding conformity assessment procedures and the manufacturer's declaration of conformity, in accordance with the relevant EU directives.
  • Page 4 BWH30 Qilin double pendulum light industrial independent welding head BWH30 Qilin double pendulum light industrial independent welding head security information When using the system, please ensure that the operation is correct and safe. Some signs or words will be used to remind you of dangerous matters and some important information.
  • Page 5 BWT40 Qilin Double pendulum Industrial Welding System user manual Receiving goods, unpacking and inspection The product uses shock-proof soft packaging. If the package has any external damage marks, please check the damage to the equipment and notify the carrier and the carrier of the damage in written documents.
  • Page 6 BWT40 Qilin Double pendulum Industrial Welding System user manual 24V power cord Urgent stop trigger line Welding head connecting wire, DB15 One point three DC line Video line Power extension line Blu-ray adjustable focus for The DC12V power supply Coaxial blowing assembly...
  • Page 7 BWT40 Qilin Double pendulum Industrial Welding System user manual catalogue Chapter 1 summary ........................8 1.1 Qilin double pendulum industrial welding system brief introduction ........... 9 1.2 Product installation size drawing ....................9 1.2.1 Touch-screen installation dimensions ................9 1.2.2 Control box / alarm light, mounting dimensions .............. 10 1.2.3 Installation dimensions of 15 V switching power supply ..........11...
  • Page 8 BWT40 Qilin Double pendulum Industrial Welding System user manual Chapter 1 summary The main contents of this section are as follows: Qilin double pendulum industrial welding system brief introduction Product installation size drawing Page 8 of 36...
  • Page 9 BWT40 Qilin Double pendulum Industrial Welding System user manual 1.1 Qilin double pendulum industrial welding system brief introduction Qilin double pendulum industrial welding system is a control system for fiber laser industrial welding. The double vibration lens motor can control seven swing modes: point, line, ring, oval, triangle, eight characters, semicircle.
  • Page 10 BWT40 Qilin Double pendulum Industrial Welding System user manual 1.2.2 Control box / alarm light, mounting dimensions The installation size of the control box is shown in the following figure The installation size is shown in the following figure The installation size is shown in the following figure...
  • Page 11 BWT40 Qilin Double pendulum Industrial Welding System user manual 1.2.3 Installation dimensions of 15 V switching power supply The installation size of the 15V switching power supply is shown in the following figure Page 11 of 36...
  • Page 12 BWT40 Qilin Double pendulum Industrial Welding System user manual Chapter 2 System wiring The main contents of this section are as follows: Control box wiring Qilin double pendulum industrial welding head structure Power Interface human-computer interface HMI Laser-decoding interface Double pendulum industrial welding head...
  • Page 13 BWT40 Qilin Double pendulum Industrial Welding System user manual 2.1 Wiring of the control box The following figure shows the wiring diagram of the whole system. The system wiring can refer to the schematic diagram and refer to the relevant chapter for detailed interface definition.
  • Page 14 BWT40 Qilin Double pendulum Industrial Welding System user manual 2.2 Double pendulum light industrial welding head structure Page 14 of 36...
  • Page 15 BWT40 Qilin Double pendulum Industrial Welding System user manual Figure 2.2 Schematic diagram of Qilin double pendulum industrial welding head structure parameter scope interface type QBH /RD laser power 4000W Collar focal length Focus focal length 200/250/300 hunting range The 0- -5mm is adjustable...
  • Page 16 BWT40 Qilin Double pendulum Industrial Welding System user manual Table 2.31 shows the definition of the + 15V interface power line Table 2.31 signal definition explain + 15 External power input, Power supply input is external power output positive at 15V...
  • Page 17 BWT40 Qilin Double pendulum Industrial Welding System user manual Table 2.32 signal definition explain + 24V external power supply input, the output power requirements of the power supply: above 200W, that is, power input the output current is greater than 8A (wire supply for...
  • Page 18 BWT40 Qilin Double pendulum Industrial Welding System user manual signal defi expl niti Power supply HMI supply electricity output, 500 mA Power supply output Power reference ground T XD The sender of the Serial port communication with the TXD signal...
  • Page 19 BWT40 Qilin Double pendulum Industrial Welding System user manual Table 2.7 signal defi explain niti Light out on trigger (alarm signal trigger signal green light) Access the robot emergency stop signal, and stop the light when Urgent stop signal pressed...
  • Page 20 BWT40 Qilin Double pendulum Industrial Welding System user manual Figure 2.9 Schematic diagram of the control interface of the wire feeder Table 2.9 signal defi expla nition Power supply output end of wire Wfeeder 24V + power feeder interface Silk feeder and board card...
  • Page 21 BWT40 Qilin Double pendulum Industrial Welding System user manual 2.10 Laser control interface The laser interface is an 8 PIN, green terminal + 4 PIN green terminal Figure 2.10 Diagram of the laser control interface Table 2.10 shows the laser interface definition.
  • Page 22 BWT40 Qilin Double pendulum Industrial Welding System user manual DA 1+ Analog voltage For laser peak power regulation, 0- output + 10V and 0-4V analog voltage selection DA 1- Analog voltage Reference to the power source output- DA 2+ Analog voltage...
  • Page 23 BWT40 Qilin Double pendulum Industrial Welding System user manual Table 2.11 signal defi expl niti CAS 1+ Used to protect the gas blowing Air valve + board control positive electrode card GAS 1 + CAS 1- Used to protect the gas to blow...
  • Page 24 BWT40 Qilin Double pendulum Industrial Welding System user manual 2.13 Robot signal interface Fig. 2.13 Schematic diagram of the robot control signal interface signal definition explain Standby port Use only when the robot communicates with the Standby port Use only when the robot...
  • Page 25 BWT40 Qilin Double pendulum Industrial Welding System user manual Figure 2.14 Schematic diagram of PNP & NPN conversion board 2.15 Alarm lamp interface Fig. 2.15 Schematic diagram of the alarm lamp interface When the RED has voltage, the alarm light is red.
  • Page 26 BWT40 Qilin Double pendulum Industrial Welding System user manual When the alarm is removed, the GREEN has a voltage, and the alarm light is green. Table 2.15 is the definition of the alarm signal light. signal defi explain niti Power supply output end of the...
  • Page 27 BWT40 Qilin Double pendulum Industrial Welding System user manual Figure 2.16, schematic diagram of dial switch Page 27 of 36...
  • Page 28 BWT40 Qilin Double pendulum Industrial Welding System user manual Chapter 3 Human-machine interface: HMI introduction The main contents of this section are as follows: Human-machine interface function and operation introduction Page 28 of 36...
  • Page 29 BWT40 Qilin Double pendulum Industrial Welding System user manual 3.1 Human-machine interface function and operation introduction Introduction of the main interface function and operation The operating panel of Qilin double pendulum industrial welding system adopts 7-inch configuration capacitive touch screen, which is dignified, generous and easy to operate. The relevant parameters of the laser and laser swing head can be set respectively, and the light mode can be controlled.
  • Page 30 BWT40 Qilin Double pendulum Industrial Welding System user manual Alarm signal light: provide real-time monitoring and reminder, monitor and alarm the temperature of laser head, air pressure, welding torch, conduction and handle. The full alarm state is displayed synchronously on the main screen and alarm light to remind users and quickly check problems.
  • Page 31 BWT40 Qilin Double pendulum Industrial Welding System user manual Schematic diagram of editing the main interface Laser control: Power: Set the peak power of the laser at welding. PWM frequency: Set the frequency of the laser PWM modulation signal. Duty cycle: Set the pulse width of the laser PWM modulation signal.
  • Page 32 BWT40 Qilin Double pendulum Industrial Welding System user manual Out-of-light control: Mode: Continuous light out mode and pulsed light mode. Light time: set light time. Light output interval: set, the interval of each light output. Restore the factory Settings: After entering the editing page, restore the single page parameters.
  • Page 33 BWT40 Qilin Double pendulum Industrial Welding System user manual Start lift: Slow rise time: the laser power slowly reaches the peak power after the set slow rise time. Slow descent time: After the laser power is turned off, the laser energy is slowly turned off.
  • Page 34 BWT40 Qilin Double pendulum Industrial Welding System user manual Process Package of Reference Parameters: 1500W laser control Laser head control order Material and power frequency duty cycle pattern frequency width number thickness Stainless Steel 1.0 3000HZ 100% ○ 10hz 1.6mm Stainless Steel 2.0...
  • Page 35 BWT40 Qilin Double pendulum Industrial Welding System user manual Use the laser welding system precautions 1. The light double pendulum industrial welding head contains lasers, water cooler, laser welding system and laser welding head. In order to avoid interference, ensure that the argon arc welding machine and related equipment with large interference, and ensure that the safe distance is kept at more than 5 meters.
  • Page 36 All parts of this description, the property right of the book belongs to Guangdong Qilin Laser Application Technology Co., LTD. Without the permission of the Company, any unit or individual shall not reprint, copy or spread the relevant content of this product description, if the content and information of this product will be changed without notice.
