LCD Monitor
User Manual
C27G2Z3/BK
®
www.aoc.com
©2024 AOC. All Rights Reserved
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the C27G2Z3/BK and is the answer not in the manual?

Questions and answers

Related Manuals for AOC C27G2Z3/BK

Summary of Contents for AOC C27G2Z3/BK

  • Page 1 LCD Monitor User Manual C27G2Z3/BK ® www.aoc.com ©2024 AOC. All Rights Reserved...
  • Page 2 Safety ....................................1 National Conventions ............................1 Power ..................................2 Installation ................................3 Cleaning .................................4 Other ..................................5 Setup ....................................6 Contents in Box ..............................6 Setup Stand & Base ..............................7 Adjusting Viewing Angle .............................9 Connecting the Monitor ............................ 10 Wall Mounting ..............................11 Adaptive-Sync function ............................. 13 Adjusting ..................................
  • Page 3 Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.
  • Page 4 Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin.
  • Page 5 Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and use mounting accessories recommended by the manufacturer.
  • Page 6 Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product.
  • Page 7 Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.
  • Page 8 Monitor Quick Start Guide Warranty Card Stand Base Audio Cable HDMI Cable Power Cable DP Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
  • Page 9 Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove: Specification for base screw: M6*13 mm (effective thread 5.5 mm)
  • Page 10 Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: NOTE: Do not touch the LCD screen when you change the angle.
  • Page 11 Connecting the Monitor Cable Connections In Back of Monitor and Computer: 1. HDMI-2 2. HDMI-1 3. DP 4. Earphone 5. Power Connect to PC 1. Connect the power cord to the back of the display firmly. 2. Turn off your computer and unplug its power cable.
  • Page 12 Specification of wall hanger screws: M4*(10+X)mm, ( X=Thickness of Wall mount bracket ) M=4.0Max M4-P0.7 L=10+0 Dk=8.0±0.2 H=1.8±0.15 - 0.6 Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. Always contact manufacturer for wall-mount installation.
  • Page 13 0° 90° -5° * Display design may differ from those illustrated. Warning： 1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees. 2. Do not press the screen while adjusting the angle of the monitor. Grasp only the bezel.
  • Page 14 Adaptive-Sync function 1. Adaptive-Sync function is working with DP/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www. AMD.com Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™...
  • Page 15 Adjusting Hotkeys Source/Exit Game Mode/< Dial Point/> Menu/Enter Power Power Press the Power button to turn on the monitor. Menu/Enter When there is no OSD, Press to display the OSD or confirm the selection. Game Mode/< When there is no OSD, press ”<” key to open game mode function, then press ”<” or “>” key to select game mode (FPS, RTS, Racing, Gamer 1, Gamer 2 or Gamer 3) basing on the different game types.
  • Page 16 OSD Setting Basic and simple instruction on the control keys. Luminance Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness HDR Mode Eco mode Standard 1). Press the MENU-button to activate the OSD window. 2).
  • Page 17 Luminance Luminance Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness Eco mode Standard HDR Mode Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment Standard Standard Mode Text Text Mode Internet Internet Mode Eco mode Game Game Mode...
  • Page 18 Color Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Luminance Color Temp. User DCB Mode Green DCB Demo Blue Recall Warm Color Temperature from Warm EEPROM. Recall Normal Color Temperature from Normal EEPROM. Recall Cool Color Temperature from Cool EEPROM.
  • Page 19 Picture Boost Picture Boost OSD Setup Extra Exit Luminance Game Setting Color Setup Bright Frame Brightness H. Position Frame Size Contrast V. Position Bright Frame on or off Disable or Enable Bright Frame Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast...
  • Page 20 OSD Setup Extra Exit Luminance OSD Setup Game Setting Color Setup Picture Boost Language English H. Position Transparence V. Position Timeout Break Reminder DP Capability 1.2/1.4 Volume Language Select the OSD language Timeout 5-120 Adjust the OSD Timeout Please be noted that only DP1.2/1.4 support DP Capability 1.1/1.2/1.4 Adaptive-Sync function...
  • Page 21 Game Setting Game Setting Extra Exit Luminance Picture Boost OSD Setup Color Setup Game Mode Game Color Adaptive-Sync Shadow Control LowBlue Mode Frame Counter Low Input Lag Overdrive For playing FPS (First Person Shooters) games. Improves dark theme black level details. For playing RTS (Real Time Strategy).
  • Page 22 Extra Game Setting Extra Exit Luminance Picture Boost OSD Setup Color Setup Input Select Auto DDC/CI Resolution : 1920(H)X1080(V) HDR Off Timer Reset H. Frequency : 67KHz Overclock Image Ratio Wide V. Frequency : 60Hz Input Select Select Input Signal Source Off timer 0-24hrs Select DC off time...
  • Page 23 Exit Luminance Picture Boost OSD Setup Color Setup Game Setting Extra Exit Exit Exit the main OSD LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange...
  • Page 24 Press hot-key (AUTO) to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual or www.aoc.com (to find the model you purchase in your Regulation & Service country and to find Regulation & Service Information in Support...
  • Page 25 Specification General Specification Model name C27G2Z3/BK Driving system TFT Color LCD Panel Viewable Image Size 68.6 cm diagonal Pixel pitch 0.3114mm(H) x 0.3114mm(V) Display Color 16.7M Colors 30k-280kHz (HDMI) Horizontal scan range 30k-320kHz (DP) Horizontal scan Size(Maximum) 597.888 mm 48-250Hz (HDMI)
  • Page 26 Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION (+/-1Hz) FREQUENCY(kHz) FREQUENCY(Hz) 640x480@60Hz 31.469 59.94 640x480@67Hz 66.667 640x480@72Hz 37.861 72.809 640x480@75Hz 37.5 640x480@100Hz 51.08 99.769 640x480@120Hz 61.91 119.518 DOS MODE 720x400@70Hz 31.469 70.087 DOS MODE 720x480@60Hz 29.855 59.710 720x576@50Hz 31.25 SVGA 800x600@56Hz 35.156 56.25 SVGA...
  • Page 27 Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-...
  • Page 28 Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
