- Page 1 SEC America Corp. Model 695 CE Rev 9, DC-DC Converter Owner's Manual March 8, 2017...
- Page 2 TABLE OF CONTENTS page Introduction Installation Mounting Connections Methods of Converter Activation III Internal Adjustments Voltage Adjustment Low Voltage Cutout IV Warranty Mounting Dimensions VI Electrical Specifications...
- Page 3 Model 695CE is a high power 12 Volt to 24 Volt DC-DC converter capable of delivering 55A to its load. It has designed for mounting in vehicles of all types and is capable of enduring harsh vibration and...
- Page 4 2) Select the suitable method of converter activation. 2.3 Methods of Converter Activation Connect terminal #1 to terminal #2 on terminal block TBA. The 695CE is so configured when shipped from the factory. This configuration allows for converter activation by turning the source power ON and OFF.
- Page 5 III Internal Adjustments Varying the adjustments of the Model 695CE require the technician to have a stable DC power supply variable from at least 10 VDC to 15 VDC with a minimum 20A current capability. To access adjustments turn the unit upside down and remove the base plate by unscrewing the 4 corner screws.
- Page 6 695CE’s are adjusted at factory to a low voltage cutout (LVC) of 11.0 V. When the vehicle voltage is drawn below 11.0 Volts, the converter shuts off and automatically stops drawing current from its source.
- Page 7 IV Warranty and Repair Should your investigations indicate that your Model 695CE is defective or damaged and your unit is still under warranty, contact SEC America, LLC at 802-865-8388 and obtain return merchandise authorization for exchange or repair. If the defective unit is new a credit may be issued at the discretion of SEC America Corp.
- Page 8 V Base Plate Mechanical Drawing 6.430 3.930 1.250 0.400 0.080 0.580 0.215 dia. Base Plate securing holes 4 places 5.430 17.800 4 places 0.125 radius 0.375 0.250 0.250 Page 6...
- Page 9 VI Electrical Specifications: Output Voltage: 26.4 VDC Nominal Output Voltage Adjust Range 24.5 VDC to 28.0 VDC Continuous Max Load Amps: 55 ADC @ 40C ambient (Input 12.5 VDC) 40 ADC @ 60C ambient Maximum Power Dissipation: 90 Watts @ Full Load (55A, 26.4 VDC out) Maximum Input Current: 125 A (12 VDC in) Overload Protection:...
