- Page 1 SEC America Corp www.secamerica.com USER MANUAL 849HSBP DC-DC Converter July 10, 2023...
-
Page 2: Table Of Contents
TABLE OF CONTENTS page Introduction Installation Mounting Connections Mechanical Drawing Remote Sense Regulation User Adjustments Warranty Electrical Specifications... -
Page 3: I Introduction
849HSBP is an isolated dc-dc converter capable of operating extreme ambient temperatures and adverse conditions. See the specification sheet at the end of this manual for ratings. It has inrush... -
Page 4: Mechanical Drawing
Converter The 849HSBP provides regulated outputs at the output terminals. When there is a large current and/or the output cable is of excessive length (longer than 6 feet), the voltage at the end of the cable may be noticeably lower than at the terminals. -
Page 5: User Adjustments
IV User Adjustments 849HSBP is gasket-sealed. Changes or adjustments to the operating modes are accomplished internally: 1) To gain access, (Disconnect power from the unit before opening) remove the 5 outer black hexagonal head screws retaining the connector plate as shown in Figure #4. Then remove the 4 screws surrounding the connector. -
Page 6: Warranty
SEC America Corp. 802-865-8388 to receive an authorization for return for an assessment and possible repair. Warranty 849HSBP Series models come with a 2-year factory warranty covering parts and labor per the following: LIMITED WARRANTY We warrant each instrument, sold by us, or our authorized agents, to be... -
Page 7: Electrical Specifications
SEC America Corp. 48 to 24 VDC Isolated Converter Model 849HSBP Step-Down Sealed DC-DC Converter Design Features - Wide Range Input Voltage - High Efficiency Isolated Design - 92% - Hi Ingress Rating, IP 67 - Adjustable Output Voltage - Optional Remote Output Voltage Sensing... - Page 8 SEC America Corp P.O. Box 2266 78 Ethan Allen Drive South Burlington 05403 Fax: 802-865-8389 www.secamerica.com Tel: 802-865-8388 cage code 07KU1 Copyright – July 2023 All rights reserved Printed in U.S.A.
