- Page 1 SNR-VP-51 IP Phone User Manual...
-
Page 2: Table Of Contents
Contents Overview ......................5 1.1. Introduction ..................5 1.2. Features ....................6 1.3. Keypad ....................8 1.4. Icons introduction ................10 Installation ...................... 11 2.1. Check package contents ..............11 2.2. Connection diagram ................11 2.3. Installation Steps ................12 Functions ...................... - Page 3 Settings ......................26 4.1. Basic Settings..................26 Language ..................26 4.1.1. Date & Time ................. 26 4.1.2. Backlight ..................27 4.1.3. Password Setting ................27 4.1.4. 4.2. Sound Settings ................... 27 Phone Volume ................27 4.2.1. Ring Tones ................... 27 4.2.2.
- Page 4 5.23. Security->Basic .................. 66 5.24. Security->Advanced ................67 6.Troubleshooting ....................68 7.Appendix:TimeZones .................... 69...
-
Page 5: Overview
1. Overview 1.1. Introduction The SNR-VP-51 is a featured one-line IP phone with full duplex hands-free speakerphone. It can be directly connected to an Internet Telephony Service Provider or to an IP PBX. Based on the SIP standard, the SNR-VP-51 has been tested to ensure comprehensive interoperability with equipment from VoIP infrastructure leaders enabling service providers to quickly roll-out competitive, feature rich services to their customers. -
Page 6: Ip-Pbx Features
1.2. Features Highlights HD Voice 2.6‘’ 132x64 Graphical LCD with Backlight Support 3-way Conference Support PoE Full Compatible with Asterisk, BroadSoft Platform Phone Features 1 Line (support 1 SIP account) Support call waiting, call forwarding, call transfer Call on hold, mute, auto-answer, redial Phonebook (500 groups), Blacklist (100 groups), call logs (100 entries) 3-Way Conference DND (Do Not Disturb) -
Page 7: Network Features
Wideband Codec: G.722 Narrowband Codec: G723_53, G723_63, G726_32，PCMA, PCMU，G.729 VAD, CNG , Echo Canceller Full-Duplex Speakerphone Network Features SIP V1(RFC2543), V2(RFC3261) Static IP/DHCP for IP configuration 3 DTMF modes: In-Band, RFC2833, SIP INFO HTTP/HTTPS Web Server for Management NTP for Auto Time Setting TFTP/FTP/HTTP/HTTPS Protocols 802.1Q VLAN ... -
Page 8: Keypad
1.3. Keypad Keypad, LED, and function key definitions Keypad Description Key name Function Description Navigation Assists you in selecting an item that you want to process under the menu by pressing the Up, Down, Right or Left key. Press the OK key to save. Soft keys 1/2/ Key combination includes functions such as History/Favorites/Redial/CallReturn/HotDesking/ XML... -
Page 9: Panel Descriptions
Headset Use the headset to call out or call in Forward Forward the call to the third party Redial View the Missed Calls, Incoming Calls and Dialed Calls. Mute Press this key in calling mode and you can hear the other side, but the other side cannot hear you. -
Page 10: Icons Introduction
1.4. Icons introduction... -
Page 11: Installation
2. Installation 2.1. Check package contents Please refer to the package list below to check the completeness of package Name Quantity SIP IP Phone unit handset RJ-9 Cable Power Adapter RJ-45 Cable Stand Quick installation guide 2.2. Connection diagram... -
Page 12: Installation Steps
SNR-VP-51 and the other end to wall network jack. Step 3 – Connect the computer Connect one end of the RJ-45 Ethernet cable to the PC port at the back of the SNR-VP-51 and the other end to the Ethernet port on your computer. -
Page 13: Functions
3. Functions Make a call 3.1. 3.1.1. Call devices ： User can make a phone call via the following methods 1. Pick up the handset, icon will be shown on the idle screen. 2. Press the Hand-free key, icon will be shown on the idle screen. 3. -
Page 14: Mute
hold the current talking. During the conversation, User can alternate between Headset, Handset and Hand-free by pressing the corresponding keys. Note: The will flash during the Incoming interface 3.3. Mute You can press the Mute key to make the user NOT be heard by the other party, but User can hear the other party. -
Page 15: Call Forward
3.7. Call Forward You can set the static forward to transfer all the incoming calls to specified number; Also you can use dynamic forward to transfer all the incoming calls forward to the number inputted when the phone is ringing. Forward: Enable call forward feature, Options as follows：... -
Page 16: Consultation Transfer
Conference soft key to invite the current talking line and the line on hold to attend the conference. The Local conference feature of IP phone SNR-VP-51 can invite two parties at most to attend conference. The conference type of IP phone SNR-VP-51 is Local conference with default. -
Page 17: Call Park
Account-->Press the Save soft key to save; 3.11.Pickup You can use pickup to answer other users’ incoming call. The IP phone SNR-VP-51 supports specified pickup and group pickup. Note: Press the group pickup only to answer line 1 incoming call if there are many lines incoming calls in group. -
Page 18: Group Pickup
3.11.2. Group Pickup Group pickup can answer group’s user incoming calls. Group pickup needs to set group members. 1. Set group pickup via phone interface PATH: Press Menu-->Features-->Programmable keys-->Soft Keys-->Group PickUp -->Press Down key to set label/Value/Account--> Save soft key; 2. -
Page 19: Intercom
Press the Intercom key or the Back soft key to end the intercom。 Answer the intercom incoming calling In default situation, the IP phone SNR-VP-51 will answer the intercom incoming calling automatically and make a noise. You can set the phone to enable silent mode when picking up the intercom call so that the other will not hear you 。... -
Page 20: Set The Hotdesking Key
3.16.1. Set the HotDesking Key To configure Intercom via Phone interface: PATH: Press Menu-->Features-->Programmable keys-->Soft Keys-->HotDesking--> Press Down key to set label--> Save soft key; 3.16.2. HotDesking Feature： After setting the HotDesking on Soft-key, back to the idle screen: Pressing the HotDesking, and enter the HotDesking screen: If you press clear on the screen, the phone will begin to clear the information stored on the phone：... -
Page 21: Hoteling
and you can choose to lock the function keys or all keys. And this function can only be configured through the web UI, please refer to the web interface for the details. Function Keys: The function keys are locked. You cannot use the SOFT KEYS, ... -
Page 22: Application
3.20.Application 3.20.1. Text Message The IP phone SNR-VP-51 can send and answer text message. The phone will make a “Du” sound and present “N piece of new message” on the LCD( For example: 1 new message), and a twinkling message icon will appear. -
Page 23: Send Text Message
interface. Select the message you will read and Press the OK key on the phone keyboard or the Enter soft key to read. Send Text Message 1. In the Idle, press the Menu soft key 2. In the mail menu interface, press the Down key on the phone keyboard to select Message, press the OK key on the phone keyboard or the Enter soft key to enter Message interface.：... -
Page 24: Voice Message
OK soft key then all the messages in the in-box will be deleted: 3.20.2. Voice Message The IP phone SNR-VP-51 can send or answer voice message. The phone will make a “Du Du” sound, the LED light of message flashes green, and the LCD presents “New Voice Message” on the LCD with a twinkling voice message icon. - Page 25 Check voice message 1. Press the Message key or the Connect soft key to call the Visit account number of voice message. 2. Check voice message according to voice prompt. Set the Visit account number of voice message first before check voice message. ...
-
Page 26: Settings
4. Settings 4.1. Basic Settings 4.1.1. Language You can change the language through below method: Press Menu -> Settings -> Basic Setting -> Language 4.1.2. Date & Time 1. The IP phone displays Time and Date in Idle status. You can set the Time and Date obtain from SNTP server automatically or you can set the time and date manually. -
Page 27: Backlight
1. The Ring Tone refers to incoming ring tone, which reminds the user that new call is coming with the phone. The IP phone SNR-VP-51 supports phone ring tone to distinguish the incomings from other near phones’ ring tone; At the same time, the IP phone SNR-VP-51 also support setting specific incoming ring tone for contacts. -
Page 28: Phone Book
4.3. Phone Book 4.3.1. Local Phone Book The Local Phone Book is used for storing the contacts names and number. The SNR-VP-51 can store up to 500 entries contacts. You can add, edit, delete, search, or call any contact from the Local Phone Book。... -
Page 29: Blacklists
Search soft key or the OK key to enter the Search Contacts interface. 4.3.2. Blacklists 100 Blacklists contacts are available with SNR-VP-51 IP phone. You can add, edit, delete, search or call contact. The phone will reject to answer automatically within the blacklists contacts’... -
Page 30: System Customizations
make calls from the calls history and delete the calls history 。 Press the History key, the LCD will display all the recent calls； Press the Left or Right key on the phone keyboard to switch the lists of All Calls, Dialed Calls, Received Calls, Missed Calls and Forwarded Calls；... -
Page 31: Basic Network Settings
4.6. Basic Network Settings Through the Basic Network setting, you can set the IP Phones to get the IP address by three ways：DHCP, static IP and PPPoE. PATH: Menu -> Settings -> Advanced Setting -> Network 4.6.1.DHCP Mode 1. In the Network Settings interface, Press the OK key on the phone keyboard or the Enter soft key to enter LAN Port：... -
Page 32: Reset To Factory
4.8. Reset to Factory In the Advanced Setting interface, press the Up or Down key on the phone keyboard to select “Reset to factory”, Press the OK key on the phone keyboard or the Enter soft key to access the reset to factory interface: 4.9. -
Page 33: Status->Basic
5.1. Status->Basic 1. First you need to open a browser (for example IE) 2. Input the IP address in the browser’s address bar and then press the Enter key 3. If successfully connected to IP phone, it will prompt a login page. In this page, please input the username and password accordingly. - Page 34 Sections Description Product Information To display the device’s information such as Model name, MAC address (IP device’s physical address), Firmware version and Hardware firmware. Network Information To display the device’s Networking status(LAN Port),such as Port Type(which could be DHCP/Static/PPPoE), Link Status, IP Address, Subnet Mask, Gateway, Primary DNS server, Secondary DNS server, and Primary NTP server and Secondary NTP server(NTP server is used to synchronize time from INTERNET automatically).
-
Page 35: Account->Basic
5.2. Account->Basic Path: Web UI -> Account->Basic Sections Description SIP Account To display and configure the specific Account settings. Status: To display register result. Display Label: Label is displayed on the phone’s LCD screen. Display Name: Name is sent to the other call party for ... - Page 36 Registration Period: The registration will expire after Registration period. The IP phone will re-register automatically within registration period. SIP Server 2 To display and configure Secondary SIP server settings. This is for redundancy, if registering to Primary SIP server fails, the IP phone will go to Secondary SIP server for registering.
-
Page 37: Account->Advanced
5.3. Account->Advanced Path: Web UI->Account->Advanced... - Page 38 Sections Description To display current Account settings or to select which account SIP Account to display. Codecs To display and configure available/unavailable codecs list. Codec means coder-decoder which is used to transfer analog signal to digital signal or vice versa. Familiar codecs are G723_53, G723_63, G726_32，PCMA, PCMU，G.729，G722.
- Page 39 rejected. Is escape non Ascii character: To transfer the symbol to Ascii character. Missed Call Log: To display the miss call log. Prevent SIP Hacking: Enable or disable to prevent SIP from hacking Music Server Address To display or configure third-party MOH (music-on-hold) server.
-
Page 40: Network->Basic
5.4. Network->Basic Path: Web UI->Network->Basic Sections Description LAN Port To display and configure LAN Port settings. DHCP: If selected, IP phone will get IP address, Subnet Mask, Default Gateway and DNS server address from DHCP server automatically. Static IP: If selected, you have to set IP address, Subnet ... - Page 41 Sections Description Local RTP To display and configure Local RTP settings. Max RTP Port: Determine the maximum port that RTP stream can use. Min RTP Port: Determine the minimum port that RTP stream can use. SNMP To display and configure SNMP settings. Active: To enable or disable SNMP feature.
- Page 42 Vid:To configure VLAN id for designated port. Priority:To select VLAN priority for designated port. Note: Please consult your administator for specific VLAN settings in your networking environment. To display and configure QoS settings. SIP QoS:To configure QoS value for all SIP message. ...
-
Page 43: Phone ->Time/Lang
5.6. Phone ->Time/Lang Path: Web UI->Phone->Time/Lang... - Page 44 Sections Description Web Language To choose the web language. LCD Language To choose the phone language. Format Setting To configure time display settings. Time Format: Determine what format to display on Phone UI(12 hour/24 hour). Date Format: Determine what format to display on ...
-
Page 45: Phone->Preference
5.7. Phone->Preference Path: Web UI->Phone->Preference Sections Description Headset Mode To enable or disable Headset Mode. Active: If enabled, the default audio track will be headset mode, if audio track is changed during a call, it will be back to headset mode after you hang up the call. Key Press Sound To configure the sound volume for key press. -
Page 46: Phone->Call Feature
5.8. Phone->Call Feature Path: Web UI->Phone->Call Feature Sections Description Mode To enable or disable feature key sync. Feature Key Sync: To enable or disable feature key sync. Mode: Select the desired mode. Forward Transfer To display and configure Forward setting. Note: There are three types of forward: Always Forward, Busy Forward and No answer Forward. - Page 47 Busy Forward: An incoming call will be forwarded if IP phone is busy. No answer Forward: An incoming call will be forwarded if it’s no answer after a specific time. Call Waiting To enable or disable Call Waiting. Call Waiting Enable: If enabled, it allows IP phones to ...
- Page 48 Delay Time: the delay time before calling out. Remote Control Remote Control allows specific host to interact with IP phone by sending HTTP or HTTPS requests. The specific action could be answering an incoming call, hang up an ongoing call and so on.
-
Page 49: Phone->Voice
5.9. Phone->Voice Path: Web UI->Phone->Voice Sections Description Echo Canceller Echo Canceller: To remove acoustic echo from a voice Communication in order to improve the voice quality. VAD (Voice Activity Detection): Allow IP phone to detect the presence or absence of human speech during a call. When detecting period of “silence”, VAD replaces that silence efficiently with special packets that indicate silence is occurring. - Page 50 the illusion of a constant transmission stream, so that background sound is consistent throughout the call and the listener does not think the line has released. Jitter Buffer Jitter buffer is a shared data area where voice packets can be collected, stored, and sent to the voice processor in even intervals.
-
Page 51: Phone->Key/Display
5.10.Phone->Key/Display Path: Web UI->Phone->Key/Display Sections Description Soft Key Allows user to assign specific feature to the designated soft keys. For softkey, the available features list: DND, Menu, MSG, Status, Book, Fwd, PickUp, Group, PickUp, Intercom, Speed Dial, History, Favorites, Redial, CallReturn, HotDesking. -
Page 52: Phone->Ring Tones
5.11.Phone->Ring tones Path: Web UI->Phone->Ringtones Sections Description All Ringtones Allow user to upload and view ringtone files or delete uploaded ringtone files. Distinctive Ringers Distinctive ringers allow different incoming calls to trigger distinctive ringtones. The IP phone will check "Alert-Info" header inside the incoming “invite”... -
Page 53: Phone->Tones
5.12.Phone->Tones Path: Web UI->Phone->Tones Sections Description Tone Allows user to select a specialized tone sets (classified by countries) or to customize own tones. Note: Available country tones sets are: China, Spain, Luxembourg, Sweden, Taiwan, Belgium, Denmark, Finland, Germany, Netherlands, Norway, Portugal. -
Page 54: Phone->Dial Plan->Replace Rule
5.13.Phone->Dial Plan->Replace Rule Path: Web UI->Phone->Dial Plan->Replace Rule Sections Description Rules Allow user to select Replace rule or Dial-now to display or edit. Rules Modify Allow user to modify selected rules information, for replace rule, you can modify related account, prefix and replace. Area Code Area codes are also known as NPAs (Numbering Plan Areas). -
Page 55: Phone ->Dial Plan->Dial Now
5.14.Phone ->Dial Plan->Dial Now Path: Web UI->Phone->Dial Plan->Dial Now Sections Description Rules Allow user to select Replace rule or Dial-now to display or edit. Dial Now Delay Allow user configure dial now delay time for dial now. It means user can configure the IP phone to dial out the phone number automatically after the designated delay time if it match any dial now rule. -
Page 56: Phone ->Action Url
5.15.Phone –>Action URL Path: Web UI->Phone->Action URL Sections Description Action URL To display and configure Action URL settings. Setup Completed: When the IP phone completes startup. Registered: When the IP phone successfully registers an account. Unregistered: When the IP phone logs off the registered ... - Page 57 Close DND: When the IP phone disables the DND mode. Open Always Forward: When the IP phone enables the always forward. Close Always Forward: When the IP phone disables the always forward. Open Busy Forward: When the IP phone enables the ...
-
Page 58: Phonebook->Local Phone Book
5.16.PhoneBook->Local Phone Book Path: Web UI->PhoneBook->Local Book Sections Description Contact To display and select local contact type. All Contacts: To display or edit all local contacts. Favorites: To display or edit favorites contacts. Black List: To display black list contacts. ... -
Page 59: Phone Book->Remote Phone Book
page. Group To display or edit Group contacts. Group Setting To display or change Group name, related ringtone or description. Import/Export To import or export the contact or blacklist file. 5.17.Phone Book->Remote Phone Book Path: Web UI->PhoneBook->Remote Book Sections Description Remote Book To display and configure Remote Book settings. -
Page 60: Phone Book->Call Log
5.18.Phone Book->Call log Path: Web UI->PhoneBook ->Call Log Sections Description Call History To display call history records. Available call history type are All calls, Dialed calls, Received calls, Missed calls, Forwarded calls. HangUp: To click to hang up ongoing call on the IP phone. Note: For “HangUp”... -
Page 61: Phone Book->Ldap
5.19.Phone Book->LDAP Path: Web UI->PhoneBook->LDAP Sections Description LDAP To display and configure LDAP phonebook settings. Name Filter: The settings used to tell LDAP server what name attributes to search. Number Filter: The settings used to tell LDAP server what number attributes to search. -
Page 62: Phone Book->Broadsoft
Number Attribute: To configure which number attributes should be feedback from LDAP server. Display Name: To configure display name on Phone UI when there is any searching result from LDAP server. Max Hits: To configure the maximum size of result ... -
Page 63: Upgrade->Basic
User Name: Username used to access Broadsoft PhoneBook server. Password: Password used access Broadsoft PhoneBook server. Note: IP phone supports at most 5 Broadsoft PhoneBook items. For Broadsoft Phone Book’s server address, port, username and password, you need to consult your Broadsoft service provider for further information. -
Page 64: Upgrade->Advanced
For example, VP50 firmware version should be like 50.xxx.xxx.xxx. Hardware Version To display Hardware version. Reset to Factory Setting To enable you to reset IP phone’s setting to factory settings. Reboot To reboot IP phone remotely from Web UI. 5.22.Upgrade->Advanced Path:Web UI->Upgrade->Advanced Sections Description... - Page 65 DHCP option: If configured, IP Phone will use designated DHCP option to get Auto Provisioning server’s address via DHCP. This setting require DHCP server to support corresponding option. Manual Update Server To display and configure manual update server’s settings. URL: Auto provisioning server address.
-
Page 66: Security->Basic
capturing once reaching this maximum size. Others To display or configure others features from this page. Confile file: To export or import configure file for IP phone. 5.23.Security->Basic Path: Web UI->Security->Basic Sections Description Web Password Modify To modify user’s password. Current Password: The current password you used. -
Page 67: Security->Advanced
5.24.Security->Advanced Path: Web UI->Security->Advanced Sections Description Web Server Certificate To display or delete Certificate which is used when IP phone is connected from any incoming HTTPs request. Note: The default certificate could not be deleted. Web Server Certificate To upload a certificate file which will be used as server Upload certificate. -
Page 68: Troubleshooting
6. Troubleshooting Issue 1：The LCD does not light up Check the AC power adapter. Make sure it is the one provided in your package. Check the power outlet. Make sure that the power that outlet you are plugging your ... -
Page 69: Appendix:timezones
7. Appendix : Time Zones Time Zone Time Zone Name −11:00 Samoa −10:00 United States-Hawaii-Aleutian −10:00 United States-Alaska-Aleutian −09:00 United States-Alaska Time −08:00 Canada(Vancouver, Whitehorse) −08:00 Mexico(Tijuana, Mexicali) −08:00 United States-Pacific Time −07:00 Canada(Edmonton, Calgary) −07:00 Mexico(Mazatlan, Chihuahua) −07:00 United States-Mountain Time −07:00 United States-MST no DST −06:00... - Page 70 Time Zone Time Zone Name −03:00 Denmark-Greenland(Nuuk) −03:00 Argentina(Buenos Aires) −03:00 Brazil(no DST) −03:00 Brazil(DST) −02:00 Brazil(no DST) −01:00 Portugal(Azores) Greenland Denmark-Faroe Islands(Torshavn) Ireland(Dublin) Portugal(Lisboa, Porto, Funchal) Spain-Canary Islands(Las Palmas) United Kingdom(London) Morocco +01:00 Albania(Tirane) +01:00 Austria(Vienna) +01:00 Belgium(Brussels) +01:00 Caicos +01:00 Chatam...
- Page 71 Time Zone Time Zone Name +02:00 Finland(Helsinki) +02:00 Gaza Strip(Gaza) +02:00 Greece(Athens) +02:00 Israel(Tel Aviv) +02:00 Jordan(Amman) +02:00 Latvia(Riga) +02:00 Lebanon(Beirut) +02:00 Moldova(Kishinev) +02:00 Russia(Kaliningrad) +02:00 Romania(Bucharest) +02:00 Syria(Damascus) +02:00 Turkey(Ankara) +02:00 Ukraine(Kyiv, Odessa) +03:00 East Africa Time +03:00 Iraq(Baghdad) +03:00 Russia(Moscow) +03:30...
- Page 72 Time Zone Time Zone Name +08:00 China(Beijing) +08:00 Singapore(Singapore) +08:00 Australia(Perth) +09:00 Korea(Seoul) +09:00 Japan(Tokyo) +09:30 Australia(Adelaide) +09:30 Australia(Darwin) +10:00 Australia(Sydney, Melbourne, Canberra) +10:00 Australia(Brisbane) +10:00 Australia(Hobart) +10:00 Russia(Vladivostok) +10:30 Australia(Lord Howe Islands) +11:00 New Caledonia(Noumea) +12:00 New Zealand(Wellington, Auckland) +12:45 New Zealand(Chatham Islands) +13:00...
