- Page 1 CS-340 OWNER’S MANUAL Mobile Audio System • PLL Synthesizer Stereo Radio • Automatic Memory Storing • RDS (Radio Data System) Operation • Preset Equalization • Digital Compact Disc Player • Full Detachable Panel • Electronic Shockproof (ESP) Function • USB Interface...
-
Page 2: Table Of Contents
CONTENTS Installation ........3 MP3 operation .......14 Take out screw before installation...3 Switching to CD (MP3) mode ..14 DIN Front-Mount (Method A) ..3 Ejecting a disc ......14 Installing the unit ......3 Selecting tracks in single step..14 Removing the unit......4 Selecting directory up/down ..14 DIN Rear-Mount (Method B) ...5 Pausing playing ......14 Using the detachable front panel 6... -
Page 3: Installation
INSTALLATION Notes: TAKE OUT SCREW BEFORE INSTALLATION • Choose the mounting location where Before install the unit, please remove the the unit will not interfere with the two screws. normal driving function of the driver. Take out screw before installation •... -
Page 4: Removing The Unit
INSTALLATION Sleeve Note: to install the short threading terminal L Key of the mounting bolt to the back of the Outer Trim Ring unit and the other long threading terminal Front Panel to the dashboard. Spring Washer Hex Nut Metal Strap Mounting Bolt R Key Plain Washer... -
Page 5: Din Rear-Mount (Method B)
INSTALLATION DIN REAR-MOUNT (Method B) If your vehicle is a Nissan, Toyota, follow these mounting instructions. Use the screw holes marked T (Toyota), N (Nissan) located on both sides of the unit to fasten the unit to the factory radio mounting brackets supplied with your vehicle. -
Page 6: Using The Detachable Front Panel
USING THE DETACHABLE FRONT PANEL REMOVING THE FRONT PANEL Precautions when handing 1. Press the release button (OPEN) on 1. Do not drop the front panel. the front panel and pull off the front 2. Do not put pressure on the display or panel. -
Page 7: Wiring Connection
WIRING CONNECTION ISO Connection Rch RED AUX IN CABLE Lch WHITE (FOR AUX IN VERSION ONLY) SUBWOOFER CABLE BLUE GREEN Amplifier Turn On (FOR SUBWOOFER VERSION ONLY) Front Rch RED BROWN Front Lch WHITE Rear Rch RED GREY CDC SOCKET (FOR CDC VERSION ONLY) Rear Lch WHITE (FOR RCA LINE OUT VERSION ONLY) -
Page 8: Operation
OPERATION LOCATION OF KEYS... -
Page 9: Switching On/Off The Unit
OPERATION • SWITCHING ON/OFF THE UNIT - TA ALARM mode: Switch on the unit by pressing any When this mode is selected, no button (except release button automatic retune mode will be (7) and EJECT button (4)). When activated. Only a double beep sound system is on, press POWER button (ALARM) will be heard. -
Page 10: Loudness
OPERATION When the PI information is not found The beep is only generated when the during retune time, the radio starts to keys with double functions are retune to the next same PI station. pressed long (1 sec). When the same PI station is not found e.g. -
Page 11: Equalization
OPERATION • EQUALIZATION RADIO OPERATION • SWITCHING TO THE RADIO MODE Press the EQ button (19) to turn on Press MOD button (6) shortly to the equalization function and to select select the radio mode, the radio mode the desired audio mode. Five kinds appears in the display together with of modes are available: the memory band and frequency. -
Page 12: Rds (Radio Data System) Operation
OPERATION • RDS (RADIO DATA SYSTEM) - JAZZ, COUNTRY OPERATION - NATION M, OLDIES - Setting RDS Mode - FOLK M, Press AF (REG) button (3) and release SPEECH group it immediately to switch on or off RDS - NEWS, AFFAIRS, INFO mode. -
Page 13: Cd Operation
OPERATION EON TA LOCAL mode CD OPERATION When the field strength level of • SWITCHING TO CD MODE EON linked station is less than the If there is no CD inserted in the drive: threshold level, the radio does not Gently insert the CD with the printed switch to that station, and the side uppermost into the CD... -
Page 14: Mp3 Operation
OPERATION MP3 OPERATION the following modes: “Searching track directly” => • SWITCHING TO CD (MP3) MODE “Searching Directory or File Name”=> If there is no MP3 disc inserted in the “Navigation” from the root by the driver: TUNE/SEEK/TRACK UP/DOWN Gently insert the MP3 disc with the buttons=>... -
Page 15: Selecting Tracks By D-Aud Button
OPERATION - Press BND/LOU (ENT) button to KEY Assigned IN Searching mode (Table 1) confirm and start playback. - Repeat the above steps if the newly AS/PS Mode Select selected title is also a directory. BND/LOU ENTER Searching From the Root Directory Press D-AUD button (18) for three A, B, C, 1 times. -
Page 16: Usb Play Operation
OPERATION CAUTION: USB PLAY OPERATION When there are important files in the USB In the front panel of the unit, there is an device, do not connect it to the main unit USB interface (25). You can connect an to play. And don’t play the CD-R/RW disc USB driver through this interface (25). -
Page 17: Disc Notes
OPERATION DISC NOTE A. Notes on discs: 1. Attempting to use non-standard shape discs (e.g. square, star, heart) may damage the unit. Be sure to use round shape CD discs only for this unit. 2. Do not stick paper or tape etc., onto the label side or the recording side of any discs, as it may cause a malfunction. -
Page 18: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls - Bass (at 100 Hz) : ± 10 dB - Treble (at 10 KHz) : ± 10 dB Maximum Output Power : 4 x 40 Watts Current Drain... -
Page 19: Trouble Shooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution No power. The car ignition switch is If the power supply is not on.
