Important Safety
Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of sufficient magnitude
to constitute a risk of electric to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OF MOISTURE.
CAUTION: Laser radiation when open. Do not stare into beam.
CAUTION: USE OF ANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
POWER SUPPLY:
Connect the supplied adapter to the side of the DVD player in the slot marked "Power In".
Plug the two-prong end of the power cord to an AC100-240V outlet. If you have difficulty
inserting the plug, turn it over and reinsert it, if the unit will not the used for a long time,
disconnect the plug from the outlet.
NOTE:
Before plugging the power cord into an AC outlet, make sure that all the connections
have been made.
1
Advertisement
Table of Contents
Related Manuals for LENCO DVP-854
Summary of Contents for LENCO DVP-854
-
Page 1: Important Safety Instructions
Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... - Page 2 Important Safety Instructions CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer to service manual for servicing instructions.
- Page 3 Important Safety Instructions Copyright Protection This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.
-
Page 4: Features
Features This product is designed portability and handily, with a stylish appearance. It incorporates DVD player and DVB-T function in one system. It is conveniently for using and taking. High-quality audio and video Excellent sound: Dolby Digital delivers AV In: External Audio, Video input can be great sound. -
Page 5: Accessories
Accessories Accessories List ITEM NAME Remote Control Unit Cell for Remote Control Owner’s Manual Power-supply Cord with AC adapter Audio/Video Cable DC Adapter (Car Adapter) Rechargeable Battery DVB Antenna NOTE Accessories and their parts numbers are subject to modification without prior notice due to improvements. -
Page 6: Table Of Contents
Contents …………………………………………..1 Important Safety Instructions …………………………………………...4 Features …………………………………………...5 Accessories …………………………………………...7 View of Main Unit ………………………………….………..9 View of Main Unit Bottom ………………………………………….10 Using of USB and SD Card …………………………………………..11 Remote Control …………………………………………..13 Preparation and Using of RC. …………………………………………..14 System Connections …………………………………………..17 Power Supply Preparation …………………………………………..18 Rechargeable Battery... -
Page 7: View Of Main Unit
View of Main Unit Front,left and right View POWER button Press to turn unit on or off. MENU button In DVD-mode: Press to display the disc title menu if the titles are coded in the disc. In DVB-T mode: Press to display the channel guide. PLAY/PAUSE button Press to start playback or pause the playback. - Page 8 View of Main Unit / /CH- Button : Press to select different items in menu’s. : Press to return to the previous list/track/chapter in DVD mode. CH-: Press to search the channel backward in DVB mode. OK button Press to confirm your selection. Remote sensor Receive the signal from the remote control for operation.
-
Page 9: View Of Main Unit Bottom
Press to open disc tray. View of Main Unit Bottom View of the bottom 1. Bracket 2. Rechargeable Battery Pack. -
Page 10: Using Of Usb And Sd Card
Using of USB and SD Card Connect the unit with the power supply. Press the “POWER” button to turn on the power. Push DVB / DVD / USB/SD button to enter USB or SD playback statement. Insert the USB device into the unit’s USB slot on the left side of the unit, or insert the SD card into the SD card slot (located on top of the unit). -
Page 11: Remote Control
Remote Control PWR button Press to turn unit on or off. INFO button Press for detailed information in the DVD or DVB mode. TITLE button Press to display title menu if the titles are coded in the disc. Direction button/CH+/-button Press to select menu items or search the channel forward or backward in the DVB mode. - Page 12 Select numbers by pressing these buttons. button Press to go to the next track or chapter in the DVD mode. Remote Control button/FAV-PR button Press to go to the beginning of current track or chapter. Press twice to go to the previous track or chapter in DVD mode.
-
Page 13: Preparation And Using Of Rc
Press to access various audio languages, when the DVD disc contains multiple audio languages.Or press to realize the switching among MONO L,MONO R, STEREO in the DVB mode. Preparation and Using of Remote Control Battery Installation Step With the remote control unit placed on a flat surface and follow the steps below to install the battery. -
Page 14: System Connections
Immediately replace used up battery. System Connections Always ensure that the DVD player, TV and any other electrical equipment that connecting with DVD player is switched off and unplugged from the power supply. Ensure that you observe the color coding when connecting audio and video cables. Connecting to TV Audio/Video connections Please follow the drawings below to connect the DVD player to TV's Audio/Video inputs... -
Page 15: Audio/Video Cable
System Connections Connecting to External AV Source The unit supports AV signal input function. Please use the audio/video cable to connect the unit to the external AV signal source such as a DVD, VCR etc. after connecting, switch the AV IN/OUT to AV IN. Note: noise may occur in speakers when input an external audio signal while playing a DVD disc. - Page 16 connect the headphones, and then raise the volume to a comfortable level. Sound from the DVD Player’s external speaker will stop when headphones are connected. System Connections Connecting to DVB-T Antenna The unit is designed with an antenna input jack. Plug the DVB-T antenna into the jack on the left panel of the unit to receive TV signal.
-
Page 17: Power Supply Preparation
Power Supply Preparation Using of AC Adapter The player is supplied with an adapter. Take the following steps to use the adapter. Connect AC adapter to the right side Of the DVD player in the slot marked DC 9.5V IN (as the right figure). Plug the two-prong end of the power cord to a grounded electrical socket, then the power indicator lights red. -
Page 18: Rechargeable Battery
accessory. Please see details in battery pack operation part of user's manual. Rechargeable Battery About Rechargeable Battery Pack Your portable DVD player comes with a lithium ion rechargeable battery that attaches to the rear of the DVD player. Charge the battery fully before initial use. Charging time is normally about 5 hours. - Page 19 Rechargeable Battery Dettaching the Battery Pack Dettach the Battery Pack as the picture below: Charging the Battery Pack Attach the battery pack to the DVD player Plug the supplied AC Power Adapter into the player’s power jack marked with ”DC 9.5V IN”, which is located on right side of the DVD Player. Plug the other end of the AC Power Adapter Cord into a household AC Outlet as shown below.
-
Page 20: Sketch Map Of Bracket
Sketch Map of Bracket Sketch Map of Bracket You can adjust the angle of viewing through opening the bracket. 1. Push the button to unlocking position as arrow 1. 2. Opening the bracket as arrow 2. -
Page 21: Dvb Setup
DVB Setup The Operation of DVB Setup Preparation: Connect the unit to the power. Press the DVD/USB/SD/DVB switching button on the panel or remote control enter the DVB mode. Press the Setup button on the panel or remote control enter the DVB setup mode. You can take below steps to go on with the setup. - Page 22 DVB Setup In this menu, press / direction buttons to select BACK/YES/NO item, select BACK return to the previous setup, select Yes enter the next setup select NO exit the setup menu Channel Guide Press the direction buttons to select Channel Guide. Press the OK button to enter the item, screen will display as below: menu, press...
- Page 23 DVB Setup TV Setting Press the button to select TV Setting, press the OK button to enter, the screen will display as below: There are two items for setting: TV system, TV Type. Press the button to select item, press the OK button to enter, press the Setup button to return.
- Page 24 DVB Setup OSD Language: press the OK button to enter the OSD Language Setting menu, press the button to select English, German, Spanish, French and Italian. Parent Control Press the button to select Parent Control, press the OK button to enter, the screen will display as below: Change pin: Press the...
- Page 25 DVB Setup System Info Press the button to select System Info, press the OK button to enter, the screen will display as below: Installation Press the direction buttons to select Installation. Press the OK button to enter the item, screen will display as below: There are three items for setting: Auto Scan, Manual Scan, Default Setup.
- Page 26 DVB Setup Select Country: Press the button to select the Select Country, press the button to enter the Select Country Setting menu, press the button to select Germany, England, Italy, France etc. Start Scan: Press the button to select the Start Scan, press the OK button to enter. Manual Scan Press the button to select Auto Scan, press the OK button to enter, the screen will...
- Page 27 DVB Setup Default Setup: Press the button to select Default Setup, press the OK button to enter, the screen will display as below: In this menu, press button to select OK/Cancel item, select OK to reset to Default. Select Cancel to return to the previous menu.
-
Page 28: Notes On Discs
Notes on Discs Compatible Disc Formats PLAYBACK TIME/ DISC LOGO DIAMETER PLAYABLE SIDES 1 3 3 m i n ( S S - S L ) 2 4 2 m i n ( S S - D L ) 12cm 2 6 6 m i n ( D S - S L ) 4 8 4 m i n ( D S - D L ) 41 min (SS-SL) -
Page 29: Playback Operation
Playback Operation PLEASE READ THE FOLLOWING INSTRUCTIONS CAREFULLY BEFORE USING YOUR DVD PLAYER FOR THE FIRST TIME. WARNING: Do not play poor-quality discs to avoid damaging the lens. Pre-operation Connect the unit to power supply through the provided AC adaptor. Press the “POWER ”... -
Page 30: Dvd Playback
Playback Operation Use of Some General Buttons (continued) ZOOM For DVD disc, press the ZOOM button to display the image as ZOOM 2-3-4-1/2-1/3-1/4-normal size button in sequence. This function is not available for CD disc During normal playback, press the A-B button to select the segment that you want to play button repeatedly. - Page 31 Playback Operation DVD Playback (continued) Press the MENU button during playback. The root menu will appear on the screen. Press the direction buttons ( ) to select the item MENU button you wish to play, and press the ENTER/OK button to confirm.
- Page 32 Playback Operation DVD Playback (continued) During DVD playback, press the SUBT button to select a subtitle language or to turn subtitle off. A DVD disc can be recorded with at most 32 subtitles. Press the SUBT button repeatedly, the mode of subtitles will recycle as follows: SUBT button SUBTITLE 1/N: Subtitle 1 appears on the screen.
- Page 33 Playback Operation DVD Playback (continued) Press the SLOW button to start slow playback as following: 1/2、1/3、1/4、1/5、1/6、1/7. Press SLOW button button on the front panel to resume normal playback. Press the ANGLE button to access multi-angles on a disc. Multi-angle means that a scene is shot from different angle so that the audience can watch from any angle, like the drawings below: ANGLE...
-
Page 34: Cd Playback
Playback Operation CD Playback Buttons Operation During playback, press the STOP button once to stop playback, then press button to resume normal STOP button playback from the place where it was stopped.Press it twice repeatedly to stop playback completely. Press the button to start fast forward playback. - Page 35 Playback Operation CD Playback (continued) Press to display or cancel the detailed information of INFO button the disc during playback. Press the AUDIO button to select desired sound effect. Press it repeatedly, the display is as follows: AUDIO button CHANNEL: [MONO L MONO R STEREO] Keep pressing for about 2 seconds to remove display...
-
Page 36: Mp3 Playback
Playback Operation MP3 Playback Buttons Operation During playback, press the STOP button once to stop playback, then press button to resume normal STOP button playback from the place where it was stopped. Press it twice repeatedly to stop playback completely. Press the button to start fast forward playback. - Page 37 Playback Operation MP3 Playback (continued) Press to display or cancel the detailed information of INFO button the disc during playback. Press the REP button to repeat a file, folder in sequence. Press it repeatedly until it displays as follows: REP button REP: [ REP 1 REP DIR REP All...
-
Page 38: Picture Cd Playback
Playback Operation Picture CD Playback Pre-operation Load a Picture CD in the disc tray, the player will search and play disc automatically. The screen displays the Root Folder with several subdirectories/subfolders. Use the , buttons on the remote control to select desired folder. Then you can press any of the buttons below to confirm your selection: ENTER button on the remote control or , OK button on the front panel. - Page 39 Playback Operation Picture CD Playback (continued) Press the REP button to repeat a file, folder in sequence. Press it repeatedly until it displays as follows: REP button REP: [ REP 1 REP DIR REP All OFF ] Press the INFO button for detailed information on the disc playing.
- Page 40 Playback Operation Picture CD Playback (continued) Picture Rotate During browsing a picture, you can press direction buttons , , , to rotate the current picture. Press the button to rotate the current picture clockwise, as following drawings: Press the button to rotate the current picture anti-clockwise, as following drawings: Press the button to rotate the current picture flip horizontal, as following drawings: Press the...
-
Page 41: Divx Playback
Some picture CD discs are restricted by their designing method, and so have no Note: rotating, zooming etc. function. Playback Operation DIVX Playback Pre-operation Load a DIVX disc in the disc tray. The screen displays the Root Folder. Use the , buttons on the remote control to select desired folder. - Page 42 Playback Operation DIVX Playback Continued During playback, press the STOP button to return to STOP root folder. Press button (on the remote control or front panel) to resume normal playback. Press the REP button to repeat a file, folder in sequence.
- Page 43 Playback Operation DIVX Playback Continued Press the GOTO button to select desired disc starting track or track starting time. During DIVX playback, press it repeatedly until it displays as follows: GOTO button Select:--/-- Go To --:--:-- Press to display or cancel the detailed information of INFO button the disc during playback.
-
Page 44: System Setup
System Setup You can change the default settings of this unit to customize its performance to your own preference. Read this section to learn how to set up the system. Note: the system should better be set up in the state that no disc is in the DVD drive or the unit is on the stop mode. - Page 45 System Setup General Setup Page 2.OSD Language This item is used to set the OSD (on-screen display) language. Press the button to highlight this item. Press the ENTER or to enter the setup of this item. It includes English, French etc. Press the button to choose the proper one.
- Page 46 System Setup General Setup Page 6. Memory This item is used to set last memory state. Note: The last memory refers to resume playback from the point that you stopped last time. Press the button to highlight this item. Press the ENTER or to enter the item.
- Page 47 System Setup Digital Setup Page 1. Dual Mono This item is used to set the channel output mode. Press the button to highlight this item. Press the ENTER or to enter the item. It includes stereo, L-Mono, R-Mono and Mix-Mono, Stereo by default.
- Page 48 System Setup System Setup Page 2. Audio Lang This item is used to set the audio output language. Press button to highlight this item. Press the ENTER or button to enter the item. The available languages are English, French, Spanish etc. Press the button to choose the preferred Language.
- Page 49 System Setup System Setup Page 5. DIVX (R) VOD This item is used to download the DIVX format video through using the registration code.Please visit the website: WWW.DIVX.COM/VOD to get the corresponding information. 6. Password Rating is protected by password. This item is used to change the password of the parental control.
-
Page 50: Definitions
Definitions Letterbox screen This refers to a screen on which the playback picture of wide-screen DVDs appears with black bands running along the top and bottom. Pan & Scan screen This refers to a screen on which the playback picture of wide-screen DVDs is cut off at the left and right sides. -
Page 51: Troubleshooting
Troubleshooting Take steps described in the tables below to solve simple problems before contacting after-sales service. If you suspect something wrong, immediately turn the power off. Disconnect the power connector and check that there is neither smoke nor heat from the unit before asking for repairs. - Page 52 Troubleshooting PROBLEM POSSIBLE SOLUTION POSSIBLE CAUSE The LCD may be off or not Turn on the LCD and choose be in correct video mode. the correct video mode. The system connection may Connect system There is no picture. be incorrect. correctly.
-
Page 53: Specifications
Specifications 8.5 inches TFT screen size 780/650 nm Laser Wavelength Video System 20Hz～20kHz ±2.5dB Frequency Response ≥85dB Audio Signal-to-noise Rate ≤－70dB (1kHz) Audio distortion+noise ≥70dB (1kHz) Channel Separation ≥80dB (1kHz) Dynamic Range Out Level: 1.5V± , Load: Analog Audio Out 10KΩ...
