Summary of Contents for LG SolarDOM MP-9485ST
- Page 1 Kombigerät "SolarDOM" LIGHT OVEN "SolarDOM" BEDIENUNGSANLEITUNG OWNER’S MANUAL LESEN SIE DIESE BEDIENUNGSANLEITUNG VOR DER INBETRIEBNAHME AUFMERKSAM DURCH. PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MP-9485ST P/No: 3828W5A4634...
- Page 2 Precautions Precautions to avoid possible exposure to excessive microwave energy. You cannot operate your oven with the door open due to the safety interlocks When heating liquids, e.g. soups, sauces and beverages in your oven with built into the door mechanism. These safety interlocks automatically switch off microwave function, delayed eruptive boiling can occur without evidence of bubbling.
- Page 3 Contents Precautions How the Microwave Function Works Contents Microwaves are a form of energy similar to radio and television waves and Unpacking & Installing 38 ~ 39 ordinary daylight. Normally, microwaves spread outwards as they travel Control Panel through the atmosphere and disappear without effect. This ovens, however, Setting the Clock have a magnetron which is designed to make use of the energy in Child Lock...
- Page 4 Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing.
- Page 5 Plug your oven into a standard household socket. Make Press the Stop/Korr. button, and press the sure your oven is the only appliance connected to the Start button one time to set 30 seconds of socket. If your oven does not operate properly, unplug it cooking time.
- Page 6 Control Panel 1. Uhr: You can set the time of day. 8. Bestätigen: You can determine the selected cooking category, microwave power level or temperature. 2. Heißluft: You can select temperature and time of convection. 9. Auftauen: You can select the food type and the weight of the food. 3.
- Page 7 Setting the You can set either12 hour clock or 24 hour clock. Clock In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book.
- Page 8 Child Lock Press Stop/Korr. Press and hold Stop/Korr. until “L” appears on the display and Your oven has a safety feature that BEEP sounds. prevents accidental running of the oven. The CHILD LOCK is now set. Once the child lock is set, you will be unable to use any functions and no The time will disappear on the display but will reappear on cooking can take place.
- Page 9 Convection In the following example I will show you how to use the convection to cook some food for 50 minutes for 220˚C Cooking temp. 1. To Preheat 2. To Cook The convection oven has a temperature range of 40°C and 100°C~250°C Press Stop/Korr.
- Page 10 Speed Combi In the following example I will show you how to programme your oven with micro power 360W and grill for a Cooking cooking time of 25 minutes. Speed Combi Press Stop/Korr. (Co-1, 2, 3) Press Kombi to select grill combination mode(Co-1, 2, 3). Your oven has a combination cooking feature which allows you to cook food with heater and microwave at the same...
- Page 11 Speed Combi In the following example I will show you how to programme your oven with micro power 360W and at a Cooking temperature 200˚C for a cooking time of 25 minutes. Speed Combi Press Stop/Korr. (Co-4) Press Kombi to select speed combination mode(Co-4). You can set four kinds of micro power level(0W, 180W, 360W, 600W) in speed combi mode(Co-4).
- Page 12 Speed Combi In the following example I will show you how to programme your oven with:- micro power 360W and at a Cooking convection temperature 200 °C for a cooking time of 25 minutes. Speed Combi Press Stop/Korr. (Co-5) Press Kombi to select convection combination mode. Turn Dial knob until display shows “Co-5”.
- Page 13 Speed Auto In the following example I will show you how to cook 0.4kg of frozen pizza(SC 1). Cooking Press Stop/Korr. Press Automatik Programme. Speed auto cook menus are programmed. Speed auto cook allows you to cook most of your favorite food quickly by selecting the food type and the weight of the food.
- Page 14 Speed Auto In the following example I will show you how to cook 0.6kg of jacket potatoes(SC 8). Cooking Press Stop/Korr. Press Automatik Programme. SPEED AUTO COOK allows you to cook most of your favorite food quickly by selecting the food type and the weight of the food.
- Page 15 SPEED AUTO COOK GUIDE Weight Instructions Category Function Utensil Food Temp. Limit SC 1 Frozen 0.30~0.50kg Metal tray Frozen This function is for cooking frozen pizza. Remove all package and place Speed auto cook pizza on the metal tray. After cooking, stand for 1~2 minutes. SC 2 French 0.20~0.75kg...
- Page 16 SPEED AUTO COOK GUIDE Weight Instructions Category Function Utensil Food Temp. Limit SC 7 Roast 0.80~1.80kg Low rack Refrigerated Brush the beef with melted margarine or butter. Place on the low rack. Speed auto cook Beef + Metal tray When BEEP, turn food over. And then press start to continue cooking.
- Page 17 SPEED AUTO COOK GUIDE Weight Instructions Category Function Utensil Food Temp. Limit SC 12 Rice / 0.10~0.30kg Metal tray + Room Place rice/pasta and boiling water with to 1 teaspoon salt in a deep Speed auto 1 / 4 cook Pasta Microwave- and large bowl(3L).
- Page 18 Defrost The temperature and density of food varies, I would recommend that the food be checked before cooking commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still slightly frozen.
- Page 19 Defrosting Guide * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the metal tray. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls.
- Page 20 Grill In the following example I will show you how to use the Grill-1 to cook some food for 12 minutes and 30 Cooking seconds. Press Stop/Korr. Press Grill to select grill mode. This feature will allow you to brown and crisp food quickly.
- Page 21 Micro Power In the following example I will show you how to cook some food on 600W power for 5 minutes and 30 Cooking seconds. Make sure that you have correctly installed your oven as described earlier in this book. Press Stop/Korr.
- Page 22 Micro Power This oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. The table Level below shows the examples of food and their recommended cooking power levels for use with this oven. OUTPUT ACCESSORY POWER LEVEL 900W...
- Page 23 Two stage In the following example I will show you how to cook some food in two stages. The first stages will cook your Cooking food for 11 minutes on HIGH(900W); the second will cook for 35 minutes on 360W. Press Stop/Korr.
- Page 24 Quick In the following example I will show you how to set 2 minutes of cooking on high power(900W). Start Press Stop/Korr. Press Start/Schnellstart four times to select 2 minutes on HIGH The Quick Start feature allows you to set power(900W).
- Page 25 More or Less In the following example I will show you how to change the preset SPEED AUTO COOK programmes Cooking for a longer or shorter cooking time. Press Stop/Korr. Set the required Automatik programme programme. If you find that your food is over or *See SPEED AUTO COOK (page.
- Page 26 Test dishes in accordance with EN 60705 Microwave setting the watts, Type of heating Function Meal Notes Cooking time in minutes Temperature in ˚C Microwave Meat 600 watts, 1-2 Place a flat plate on the metal tray. Defrosting + 90 watts, 5-7 Turn over after 600 watts, 1-2 minutes.
- Page 27 WARNING Important safety instructions Please ensure cooking times are correctly set as over cooking may result in FIRE and subsequent Read carefully and keep for future reference DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any adjustments or repairs to the 12 Before cooking, pierce the skin of potatoes, apples or any such fruit or door, control panel, safety interlock switches or any other part of the oven.
- Page 28 Important safety instructions Read carefully and keep for future reference 24 Only use utensils that are suitable for use in microwave ovens. 38 Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering 25 When heating food in plastic or paper containers, keep an eye on the oven of the glass.
- Page 29 Microwave-safe Utensils Never use metal or metal trimmed utensils in using microwave function Paper Microwaves cannot penetrate metal. They will bounce off any metal object in Paper plates and containers are convenient and safe to use in using the oven and cause arcing, an alarming phenomenon that resembles microwave function, provided that the cooking time is short and foods to be lightning.
- Page 30 Food characteristics & Microwave cooking Keeping an eye on things Moisture content of food The recipes in the book have been formulated with great care, but your success in Since the heat generated from microwaves tends to evaporate moisture, relatively dry food preparing them depends on how much attention you pay to the food as it cooks.
- Page 31 Food characteristics & Microwave cooking Stirring To Clean Your Oven Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred for the purpose of blending. Microwaved food, however, is stirred 1 Keep the inside of the oven clean in order to spread and redistribute heat.
- Page 32 Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to cook popcorn in this oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown below Relay is failed...
- Page 33 Plug wiring information/ Technical Specifications Warning Technical Specification MP-9485ST This appliance must be earthed Power Input 230 V AC / 50Hz The wires in this mains lead are colored in accordance with the Output 900 W (IEC60705 rating standard) following codes Microwave Frequency 2450 MHz BLUE ~ Neutral...
- Page 34 Memo...
- Page 35 Memo...
- Page 36 4. For more detailed information about disposal of your old appliance, please contact your city office, waste disposal service or the shop where you purchased the product. LG Electronics Deutschland GmbH Jakob-Kaiser-Str.12 Printed in Korea D-47877, Willich...
