- Page 1 Health & Safety, Use & Care, Installation Guide and Online Warranty Registration Information Model: IWSH6041CAUS IWSH9051CAUS IWHH9050CC www.whirlpool.com.au www.whirlpool.co.nz...
- Page 2 INDUCTION COOKTOP USE AND CARE GUIDE Dear User, Thank you for choosing our products. We are sure you will find your new appliance a pleasure to use. Before you use the appliance, we recommend that you read through these instructions carefully and retain for future reference. Design and specification may change due to product development, no prior notice will be given.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Safety Instructions Important To Be Read And Observed Download the complete instruction manual on Whirlpool official website or call the phone number shown on the official website. Before using the appliance, read these safety instructions. Keep them nearby for future reference.
- Page 4 should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. Permitted Use CAUTION: the appliance is not intended to be operated by means of an external switching device, such as a timer, or separate remote controlled system. This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments;...
- Page 5 The appliance must be installed and connected in accordance with current regulations.After unpacking the appliance, ensure there is no visible damage. If it has been damaged during transit, DO NOT USE, contact the "seller/ dealer/ Whirlpool After- Sales Service" immediately.
- Page 6 (mm) (mm) (mm) (mm) (mm) IWSH6041CAUS IWSH9051CAUS IWHH9050CC Under any circumstances, make sure the induction cooktop is well ventilated and the air inlet and outlet are not blocked. Ensure the induction cooktop is in good work state. As shown below: Note: The safety distance between the cooking zones and the cupboard above the cooking zones should be at least 760mm.
- Page 7 Installing the foam gasket Before inserting the cooktop into the opening in the kitchen worktop, the supplied foam gasket (in a plastic bag) must be attached to the lower side of the ceramic glass. Do not install the cooktop without the foam gasket! The gasket should be attached to the cooktop in the following method: •...
- Page 8 Fix cooktop to cabinet Insert the cooktop into the cabinet/work surface as below diagrams and the mounted clips on the sides can secure your cooktop sturdily. Connecting the cooktop to the mains power supply The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker.
- Page 9 For those model power cord without plug, the method of connections shown below. 380-415V 3N~ 380-415V 3N~...
- Page 10 OPERATION INSTRUCTIONS Model: IWSH6041CAUS 1. (Φ160mm) 1500W boost 2000W Cooking Zone 2. (Φ210mm) 2000W boost 3000W Cooking Zone 3. (Φ210mm) 2000W boost 3000W Cooking Zone 4. (Φ160mm) 1500W boost 2000W Cooking Zone 5. Control panel Control Panel 1. Booster function control button 2.
- Page 11 Model:IWSH9051CAUS 1. (Φ160mm) 1500W boost 2000W Cooking Zone 2. (Φ210mm) 2000W boost 3000W Cooking Zone 3. (Φ210mm) 2000W boost 3000W Cooking Zone 4. (Φ160mm) 1500W boost 2000W Cooking Zone 5. (Φ280mm) 2300W boost 3000W Cooking Zone 6. Control panel Control Panel 1.
- Page 12 Model: IWHH9050CC 1. (190*190mm) 1500W boost 2000W Cooking Zone 2. (190*190mm) 2000W boost 2600W Cooking Zone 3. (190*400mm) 3000W boost 3600W Left Flexicook Zone 4. (Φ280mm) 2300W boost 3000W Cooking Zone 5. (190*190mm) 2000W boost 2600W Cooking Zone 6. (190*190mm) 1500W boost 2000W Cooking Zone 7.
- Page 13 Even a thin film of water may make the controls difficult to operate. For IWSH6041CAUS, by touching the -/+ button of control panel to adjust on the power level and timer. For IWSH9051CAUS and IWHH9050CC, move your finger horizontally across the scroll keypad (Slider) to adjust on the power level and timer.
- Page 14 pure stainless steel, aluminum or copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware. • Induction cooktop are made from smooth ceramic glass, the heat comes from a magnetic induction coil which heats the cookware but not the cooking surface. The heat from the cookware is transferred to the food.
- Page 15 The cooking level indicator of the selected zone flashes, you may adjust its heat level as below: • For IWSH6041CAUS, adjust the heat setting by touching the power level -/+ button. • For IWSH9051CAUS, IWHH9050CC, adjust the heat setting by sliding the slider control.
- Page 16 To turn off cooktop 1. You can turn the cooking zone off by adjust the heat setting to level 0, which indicator shows“-“. 2. You can also turn the cooktop off by touching the ON/OFF control button. Note: If there is power cut off during cooking, all setting will be cancelled. Note: The cooling fan of induction cooktop will remain on for about 1 minute after the cooktop is turned off.
- Page 17 cookware originally was placed, and the part that is not covered by cookware is automatically switched off. Ideal for cooking with oval or rectangular pots or with pan supports. Important: Make sure to place the cookwares centered on the single cooking zone. In case of big pot,oval,rectangular and elon- gated pans make sure to place the pans centered on the cooking zone covering both cross.
- Page 18 If the cooktop is turned off without unlocking the Child Lock function, the Child Lock function will still remain active when the cooktop is turn on later. You will have to unlock first then the cooktop can be turned on. STOP &...
- Page 19 -/+button or sliding the scroll keypad. • To confirm, press the timer control button. • For IWSH6041CAUS, adjust timer by touching the timer -/+ button • For IWSH9051CAUS, IWHH9050CC, adjust timer by sliding the slider control.
- Page 20 • For IWSH9051CAUS, IWHH9050CC, adjust timer by sliding the slider control. timer up Note: By continuous touch the timer control button, the slider works at below consequence: “Single Digit-Tens Digit- Confirm Setting -Single Digit-…” 4. When the timer is set, it will begin to count down immediately, the display will show the remaining time.
- Page 21 RESIDUAL HEAT WARNING Beware of hot surfaces When the cooktop has been operating for some time, there will be some residual heat. The letter “ H ”appears in cooking level indicator to warn you to keep away from it. It can also be used as an energy saving function: If you want to heat up your pans, you may use the cooking zone when it is still hot.
- Page 22 Simmering, cooking rice • Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender stews because flavors develop without overcooking the food. You should also cook egg-based and flour thickened sauces below boiling point.
- Page 23 COOKING TABLE The cooking table offers an example of the cooking type for each power level. The actual delivered power of each power level depends on the cooking zone dimension. LEVEL USE Heat setting (indicating cooking experience and habits) Zero •...
- Page 24 CLEANING AND MAINTENANCE Important: Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from ELECTRICITY supply and ensure the appliances is completely cool. Cleaning the cooktop surface Clean spillages from the cooktop surface as soon as possible. Always ensure the surface is cool enough before cleaning.
- Page 25 Hints and Tips Important! What? How? Everyday 1.Switch off the power supply. •When turn off the power supply of soiling on glass 2.Apply a vitro-ceramic glass cooktop, there will be no ‘hot (fingerprints, cleaner while the glass is still surface’ indication but the cooking marks, stains warm (but not hot!) zone may still be hot! Take extreme...
- Page 26 TROUBLESHOOTING If there is a problem with the hob, please check the points listed below before calling for service: 1. There is no power to the appliance: -Check whether there is a power cut of your department; -Check whether the appliance is connected to the electricity properly; -Check whether the timer setting has elapsed;...
- Page 27 TECHNICAL SPECIFICATIONS Model No. IWSH6041CAUS Rated Voltage & Frequency 220-240V~ or 380-415V 3N~, 50-60Hz Rated Power 7200W Product Size 590*520*56mm Carton Size 635*568*113mm Net Weight 8.4kg Gross Weight 10.0kg Model No. IWSH9051CAUS Rated Voltage & Frequency 220-240V~ or 380-415V 3N~, 50-60Hz...
- Page 28 If an abnormality comes up, the induction cooktop will enter the protective state automatically and display corresponding protective codes: Problem Possible causes What to do Abnormal supply voltage Please check whether power supply E1/E2 is normal, Power on after the power supply is normal.
- Page 29 AFTER-SALES SERVICE To receive complete assistance, please register your product in your local market. Before calling the after-sale service: 1. See if you can solve the problem by yourself with the help of the TROUBLESHOOTING suggestions. 2. Switch the appliance off and on again to see if the fault persists. If after the above checks the fault still occurs, get in touch with the nearest after- sales service.
- Page 30 This QR Code is only applicable to New Zealand. You can download the user manual by You can download the user manual by Visiting our website www.whirlpool.com.au Visiting our website www.whirlpool.co.nz Contracting our Customer Service Center at 1300 363 344 Contracting our Customer Service Center at 0800 442 584 -http://www.whirlpool.com.au...
