Yamaha Star XV19CB 2011 Owner's Manual

Hide thumbs

100

page of 100

/ 100
Bookmarks

Quick Links

Download this manual

Read this manual carefully before operating this vehicle.

OWNER'S MANUAL

XV19CB(C)

LIT-11626-25-52

1US-28199-10

Need help?

Do you have a question about the Star XV19CB 2011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Yamaha Star XV19CB 2011

Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL XV19CB(C) LIT-11626-25-52 1US-28199-10...
Page 2 EAU10042 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
Page 4 IMPORTANT MANUAL INFORMATION EAU10133 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
Page 5 IMPORTANT MANUAL INFORMATION EAU10193 XV19CB(C) OWNER’S MANUAL ©2011 by Yamaha Motor Corporation, U.S.A. 1st edition, August 2011 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.
Page 6 TABLE OF CONTENTS LOCATION OF IMPORTANT EXUP system ....... 4-16 Forged wheels ......7-16 LABELS ..........1-1 Sidestand ........4-16 Clutch lever ........7-17 Ignition circuit cut-off system ..4-17 Checking the brake lever free SAFETY INFORMATION ....2-1 Auxiliary DC connector ....4-19 play ...........
Page 7 Matte color caution ......8-1 Care ..........8-1 Storage ...........8-4 SPECIFICATIONS ......9-1 CONSUMER INFORMATION...10-1 Identification numbers ....10-1 Reporting safety defects ....10-3 Motorcycle noise regulation ..10-4 Maintenance record ......10-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ......10-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ........10-9...
Page 8 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer. 1,2,3...
Page 9 LOCATION OF IMPORTANT LABELS 2 California only VACUUM HOSE ROUTING PRESS. SENSOR INTAKE MANIFOLD 34B-21684-00 3 California only WARNING EMISSION HOSE ROUTING BEFORE YOU OPERATE THIS VEHICLE, READ THE OWNER’S MANUAL AND ALL LABELS. THROTTLE BODY FUEL TANK ALWAYS WEAR AN APPROVED MOTORCYCLE HELMET, eye protection, and protective clothing.
Page 10 SAFETY INFORMATION EAU10289 Safe Riding • Ride where other motorists can Perform the pre-operation checks each see you. Avoid riding in another time you use the vehicle to make sure it motorist’s blind spot. Be a Responsible Owner is in safe operating condition. Failure to ●...
Page 11 SAFETY INFORMATION ● ● due to excessive speed or under- This motorcycle is designed for on- A passenger should also observe cornering (insufficient lean angle road use only. It is not suitable for the above precautions. for the speed). off-road use. •...
Page 12 Yamaha accessories, which are avail- of the motorcycle is changed. To avoid to minimize imbalance or instabili- able only from a Yamaha dealer, have the possibility of an accident, use ex- been designed, tested, and approved treme caution when adding cargo or ●...
Page 13 • Accessories fitted to the handle- ● Use caution when adding electri- genuine Yamaha accessories, recog- bar or the front fork area can cal accessories. If electrical acces- nize that some aftermarket accessories...
Page 14 SAFETY INFORMATION ● Check that the fuel cock (if equipped) is in the “OFF” position and that there are no fuel leaks. ● Point the front wheel straight ahead on the trailer or in the truck bed, and choke it in a rail to pre- vent movement.
Page 15 DESCRIPTION EAU10410 Left view 3,4 5 1. Headlight (page 7-29) 9. Engine oil drain bolt B (crankcase) (page 7-10) 2. Seat lock (page 4-12) 10.Engine oil drain bolt A (crankcase) (page 7-10) 3. Main fuse (page 7-27) 11.Shift pedal (page 4-7) 4.
Page 16 DESCRIPTION EAU10420 Right view 2,3,4 5 1. Helmet holder (page 4-13) 9. Rear brake light switch (page 7-18) 2. Rear brake fluid reservoir (page 7-19) 10.Engine oil filter cartridge (page 7-10) 3. Fuel injection system fuse (page 7-27) 11.Engine oil drain bolt (oil tank) (page 7-10) 4.
Page 17 DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 4-7) 9. Brake lever (page 4-8) 2. Left handlebar switches (page 4-5) 3. Clutch fluid reservoir (page 7-19) 4. Multi-function meter unit (page 4-2) 5. Main switch (page 4-1) 6. Front brake fluid reservoir (page 7-19) 7.
Page 18 INSTRUMENT AND CONTROL FUNCTIONS EAU10450 EAU45751 EAU49391 Main switch Indicator lights and warning All electrical systems are off. The key lights can be removed. EWA10072 WARNING Never turn the key to “OFF” while the vehicle is moving, otherwise the electrical systems will be switched off, which may result in loss of con- trol or an accident.
Page 19 3.0 seconds. If this oc- EAU44598 Multi-function meter unit High beam indicator light “ ” curs, have a Yamaha dealer check the This indicator light comes on when the vehicle. high beam of the headlight is switched EAU11534 Engine trouble warning light “...
Page 20 INSTRUMENT AND CONTROL FUNCTIONS ● two tripmeters (which show the Fuel gauge distance traveled since they were last set to zero) 160 60 ● a fuel reserve tripmeter (which shows the distance traveled on the fuel reserve) km/h ● a clock ●...
Page 21 INSTRUMENT AND CONTROL FUNCTIONS F-TRIP → TRIP A → TRIP B → ODO Odometer, tripmeters, fuel reserve 3. Push the “SELECT” switch, and → F-TRIP tripmeter and clock the minute digits will start flashing. To reset a tripmeter, select it by push- 4.
Page 22 If the odometer/tripmeter/clock display To set the brightness EAU1234A Handlebar switches indicates any error codes, note the 1. Turn the key to “OFF”. code number, and then have a Yamaha 2. Push and hold the “SELECT” Left dealer check the vehicle. switch. ECA11590 3.
Page 23 This model can be equipped with op- control mode of the multi-function lights will self-cancel after the vehicle tional lights available at a Yamaha meter unit. has traveled both about 150 m (490 ft) dealer.
Page 24 INSTRUMENT AND CONTROL FUNCTIONS See “Multi-function meter unit” on page EAU12820 EAU12871 Clutch lever Shift pedal 4-2 for detailed information. 1. Clutch lever 1. Shift pedal The clutch lever is located at the left The shift pedal is located on the left handlebar grip.
Page 25 INSTRUMENT AND CONTROL FUNCTIONS EAU12891 EAU12941 EAU13122 Brake lever Brake pedal Fuel tank cap 1. Brake lever 1. Brake pedal 1. Fuel tank cap lock cover 2. “ ” mark The brake lever is located on the right The brake pedal is on the right side of 3.
Page 26 INSTRUMENT AND CONTROL FUNCTIONS 2. Turn the key counterclockwise to EAU13212 Fuel the original position, remove it, and Make sure there is sufficient gasoline in then close the lock cover. the tank. EWA10881 WARNING The fuel tank cap cannot be installed unless the key is in the lock.
Page 27 ● Check the fuel tank breather/over- flow hose for cracks or damage, Your Yamaha engine has been de- and replace it if damaged. signed to use premium unleaded gaso- ● Make sure that the end of the fuel...
Page 28 INSTRUMENT AND CONTROL FUNCTIONS EAU13445 ECA10701 EAU44460 Catalytic converters Steering lock NOTICE This vehicle is equipped with catalytic Use only unleaded gasoline. The use converters in the exhaust system. of leaded gasoline will cause unre- EWA10862 pairable damage to the catalytic WARNING converter.
Page 29 INSTRUMENT AND CONTROL FUNCTIONS To unlock the steering EAU52251 Rider seat To remove the rider seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 2. Seat holder 1. Unlock. 2. Push the front of the seat down to 1.
Page 30 INSTRUMENT AND CONTROL FUNCTIONS Water and harsh sunlight can damage 5. Remove the protective covers be- EAU44441 Helmet holder leather. Use the protective seat covers fore riding. Press down firmly on provided when parking in the rain or the seat when turning the key. where dew is expected, when washing the vehicle, and when parking for ex- tended periods in strong sunlight.
Page 31 INSTRUMENT AND CONTROL FUNCTIONS To release the helmet from the hel- EAU38405 Adjusting the shock absorber met holder assembly Remove the rider seat, remove the hel- This shock absorber assembly is met holding cable from the helmet hold- equipped with a spring preload adjust- er and the helmet, and then install the ing nut.
Page 32 INSTRUMENT AND CONTROL FUNCTIONS load and thereby soften the sus- Spring preload: pension, turn the adjusting nut in Minimum (soft): direction (b). Distance A = 172 mm (6.77 in) Standard: ● To make the adjustment, use Distance A = 172 mm (6.77 in) the special wrench and exten- Maximum (hard): sion bar included in the addi-...
Page 33 EAU15305 EXUP system Sidestand sorber assembly to an open This model is equipped with Yamaha’s The sidestand is located on the left side flame or other high heat source. EXUP (EXhaust Ultimate Power valve) of the frame. Raise the sidestand or This may cause the unit to ex- system.
Page 34 INSTRUMENT AND CONTROL FUNCTIONS this system regularly and have a EAU44892 Ignition circuit cut-off system Yamaha dealer repair it if it does not The ignition circuit cut-off system (com- function properly. prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
Page 35 INSTRUMENT AND CONTROL FUNCTIONS WARNING With the engine turned off: 1. Move the sidestand down. If a malfunction is noted, have a Yamaha 2. Make sure that the engine stop switch is set to “ ”. dealer check the system before riding.
Page 36 INSTRUMENT AND CONTROL FUNCTIONS EAU44586 Auxiliary DC connector EWA12531 WARNING To prevent electrical shock or short- circuiting, make sure that the cap is installed when the auxiliary DC con- nector is not being used. ECA15311 NOTICE 1. Battery band 1. Wire harness protective cover The accessory connected to the 2.
Page 37 • Check vehicle for oil leakage. Transfer case oil • Check vehicle for oil leakage. 7-13 • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 7-19, 7-19 •...
Page 38 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-14, 7-22 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables 7-22 •...
Page 39 FOR YOUR SAFETY – PRE-OPERATION CHECKS ITEM CHECKS PAGE Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-16 • If system is not working correctly, have Yamaha dealer check vehicle.
Page 40 ● a lean angle sensor to stop the en- understand, ask your Yamaha dealer. ● The transmission is in the neutral gine in case of a turnover. In this EWA10271 position.
Page 41 The neutral indicator light should come on. If not, ask a ● Even with the transmission in Yamaha dealer to check the elec- the neutral position, do not trical circuit. coast for long periods of time 3. Start the engine by pushing the with the engine off, and do not start switch.
Page 42 OPERATION AND IMPORTANT RIDING POINTS 4. At the recommended shift points 3. Shift the transmission into the neu- EAU16841 Engine break-in shown in the following table, close tral position when the motorcycle There is never a more important period the throttle, and at the same time, is almost completely stopped.
Page 43 If any engine trouble should occur ans or children are not likely to during the engine break-in period, touch them and be burned. immediately have a Yamaha dealer ● Do not park on a slope or on soft check the vehicle.
Page 44 – possibly leading to pending on the weather, terrain, geo- that is certified (if applicable). Yamaha death. See page 2-2 for more in- graphical location, and individual use, dealers are trained and equipped to...
Page 45 If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you.
Page 46 From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. ● Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the service. EAU17601 Periodic maintenance chart for the emission control system...
Page 47 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Evaporative emis-...
Page 48 PERIODIC MAINTENANCE AND ADJUSTMENT EAU32186 General maintenance and lubrication chart INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months...
Page 49 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Swingarm pivot...
Page 50 Front and rear brake √ √ √ √ √ √ 25 * • Check operation. switches • Apply Yamaha chain and cable √ √ √ √ √ √ 26 * Control cables lube or engine oil thoroughly. • Check operation.
Page 51 PERIODIC MAINTENANCE AND ADJUSTMENT INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Lights, signals and...
Page 52 Do not attempt to diagnose 0.8–0.9 mm (0.031–0.035 in) such problems yourself. Instead, have a Yamaha dealer check the vehicle. Clean the surface of the spark plug If a spark plug shows signs of electrode gasket and its mating surface, and then...
Page 53 PERIODIC MAINTENANCE AND ADJUSTMENT EAU19681 EAU3836A completely cooled down, and then Canister (for California only) Engine oil and oil filter car- warmed up again for several minutes to tridge normal operating temperature. The engine oil level should be checked THROTTLE BODY FUEL TANK 4.
Page 54 PERIODIC MAINTENANCE AND ADJUSTMENT ECA10900 NOTICE Make sure that the oil filler cap is se- curely tightened, otherwise oil may seep out when the engine is run- ning. To change the engine oil (with or without oil filter cartridge replace- ment) 1.
Page 55 An oil filter wrench is available at a Yamaha dealer. Tightening torques: Engine oil drain bolt A (crankcase): 9. Apply a thin coat of clean engine 32 Nm (3.2 m·kgf, 23 ft·lbf)
Page 56 “CD” or oils of a high- changed by a Yamaha dealer at the in- 14. Remove the engine oil filler cap, er quality than specified. In...
Page 57 To prevent this Have a Yamaha dealer replace the air from occurring, the valve clearance filter element. must be adjusted by a Yamaha dealer at the intervals specified in the periodic maintenance and lubrication chart.
Page 58 (i.e., when the temperature cause an accident. tact a Yamaha dealer immediately and of the tires equals the ambient have the tire replaced. temperature).
Page 59 Manufacturer/model: for cracks, bends, warpage or related wheel parts replacement METZELER/ME880 MARATHON damage before each ride. If any should also be left to a Yamaha Rear tire: damage is found, have a Yamaha Size: dealer. dealer replace the wheel. Do not 210/40R18M/C 73H ●...
Page 60 If there is air Tightening torques: in the hydraulic system, have a Valve stem nut: Yamaha dealer bleed the system be- 2.0 Nm (0.20 m·kgf, 1.4 ft·lbf) Valve stem locknut: fore operating the motorcycle.
Page 61 If there is free play, come on just before braking takes ef- have a Yamaha dealer inspect the fect. If necessary, adjust the rear brake brake system. light switch as follows, but the front...
Page 62 EAU38631 Checking the front and rear Checking the brake and clutch peared, have a Yamaha dealer replace brake pads fluid levels the brake pads as a set. The front and rear brake pads must be...
Page 63 ● Refill with the same type of or clutch fluid level goes down sudden- ly, have a Yamaha dealer check the brake fluid. Adding a brake fluid cause before further riding. other than DOT 4 may result in a 1.
Page 64 The drive belt slack should be checked applied to the belt with a belt ten- and adjusted at the intervals specified Have a Yamaha dealer change the sion gauge as shown. in the periodic maintenance and lubri- brake and clutch fluids at the intervals cation chart.
Page 65 5. If the drive belt slack is incorrect, EAU23095 EAU49920 Checking and lubricating the Checking and lubricating the have a Yamaha dealer adjust it. cables throttle grip and cable The operation of all control cables and The operation of the throttle grip should the condition of the cables should be be checked before each ride.
Page 66 PERIODIC MAINTENANCE AND ADJUSTMENT EAU44273 EAU43601 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...
Page 67 The operation of the sidestand should The pivoting points of the rear suspen- be checked before each ride, and the sion must be lubricated by a Yamaha sidestand pivot and metal-to-metal dealer at the intervals specified in the contact surfaces should be lubricated if periodic maintenance and lubrication necessary.
Page 68 WARNING! To avoid injury, of it falling over. have a Yamaha dealer check or re- [EWA10751] securely support the vehicle so 2. Hold the lower ends of the front pair it.
Page 69 WARNING To charge the battery ● Electrolyte is poisonous and Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to furic acid, which causes severe have discharged. Keep in mind that the burns.
Page 70 PERIODIC MAINTENANCE AND ADJUSTMENT battery tends to discharge more quickly is turned to “OFF”, then con- EAU42584 Replacing the fuses if the vehicle is equipped with optional nect the positive lead before The main fuse, the fuel injection system electrical accessories. connecting the negative lead.
Page 71 8. Spare fuse the electrical circuit in question to check if the device operates. 5. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. 6. Install the battery cover, and then hook the battery band onto the holder.
Page 72 PERIODIC MAINTENANCE AND ADJUSTMENT EAU48513 Replacing the headlight bulb This model is equipped with a halogen bulb headlight. If the headlight bulb burns out, replace it as follows. ECA10650 NOTICE Take care not to damage the follow- ing parts: ● Headlight bulb 1.
Page 73 2. Screw 1. “TOP” mark 2. Remove the burnt-out bulb by pushing it in and turning it counter- 6. Install the headlight unit by install- clockwise. ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. 7-30...
Page 74 PERIODIC MAINTENANCE AND ADJUSTMENT EAU24324 Replacing a license plate light bulb 1. Remove the license plate light unit by removing the nuts, washers and rubber dampers. 1. Turn signal light bulb 1. Nut 2. Washer 3. Insert a new bulb into the socket, 3.
Page 75 However, should your motorcycle To service the front wheel require any repair, take it to a Yamaha 1. Stabilize the rear of the motorcycle dealer, whose skilled technicians have by using a motorcycle stand or, if...
Page 76 PERIODIC MAINTENANCE AND ADJUSTMENT heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or property damage. 7-33...
Page 77 Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the battery. 4. Battery The engine turns over The battery is good.
Page 78 Rust and corrosion can develop matte colored finished parts. Be 4. Remove extremely stubborn dirt, sure to consult a Yamaha dealer for even if high-quality components are like oil burnt onto the crankcase, advice on what products to use be- used.
Page 79 MOTORCYCLE CARE AND STORAGE ● Improper cleaning can damage electric components (couplers, After riding in the rain, near the sea or plastic parts (such as cowlings, connectors, instruments, on salt-sprayed roads panels, windshields, headlight switches and lights), breather Since sea salt or salt sprayed on roads lenses, meter lenses, etc.) and hoses and vents.
Page 80 EWA11131 WARNING Contaminants on the brakes or tires ● Consult a Yamaha dealer for ad- can cause loss of control. vice on what products to use. ● Make sure that there is no oil or wax on the brakes or tires.
Page 81 MOTORCYCLE CARE AND STORAGE EAU44453 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps Storage stabilizer (if available) to prevent from the spark plugs, and then the fuel tank from rusting and the install the spark plugs and the Short-term fuel from deteriorating.
Page 82 MOTORCYCLE CARE AND STORAGE Make any necessary repairs before storing the motorcycle.
Page 83 SPECIFICATIONS Dimensions: Engine oil: Fuel: Overall length: Recommended brand: Recommended fuel: 2572 mm (101.3 in) YAMALUBE Premium unleaded gasoline only Overall width: Type: Fuel tank capacity: 925 mm (36.4 in) SAE 10W-30, 10W-40, 10W-50, 15W-40, 15.9 L (4.20 US gal, 3.50 Imp.gal) Overall height: 20W-40 or 20W-50 Fuel reserve amount:...
Page 84 SPECIFICATIONS Gear ratio: Loading: Specified brake fluid: 1st: DOT 4 Maximum load: 2.375 (38/16) Rear brake: 195 kg (430 lb) 2nd: (Total weight of rider, passenger, cargo and Type: 1.571 (33/21) accessories) Single disc brake 3rd: Tire air pressure (measured on cold Operation: 1.160 (29/25) Right foot operation...
Page 85 SPECIFICATIONS Headlight: Ignition fuse: 20.0 A Bulb type: ECU fuse: Halogen bulb Bulb voltage, wattage × quantity: 15.0 A Fuel injection system fuse: Headlight: 12 V, 60 W/55 W × 1 15.0 A Auxiliary DC connector fuse: Tail/brake light: 3.0 A Backup fuse: Front turn signal/position light: 12 V, 23 W/8.0 W ×...
Page 86 Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER: 1.
Page 87 This information illustration. This label shows specifica- will be needed when ordering spare tions related to exhaust emissions as parts from a Yamaha dealer. required by federal law, state law and Environment Canada. 10-2...
Page 88 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Page 89 CONSUMER INFORMATION EAU26560 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
Page 90 CONSUMER INFORMATION EAU26632 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
Page 91 CONSUMER INFORMATION Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-6...
Page 92 CONSUMER INFORMATION EAU26663 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this Engine new Yamaha motorcycles will be free from defects in warranty shall be to: Displacement Period...
Page 93 CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.
Page 94 This excellent Y.E.S. plan coverage is only available to dealer to see how comforting uninterrupted factory- Yamaha owners like you, and only while your Yamaha is still backed protection can be. within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts.
Page 95 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
Page 96 INDEX Fuel............4-9 Fuel level warning light ......4-2 Air filter element ........7-14 Parking ............6-4 Fuel tank breather/overflow hose ..4-10 Auxiliary DC connector ......4-19 Part locations .......... 3-1 Fuel tank cap .......... 4-8 Fuses, replacing ........7-27 Battery...........
Page 97 INDEX Turn signal light bulb, replacing.... 7-30 Turn signal switch........4-6 Valve clearance ........7-14 Vehicle Emission Control Information label......... 10-2 Vehicle identification number....10-1 Warranty, extended ......10-9 Warranty, limited........10-7 Wheel bearings, checking ....7-26 Wheels..........7-16...
Page 99 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
Page 100 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2011.10-0.5×1 CR...
