BW-90-3RGBW DXX-RL User Manual Please read the instructions carefully before use...
Page 2
CONTENTS ................... 2 1. Safety Instructions ..................4 2. Technical Specfications ..................5 3. How To Set The Unit ................... 5 3.1 Control Panel ..................6 3.2. Main Functions ................. 12 4. How To Control The Unit ..........12 4.1 Master/Slave Built In Preprogrammed Function ..................
Page 3
1. Safety Instructions Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Caution:...
Page 4
bare-hand during its operation. Never run on for a long time lest shortening lifespan. Avoid any inflammable liquids, water or metal objects entering the unit. Once it happened, cut off the mains power immediately. DO NOT operate in dirty and dusty environment, also cleaning fixtures regularly. DO NOT allow children to operate the fixture.
Page 5
2. Technical Specfications 3 DMX Channel Modes: 4/5/7 Channels Mode. Digital Display for Address and Function Setting. VD-T Controller for Channel Mode and Address Setting. Built-in Master/Slave preprogram function. Voltage: AC 100~240V, 50/60Hz Power consumption: 246W Light source: 90pcs x 3W CREE LED (R: 20pcs;...
Page 6
3. How To Set The Unit 3.1 Control Panel ① Display and Button: Display: To show the menu and the selected functions Button: MENU To select the programming functions DOWN To go backward in the selected functions To go forward in the selected functions ENTER To confirm the selected functions ②...
Page 7
④ DMX output: Water proof connectors for DMX 512 operation, 3-pin XLR cable to output DMX signal ⑤ Connect to lamp panel: ⑥ Nut for Omega Clamp: When using the fixture as fixed installation at outdoor place, please remove the Nut for Omega Clamp to avoid rusting 3.2.
Page 9
DMX 512 Address Setting 1. Press the MENU button until is displayed. Press ENTER to confirm. 2. The current address will now be displayed and flashing. Press the UP or DOWN buttons to find your desired address. When you have found your desired DMX address press ENTER to confirm or automatically exit menu mode without any change after one minute.
Page 10
Color Setup 1. Press the MENU button until is displayed. Press ENTER to confirm, will now be displayed, press ENTER, use the UP or DOWN button to adjust to your desired intensity (0~255). Press ENTER after the intensity adjustment. 2. After you press ENTER then press UP and will be displayed, press ENTER, Use the UP or DOWN buttons to adjust the value from 0 to 255.
Page 11
Cipher Setup 1. Press the MENU button until is displayed. Press ENTER. will now be displayed and flashing. Press the UP or DOWN button to adjust the password (0~9999) to your desire. 3. When you find your desired password, press ENTER to confirm or automatically exit menu mode without any change after one minute.
Page 12
(Display inversion). If you want to return back to (Normal), press ENTER button again. LED Mode 1. Press the MENU button until is displayed, Press ENTER to confirm. 2. The display will show either . Select to keep display on at all times, or to switch to have the LED display switch off after 60 seconds.
Page 13
2. By DMX controller (For the BW-90-3RGBW DXX-RL) 3. By VD-T VD-T is a specially designed handy setup tool for all Visio integral fixtures and Controllers. By connecting VD-T to any fixture via XLR, you can easily setup DMX Address, Channel Modes, White Balance, Manual Colors, and Fade Speed functions.
Page 14
button again. Please refer to the following diagram to address your DMX512 channel for the first 4 units: 4 Channels: 4D Channels: : 4C Channels...
Page 16
4.4 DMX512 connections 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
Page 17
5. Each lighting unit needs to have an address set to receive the data sent by the controller. The address number is between 0-511 (usually 0 & 1 are equal to 1). 6. The end of the DMX 512 system should be terminated to reduce signal errors. 7.
Page 18
may cause damage or interference to DMX interface circuit. 6. Fixture Cleaning The cleaning of internal must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
