SNR VP-80 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
VP-80

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-80 and is the answer not in the manual?

Questions and answers

Related Manuals for SNR VP-80

Summary of Contents for SNR VP-80

  • Page 1 User Manual VP-80...

  • Page 2: Table Of Contents

    Content 1 Welcome................... 6 2 Product Overview................8 2.1 Instruction......................8 2.2 Technical Specification..................9 2.3 Equipment Appearance And Interface Description........10 2.3.1 Interface Description................11 2.3.2 Keypad Description................11 2.4 Indicators......................12 3 Installation..................13 3.1 Equipment Packaging..................13 3.2 Connecting Video Phone................13 3.3 Installation Considerations................14 4 Getting Started................15 4.1 Basic Operation....................
  • Page 3 4.7 Call Settings....................35 4.7.1 Do Not Disturb..................35 4.7.2 Call Waiting..................36 4.7.3 Always forwarding&Forwarding Number..........36 4.7.4 Call forwarding busy&Forwarding Number.........37 4.7.5 No Answer Forwarding&Forwarding Number........37 4.7.6 Time out....................38 4.7.7 Playtone....................38 4.7.8 Intercom....................38 4.8 Dial Plan......................39 4.9 Auto Provision....................40 4.10 Personalize....................41 4.10.1 Log Level....................
  • Page 4 5.15.1 View Photo & Picture & Video............79 5.16 Bluetooth......................79 5.16.1 Turning Bluetooth On /Off..............80 5.16.2 Changing Bluetooth Device Name............ 80 5.16.3 Paring VP-80 With A Bluetooth Device..........80 5.16.4 Un-pairing A Bluetooth Device............81 5.17 USB....................... 81 5.18 Calendar....................... 82 5.18.1 Add An Account.................82...
  • Page 5 6.1.1 Select Other Upgrade Package............99 6.1.2 Local Update..................99 6.1.3 Remote Update................. 100 6.2 Auto Update Period..................102 6.3 Upgrade on the web..................102 6.4 Check Update After System Power On............103 7 System Maintenance..............104 7.1 System State Inspection................104 7.2 IP Query......................104 7.3 SIP Account Registration Query..............105 7.4 Backup &...

  • Page 6: Welcome

    1 Welcome Thank you for purchasing SNR VP-80 Multimedia VoIP Phone. The SNR VP-80 is an innovative smart desk phone loaded with tremendous value for business communications as well as unprecedented power for advanced custom business applications development and personalization. Featuring Android 4.2 system, a 7...
  • Page 7 minimum distance 20cm between the radiator& your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 8: Product Overview

    2 Product Overview 2.1 Instruction SNR VP-80 is an Android-based multimedia terminal with a 7 inch touch screen and a 2M CMOS sensor camera. It supports H.264/H.263 codec with adaptive bandwidth adjustment. The 7 inch touch screen offers excellent user experiences such as high quality videophone, smooth internet surfing, various Android Apps and daily information.

  • Page 9: Technical Specification

    2.2 Technical Specification Model SNR VP-80  7 inch capacitive touch screen TFT LCD, 1024x600 pixels, 16:9 wide Graphic Display screen aspect ratio Camera  2 mega pixels CMOS camera, free rotation Network Protocol  SIP RFC3261,TCP/UDP/IP,PPPOE,RTP/RTCP Operation System  Android 4.2 ...

  • Page 10: Equipment Appearance And Interface Description

    2.3 Equipment Appearance And Interface Description Figure 1-1 SNR VP-80 Front View Figure 1-2 SNR VP-80 Rear View...

  • Page 11: Interface Description

    Figure 1-3 SNR VP-80 Profile View 2.3.1 Interface Description Interface Description Camera Adjustable camera shooting angle, rotate down the camera to "off" angle. USB interface External USB storage device Headset Connect to 3.5mm stereo headphone, headset device HDMI Use HDMI cable to output the video to a TV screen Network interface can be connected to a hub, switch or other network Power over Ethernet) .

  • Page 12: Indicators

    Volume Press + or – for the phone volume adjustment Standard Keypad Input the number or symbol Delete Delete a character before the cursor Same function with soft keyboard "Enter" key Message Optional Contact Enter Into the contacts list, you can view the local contact Conference The first party is held in the case, according to a conference Function Key...

  • Page 13: Installation

    3 Installation 3.1 Equipment Packaging Name Quantity Main Case Handset Phone Cord Power Adapter Ethernet Cable Quick Start Guide 3.2 Connecting Video Phone  Connection diagram...

  • Page 14: Installation Considerations

     Connecting to Network Use the matched network cable to connect the LAN Port of the video phone to the Router or Switch. Viewing the top right corner of the screen, if the indicator light is on, network cable is connected properly. ...

  • Page 15: Getting Started

     Do Not Disturb plug-in, When enabled DND, prohibit incoming calls in; Incoming call will be normal when DND is closed.  Accounts, SNR VP-80 supports 6 lines. Accounts list will show the status of the current account.  Extended Screen Prompt, Display the location of current screen page; and show how many pages extended.

  • Page 16: Status And Notifications Instruction

    4.1.2 Status And Notifications Instruction The status bar in main screen is divided into two zones, notification area and status area, as shown below: Status Area Icon Description Network is connected Network is not connected Mute mode Alarm clock is set PPPOE is connected PPPOE is failed Notification Area...

  • Page 17: Using The Touchscreen

    4.1.3 Using The Touchscreen  Tap To select items on the screen (e.g., setting options, apps); to press onscreen buttons; to type letters and symbols using the onscreen keyboard.  Touch and Hold Touch the item on the screen and hold it without lifting your finger from the screen till an action occurs.

  • Page 18: View / Turn Off Notifications

    "Back" on the hard keyboard. Click on the icon to clear up the notice 4.2 Connecting To Network And Wi-Fi SNR VP-80 supports a variety of network connections (Ethernet, Wireless) and device Network connections includes four modes, Static IP, DHCP, PPPOE, Wi-Fi access.

  • Page 19: Configuring Static Ip

    DHCP is the default configuration. Device connections include EHS headset, USB and Bluetooth device. 4.2.1 Configuring Static IP You can select one of the following methods to enter the static IP configuration:  Mode 1: In the main screen, press "Menu" key on the hard keyboard-> System Settings->...

  • Page 20: Configuring Dhcp

    Subnet Mask set the subnet mask of the device Default Gateway set the default gateway DNS Server set the DNS address Alternative DNS Server set the backup DNS address 4.2.2 Configuring DHCP You can select one of the following methods to enter the DHCP configuration: ...

  • Page 21: Configuring Pppoe

    Note: 1) If DHCP acquired IP, it will display dynamic IP address information on the location of static IP configuration, cannot be modified, and there is a item of Use static DNS at the bottom the alternative DNS server, when checked, you can modify the primary DNS address and Secondary DNS address.
  • Page 22 Configuration page is shown as below： Parameter specification： Parameter Specification Use PPPOE Check is to enable PPPOE，otherwise, disable. User Name PPPOE account, provided by ISP Password PPPOE password, provided by ISP Proceed as follows: 1) Check Use PPPOE 2) Enter the correct user name and password of PPPOE Note: 1) After dialing, can display the acquired IP address, server IP, the primary DNS, Secondary DNS information, status as connected...

  • Page 23: Configuring Wi-Fi

    4.2.4 Configuring Wi-Fi You can select one of the following methods to enter the Wi-Fi configuration:  Mode 1: In the main screen, press "Menu" key on the hard keyboard-> System Settings-> Wireless & Networks-> Ethernet- >Wi-Fi.  Mode 2: In the main screen, tap ->...
  • Page 24 the connection will not be successful, as shown below: 4）check Show advanced options, you can set Proxy server and IP mode.  Proxy Settings  IP settings(Static IP):...
  • Page 25 5）Long press on the connected Wi-Fi AP, it will pop-up a dialog box, you can forget the network or modify the network. Long press on the non-connected Wi-Fi AP, it will pop up a dialog box, and you can click and connect to network. 6）Click WPS(Wi-Fi Protected Setup) button, if the wireless router has WPS function, and the router WPS button is pressed, the video phone will be able to connect to the Wi-Fi without entering a password.

  • Page 26: Sip Account Configuration

    a. Check Network notification, it will notify you when an open network is available; b. Check Avoid poor connections, it will prompt that don’t use a WiFi network unless it has a good internet connection; View the Wi-Fi Mac address and IP address; 4.3 SIP Account Configuration You can select one of the following methods to enter the SIP account configuration: ...

  • Page 27: Add Account

    4.3.1 Add Account Click an account to enter Account Editor...
  • Page 28 Configuration parameters are described as follows: Parameter Specification Register Name SIP Account ID provided by ISP User Name SIP User Name provided by ISP Password SIP Password provided by ISP Display Name SIP Display name SIP Register Server, format: domain/IP, for example: Reg Server IP 194.168.1.2 Reg Server Port...

  • Page 29: Sip Account On/Off

    4.3.2 SIP Account ON/OFF After SIP account is configured and registered successfully, it will display the prompt ”Registered” in the Account Manager, and the icon will be displayed on the status bar. If you want to disable the account, please click If the sip account is failed to register, the failure code will be displayed under the account, and then you can check with the account configuration or network connection.

  • Page 30: Sound

    4.4 Sound You can select one of the following methods to enter the Sound configuration:  Mode 1: In the main screen, press "Menu" key on the hard keyboard-> System Settings-> Sound.  Mode 2: In the main screen, click ->...

  • Page 31: Silent Mode

    Including Volume, Ringtone and Notification, Dial pad touch tones and Touch sound. 4.4.1 Silent Mode Long press the Power button, then choose Silent mode in the pop-up menu. In addition to the media and the alarm sound, the rest sound is mute. As shown in the picture below:...

  • Page 32: Volumes

    4.4.2 Volumes In Sound configuration page, click “Volumes”, the volume configure is shown as below：  Volume options include ringtones and notifications, Media, Alarm clock.  You can hold and drag the slide button or just directly click a volume location to adjust the volume.

  • Page 33: System Sound

    4.4.4 System Sound If you want to enable Dial pad touch tones and Touch sounds, please go to Sound configuration page to click the correspond sound. Dial pad touch tones and Touch sounds are enabled in default configuration. 4.5 Audio Settings To setup the corresponding audio parameters and Volume.

  • Page 34: Video Settings

    4.6 Video Settings To configure the video corresponding parameters.

  • Page 35: Call Settings

    4.7 Call Settings 4.7.1 Do Not Disturb DND function is to prevent foreign phone from disturbing, if open DND, external...

  • Page 36: Call Waiting

    phone call is unable to call in, turned off by default. Configuration on the phone: 1.Phone Settings-> Call Settings-> DND 2.Select the desired account. 3.Enable Do not Disturb. 4.7.2 Call Waiting Open call waiting, if enable call waiting, after establishment of a conversation, there is a third party call in, then video phone will have a new call tips, you can choose to answer or reject the call.

  • Page 37: Call Forwarding Busy&Forwarding Number

    4.7.4 Call forwarding busy&Forwarding Number The incoming calls will be forwarded to specified number when the phone is busy. Configuration on the phone: 1. Phone Settings->Call Settings->Call Forwarding->Call Forwarding Busy 2. Select the desired account. 3. Enable Call Forwarding Busy. 4.

  • Page 38: Time Out

    It is used to answer the incoming call automatically after users set up the intercom function. In default situation, the IP phone SNR VP-80 will answer the intercom incoming calling automatically and make a noise. You can set the phone to enable...

  • Page 39: Dial Plan

    4.7.9 Hoteling The Hot line refers to the number you often dial. You can set hot lines in the phone, the phone will dial the hot line number automatically when you pick up the handset, press the hand-free or the account key. Also you can set the timeout of dialing the hot line number, then the phone will dial the hot line number automatically after the timeout.

  • Page 40: Auto Provision

    4.9 Auto Provision SNR VP-80 IP Phone can be configured to resynchronize its internal configuration state to match a remote profile periodically and on power up by contacting a normal provisioning server (NPS) or an access control server (ACS). In this document, we assume that the administrator knows how to set up the NPS and ACS (DHCP, PNP, TFTP, FTP, HTTP, and HTTPS servers).

  • Page 41: Personalize

    4.10 Personalize 4.10.1 Log Level The Log level is divided into seven levels: EMERG, ALERT, CRIT, ERR, WARNING, NOTICE, INFO, DEBUG, log class is from low to high. The default setting is EMERG, which is the lowest grade log. 4.10.2 Hook Mode Hook Mode is divided into Phone Mode, Disable, App Mode, Auto Mode.

  • Page 42: Reboot Manager

    When there is incoming call, the phone can be answered by handset. 4.11 Reboot Manager 4.11.1 Reboot time User can setup the reboot date and hour you want . 4.11.2 Status of time If the status is enable ,users can edit the reboot time you want. 4.11.3 Status of active Enable/disable the reboot function 4.11.4 Reboot settings...

  • Page 43: Date & Time

    4.12 Date & Time You can select one of the following methods to enter Date & Time configuration:  Mode 1: In the main screen, press "Menu" key on the hard keyboard-> System Settings-> Date & time.  Mode 2: In the main screen, tap ->...
  • Page 44 You can increase or decrease the corresponding value by dragging upper or lower, also can directly input corresponding value in input flied, and then click the "Done" button. Click "Set time, time settings, as shown below: In the figure, uncheck Use 24-hour format, you can increase or decrease the corresponding time value by dragging upper and lower.

  • Page 45: Personalization Settings

    4.13 Personalization Settings According to personalized settings, you can make the equipment more characteristic. 4.13.1 Wallpaper You can use the following three ways to change your favorite wallpaper. Mode 1: 1) You can choose one of the following steps to enter into the choice of wallpaper source: ...

  • Page 46: Widgets

    picture you want to set as wallpaper, then press and hold the clip frame picture, drag the clip box, crop the picture finally click "OK". When clipping, if you want to change clip size of the box, press clipping frame, the border follows the direction of the arrow to be shown in the figure, you can drag it to the border or outside the borders, to change the size of the crop box.
  • Page 47 4.13.2.1 Add A Widget 1) In the main screen, Click , left-slide the screen, choose and add a widget. The following window: 2) Each widget has indicated the name and the location, press and hold the component, put it to the designated location on the desktop. 4.13.2.2 Modify An Added Widget If you want to modify the location of added widgets on the desktop, hold the widget...

  • Page 48: Shortcuts

    At this time, you can control the blue point to drag the border to change the size of the widget frame. And then only need to press “Back” button on the keyboard to save the change. 4.13.2.3 Delete A Widget Hold the widget until the icon appears on the upper left corner of the screen, you can drag the widget to...

  • Page 49: Modify Extended Bar

    4.13.3.2 Modify A Shortcut If you want to modify the location of shortcut on the desktop, hold the shortcut until the icon appears on the upper left corner of the screen, you can drag the shortcut to the corresponding position of the desktop. 4.13.3.3 Delete A Shortcut Hold the shortcut until the icon...

  • Page 50: Backup & Reset

    the below steps: 1) Click -> Music(App). 2) See the music list in App, select and press a music, and then In the pop-up menu options, select "Ringtone" -> "Phone" 4.14 Backup & Reset 1) Click Setting 2) Click “Backup & reset”; 3) Click “Factory data reset”;...

  • Page 51: Function

    5 Function 5.1 Call Function SNR VP-80 supports audio calls and video calls. Please ensure that the device has registered SIP account successfully before using the call function. SIP account configuration refers to chapter 4.3 5.1.1 Make A Call You can directly dial from the keypad, from the contact or from call records.
  • Page 52 1) By pressing the number keys on the dial interface or directly pressing the number on keypad. To delete a number, press the on the dial interface, or press Delete button on the keypad. 2) If you want to make an audio call, please click "Audio Call"; if you want to make a video call, please click "Video Call".

  • Page 53: Dial Out From Contact

    5.1.2 Dial Out From Contact You can choose one of the following steps to enter into the contacts:  In dialing interface, Click the icon Contact is shown as below： Contact supports rapid locating the contact through first letter. 1) Click the contact in Contacts, and you can view the details on the right side. As shown in below picture：...

  • Page 54: Receive A Call

    For example, to find Inn, only press the number keys 22 to locate the contact quickly. When input no number, displaying the current call records; when input numbers, list the current matching results. Click the contact, and it will enter the telephone number to dial automatically.
  • Page 55 Click "Audio" to establish the audio call, and video is not visible; click "Video" to establish the video call, and video is visible. Pick up the handset to answer the call as a video call. 3) Answer a video invite During an audio call, if a video invite is requested, it will pop up the following window: Click “Accept”...

  • Page 56: Call Options

    5.1.4 Call Options Call options as shown below: Call options are described as below: Click the button to hold the current call. Click the button to resume the current call. Mute Click to switch to video call Click to switch to audio call Click to switch to Speaker Click to switch to handset Extended function...

  • Page 57: Call Records

    5.1.4.2 Video Options During video call you can switch picture through the button on the video interface. Switch to full screen View local video View the other part video 5.1.4.3 Multiple Calls  The Phone supports more than 3 line calls. The line information is on the right side of call interface.
  • Page 58 2) Click 1) You can click the drop-down list to choose the call record types, it supports for all call, missed call, received call, dialed call and forwarded call five types of call information. 2) Call records are shown on the left, and show the total number in the bracket. Click the number or contact, and you can view all the call records details on the right.
  • Page 59  If you want to send a message directly, please click the icon in call records; 5.1.5.3 Delete Call Records 1) If you want to delete one call record, steps as below:  Long press the call record you want to delete; ...

  • Page 60: Contacts

    5.2 Contacts You can choose the following method to enter into Contacts interface:  Enter the dialing interface, and then click the icon 5.2.1 Local Phone Book You can view, audio call, video call, add, edit, delete the Local contacts. 5.2.1.1 Add A New Contact 1) Click the icon...
  • Page 61 Edit the contact photo, Browse the image from “Take Photo” or “Choose photo from Gallery” Delete the note Cancel the edit Save the contact Some more information If you want to add some more information, please click ，it will pop up the page of contact details, as shown:...
  • Page 62 Click to save the contact. 5.2.1.2 Modify The Contact 1) Select the contact you need to modify in the contact list; 2) Click 3) Enter into contact edit page, you can edit the contact information. 5.2.1.3 Delete The Contact You can choose one of the following methods to delete the contacts: ...

  • Page 63: Broadsoft Phone Book

    5.2.2 Broadsoft Phone Book To setup Broadsoft contact. For Broadsoft PhoneBook’s server address, port, username and password, you need to consult your Broadsoft service provider for further information. 5.2.3 Remote Phone Book 1. Access the remote phone book, add the contacts to the local phone book from the remote phone book or make calls from the remote phone book.

  • Page 64: Group

    details, please consult with your system administrator for further information. 5.2.5 Group Group, it will be convenient for you to have contact group management. Contacts should at least belong to a group, the default is no group. 5.2.5.1 Add A New Group 1) Click 2) Choose “New group”;...

  • Page 65: Blf

    Click Edit Member, or hold the existed member, it will pop up a prompt to delete the member. 5.3 BLF Busy Lamp Field (BLF) is used to monitor a specific user for status changes on IP phones. For example, you can configure a BLF key on a supervisor’s phone to monitor the phone user status (busy or idle).
  • Page 66 Note ： After you finish BLF Key configuration, you need to drag ExtKey from the WIDGETS to the main interface. As shown below.

  • Page 67: Intercom

    5.4 Intercom Select Type as Intercom, enter intercom code in Value. Choose the availed account. To click Confirm to save. Note: Different SIP server has different codes. 1. Press the Intercom key when the phone is available. The phone will connect the...

  • Page 68: Call Return

    2. Answer the intercom incoming calling. 3. In default situation, the IP phone SNR VP-80 will answer the intercom 4. Incoming calling automatically and make a noise. You can set the phone to enable silent mode when picking up the intercom call so that the other will not hear you.

  • Page 69: Pickup & Group Pickup

    5.7 Pickup & Group Pickup You can use pickup to answer other users’ incoming call. The IP phon SNR VP-80 supports specified pickup and group pickup. Specified pickup can answer specified user’s incoming calls. When the user of specified pickup number is off or busy, you can press the pickup key to answer incoming call.

  • Page 70: Acd

    Note: Press the group pickup only to answer line 1 incoming call if there are many lines incoming calls in group. 5.8 ACD Automatic Call Distribution (ACD) enables organizations to manage a large number of phone calls on an individual basis. ACD enables the use of IP phones in a call-center role by automatically distributing incoming calls to available users, or agents.

  • Page 71: Hot Desking

    5.9 Hot Desking In some working place, the people are always walking around. HotDesking feature will make the staffs login his account on any computer in the company. In some public places, the working people is not fixed, anyone can use HotDesking for logging his account, and setting the phones to the familiar mode, such as the remote function of the computer.

  • Page 72: Conference

    5.10 Conference You can use the conference feature to hold a 3-way conference by pressing the Conference soft key to invite the current talking and one line talking held to attend conference. 5.10.1 Create 3-way conference 1. Create talking with first party; 2.

  • Page 73: Transfer

    5.11 Transfer 5.11.1 Blind Transfer 1. When the IP phone blind transfers a call.

  • Page 74: Attended Transfer

    2. Pick up a call, press transfer key on the keypad or click 3. Drag down the current call into the gray box 4. Press to enter the target number, then click Confirm. 5. Click Blind to transfer the number. 5.11.2 Attended Transfer 1.

  • Page 75: Keypad Input

    5.12 Keypad Input Only numbers, * and # can be input by keypad. The default Input method is Android keyboard. You can also download your preferred input method from the internet. 5.13 Webpage Browser This section describes the default web browser in the video phone, and you can also download your preferred browser through the internet.

  • Page 76: Camera

    5.13.1.2 Bookmark And Browsing History Run the browser, click to view the “bookmark”: Add a new webpage View the bookmark and browsing history Others 5.14 Camera Open the camera: in the main screen, click -> You can view your photos and videos in “Gallery” 5.14.1 Photograph Mode Turn on the camera, and the default mode is photograph mode.
  • Page 77 5.14.1.1 Basic Setting Click on the upper right corner or long press on the screen to pop up the menu Setting White balance setting 5.14.1.2 Mode Switch Click on the lower right corner to switch the mode. Panoramic camera mode Video mode Photo mode 5.14.1.3...

  • Page 78: Gallery

    5.14.1.4 Take A Video Click -> to swith to video mode. Click ，video starts when the icon turns to . And click to stop the video recording and save. 5.15 Gallery You can use Gallery to view photos or videos, and you can also view the picture or video downloaded from the Internet.

  • Page 79: View Photo & Picture & Video

    Bluetooth is a proprietary, open wireless technology standard for exchanging data over short distances from fixed and mobile devices, creating personal area networks with high levels of security. On SNR VP-80, users could use Bluetooth to transfer files, share contact information with other Bluetooth portable devices by installing Bluetooth Application, or use Bluetooth headset for making calls.

  • Page 80: Turning Bluetooth On /Off

    SNR VP-80 so that both devices know how to connect securely to each other. After that, users could simply connect to a pared device. Turn off Bluetooth if it’s not used. Bluetooth related settings are under SNR VP-80’s Settings application → Wireless &...

  • Page 81: Un-Pairing A Bluetooth Device

    “Pairing” under the device ID. Make sure the Bluetooth device is active in pairing mode. Then tap on the device ID on the SNR VP-80 to pair them. Confirm the passkey in the prompted message (if any). Or if PIN is required, please refer to the device’s documentation or other procedures to...

  • Page 82: Calendar

     It will take a few seconds for the video phone to prepare the connection;  To access USB storage, click on the screen -> Explorer -> USB, to access and manage your data. 5.18 Calendar To start the calendar： ...

  • Page 83: View Calendar

    Click ”Add account” to add an account, and then synchronize all the schedules of the account to the calendar. 5.18.2 View Calendar The calendar will display weekly by default, and you can slide the calendar up and down to view the different weeks. In order to view the activities or create the new activities, you can also make the calendar display daily or monthly.

  • Page 84: Edit Activities

    3) Click “Done” to finish. 5.18.4 Edit Activities You can click on schedule needed to be modified to edit the schedule. 5.18.5 Delete Activities While viewing the activity, you can click “DELETE” on the upper right corner to delete...

  • Page 85: Clock

    the activity. 5.19 Clock Enter the Clock:  In the main screen, click -> Clock; As shown below: Description: Alarm Countdown timer Stopwatch Time zone Others 5.19.1 Alarm You can add one or multiple alarms:...
  • Page 86 1) Click 2) Click 3) Input the time of alarm; 4) If you want to repeat the alarm in some days of a week, please click “REPEAT”; 5) You can choose the ringtone of the alarm. 5.19.1.1 Enable/Disable Alarm You can click ON/OFF to enable or disable the alarm. Note: If power off the phone, the alarm will also be off.

  • Page 87: Countdown Timer

    5.19.1.2 Modify Alarm If you want to modify the status of the alarm, including time, repeat data, alarm ringtone, you can directly click on the alarm. 5.19.1.3 Delete Alarm In Alarm page, you can use the following method to delete the alarm: ...

  • Page 88: Stopwatch

    5.19.3 Stopwatch 1) Click 2) Click “START” or “STOP” to start or stop the stopwatch; 3) Click the time icon to start a new time; 4) When the time is on hold, click to reset the timer. 5.20 Email Email Application can let you use POP3 or IMAP service to send and receive e-mail. Start Email：...

  • Page 89: Music

     If you have already set up an email account, In the main Email page, Press “Menu” button, and then click “Account”, and last press ”Menu” to “Add Account”. 2) Input the email account and password, and then click “Next”; If there is no account type in the equipment database you want to set, the device will require you to enter more detailed information (the receiving server settings and outgoing server settings).

  • Page 90: Explorer

    You can click the labels of Artists, Albums or Songs to view all songs. You can also view or play the songs from the playlists. To view the currently playing song, please click the "now playing" label. 5.22 Explorer You can use explorer to manage the files in the device. In the main screen, click ->...
  • Page 91 Home Page Upper Layer Multiple Choices, And the selected file will change to blue color. Editor, you can do Copy, Delete, Move, Paste, Rename, Send, Create shortcut operations. New Folder Previous File Next File If you insert a SD card, you can view the files in SD card. (Optional) View the internal files of the device View the files in inserted USB device...

  • Page 92: Video Player

    5.23 Video Player You can use video player to play local videos. To run the video player: In the main screen, click -> Video After entering, you can click on the list of videos to watch. As shown below: Bookmark Screen Brightness Adjustment The previous video, and long press to make video fast backward.

  • Page 93: Floating Browse Mode

    5.23.1 Floating Browse Mode Click on during playing a video to enter the floating browse mode. As shown below： You can click on to play the video, click to shrink the floating window. And use two fingers to press on the screen, shrinkage or expansion to adjust the window size.

  • Page 94: Ping Tool

    5.24.1.1 Install You can click “Install”, and then browse the path: The system will list all the Apk applications under the path, click the Apk to install. 5.24.1.2 Manage You can click on "Manage" button to browse the Apk installed in the system. 5.24.2 Ping Tool You can use the Ping tool for Ping query, network packet capture and view the...
  • Page 95 log information. 5.24.2.1 Ping Query Ping query interface is as shown： You can input the address you want to Ping, click the Ping button, you can view the Ping query results. If you take a long Ping query, in the input box, please manually enter the Ping + address, such as: , and then click the Ping button.
  • Page 96 You can choose what type protocol and specified port you need to capture the logs. Press “Start Tcpdump” to start the log captured. If you want to finish the log captured, you can press “Stop Tcpdump” to stop the capture, and the system will prompt the file saved path. You can use Wireshark and other tools on PC to read the logs.
  • Page 97 You can use , enter the key word to search the log information, and select the log level through the drop-down list. Or click to see more options. if you need to save the log, please click , select "Save". If you need to highlight the log information, please click , select "highlight", and then the log will be showed as different color.

  • Page 98: Software Upgrade

    6 Software Upgrade 6.1 Immediate Update Choose one way below to enter the system upgrade interface:  In the main screen, press “Menu” on board -> System Settings -> System -> About Multimedia Terminal -> System Upgrade -> System Update Now ...

  • Page 99: Select Other Upgrade Package

    6.1.1 Select Other Upgrade Package 1) Via USB to Upgrade Put upgrade package into USB, insert USB, then click “Select other upgrade package”, find “/mut/usb_storage”, find the upgrade package, then click “OK” to upgrade. 2) Via Internal Memory to Upgrade Use USB to copy the upgrade package into Internal Memory, then press “Select other upgrade package”, find “/mnt/sdcard”...

  • Page 100: Remote Update

    2) Via built-in SD Card to upgrade First, change the name of upgrade package into upgrade.zip, then copy it into USB, and then use USB to copy the upgrade package into Internal Memory, enter the upgrade interface, will find path upgrade package:/mut/sdcard/upgrade.zip, because...
  • Page 101 2) Click “Remote Upgrade”, video phone will check the new version automatically. If exist a new version, it will prompt. Press “OK” to download upgrade document. 3) After finish downloading, it prompts “Download update image success! You need to restart system for update! ”, press reboot now, and then system will upgrade automatically.

  • Page 102: Auto Update Period

    6.2 Auto Update Period Auto Update Period includes four modes: None, One Day, One Week, and One Month. The terminal will detect the new version automatically in time, if there is, the status bar will show “There is a new version, please update!”. Click and download the image for upgrade.

  • Page 103: Check Update After System Power On

    6.4 Check Update After System Power On Click “Check Update After System Power On” in figure 5-1. Every time you power on, the system will check the new version automatically. If there is a new one, the status bar will notice: “System has new version, please update now!”, click and download the image for upgrade.

  • Page 104: System Maintenance

    7 System Maintenance 7.1 System State Inspection Mode 1: In the main screen, press "Menu" key on the hard keyboard-> System Settings-> About Multimedia Terminal Mode 2: In the main screen, click -> -> About Multimedia Terminal It will display phone status, software version and hardware version in this item. 7.2 IP Query Mode 1: In the main screen, press "Menu"...

  • Page 105: Sip Account Registration Query

    Mode 3 and Mode 4 can check the corresponding network information in setting interface. 7.3 SIP Account Registration Query You can choose one of the following methods to enter the SIP account registration query. If the account is successfully registered, the icon will be light up in notification area of phone.

  • Page 106: Backup & Reset

    Mode 1: Press Speaker button or pick up to enter the dialing interface, click on upper right corner, check Account Manager. Mode 2: Slide down the top-left , click the account, enter the setup interface, check Account Manager. 7.4 Backup & Reset Mode 1: In the main screen, press "Menu"...
  • Page 107  Please check whether the adapter fits this product requirement;  Please check whether the outlet is working properly. Failure 2: No voice when pick up the handset  Please check whether the connection of handset is working properly;  Please adjust the volume + key on keyboard when off-hook the phone, Observe the display of “volume”...

  • Page 108: Web Interface

    8 Web Interface 8.1 Web login 1. Open the browser on your computer. 2. Input the IP address in the address bar. 3. Enter the user name and password (user name: admin, password: admin), then click 8.2 Status->Basic Click Status->Basic to check the phone information.
  • Page 109 Sections Description Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address),Hardware Model, Firmware version and Hardware firmware. Network Information To display the device’s Networking status(LAN Port),such as Port Type(which could be DHCP/Static/PPPoE), Link Status, IP Address, Subnet Mask, Gateway, Primary DNS server, Secondary DNS server.

  • Page 110: Account->Basic

    8.3Account->Basic Sections Description SIP Account To display and configure the specific Account settings. Status: To display register result.  Display Label: Which is displayed on the phone’s LCD  screen. Display Name: Which is sent to the other call party for ...
  • Page 111 Sections Description SIP Server 2 To display and configure Secondary SIP server settings. This is for redundancy, if registering to Primary SIP server fails, the IP phone will go to Secondary SIP server for registering. Note: Secondary SIP server is used for redundancy, it can be left blank if there is not redundancy SIP server in user’s environment.

  • Page 112: Account->Advanced

    8.4 Account->Advanced Sections Description SIP Account To display current Account settings or to select which account to display. Audio Codecs To display and configure available/unavailable Audio codecs list. Codec means coder-decoder which is used to transfer analog signal to digital signal or voice versa. Familiar codecs are PCMU(G711U), PCMA(G711A), G722 (wid-bandth codecs),G729 and so on.
  • Page 113 Codec Resolution: It can support QCIF, CIF, VGA, 4CIF,  720P. Codec Bitrate: The lowest bitrate is 128, the highest  bitrate is 2048. Codec payload: From 90-119.  Sections Description Subscribe To display or configure session timer settings. Active: To enable or disable this feature, If enable, the ...
  • Page 114 Sections Description DTMF To display and configure DTMF settings. Type: Support Inband,Info,RFC2833 or their  combination. How To Notify DTMF: Only available when DTMF Type is  Info/Info+Inband/Info+RFC2833. DTMF Payload: To configure payload type for DTMF.  Note: By default, DTMF type is RFC2833 which is the standard.
  • Page 115 from SIP server. User=phone: If enabled, IP phone will send user=phone  within SIP message. Anonymous Call: If enabled, all outgoing call for the  designated account will be anonymous number. Anonymous Call Rejection: If enabled, all incoming  anonymous-out call for the designated account will be rejected.
  • Page 116 platform. Note: Please consult your administrator further information. Sections Description To display NAT-related settings. UDP Keep Alive message: If enabled, IP phone will send  UDP keep-alive message periodically to router to keep NAT port alive. UDP Alive Msg Interval: Keepalive message interval. ...

  • Page 117: Network ->Advanced

    Remote User Agent This feature need to be used with Auto Anser Doorphone Delay. Go to the path: Phone->Call Feature. Separator: Setup a separater ,such as “,” , “*”or “#” to  separate many door phone account.  NumberList DoorPhone: Fill multiple doorphone number . 8.5 Network ->Advanced Sections Description...

  • Page 118: Phone->Time

    VLAN To display and configure VLAN settings. LAN Port/PC Port: You can configure VLAN setting for  both ports respectively. Active: To enable or disable VLAN feature for designated  port. VID: To configure VLAN id for designated port.  Priority: To select VLAN priority for designated port.

  • Page 119: Phone->Preference

    8.7Phone->Preference Sections Description Key Press Sound To configure the sound volume for key press. Volume: The valid volume range is from 0~15,by default  it’s 8. Ringtone Volume To configure the sound volume for ringtone. Volume: The valid volume range is from 0~15,by default ...

  • Page 120: Phone ->Call Feature

    8.8 Phone ->Call Feature Sections Description Mode Phone To enable or disable feature key sync. Feature Key Sync: To enable or disable feature key sync.  Mode: Select the desired mode.  Forward Transfer To display and configure Forward setting. Note: There are three types of forward: Always Forward, Busy Forward and No answer Forward.
  • Page 121 DND Emergency: Enable this function, users can still  receive the call from DND Authorized number when in emergency situation. DND Authorized Number: SNR VP-80 supports  multiple authorized numbers. Please use comma to separate. DND Priority: Enable this function. If you enable DND ...
  • Page 122 active call. Call Waiting Tone: If enabled, it allows IP phones to play  the call waiting tone to the waiting callee. Auto Redial Auto redial allows IP phones to redial an unsuccessful call for designated times within designated interval. Auto Redial: To enable or disable auto redial feature.
  • Page 123 available user or agents. ACD Activated Auto: If enabled, Agent status will turn to  available automatically within designated time(decided by ACD Activated Auto Timer). ACD Activated Auto Timer: To configure interval when  will Agent status becomes available automatically. ACD Pwd Required: To enable the ACD password.

  • Page 124: Phone->Audio

    Door Phone When there is an incoming call from doorphone, setup the delay auto answer time, SNR VP-80 will auto answer the call after the timeout. Note: if you enable Auto Answer function, this feature will be not available.
  • Page 125 Mic Volume To configure Microphone volume for handset mode. Automatical Generation SNR VP-80 will auto adjust amplification circuit gain via signal. Control Automatic Gain Control(Sending-side): Disabled by  default Automatic Gain Control(Receiving-side): Disabled by ...

  • Page 126: Phone->Video

    8.10 Phone->Video Sections Description Media Feedback NACK: Enabled it to filter mosaic.  Tmmbr: Send the maximum temporary rate request.  Disabled by default. H264 Settings H264: A video stream compression standard. Different from H263, it provides an approximately identical level of video stream quality but a half bit rate.

  • Page 127: Phone->Ext Key

    8.11 Phone->Ext Key Sections Description Current Page SNR VP-80 can support 4 pages Ext Key. 20 Ext Keys for each page. Allows user to assign specific feature to the designated key on expansion module.
  • Page 128 For keys, the available feature list: DND, Menu, MSG, Status, Book, Fwd, PickUp, Group PickUp, Intercom, Speed Dial, History, Favorites, Redial, Account, ACD, BLF, BLFList,Call Return, Hot Desking, Record, XML Browser, DTMF. 8.12 Phone-> Tone Sections Description Tone Allows user to select a specialized tone sets (classified by countries) or to customize own tones.

  • Page 129: Phone->Replace Rule

    8.13 Phone->Replace Rule Sections Description Rules Allow user to select Replace rule or Dial-now to display or edit. Rules Modify Allow user to modify selected rules information. Once you dial prefix value, it will call out Replace number. Click Add to add new replace rules. ...

  • Page 130: Phone->Dial Plan

    code rule, the IP phone will automatically prefix outgoing number with area code. Note: There is only one area code rule supported. 8.14 Phone->Dial Plan Sections Description Rules Allow user to select Replace rule or Dial-now to display or edit. Dial Now Delay Allow user configure dial now delay time for dial now.

  • Page 131: Phone->Action Url

    Click submit to save.  All dial now numbers will show in the list. Users can edit or delete the exited dial now number. Area Code Area codes are also known as NPAs(Numbering Plan Areas). They usually indicate different geographical areas within one country.
  • Page 132 account. Unregistered: When the IP phone logs off the registered  account. Register Failed: When the IP phone fails to register an  account. Off Hook: When the IP phone is off hook.  On Hook: When the IP phone is on hook. ...

  • Page 133: Phone->Multicast

    transfer a call. Transfer Failed: When the IP phone fails to transfer a  call. Idle To Busy: When the state of the IP phone changes  from idle to busy. Busy To Idle: When the state of phone changes from ...
  • Page 134 8.17 Phone-> Local Book Sections Description Contact To display and select local contact type. All Contacts: To display or edit all local contacts.  Favorites: To display or edit favorites contacts.  Black List: To display black list contacts.  Search To search designated contacts from local phonebook.
  • Page 135 Sections Description Group To display or edit Group contacts. Group Setting To display or change Group name, related ringtone or description. Import/Export To import or export the contact or blacklist file.

  • Page 136: Phonebook->Local Book

    8.18 PhoneBook->Remote Book Sections Description Remote Book To display and configure Remote Book settings. Index: To select desired Remote Book item to display  and configure. Local Book URL: To configure remote book server  address Local Book Name: To configure display remote book ...

  • Page 137: Phonebook->Call Log

    8.19 PhoneBook->Call Log Sections Description Call History To display call history records. Available call history types are All calls, Dialed calls, Received calls, Missed calls, Forwarded calls. HangUp: To click to hangup ongoing call on the IP phone.  Note: For “HangUp” feature, you need to have the remote control privilege to control IP phone via Web UI.

  • Page 138: Phonebook->Ldap

    8.20 PhoneBook->LDAP Sections Description LDAP To display and configure LDAP phonebook settings. Name Filter: The settings used to tell LDAP server what  name attributes to search. Number Filter: The settings used to tell LDAP server  what number attributes to search. Server: To configure LDAP server’s address.

  • Page 139: Phonebook->Broadsoft

    Display Name: To configure display name on Phone UI  when there is any searching result from LDAP server. Max Hits: To configure the maximum size of result  response from LDAP server. Search Delay Time: To configure delay time before ...

  • Page 140: Upgrade->Basic

    To select upgrading zip file from local or a remote server automatically. Note: Please make sure it’s right file format for right model. Reset to Factory Setting To setup SNR VP-80 to factory setting. Reset Config to Factory To setup the configuration file to factory setting. Setting...
  • Page 141 Sections Description PNP Option To display and configure PNP setting for Auto Provisioning. PNP: Plug and Play, once PNP is enabled, the phone will  send subscription message server automatically to get Auto Provisioning server’s address. By default, this SIP message is sent to multicast address 224.0.1.75(PNP server address by standard).
  • Page 142 Sections Description Manual Autop To display and configure manual update server’s settings.  URL: Auto provisioning server address.  User name: Configure if server needs an username to access, otherwise left blank.  Password: Configure if server needs a password to access, otherwise left blank.
  • Page 143 Sections Description Reboot Schedule Enable to set the reboot at designed time. System Log To display syslog level and export syslog file. Syslog level: From level 0~7.The higher level means the  more specific syslog is saved to a temporary file. By default, it’s level 3.

  • Page 144: Security->Basic

    Others To display or configure others features from this page. Config file: To export or import configure file for IP  phone. 8.24 Security->Basic Sections Description Web Password Modify To modify user’s password. User Name: Choose the character you are.(admin or ...

  • Page 145: Security->Advanced

    8.25 Security->Advanced Sections Description Web Server Certificate To display or delete Certificate which is used when IP phone is connected from any incoming HTTPs request. Note: The default certificate could not be deleted. Web Server Certificate To upload a certificate file which will be used as server Upload certificate.

Table of Contents
