- Page 1 SEC America Corp www.secamerica.com USER MANUAL 600HS Series DC-DC Converters Applies to Models: 618HS 638HS 628HS 652HS July 10, 2019...
-
Page 2: Table Of Contents
TABLE OF CONTENTS page Introduction Installation Mounting Connections Mechanical Drawing Remote Sense Regulation User Adjustments Warranty Electrical Specifications... -
Page 3: I Introduction
600HS Series models are fully isolated dc-dc converters capable of delivering up to 450 Watts in extreme ambient temperatures and adverse operating conditions. See specification sheets at the end of this manual for the ratings of a particular model. -
Page 4: Mechanical Drawing
Figure 2 All dimensions are in inches III Regulation With Remote Sense DC-DC Load Figure 3 twisted pair Converter The HS Series provides regulated outputs at the output terminals. When there is a large current and/or the output cable is of some length, the voltage at the end of the cable may be noticeably lower than at the terminals. -
Page 5: User Adjustments
IV User Adjustments Series 600HS units are gasket-sealed. Changes or adjustments to the operating modes of any unit are accomplished internally: 1) To gain access, (Disconnect power from the unit before opening) remove the 5 outer black hexagonal head screws retaining the connector plate as shown in Figure #4. Then remove the 4 screws surrounding the connector. -
Page 6: Warranty
SEC America Corp. 802-865-8388 to receive an authorization for return for an assessment and possible repair. Warranty 600HS Series models come with a 2-year factory warranty covering parts and labor per the following: LIMITED WARRANTY We warrant each instrument, sold by us, or our authorized agents, to be... -
Page 7: Electrical Specifications
Page 5... - Page 8 Page 6...
- Page 9 Page 7...
- Page 10 Page 8...
- Page 12 SEC America Corp P.O. Box 2266 78 Ethan Allen Drive South Burlington 05403 Fax: 802-865-8389 www.secamerica.com Tel: 802-865-8388 cage code 07KU1 Copyright – July 2019 All rights reserved Printed in U.S.A.
