Summary of Contents for LENCO L-30
- Page 1 Model : L-30/L-101 USER MANUAL Wooden turntable with MMC cartridge and PC encoding...
- Page 2 English CAUTION: Usage of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. PRECAUTIONS BEFORE USE KEEP THESE INSTRUCTIONS IN MIND: Do not cover or block any ventilation openings. When placing the device on a shelf, leave 5 cm (2”) free space around the whole device.
- Page 3 22. Never place this device on other electrical equipment. 23. Do not allow children access to plastic bags. 24. Only use attachments/accessories specified by the manufacturer. 25. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as the power supply cord or the plug, when liquid has been spilled or objects have fallen into the device, when the device has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 4 TURNTABLE PARTS:...
- Page 5 1. Phono Stylus Cartridge 2. Turntable Platter 3. Lift Lever 4. Turntable Arm Lock 5. Auto Stop Control Switch 6. Speed Selection Switch 7. Turntable Shaft 8. Turntable Arm 9. RCA Output Jack 10. USB Jack 11. Power Adaptor Jack 12.
- Page 6 * Please ensure you have installed the software before starting. Setting up your PC to work with Audacity 1. Connect an input source to the unit. 2. Connect the USB lead to your computer. 3. Install the Audacity recording software. 4.
- Page 7 Recording Albums with Audacity 1. Saving a project Audacity writes all the changed and recorded audio to a directory called Projectname_data, which is located right where you saved the project file itself. Thus, select Save Project as from your Audacity File tab and choose a location and filename for your project.
- Page 8 100-240V Output voltage 3.0-24.0V Output current 0.01-2.4A Output Power Average active efficiency 84.1% Efficiency at low load (10%) 79.27% No load Power consumption 0.08W Lenco Turntable L-30 / L-101 Type Belt drive auto-stop Drive Motor DC motor Speed 33 1/3rpm,45rpm...
- Page 9 ﹤0.35% Wow and flutter Turntable platter 300mm Cartridge Type Audio Technica AT-3600L Stylus 0.6mil Optimum tracking force 2.5-3.5gr Output 2.4mv±3db Frequency response -1.5±6db(10KHz) Crosstalk 16db(1KHz) Signal-to-noise ratio(S/N) 40db General input AC100-240V～50/60Hz0.5A ADAPTOR output DC12V1000mA PRODUCT DC12V200mA Audio output(Line Out) 400-600mv Power consumption 2.4W Dimension...
- Page 10 Hereby, Commaxx B.V. Wiebachstraat 37, 6466 NG Kerkrade, The Netherlands, declares that this product is in compliance with the essential EU directive requirements. The declaration of conformity may be consulted via techdoc@commaxxgroup.com Service For more information and helpdesk support, please visit www.lenco.com Commaxx B.V. Wiebachstraat 37, 6466 NG Kerkrade, The Netherlands.
