Delfield SADBP1-SH Specifications

Specification Line®
Solid Door Single Section Dual Temp Refrigerator/
Freezer Pass-Thru Units
Models
SSDTP1-SH Refrigerator top/freezer bottom stainless exterior and interior half door
SSDBP1-SH Freezer top/refrigerator bottom stainless exterior and interior half door
SADTP1-SH Refrigerator top/freezer bottom stainless exterior and aluminum interior half door
SADBP1-SH Freezer top/refrigerator bottom stainless exterior and aluminum interior half door
SMDTP1-SH Refrigerator top/freezer bottom stainless front aluminum exterior and interior half door
SMDBP1-SH Freezer top/refrigerator bottom stainless front aluminum exterior and interior half door
SSDBP1-SH
(shown with optional casters)

Specifications

Exterior: SS and SA models shall have corrosion resistant stainless
steel exterior cabinet sides, front and shroud. SM models shall have
corrosion resistant aluminum on exterior cabinet sides and will have
stainless front and shroud. All units shall have the upper shroud
hinged with a gas assist stay open feature to provide easy access to
the refrigeration system.
Interior: Cabinet interior shall be corrosion resistant stainless steel
(SS models) or heavy gauge aluminum (SA and SM models). Bottom
and top surfaces shall be die stamped to provide radius corners
and recessed floor. Four wire shelves are provided, SA/SS standard
shelves are chrome plated, SM standard shelves are epoxy coated.
Shelves rest on clips which are adjustable on 1" increments on
stainless steel pilasters affixed to the cabinet interior. Pilasters are
removable without tools for cleaning. Mounted to the interior ceiling
of each compartment, the interior incandescent lights are controlled
automatically through a switch mounted in the hinge assembly to
protect against breakage. Door openings are protected with heavy
gauge stainless steel breaker strips. An air duct shall be mounted to
the ceiling assuring low velocity, even air movement throughout the
cabinet interior.
Doors: Exterior shall be corrosion resistant stainless steel. Interior
liner shall be resilient high impact ABS material formed to protrude
beyond the door gasket to protect the gasket from tearing. Each
door has two edge mount, self closing, cam lift style hinges. Doors
980 S. Isabella Rd.
Mt. Pleasant, Michigan 48858
Standard Features
• Stainless steel interior and exterior (SS)
• Stainless steel exterior, aluminum interior (SA)
• Aluminum interior and exterior, stainless front
(SM)
• Built in door locks with heavy duty strikes
• Recessed metal door handle
• Pressure relief valve is standard to prevent door
vapor lock
• Two exterior digital thermometers with high/
low temperature alarm
• Easy to use electronic control
• Easy access "flip up" shroud
• Four wire shelves - SA/SS standard with chrome
plated shelves and SM standard with epoxy
coated shelves
• Tough ABS interior door liners
• 10' attached cord and plug
• 6" adjustable stainless steel legs
• Stainless steel breaker strips
• High density foamed in place environmentally
friendly, Kyoto Protocol Compliant, Non ODP
(Ozone Depletion Potential), Non GWP (Global
Warming Potential) polyurethane keeps energy
costs low
• Energy savings door heater switch
• Two year parts & labor warranty
• Five year compressor warranty
can be removed from the cabinet without the use of tools. Metal
door handle shall be recessed into the door for easy grip without
impacting aisle space. Keyed door lock is mounted in the door next
to the handle. Lock engages into a heavy duty strike mounted to
the cabinet face. Door gaskets are magnetic and mount to the door
snapping in place and are removable without tools.
Refrigeration system: Each compartment has its own separate
refrigeration system. Condensing units are located on top of the
cabinet, outside the food zone, behind the removable upper
shroud. Evaporator coils are located inside the cabinet mounted
to the interior ceiling of each compartment. Defrost is automatic.
Condensate travels down a tube in the cabinet side wall to a
receptacle mounted to the exterior bottom of the cabinet where it
is evaporated with the aid of an electric heater. Each compartment's
temperature is individually monitored, controlled and displayed on
the exterior of the cabinet. Refrigerator compartment maintains
between 33°F and 41°F. Freezer compartment maintains temperature
between 0ºF and -5ºF.
Electrical: Unit comes with one 10' cord and plug with single point
connection to all cabinet and refrigeration system electronics. It
is attached to a junction box mounted on the exterior top of the
cabinet.
Phone: 800-733-8948 or 989-773-7981
Fax: 800-669-0619
Project __________________________________
Item ____________________________________
Quantity ________________________________
CSI Section 11400
Approved _______________________________
Date ____________________________________
www.delfield.com
Options &
Accessories
• Security (prison) package
• 6" polyurethane casters
• Door field rehingability
• Stainless steel interior door liner
• Additional shelves
• Tray slides
• Stainless steel back
• Laminate on front, sides and back
• Bottom mount electrical
• Stainless steel banking strip
• Heat shield end
• Stainless steel kick plate
• Laminate kick plate
• 4" stainless steel utility base
• 230-50-1 electrical
• 220-60-1 electrical
