- Page 1 PRIMUS Assembly and operating instructions...
- Page 2 2 |24...
- Page 3 Foreword We are pleased that you have chosen our product. By purchasing a CARAVITA product, you have opted for quality, made from the best materials and designed to meet the highest standards. Read the instructions in this document carefully to set up the product safely.
- Page 4 Table of contents Table of contents Foreword .......................... 3 Introduction ........................5 Safety information ............................5 Information on the target group and application of the instructions .............. 5 Explanation of signal words ........................... 5 Basic safety instructions ..........................5 Product information ......................7 Intended use ..............................
- Page 5 It is important for the safety of persons to follow the instructions. Failure to observe the instructions may result in personal injury and/or damage to property when using the product. Failure to comply shall release Caravita from liability. Warnings are labelled with this or a similar symbol in the instructions.
- Page 6 Fire hazard due to flying sparks The fabric of the sunshade is flammable. DANGER Danger to life and limb from lightning strikes The sunshade can become a lightning conductor. ◼ Never seek shelter under a sunshade during thunderstorms. DANGER Choking hazard due to packaging material Plastic films, polystyrene parts and small parts from the packaging can become dangerous toys for children.
- Page 7 This makes the sunshade light and mobile. Primus is available with an aluminium frame and as the Primus Wood model with a solid ash wood frame. The fabric of the sunshade roof is made of easy-care and washable material. The shape of the sunshade roof is available in different designs.
- Page 8 Assembly Assembly CAUTION Risk of injury due to tipping during assembly Tipping or dropping the product can result in serious injuries. ◼ 2 people are required to assemble and set up the product. ◼ Mount the product on a level surface. NOTE When installing several sunshades, a distance of at least 20 cm must be maintained between the individual sunshades.
- Page 9 Assembly Scope of delivery 1 x pole 1 x strap 1 x sunshade roof 1 x protective 4 x fastening screw for sunshade roof cover case 1 x assembly and operating instructions 1 x telescopic push rod (optional) 1 x cover cap for sunshade roof Fig.
- Page 10 Assembly Set up product CAUTION Risk of injury due to tipping Carelessness can cause the sunshade to tip over with its heavy weight. ◼ Two people are always required for assembly. ◼ The base must be designed with sufficient ballast to prevent the closed sunshade from tipping over in strong winds. Preparation ◼...
- Page 11 Assembly Assemble the pole on the base The pole is positioned horizontally next to the base. 1 The 1st person inserts the lower end of the pole into the standpipe while the 2nd person raises the sunshade. 1 The 1st person places their foot on the lower end of the pole and presses against it, while the 2nd person raises the sunshade.
- Page 12 Assembly 5 Putting into use WARNING Risk of injury due to improper use of the sunshade. Improper use can result in personal injury. ◼ Do not reach into openings on the product during commissioning. ◼ Do not hang any foreign objects on the sunshade that are not expressly mentioned in the instructions. ◼...
- Page 13 Operation Operation CAUTION Risk of crushing due to carelessness when operating! Persons in the travelling area may be injured. ◼ Keep travelling area clear of people! ◼ Keep children away from the controls! Remove the protective case. Using the Using telescopic rod, Chapter telescopic push rod (optional), page 17...
- Page 14 Operation 2 Pull the struts slightly outwards. The struts are loosened. 3 Grasp the pull rope under the cover. 4 Pull the pull rope until the sunshade fabric is taut. 5 Insert the locking pin through one of the holes in the pole. The sunshade should be easy to open.
- Page 15 Material damage due to abrasion of the sunshade fabric Permanent flapping in the wind can damage the sunshade fabric by rubbing against the struts. No claims for damages can be asserted against CARAVITA for this. ◼ Always secure the closed sunshade roof with the strap.
- Page 16 Operation 5 Pull the sunshade fabric out from between the struts to prevent it from becoming trapped or damaged. 6 Secure the closed sunshade roof with the strap. 7 Cover the sunshade roof with the protective case. INFO The telescopic push rod is used for easier operation during activities such as pulling over the protective case.
- Page 17 Operation Using the telescopic push rod (optional) Attach the key ring to the zip of the protective case. 2 Open the knurled screw on the telescopic push rod. 3 Pull the telescopic push rod to the required length. 4 Tighten the knurled screw on the telescopic push rod. 17 |24...
- Page 18 Operation 5 Insert the telescopic push rod into the pocket of the protective case. 6 Lift the protective case over the sunshade using the telescopic push rod. 7 Attach the eyebolt of the telescopic push rod to the key ring on the zip of the protective case.
- Page 19 Care instructions 7 Maintenance and care Sunshade fabric NOTE Material damage to the sunshade fabric due to incorrect cleaning and cleaning agents The acrylic fabric of the sunshade roof is impregnated and requires special cleaning and cleaning agents. ◼ Always wash the sunshade fabric in cold water. ◼...
- Page 20 Material damage due to abrasion of the sunshade fabric Permanent flapping in the wind can damage the sunshade fabric by rubbing against the struts. No claims for damages can be asserted against CARAVITA for this. ◼ Always secure the closed sunshade roof with the strap.
- Page 21 9 Troubleshooting If the sunshade malfunctions and cannot be rectified with the help of the following instructions, please contact us via our CARAVITA service hotline. You will find the contact details on the first and last page of these instructions.
- Page 22 Warranty conditions 10 Warranty conditions The following warranty conditions apply: www.caravita.de/garantie 11 Other notes Please observe the general safety instructions: www.caravita.de/hinweise 22 |24...
- Page 23 23 |24...
- Page 24 Subject to printing errors, changes and deviations. CARAVITA GmbH - Hans-Wilhelm-Renkhoff-Straße 2 -97828 Marktheidenfeld – Germany www.caravita.de...
