- Page 1 TACX NEO 3M ® Quick Start Manual........2 Manuel de démarrage rapide ......15 Guía de inicio rápido ........28 Sổ tay hướng dẫn khởi động nhanh ....41...
- Page 2 • Read the instructions before you assemble the trainer and attach your bike. • For best results, use the Tacx NEO 3M trainer with a firm mat or low pile carpet. Avoid soft and high pile carpet. You can use a training mat that is 181 x 92 cm (71.3 x 36.2 in.) or larger.
- Page 3 If you are using a 130 mm quick release axle or 148 mm thru axle, you must swap out the end cap supports using the blue end cap tool. For more instructions, go to www.garmin.com/manuals/NEO3M. Attaching Your Bike to the Trainer 1 Unfold the sides of the trainer, and lift up on the handle 2 Ensure both sides of the trainer lock into place.
- Page 4 3 Place the trainer on a firm and level surface. 4 Open the installation kit , and select the end caps for your axle type. The end caps are labeled QR and Thru-Axle 12mm. 5 Snap the end caps into the pre-installed end cap supports. 6 On your bike, shift to the smallest cassette gear.
- Page 5 For more information, see the instructions for your disc brakes. 9 For a quick release axle, follow these steps: Insert the skewer from the non-drive side of the trainer. Place the conical spring on the skewer. Hand tighten the cap , leaving enough room for the bike frame.
- Page 6 10 For a thru axle, follow these steps: 10.1 Place your bike on the trainer, making sure the chain is on the smallest sprocket of the trainer cassette. 10.2 Insert the axle, and hand tighten. 10.3 Tighten the axle to the torque specification indicated on the axle or in your bike instructions. Positioning the Front Wheel Support Before you can position the front wheel support, you must attach your bike to the trainer.
- Page 7 The two-sided front wheel support raises the front wheel of the bike for a natural cycling position and increased stability. The smaller side of the wheel support can hold a maximum tire width of 30 mm (1.18 in.). The larger side of the front wheel support can hold a maximum tire width of 61 mm (2.4 in.). 1 Place the front wheel support under your front wheel.
- Page 8 The power cable is in the product box. Do not attempt to use a third-party power cable or adapter with the Tacx NEO 3M trainer because this could lead to personal injury or damage to the trainer. 1 Plug the power cable...
