USER'S MANUAL AND OPERATING INSTRUCTIONS
For product
registration
READ INSTRUCTIONS CAREFULLY:
Read and follow all instructions. Place
instructions in a safe place for future ref-
erence. Do not allow anyone who has
not read these instructions to assemble,
light, adjust or operate the heater.
PORTABLE PROPANE HEATER FOR
OUTDOOR, EMERGENCY INDOOR,
AND RECREATIONAL ENCLOSURES
FOR US SALE EXCEPT
MASSACHUSETTS
WARNING
FIRE OR EXPLOSION HAZARD
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect fuel supply.
4. Leave the area immediately.
5. Allow gas to dissipate 5 minutes before
relighting the appliance.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Failure to follow these instructions could result
in fire or explosion, which could cause property
damage, personal injury, or death.
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 877-447-4768 8:30 a.m. – 4:30 pm CST, Monday – Friday
Model #
GG18BK
GG10BK
GG18G
GG10G
GG18O
GG10O
GG18R
GG10R
Regulator
1 lb. DOT Approved Cylinder
Tank
CONSUMER: Retain this manual for future reference.
or email us at customerservice@ghpgroupinc.com
www.ghpgroupinc.com
RADIANT HEATER
GG10RE
GG10GE
GG18RE
GG18GE
Grab 'N Go 10K
Portable Heater
CARBON MONOXIDE POISONING
MAY CAUSE DEATH OR INJURY
When used without adequate combustion and
ventilation air, heater may give off excessive CARBON
MONOXIDE, an odorless, poisonous gas.
This is an unvented gas-fired heater. The heater uses
air (oxygen) from the area in which the heater is used.
Adequate combustion and ventilation air must be
provided. (Refer to page 4)
This heater is equipped with a SAFETY SYSTEM designed to
turn off the heater if not enough fresh air is available.
DO NOT TAMPER WITH THE SAFETY SYSTEM!
If the heater shuts off, do not relight until you provide fresh air.
PIKOT FLAME
PILOT AIR HOLE
If heater keeps shutting off, have the heater serviced. Keep
burner and control compartment clean.
1
1
GRAB 'N GO
US
ANSI Z21.103-2017 Unvented portable type
gas camp heaters for indoor and outdoor use
Regulator
Fuel Filter &
Hose Kit #
HAKITDG
Grab 'N Go 18K
Portable Heater
WARNING
PILOT
POSITION
HIGH
POSITION
IMGG10GG18-PFS
W
DIR
OFF
POSITION
KNOB
REGU
INDICATOR
MARK
CONTROL
KNOB
LOW
POSITION
Advertisement
Related Manuals for Dyna-Glo GRAB 'N GO GG10BK
Summary of Contents for Dyna-Glo GRAB 'N GO GG10BK
- Page 1 GRAB 'N GO RADIANT HEATER USER'S MANUAL AND OPERATING INSTRUCTIONS Model # GG18BK GG10BK GG10RE GG18G GG10G GG10GE GG18O GG10O GG18RE GG18R GG10R GG18GE For product registration ANSI Z21.103-2017 Unvented portable type READ INSTRUCTIONS CAREFULLY: gas camp heaters for indoor and outdoor use Read and follow all instructions.
- Page 2 TABLE OF CONTENTS Service / Parts Ordering Information ................... 1 General Information ......................3 General Safety Instructions ....................4 Tank Installation Instructions ....................5 Tank Installation for 20 lb. Propane Cylinder ............... 6 Additional Information Regarding Optional Accessories to Connect a 20lb LP Tank ....6 Lighting Operation Instructions ...................
- Page 3 Operations" section. • NOTE: THIS HEATER MAY BE OPERATED WITH DISPOSABLE 1LB. PROPANE CYLINDERS OR WITH (1) REMOTE REFILLABLE PROPANE CYLINDER MAX. 20 LBS USING DYNA-GLO KIT # HAKITDG WHICH INCLUDES A 12’ PROPANE HOSE AND FUEL FILTER (SOLD SEPARATELY) COLD WEATHER OPERATION: •...
- Page 4 CAUTION: SPECIFICATIONS • Some linoleum surfaces may discolor if heater MODEL NO..GG10BK / GG10G / GG10O / GG10R / GG18BK / GG18G / GG18O / GG18R / is placed directly on these floor coverings. GG10RE / GG10GE / GG18RE / GG18GE GAS TYPE ....................PROPANE INPUT BTU/HR.
- Page 5 HANDLE POSITIONING FOR NORMAL OPERATION The heater ships with the handle in a compact position that must be raised for normal operation (Fig. 1a) • Grab handle and pull directly upward until the handle snaps into position. • Do not lower the handle to the previous location. The “UP” position is the normal operating orientation. Handle raised to Handle in "shipped"...
- Page 6 • The use of a fuel filter is also recommended but not mandatory. The fuel filter can reduce potential contaminants from the 20 lb. LP tank/hose and extend the life of the heater. • We recommend using the Dyna-Glo 20 lb. tank connection kit model# HAKITDG, which includes (1) 12’ extension hose and (1) fuel filter (sold separately).
- Page 7 LIGHTING, OPERATION, AND SHUTDOWN INSTRUCTIONS Dyna-Glo 10K Portable Heater Unvented Portable Type Heaters Must Not be Exposed to Flammable Control Graphics Vapors or Liquids. 1. Make sure the control knob is in the OFF position. 2. Open the access door as needed and install the one pound cylinder(s) as described on page 5.
- Page 8 • Inspect the hose before each use of the heater. If there is excessive abrasion or wear, or the hose is cut, replace prior to using the heater with Dyna-Glo HAKITDG. • The propane cylinder must include a listed overfilling protection device as well as a collar to protect the cylinder valve.
- Page 9 GHP Group, Inc. is a leading manufacturing company specializing in portable heating products. Our products can be found at most major home centers, hardware stores and internet retailers across North America. These heaters, which are sold under the Dyna-Glo brand feature an Oxygen Depletion Sensor (“ODS”), which shuts off the heater if the oxygen in the room gets below a certain point and a tip-over safety switch that turns it off in the event of it being knocked on its side.
- Page 10 MAINTENANCE: Always keep the heater area clear and free from combustible Burner Orifice materials, gasoline and other flammable vapors and liquids. Keep the vent areas (slots in the bottom and the top at the front of heater) clear at all times so combustion air and ventilation is not obstructed.
- Page 11 TROUBLESHOOTING WARNING: If you smell gas: • Do not attempt to light appliance. • Extinguish any open flame. • Disconnect fuel supply. • Leave the area immediately. • Allow gas to dissipate 5 minutes before relighting the appliance IMPORTANT: Operating heater where impurities in air exist may create odors. Cleaning supplies, paint, paint remover, cigarette smoke, cements and glues, new carpet or textiles, etc., create fumes.
- Page 12 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Burner backfiring 1. Burner orifice is clogged or 1. Clean burner orifice (see Care and during combustion. damaged. Maintenance on page 9) or contact customer service. 2. Burner is damaged. 2. Contact qualified service technician. 3.
- Page 13 序号 数量 型号 名称 后板 HA10K-15 PARTS LIST MODEL NUMBERS 旋钮 HA10K-27 ITEM QTY DESCRIPTION GG10BK GG10G GG10O GG10R 提手 HA10K-06 Back Panel HA10K-15 防护网 GG10K-01 Control Knob HA10K-27 Handle Bar HA10K-06 热电偶 HA10K-19-01 Wire Guard GG10K-01 ODS Thermocouple HA10K-19-01 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
- Page 14 脉冲款 序号 数量 名称 型号 PARTS LIST 后板 HA10K-15(E) MODEL NUMBERS ITEM QTY DESCRIPTION GG10BKE GG10GE GG10OE GG10RE 旋钮 HA10K-27 Back Panel HA10K-15(E) 提手 HA10K-06 Control Knob HA10K-27 防护网 GG10K-01 Handle Bar HA10K-06 Wire Guard GG10K-01 热电偶 HA10K-19-01 ODS Thermocouple HA10K-19-01 脉冲点火器...
- Page 15 PARTS LIST MODEL NUMBERS ITEM QTY DESCRIPTION GG18BK GG18G GG18O GG18R Back Panel HA18K-02 Handle Assy HA18K-18S Door Left HA18K-16 Wire Guard HA18K-11 Thermocouple HA18K-15-01 Door Right HA18K-17 Control Knob HA18K-14 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
- Page 16 PARTS LIST MODEL NUMBERS ITEM QTY DESCRIPTION GG18BKE GG18GE GG18OE GG18RE Back Panel HA18K-02(E) Handle Assy HA18K-18S Door Left HA18K-16(B) HA18K-16(G) HA18K-16(O) HA18K-16(R) Wire Guard HA18K-11 Thermocouple HA18K-15-01 Door Right HA18K-17(B) HA18K-17(G) HA18K-17(O) HA18K-17(R) Control Knob HA18K-14 Electronic Ignitor HA10K-30 NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!
- Page 17 WARRANTY LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale (lifetime warranty for the brass nozzle burner only). GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase.
- Page 18 WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
- Page 19 CALEFACTOR RADIANTE GRAB N' GO MANUAL DEL USUARIO E INSTRUCCIONES DE FUNCIONAMIENTO N.° de modelo GG18BK GG10BK GG10RE GG18G GG10G GG10GE GG18O GG10O GG18RE GG18R GG10R GG18GE ANSI Z21.103-2017 Calentadores de campamento de gas de tipo Para registro portátil sin ventilación para uso en interiores y exteriores del producto LEA ATENTAMENTE LAS INSTRUCCIONES: Lea y respete todas las instrucciones.
- Page 20 CONTENIDO Servicio / Información de pedido de piezas ................. 18 Información general ......................19 Instrucciones generales sobre seguridad ................20 Instrucciones de instalación del tanque ................21 Instalación del tanque para cilindros de gas propano de 20 lb ..........22 Información adicional sobre accesorios opcionales para conectar un tanque de gas propano líquido de 20 lb.
- Page 21 • NOTA: ESTE CALEFACTOR PUEDE FUNCIONAR CON CILINDROS DE GAS PROPANO DESECHABLES DE 1 LB O CON (1) CILINDRO DE GAS PROPANO RECARGABLE REMOTO DE 20 LB COMO MÁXIMO UTILIZANDO (1) MANGUERA DE EXTENSIÓN DE 12’ DYNA-GLO MODELO N.º HAKITDG Y (1) FILTRO DE COMBUSTIBLE DYNA-GLO MODELO N.º HAKITDG (SE VENDEN POR SEPARADO) FUNCIONAMIENTO EN CLIMA FRÍO:...
- Page 22 ESPECIFICACIONES PRECAUCIÓN: • Las superficies de linóleo se pueden decolorar GG10BK / GG10G / GG10O / GG10R / GG18BK / GG18G / GG18O / GG18R N.º DE MODELO / GG10RE / GG10GE / GG18RE / GG18GE si el calefactor se coloca directamente sobre el revestimiento.
- Page 23 POSICIONAMIENTO DE LA MANIVELA PARA SU NORMAL FUNCIONAMIENTO El calefactor se suministra con el mango en una posición compacta que debe levantarse para su normal funcionamiento (Fig. 1a) • Agarre la manivela y hale directamente hacia arriba hasta que la manivela encaje en su posición. •...
- Page 24 20 lb y a su vez prolongar la vida útil del calefactor. • Se recomienda usar el kit de conexión del tanque de gas propano de 20 lb Dyna-Glo, (modelo n.° HAKITDG), que incluye (1) manguera de extensión de 12' y (1) filtro de combustible (se vende por separado).
- Page 25 INSTRUCCIONES DE OPERACIÓN Dyna-Glo 10K Portable Heater APAGADO DE ILUMINACIÓN Control Graphics Los calefactores portátiles no ventilados no deben estar expuestos a vapores líquidos inflamables. 1. Asegúrese de que la perilla de control esté en la posición de APAGADO "...
- Page 26 • Inspeccione la manguera antes de cada uso. Si hay demasiada abrasión o está demasiado gastada, reemplácela antes de usar el calefactor con Dyna-Glo HAKITDG. • El cilindro de gas propano debe incluir un dispositivo de protección contra sobrellenado registrado y un collarín para proteger la válvula del cilindro.
- Page 27 Internet de Norteamérica. Estos calefactores, que se venden bajo la marca Dyna-Glo, incluyen un sensor de agotamiento de oxígeno (ODS), que apaga el calefactor si el oxígeno de la habitación disminuye a un cierto punto, y un interruptor de vuelco que apaga el calefactor...
- Page 28 MANTENIMIENTO: Orificio del Siempre asegúrese de que no haya material combustible, Burner Orifice quemador gasolina ni otros vapores y líquidos inflamables en el lugar donde se encuentra el calefactor. Mantenga en todo momento despejadas las áreas de ventilación (ranuras en la parte inferior y superior, en el frente del calefactor) de manera que la combustión y el aire de ventilación no estén obstruidos.
- Page 29 SOLUCIÓN DE PROBLEMAS ADVERTENCIA: Que hacer si siente olor a gas: • No intente encender el aparato. • Apague cualquier llama abierta. • Desconecte el suministro de combustible. • Salga de la zona inmediatamente. • Permita que el gas se disipe durante 5 minutos antes de volver a encender el aparato. IMPORTANTE: Poner en funcionamiento el calefactor cuando hay impurezas en el aire podría causar olores.
- Page 30 SOLUCIÓN DE PROBLEMAS PROBLEMA POSIBLE CAUSA ACCIÓN CORRECTIVA El quemador hace 1. El orificio del quemador está 1. Limpie el orificio del quemador (consulte Cuidado explosiones durante la obstruido o dañado. y mantenimiento, página 24) o comuníquese con combustión. el servicio al cliente. 2.
- Page 31 普通款 序号 数量 型号 名称 LISTA DE PIEZAS 后板 HA10K-15 ARTÍCULO CANT. DESCRIPCIÓN GG10BK GG10G GG10O GG10R 旋钮 HA10K-27 Panel posterior HA10K-15 提手 HA10K-06 Perilla de control HA10K-27 Barra de la manivela HA10K-06 防护网 GG10K-01 Rejilla Protectora GG10K-01 热电偶 HA10K-19-01 Termopar ODS (detector de HA10K-19-01 agotamiento de oxígeno)
- Page 32 脉冲款 序号 数量 名称 型号 LISTA DE PIEZAS HA10K-15(E) 后板 ARTÍCULO CANT. DESCRIPCIÓN GG10BK GG10G GG10O GG10R 旋钮 HA10K-27 Panel posterior HA10K-15(E) Perilla de control HA10K-27 提手 HA10K-06 Barra de la manivela HA10K-06 防护网 GG10K-01 Rejilla Protectora GG10K-01 热电偶 HA10K-19-01 Termopar ODS (detector de HA10K-19-01 agotamiento de oxígeno)
- Page 33 LISTA DE PIEZAS ARTÍCULO CANT. DESCRIPCIÓN GG18BK GG18G GG18O GG18R HA18K-02 Panel posterior Montaje de la HA18K-18S manivela Puerta, KH HA18K-16(B) HA18K-16(G) HA18K-16(O) HA18K-16(R) Barra de la HA18K-11 manivela Termopar ODS (detector de HA18K-15-01 agotamiento de oxígeno) Puerta, RH HA18K-17(B) HA18K-17(G) HA18K-17(O) BEQ18K-17(R)
- Page 34 LISTA DE PIEZAS ARTÍCULO CANT. DESCRIPCIÓN GG18BKE GG18GE GG18OE GG18RE HA18K-02(E) Panel posterior Montaje de la HA18K-18S manivela Puerta, KH HA18K-16(B) HA18K-16(G) HA18K-16(O) HA18K-16(R) Barra de la HA18K-11 manivela Termopar ODS (detector de HA18K-15-01 agotamiento de oxígeno) Puerta, RH HA18K-17(B) HA18K-17(G) HA18K-17(O) HA18K-17(R)
- Page 35 GARANTÍA GARANTÍA LIMITADA: Esta garantía limitada se extiende al comprador minorista original de este calefactor de aire forzado/convección/radiante, que está garantizado contra defectos de materiales y mano de obra por un período de un (1) año a partir de la fecha de la venta minorista (garantía de por vida solo para el quemador con boquilla de bronce).
- Page 36 REGISTRO DE LA GARANTÍA IMPORTANTE: Lo instamos a que complete la tarjeta de registro de la garantía dentro de los catorce (14) días de la fecha de compra. También puede registrar la garantía por Internet en www.ghpgroupinc.com. Complete el número de serie. Conserve esta parte de la tarjeta para su constancia.
