Installation Instructions
If you have questions, call 1.800.GE.CARES or visit our website at: GEAppliances.com.
In Canada, call 1.800.561.3344 or visit our website at: geappliances.ca
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
•
local inspector's use.
IMPORTANT –
•
and ordinances.
Note to Installer –
•
instructions with the Consumer.
Note to Consumer –
•
for future reference.
• Skill level
basic mechanical skills.
• Completion time
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
WATER SUPPLY TO THE ICE
MAKER
(on some models)
be connected to a cold water line. A water supply
kit (containing copper tubing, shutoff valve, fittings
and instructions) is available at extra cost from your
dealer, by visiting our Website at GEAppliances.
com (in Canada at geappliances.ca) or from Parts
and Accessories, 1.877.959.8688. See instructions
REFRIGERATOR LOCATION
•
will go below 55°F (12.7°C) because it will not run
often enough to maintain proper temperatures.
compartment can be installed at temperatures at,
but not below, 38°F (3.3°C).
•
temperature will go above 110°F (43.3°C)
because it will not perform properly.
•
to water (rain, etc.) or direct sunlight.
loaded.
10
Save these instructions for
Observe all governing codes
Be sure to leave these
15 minutes
15 minutes
Models 16, 17, 18, 19, & 22
CLEARANCES
Allow the following clearances for ease of installation,
proper air circulation and plumbing and electrical
connections.
• Back 1" (25 mm) on 16 & 17 cuft models
ROLLERS AND LEVELING LEGS
Leveling legs near each front corner of the refrigerator
are adjustable. They firmly position the refrigerator
and prevent it from moving when the doors are
opened. Leveling legs should be set so the front of
the refrigerator is raised just enough that the doors
close easily when opened about halfway.
Turn the leveling legs clockwise to raise the
refrigerator, counterclockwise to lower it.
Rollers next to the leveling legs allow you to move the
refrigerator away from the wall for cleaning.
Turn the legs counterclockwise until the weight of the
refrigerator is transferred from them to the rollers.
After rolling the refrigerator back into place, turn the
legs clockwise until the legs again bear the weight of
the refrigerator.
