OWNER'S MANUAL
Portable Bluetooth
Speaker
Please read this manual carefully before operating your set and retain it for
future reference.
MODEL
XG8T
www.lg.com
2307_Rev01
Copyright © 2023 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XG8T and is the answer not in the manual?

Questions and answers

Related Manuals for LG XG8T

Summary of Contents for LG XG8T

  • Page 1 OWNER’S MANUAL Portable Bluetooth Speaker Please read this manual carefully before operating your set and retain it for future reference. MODEL XG8T www.lg.com 2307_Rev01 Copyright © 2023 LG Electronics Inc. All Rights Reserved.
  • Page 2 Portable Bluetooth Speaker Quick Guide Connecting and Using the Speaker 5 V 0 2 A DC IN a Charge the speaker before using it by opening the rear cover and connecting the speaker to the charging adapter.
  • Page 3 (Off > On C Find "LG-XG8T (XX)" on the device list on the smartphone and connect to it. Once the smartphone is connected via Bluetooth, the Bluetooth LED will turn on. D On the smartphone, play a music of your choice.

  • Page 4: Table Of Contents

    Bluetooth Connecting Two Bluetooth Devices to the Speaker Talking on the Phone Hands-free 20 Using Voice command Connecting to the LG XBOOM Installing app 23 Using the Wireless Party Link Additional Functions 27 Setting Sound Effects 28 Charging a smartphone...

  • Page 5: Exploring The Product

    Exploring the Product Front a Battery LED Please check the battery charging level and battery status. ([ See “Checking Battery Status” on page 13.) • Press and hold the Power button for 2 seconds to check the battery level while the power or the speaker is on.
  • Page 6 e Play/Pause While Bluetooth is connected, press the button to operate the Bluetooth device. • Play/Pause: Press the button. • Moving to the next music: Press the button twice quickly. • Moving to the previous music: Press the button three times quickly. • Using the Hands-Free function: Press the button in Bluetooth function when you receive a call from a device connected via Bluetooth.

  • Page 7: Back

    SERVICE ONLY For service only d Side Lighting LED You can change the effect of Side Lighting and turn it on or off in the LG XBOOM app. e Back Cover Make sure to fully close the back cover after use.

  • Page 8: Carrying The Unit

    Carrying the unit To use on the shoulder a Remove the hook attached to the provided strap in the direction shown in the picture. b Place the speaker facing the front as shown in the picture, and insert both straps with the padded part of the strap facing down.
  • Page 9 d With the hooks at both ends of the strap fastened, pull the middle part of the strap all the way up. e You can be worn over the shoulder.
  • Page 10 To use for handheld a Remove the hook attached to the provided strap in the direction shown in the picture. b Place the speaker facing the front as shown in the picture, and insert both straps with the padded part of the strap facing down. c Insert the long part of the hook into the ends of both straps as shown in the picture.
  • Page 11 d With the hooks on both ends of the strap, pull both ends of the strap to flatten them. e After facing the strap in the direction shown in the picture, hang each hook. f Once the hook fastening is complete, you can easily carry it by hand and use it.

  • Page 12: Charge

    Charge Charging the Battery The speaker is a built-in battery. Make sure to charge the battery sufficiently before use. a Open the back cover and plug the AC adapter into the DC IN terminal. b Plug the power cable into the AC adapter. c Plug the power cable connected to the AC adapter into an outlet.

  • Page 13: Checking Battery Status

    Checking Battery Status Charging Status Once the battery charging starts, the battery LED indicates the charging status. LED Status / Battery Status It is green. / Charging is complete. It is red. / Charging is in progress. Note • Playing tracks while charging may lengthen the charging time. • When the speaker’s battery is fully charged with the power off, the battery LED lights up green for 15 seconds and then off.
  • Page 14 Use Status When you turn on the speaker or press and hold the Power button for 2 seconds, the battery LED is turned on for 3 seconds according to the battery status. LED Status / Battery Status Turns on in green. / The battery level is above 70 %. Turns on in amber.

  • Page 15: Connecting To Bluetooth

    Connecting to Bluetooth Connecting Smartphone to the Speaker via Bluetooth You can play tracks or run a music app on a Bluetooth device and enjoy the sounds through the speaker. Please check the following first. • The speaker’s Bluetooth specifications are as follows: - Bluetooth version: 5.1 - Bluetooth codec: SBC, AAC • This product supports Bluetooth devices such as smartphones and laptops.
  • Page 16 Bluetooth. (Android Phone) (iPhone) c Turn on the Bluetooth function. (Off > On d You will see a list of connectable devices on the smartphone screen. Find and tap “LG-XG8T (XX)". Bluetooth LG Smart Phone AVAILABLE DEVICES LG-XG8T (XX) LG Smart Phone...
  • Page 17 • When the product is charging, if you try to connect to the product via the Bluetooth device with a connection history, the product will automatically turn on and connect to the Bluetooth device. You can control this function in the LG XBOOM app. ([ See “Using Auto power - on.” on page 32.)

  • Page 18: Connecting Two Bluetooth Devices To The Speaker

    Connecting Two Bluetooth Devices to the Speaker Multi phone pairing a Connect one Bluetooth device to the speaker first. ([ See “Connecting Smartphone to the Speaker via Bluetooth” on page 15.) b When the Bluetooth device and speaker are connected, press the Bluetooth button.

  • Page 19: Talking On The Phone Hands-Free

    Talking on the Phone Hands-free a Connect a smart device to the speaker. ([ See “Connecting Smartphone to the Speaker via Bluetooth” on page 15.) b You can use the Hands-Free function by operating as in the table below. Function How to Use Receiving phone call Press the Play/Pause...

  • Page 20: Using Voice Command

    Using Voice command You can turn on the Google Assistant or Siri function on your smartphone and use voice command through the speaker’s microphone. Please check the following first. • Use a smart device that provides a voice command function. • This function may not work depending on the Bluetooth device.

  • Page 21: Connecting To The Lg Xboom App

    Installing app Use the various functions of the speaker on the LG XBOOM app. To install the LG XBOOM app, scan the QR code with an app or install LG XBOOM on the Google Play or App Store. Please check the following first.
  • Page 22 Downloading in Google Play or App Store a Find the LG XBOOM app on the Google Play or App Store and install it on your smartphone. (Android™ Phone) (iPhone) b Connect the smartphone to the speaker via Bluetooth. ([ See “Connecting Smartphone to the Speaker via Bluetooth”...

  • Page 23: Using The Wireless Party Link

    Using the Wireless Party Link You can connect multiple speakers in the LG XBOOM app's Wireless Party Link. There are two ways for using the Wireless Party Link: Dual mode and Multi mode. Dual mode Wireless Party Link Dual mode lets you enjoy stereo sound with the same two speakers.
  • Page 24 In the TV settings, find and select the main speaker within 60 seconds. You can listen to the TV sound through two speakers. Note • When using in dual mode with a TV, you cannot control the speakers with the LG XBOOM app. Multi mode Wireless Party Link Multi mode lets you enjoy more powerful sound with multiple speakers.
  • Page 25 Note • The Main speaker connects only one Bluetooth device. • When using Dual/Multi mode to connect multiple speakers, the multi phone pairing connection is not supported. • When you turn the speakers off and on again, the speakers do not automatically reconnect. • You can only use the Main speaker for calls or voice commands.
  • Page 26 Interworking multiple speakers This speaker interworks with other LG Bluetooth speakers such as XG8T/XG9Q/XG7Q/XG5Q and XO3Q. Same model Dual mode (e.g. XG8T/XG8T) Main/Other Volume Lighting Auto Power Management Sleep Timer Same series Multi mode (XG8T/XG9Q/XG7Q/XG5Q) Main/Other Lighting Auto Power Management...

  • Page 27: Additional Functions

    Additional Functions Setting Sound Effects You can select a desired sound effect by using SOUND BOOST button. SOUND BOOST LED ( Off / Function / Description Standard / You can enjoy High-fidelity sound with balanced and natural. SOUND BOOST / You can enjoy the wide sound field and powerful sound.

  • Page 28: Charging A Smartphone

    Charging a smartphone Use the USB cable to charge your smartphone like a spare battery for the speaker. Please check the following first. • The method of charging your smartphone differs depending on the device. Refer to your smartphone's manual. a Open the back cover of the speaker and connect the smartphone to the DC OUT (5 V 0 2 A) terminal via the USB cable.
  • Page 29 5 V 0 2 A DC IN Power input / Speaker status Smartphone charging Disconnected / Power On Disconnected / Power Off Note • When charging the smartphone by speaker, the battery of speaker is consumed. • Charging of devices other than smartphones cannot be guaranteed. • *If the Auto Power Management function is enabled when the power input is disconnected, the smartphone is not charged when the speaker is turned off.

  • Page 30: Resetting The Speaker

    Resetting the Speaker You can reset the speaker when it operates improperly. a Press and hold the Power and SOUND BOOST buttons on the speaker for 7 seconds SOUND BOOST simultaneously. Then the speaker will turn off automatically. b Turn on by pressing the Power button.

  • Page 31: Using Auto Power Management

    • The Power LED will blink five times with beep sound. Note • You can enable or disable this function on the LG XBOOM app. • When using the Wireless Party Link, the Auto Power Management time works for 15 minutes (plugged in) or 6 hours (not plugged in) depending on the charging cable connection status of the Main speaker.

  • Page 32: Using Auto Power - On

    • You can turn this function on and off with the LG XBOOM app only. How to deactivate the wireless network connection(s). Set up the [Auto power-on.] to off on LG XBOOM app and turn off the product by pressing the Power button.

  • Page 33: Safety Precautions

    Safety Precautions Safety and Regulatory CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 34 CAUTION concerning the Power Cord The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily accessible. Check the specification page of this owner’s manual to be certain of the current requirements. Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous.
  • Page 35 For models using a battery This device is equipped with a portable battery or accumulator. CAUTION: Risk of fire or explosion if the battery is replaced by an incorrect type. For models using a built-in battery Do not store or transport at pressures lower than 11.6 kPa and at above 15,000 m altitude. • Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types);...

  • Page 36: Prevention Of Product Misuse

    Prevention of product misuse To prevent misuse of the product, please be sure to check the contents below. Precautions for installing the product • Do not install the product in an unstable or vibrating place, such as on a shaking shelf or inclined surface.
  • Page 37 Precautions for using the product • Do not lift or move the product while it is operating. - Otherwise, it may cause a breakdown. • When moving the product, pull out the power cord and all cables connected to the product. - Otherwise, it may cause a fire or electric shock.
  • Page 38 - Otherwise, it may negatively affect your hearing ability. • The software of this product can be updated with the LG XBOOM app. Do not turn off the power of the product while updating the software. Once the update is complete, the product power turns off automatically.
  • Page 39 The following only applies to models with a remote control • Do not let children use the remote control. Keep the remote control out of reach of toddlers. • Do not let children put the remote control in their mouth. Make sure that children don’t swallow the remote control cover or a battery.

  • Page 40: Before Reporting Product Malfunction

    • Use this product in a place where the temperature and humidity are not too normally. high or low. If the problem continues, contact LG Electronics’ Customer Service Centre. • Power LED and Bluetooth LED blink when the speaker malfunction occurs and the speaker does not operate normally.

  • Page 41: Appendix

    Appendix Specifications General 19 V 0 3.42 A (AC adapter) Power Supply Built-in rechargeable battery Power consumption Refer to the main label. • Model: DA-65F19 • Manufacturer: Asian Power Devices Inc. AC adapter • Input: 100-240 V ~ 50/60 Hz • Output: 19 V 0 3.42 A Dimensions (W x H x D) Approx.

  • Page 42: Registered Trademarks And Licenses

    All trademarks and trade names are the property of their respective owners. The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.

  • Page 43: Handling The Product

    Handling the Product When shipping the Product Please save the original shipping carton and packing materials. If you need to ship the product, for maximum protection, re-pack the product as it was originally packed at the factory. Keeping the exterior surfaces clean • Do not use volatile liquids such as insecticide spray near the product.
