BB-3000W-KDS
Wireless Bump Bar
User Manual
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
This device and its antenna(s) must not be co-located or operating in conjunction with
any other antenna or transmitter.
BB-3000W-KDS Ver. A0
1
Advertisement
Table of Contents
Related Manuals for POSIFLEX BB-3000W-KDS
Summary of Contents for POSIFLEX BB-3000W-KDS
- Page 1 (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. BB-3000W-KDS Ver. A0...
- Page 2 SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants. BATTERY WARNING Risk of explosion if battery is replaced by an incorrect type. Dispose of expended battery in accordance with local disposal regulations.
- Page 3 BB-3000W-KDS Wireless Bump Bar User Manual Package Contents BB-3000W-KDS Bump Bar……………...x1 USB Dongle……………………….....x1 Battery………………........x2 Views of the Wireless Bump Bar Top View Bottom View Screw Holes Battery Cover...
- Page 4 Each BB-3000W-KDS bump bar is configured with one of the 100 predetermined channels and should be paired with the USB dongle that has the matching channel number. To avoid channel conflict, do not use BB-3000W-KDS bump bars with duplicate channel number in the same setup.
- Page 5 USB dongle attached to the working terminal as long as the channel number on the USB dongle is the same as that on the BB-3000W-KDS bump bar; if the channel number on the USB dongle is different from that on the BB-3000W-KDS bump bar, the pairing will fail.
-
Page 6: Installation Considerations
USB dongle and bump bar increase, the range decreases. For best results, the bump bar should be positioned and the key pad side of the BB-3000W-KDS bump bar had better be located toward the USB dongle connected to your host terminal as possible as you can. - Page 7 Installing the VCOM Driver and Utility If your BB-3000W-KDS works in the HID mode, you do not need to install any driver but install the utility for BB-3000W-KDS; if your BB-3000W-KDS works in the VCOM mode, please install the VCOM driver first.
- Page 8 3. Now, you enter the programing area. Start to program your BB-3000W- KDS. On the utility, there are 4 menus – File, Config, Test, and Help. File: By clicking the File menu, you can open a configured and saved file (.tpl) and save a file (.tpl) you have configured for the bump bar.
- Page 9 To get more detailed information on key programming, contact directly the Posiflex' technical service team. Setting up USB Dongle The USB dongle for BB-3000W-KDS bump bar can be set up through the utility that is installed. 1. Double click the “Posiflex BB3000W Setup Tool”...
- Page 10 Test Mode: This Test Mode option is provided for technical users to test the BB-3000W-KDS with a default test code. After finishing in doing the setting, tap the Writing Setting button.
- Page 11 Serial No. & Channel No. Before changing the channel number and serial number of your dongle, note that the numbers of the dongle must be the same as those of your BB-3000W-KDS keyboard. To change the channel number and serial...
- Page 12 Keep the BB-3000W-KDS bump bar away from another one working in the same channel at a site. To check whether a serial number in the same channel which the dongle works is given during operation of the BB- 3000W, tick off the Show Serial Number item.
- Page 13 Measuring the Received Signal Strength of the BB-3000W-KDS The tool is well designed and provided for you to easily measure the received signal strength of the BB-3000W-KDS. 1. Double click the “Posiflex BB3000W Setup Tool” icon. 2. Select BB3000W RSSI Measure (1) and then click Open (2).
-
Page 14: Regular Cleaning
The quality levels are classified into Signal Good, Signal Normal, and Signal Bad. Always keep the BB-3000W-KDS bump bar working in the quality level of Signal Normal. 7. To measure the received signal strength of the BB-3000W-KDS again, tap Retry. -
Page 15: Specifications
Specifications General 100% true spill-proof structure, state of the art top Construction notch solid design, 10 programmable keys with 2 x 5 matrix Key Switch Type Tact switch for 2 x 5 keys. Key Stroke Travel 0.35 mm +/- 0.1 mm Key Size 20 x 14 mm (2 x 5 keys) 2 x 5 keys as: SERVE / RREV / RECALL / SIDE... - Page 16 Mechanical Dimensions 209.0 mm (W) x 95.0 mm (D) x 30.5 mm (H) Weight 540g (not including battery cells) Environmental Operating temperature 0°C to +40°C Storage temperature -35°C to +80°C Relative humidity 10 to 90%; 5 to 90%, non-condensing Vibration Shock Reliability Information Push key switch...
