Related Manuals for LG XL5T
Summary of Contents for LG XL5T
- Page 1 OWNER’S MANUAL Portable Bluetooth Speaker Please read this manual carefully before operating your set and retain it for future reference. Model XL5T www.lg.com 2407_Rev01 Copyright © 2024 LG Electronics Inc. All Rights Reserved.
- Page 2 Portable Bluetooth Speaker Quick Guide Connecting and Using the Speaker ECHO 1 ECHO 2 <Android> <iOS> A Handle B Controls C Flash Lighting D Speaker (Tweeter) E Speaker (Woofer) / Woofer Lighting a Connect the power cord to the product by opening the rear cover and charge it before use...
- Page 3 Connecting to the LG XBOOM App ([ See “Installing app” on page 17.) A Find the LG XBOOM app on the Google Play or App Store and install it on your smartphone. B Run the LG XBOOM app and use its functions. (EQ, Wireless Party Link, Lighting, Setting etc.) e Power Saving ([ See “Power Saving Mode”...
- Page 4 Connecting Smartphone to the Speaker Reporting Malfunction via Bluetooth 38 Troubleshooting Connecting with two smartphones Appendix Connecting to the LG XBOOM 40 Product Specifications Registered Trademarks and Licenses Installing app 42 Handling the Product Using the Wireless Party Link Connecting to USB...
- Page 5 Changes sound effect. ([ See “Setting Sound Effects” on page 25.) b Lighting Press the button to select the desired Woofer Lighting. • You can customize the Woofer Lighting mode as you want by connecting to the LG XBOOM app. • If you press and hold the Lighting button for 2 seconds with product, turn the Woofer Lighting, Flash lighting off.
- Page 6 h Function Press the button repeatedly to select the desired input mode or function. • BT: It connects the product via Bluetooth. • USB: It connects the product to a USB storage device. • Press the Function button on the product repeatedly to select the BT function. ([ See “Connecting Smartphone to the Speaker via Bluetooth”...
- Page 7 Back a MIC Turns the knob to the right (+) or left (-) to adjust the Microphone sound volume. Connect a microphone to the MIC jack. b GUITAR Turns the knob to the right (+) or left (-) to adjust the Guitar sound volume. Connect a guitar to the GUITAR jack.
- Page 8 > CAUTION • Be careful not to drop the product when you carry it. • Disconnect the connected cable before carrying the product. • Do not step or sit on the product. Otherwise this product may fall down and cause personal injury. • Be careful that the product should not fall down.
- Page 9 Charge Charging the Battery This product has a built-in battery. Make sure to charge the battery sufficiently before use. a Open the back cover and plug the power cable into the product. b Plug the power cable connected to the product into an outlet. Note • It takes about 3.5 hours to fully charge the speaker.
- Page 10 Attaching the ferrite core (optional) A ferrite core may not be provided depending on national standards. Attaching the ferrite core to the power cord cable Attach the ferrite core to the cable to reduce radio noise. a Pull Part [a] to open the ferrite core. b Wind the power cord cable twice around the ferrite core.
- Page 11 Checking Battery Status Charging Status When the battery of the product starts charging, you can see the charging status in the battery LED. Battery LED LED Status / Battery Status It is green. / Charging is complete. It is red. / Charging is in progress. Note • Playing tracks while charging may lengthen the charging time.
- Page 12 Connecting to Bluetooth Connecting Smartphone to the Speaker via Bluetooth You can play music files stored on a Bluetooth device, or run music apps to enjoy the music with this product. Please check the following first. • The following are the Bluetooth specifications of the product. - Bluetooth version: 5.1 - Codec: SBC, AAC • How to connect the device to the product may differ depending on the type and model of the...
- Page 13 (iPhone) d Turn on the Bluetooth function. ( Off > e You will see a list of connectable devices on the smartphone screen. Find and tap the name “LG- XL5T(XX)”. Bluetooth LG Smart Phone AVAILABLE DEVICES LG Smat Phone LG-XL5T(XX)
- Page 14 • When using Bluetooth, adjust the volume of the Bluetooth device to an appropriate level. • XX are the last two digits of the Bluetooth address. An example would be “LG-XL5T(08).” • When power is connected to this product, if you try to connect to the product via a Bluetooth product with a connection history, the product will automatically turn on and connect to the Bluetooth device.
- Page 15 Connecting with two smartphones Pairing (Connecting) Multiple Phones a Connect the product and a smartphone first. ([ See “Connecting Smartphone to the Speaker via Bluetooth” on page 12.) b Press and hold the Function button on the product for 2 seconds. The BT LED blinks for 60 seconds.
- Page 16 d When two smartphones and the product are connected, the BT LED turns on. PARTY LINK PARTY LINK Note • Multi-phone pairing (connecting) connects up to two smartphones. • Even if two smartphones are connected, the product plays music only on one smartphone. If the music stops on the currently played smartphone, it can be played on another smartphone.
- Page 17 Installing app Use the various functions of the speaker on the LG XBOOM app. To install the LG XBOOM app, scan the QR code with an app or install LG XBOOM app on the Google Play or App Store. Please check the following first.
- Page 18 • Google, Android, and Google Play are trademarks of Google LLC. • The software of this product can be updated with the LG XBOOM app. Do not turn off the power of the product while updating the software. Once the update is complete, the product power turns off automatically.
- Page 19 Using the Wireless Party Link You can connect multiple speakers in the LG XBOOM app's Wireless Party Link. There are two ways for using the Wireless Party Link: Dual mode and Multi mode. Dual mode Wireless Party Link Dual mode lets you enjoy stereo sound with two same model speakers.
- Page 20 In the TV settings, find and select the main speaker within 60 seconds. You can listen to the TV sound through two speakers. Note • When using in dual mode with a TV, you cannot control the speakers with the LG XBOOM app. Multi mode Wireless Party Link Multi mode lets you enjoy more powerful sound with multiple speakers.
- Page 21 Note • The Main speaker connects only one Bluetooth device. • When using Dual/Multi mode to connect multiple speakers, the multi phone pairing connection is not supported. • When you turn the speakers off and on again, the speakers do not automatically reconnect. • When you connect multiple speakers in Dual/Multi mode in USB function, it will change to Bluetooth function.
- Page 22 Interworking multiple speakers This speaker interworks with other LG Bluetooth speakers such as XL7T/XL5T. Same model Dual mode (e.g. XL5T/XL5T) Main/Other Volume Lighting Auto Power Management Same series Multi mode (e.g. XL5T/XL7T) Main/Other Lighting Auto Power Management...
- Page 23 Connecting to USB Connecting the product to a USB storage device You can enjoy sound by connecting a USB storage device with music files to the product. a Open the back cover of the product and plug the USB storage device into the USB terminal. • The product cannot play any devices connected with a USB storage device hub or a USB storage device cable.
- Page 24 Note • USB devices with large storage volume can take several minutes or more to browse files. • LG Electronics is not responsible for any data loss. Please always back up the data to minimise damage caused by data loss.
- Page 25 Standard / You can enjoy High-fidelity sound with balanced and natural. Custom / You can adjust the sound as you want. If you want to use Custom EQ, connect to the LG XBOOM app. SOUND BOOST / You can enjoy the wide sound field and powerful sound.
- Page 26 Resetting the product You can reset the product when it operates improperly. a Open the back cover of the product and use a sharp object to press the RESET button to power off the product. b Turn on by pressing the Power button.
- Page 27 Note • You can turn this function on and off with the LG XBOOM app only. Voice feedback function When you select a function or sound, the current status of the product is guided by voice. (English voice only) You can turn this function on and off with the LG XBOOM app.
- Page 28 Use of Tripod You can mount the product on a tripod. The tripod is an optional purchase. > CAUTION • Extend the tripod legs as much as possible and tighten up the screw securely. • Before connecting with the product, you must set up the tripod completely to prevent shaking. • You should work together with two or more people when connecting the product and the tripod.
- Page 29 c Lift the product and connect the tripod to fixing part on the bottom of the product.
- Page 30 Note • If you use a tripod, use the tripod only for product. • Use tripod as below : - From tripod’s center to tripod’s leg : above 700 mm - From top of tripod to bottom of tripod : below 1100 mm - Stand pole size : Φ 35 mm • For safe use, set the tripod as low as possible.
- Page 31 Safety Precautions Safety and Regulatory CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER- SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
- Page 32 CAUTION concerning the Power Cord The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily accessible. Check the specification page of this owner’s manual to be certain of the current requirements. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous.
- Page 33 For models using a battery This device is equipped with a portable battery or accumulator. CAUTION: Risk of fire or explosion if the battery is replaced by an incorrect type. For models using a built-in battery Do not store or transport at pressures lower than 11.6 kPa and at above 15,000 m altitude. • replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types);...
- Page 34 Prevention of product misuse To prevent misuse of the product, please be sure to check the contents below. Precautions for installing the product • Do not install the product in an unstable or vibrating place, such as on a shaking shelf or inclined surface.
- Page 35 Precautions for using the product • Do not lift or move the product while it is operating. - Otherwise, it may cause a breakdown. • When moving the product, pull out the power cord and all cables connected to the product. - Otherwise, it may cause a fire or electric shock.
- Page 36 - Otherwise, it may negatively affect your hearing ability. • The software of this product can be updated with the LG XBOOM app. Do not turn off the power of the product while updating the software. Once the update is complete, the product power turns off automatically.
- Page 37 The following only applies to models with a remote control • Do not let children use the remote control. Keep the remote control out of reach of toddlers. • Do not let children put the remote control in their mouth. Make sure that children don’t swallow the remote control cover or a battery.
- Page 38 Things to Check before Reporting Malfunction Troubleshooting If you experience the following symptoms while using the product, please check them again. They may not be malfunctions. Symptom Cause and Solution Power is not • The battery is discharged. Recharge the battery. supplied.
- Page 39 • Use this product in a place where the temperature and humidity are not too normally. high or low. If the problem continues, contact LG Electronics’ Customer Service Centre. • If a problem occurs while charging the battery of the product, the battery LED alternates between red and amber and charging stops.
- Page 40 Appendix Product Specifications General Refer to the main label. Power requirements Built-in rechargeable battery Power consumption Refer to the main label. Dimensions (W x H x D) Approx. 289 mm X 570 mm X 280 mm Operating Temperature 5 °C - 35 °C Operating Humidity 5 % - 80 % RH Ingress protection...
- Page 41 All trademarks and trade names are owned by their respective owners. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.
- Page 42 Handling the Product When shipping the Product Please save the original shipping carton and packing materials. If you need to ship the product, for maximum protection, re-pack the product as it was originally packed at the factory. Keeping the exterior surfaces clean • Do not use volatile liquids such as insecticide spray near the product.
