- Page 1 Document number CMM_685_Ulyser Novega Produktionssysteme GmbH Gewerbepark 2 | 87477 Sulzberg (See) | Germany Fon: +49/8376/92990-0 info@novega.de www.novega.de PNR: 22098-00 Cage Code: CG871 ECCN: EAR99 Rev01...
- Page 2 This document/data is the property of Novega. You may not possess, use, copy, or disclose this document/data or any information contained therein, for any purpose, including without limitation to design, manufacture, or repair parts, or obtain EASA or any other government approval to do so, without Novega express written permission. Neither receipt nor possession, use, copying, or disclosing by anyone without Novega express written permission is not authorized and may result in criminal and/or civil liability.
- Page 3 Low Battery Screen ......................13 Test Procedure ............................ 13 General ............................13 Switching On/Off the Ulyser ..................... 13 Functional Test and Readout of Novega-ULD ................ 14 ULD Report Creator ........................... 16 Setup ULD Report Creator ......................16 Data Transfer ..........................17 Analyse the transferred Data ....................
- Page 4 Figure 10: Connecting Screen with process bar ..................11 Figure 11: Measurement Screen example (Novega) ................12 Figure 12: Measurement Screen example (Novega) with Signal OK-symbol ........12 Figure 13: Memory Screen example ......................12 Figure 14: Sending Screen ......................... 12 Figure 15: Low Battery Screen ........................
- Page 5 Table 2-1: Log of Revisions .......................... 6 Table 3-1: Type Plate information ......................8 Table 3-2: Specification ..........................8 Table 3-3: Component scope ........................9 Table 4-1: Device description ........................10 Rev01 09 Aug 2024 Page 5 of 25 © Novega 2024, confidential and proprietary document...
- Page 6 2.3 Abbreviations ECCN ....................Export Control Classification Number PNR ............................Part number SER ............................Serial number ULB ......................... Underwater Locator Beacon ULD ......................... Underwater Locating Device Rev01 09 Aug 2024 Page 6 of 25 © Novega 2024, confidential and proprietary document...
- Page 7 ULD. This data can be analysed with a special software. The Ulyser meets the requirements of the EU-Directives for CE marking. Figure 1: Ulyser Rev01 09 Aug 2024 Page 7 of 25 © Novega 2024, confidential and proprietary document...
- Page 8 Size (L x W x H): 94 mm (3.70 inch) x 49 mm (1.93 inch) x 16 mm (0.63 inch) Weight: 55 g (1.9 oz) Table 3-2: Specification Rev01 09 Aug 2024 Page 8 of 25 © Novega 2024, confidential and proprietary document...
- Page 9 CMM_685_Ulyser_Maritime 3.5 Component Scope Figure 4: Component scope Position Name Ulyser 22097-00 Activation Cord 21860-00 Short USB Cord 22099-00 Case 24082-00 Table 3-3: Component scope Rev01 09 Aug 2024 Page 9 of 25 © Novega 2024, confidential and proprietary document...
- Page 10 Figure 6: Ulyser back side Figure 5: Ulyser front side Position Name Touchscreen Jack/measuring adapter USB Micro-B Port On/Off-Button Loudspeaker Microphone Works Test Sticker Table 4-1: Device description Rev01 09 Aug 2024 Page 10 of 25 © Novega 2024, confidential and proprietary document...
- Page 11 ULD is activated. Successfully measuring is confirmed by a single “beep”; the Ulyser automatically switches to the Measurement Figure 10: Connecting Screen with Screen (Figure 11). process bar Rev01 09 Aug 2024 Page 11 of 25 © Novega 2024, confidential and proprietary document...
- Page 12 Return to the Start Menu (Figure 8) by tapping the screen. 4.2.5 Memory Screen By pressing the Memory-button , the last stored measurement data of a Novega device is displayed (Figure 13). Note: Return to the Start Menu (Figure 8) by tapping the screen.
- Page 13 The Ulyser turns off automatically two minutes after the last operation. the Ulyser Data of the last readout remain recorded under normal conditions (e.g. battery level is not low) on the Ulyser. Rev01 09 Aug 2024 Page 13 of 25 © Novega 2024, confidential and proprietary document...
- Page 14 Ulyser Component Maintenance Manual Document Name: CMM_685_Ulyser_Maritime 5.3 Functional Test and Readout of Novega-ULD Perform the following steps for the functional test and readout of a Novega-ULD 5.3.1 Place the Ulyser, the Activation Cord and the ULD on a table.
- Page 15 To ensure that the ULD switches back into sleep mode, wait until the pulse symbol on the display disappears and the audible pulse repetition of the Ulyser stops. Rev01 09 Aug 2024 Page 15 of 25 © Novega 2024, confidential and proprietary document...
- Page 16 (Figure 23). Figure 23: Adding a company logo Note: At the next software start, the entered data will still be displayed. Rev01 09 Aug 2024 Page 16 of 25 © Novega 2024, confidential and proprietary document...
- Page 17 If the Ulyser is correctly detected, the button is disabled. 6.2.5 Press the sending button on the Ulyser to transfer the readout data from the Ulyser to the PC. Rev01 09 Aug 2024 Page 17 of 25 © Novega 2024, confidential and proprietary document...
- Page 18 The test results are shown as passed, if the acoustic signal, the battery voltage and the battery status are ok (Figure 25). Figure 25: Test passed Rev01 09 Aug 2024 Page 18 of 25 © Novega 2024, confidential and proprietary document...
- Page 19 The test results are shown as failed, if the acoustic signal, the battery voltage or the battery status are not ok (Figure 26). Figure 26: Test failed Rev01 09 Aug 2024 Page 19 of 25 © Novega 2024, confidential and proprietary document...
- Page 20 Document Title: Ulyser Component Maintenance Manual Document Name: CMM_685_Ulyser_Maritime 6.4 Report Creation Press the button to create the test report (Figure 27). Figure 27: Test report Rev01 09 Aug 2024 Page 20 of 25 © Novega 2024, confidential and proprietary document...
- Page 21 Ulyser after Note: The next measurement starting measurement. can be performed when the ULD drops back into sleep mode after 66 seconds. Rev01 09 Aug 2024 Page 21 of 25 © Novega 2024, confidential and proprietary document...
- Page 22 Start the functional test again three pulses. and hold the Ulyser in the Note the pulse repetition rate direction of the ULD. prevent losing the acoustic signal. Rev01 09 Aug 2024 Page 22 of 25 © Novega 2024, confidential and proprietary document...
- Page 23 Open the battery cover on the back side of the Ulyser by pulling it in the direction shown (Figure 29). Figure 29: Open the battery cover Rev01 09 Aug 2024 Page 23 of 25 © Novega 2024, confidential and proprietary document...
- Page 24 Close the battery cover (Figure 31). Figure 31: Close the battery cover 7.1.8 Mount the silicone sleeve (Figure 32) Figure 32: Mount the silicone sleeve Rev01 09 Aug 2024 Page 24 of 25 © Novega 2024, confidential and proprietary document...
- Page 25 Gewerbepark 2 | 87477 Sulzberg (See) | Germany Fon: (+49) 8376-92990-0 E-Mail: info@novega.de www.novega.de 9 Warranty and Guaranty For further information regarding warranty and guaranty, please contact our service department (Service Address). Rev01 09 Aug 2024 Page 25 of 25 © Novega 2024, confidential and proprietary document...
