VOGELS EFWE 6455 RC Parts List

EFWE 6455 RC
Part number Partname
0801627 SINGLEDOOS EFW6445/6455
0802644 INTERIEUR EPS EFWE6455RC
0803615 OMDOOS EFW6445/6455
0805617 GEBRUIKSAANWIJZING EFWE6455
0806205 SLEEVE EFWE6455RC
0870019 REMOTE CONTROL EFWE6455RC
0870020 MOTOR & MCU
0870021 EFWE6455 KABELSET EU
0870022 EFWE6455 KABELSET UK
0884030 HEX FLANGE BOLT M8X10 DIN6921
0886027 ADAPTER BAR DOP A
0886028 ADAPTER BAR DOP B
0886064 ADAPTER AFDEKKAP C4 ANTHR
0890026 GUIDE END CAP
0890027 HINGE ARM LEFT
0890028 HINGE ARM RIGHT
0890029 COVER DRIVING ARM
0890034 INTERFACE ROD
0890049 COVER WALL PLATE EFWE6455
0896006 SAM ZAKJE ADAPTER C3
0896011 SAM ZAKJE SONY/PANASONIC C3
0896019 SAM ZAKJE EFWE6455RC
0995811 MOER M8 DIN557 VIERKANT
0999065 PLAKSTRIP IR EFWE6455RC
0999932 SONY/PHILIPS SERVICE KIT 2
Only the items mentioned in this table are available as spare part
Parts list
English description
single box
packaging interior
outer box
manual
packaging sleeve
remote control
motor & mcu
cables EU
cables UK
hex flange bolt M8X10
ANTHR adapter bar cover
ANTHR adapter bar cover
adapter cover
guide end cap
hinge arm
hinge arm
cover driving arm
interface rod
cover wall plate
fastener bag
fastener bag
fastener bag
bolt M8
tape for infrared module
service kit
Glider (8326504)
Letter in
exploded view
-
-
-
-
-
-
-
-
-
Q
U
U
P
-
Y
Y
-
S
N
II
III
I
R
-
IV
