Summary of Contents for Albixon ELEGANCE 70
- Page 1 SWIM JET ELEGANCE 70 / 8 0 / 9 5 INSTALLATION AND USER GUIDE 12. 11. 2023...
- Page 2 Thank you for choosing our product and trusting our company. To help you to get the maximum pleasure from using this product, please read these instructions carefully before use and strictly follow the user´s manual to prevent damage to the device or unnecessary injuries. / Swim jet ELEGANCE 70...
- Page 3 250 mm below the surface. You must follow and adhere to these instructions and correctly mount the device to ensure that it operates correctly. PIC. 1 WATER LEVEL DISPLACEMENT INTAKE CORRECT INCORRECT INCORRECT Swim jet ELEGANCE 70 /...
- Page 4 PIC. 2d INSTALLATION IN PANEL INSTALLATION IN PREFABRICATED OR SHEET METAL (LAMINATE OR POLYPROPYLENE) SWIMMING POOLS WITH LINER SWIMMING POOL POOL WALL PANEL OR SHEET METAL APERTURE APERTURE (Ø 270 mm) (Ø 270 mm) LINER / Swim jet ELEGANCE 70...
- Page 5 The mounting may differ from the recommendations of the swim jet manufacturer. It may also be in a different location according to the individual types and dependent on the design of the swimming pool. Swim jet ELEGANCE 70 /...
- Page 6 Then pull the end of the cable through the opening in the counterflow body (No. 20, Fig. 3) and fasten it with the grommet (No. 14). Finally, connect the button to the switchboard. / Swim jet ELEGANCE 70...
- Page 7 Connect the complete front cover with the counterflow body and make sure that the ring (No. 12) is inserted into the mouth of the discharge opening (ø 75 mm). • Tighten the four screws (No. 3, Fig. 3). Once tightened, the front cover is ready for use. Swim jet ELEGANCE 70 /...
- Page 8 The minimum recommended proportions of the technology space required for the device installation, see pic.5 + table. width (mm) length A (mm) height B (mm) 1420 PIC. 5 Air outlet Ventilation To the el. switching Water level 25 cm / Swim jet ELEGANCE 70...
- Page 9 The water stream with air: For setting or reducing the air flow, turn the outside of the nozzle (no. 3 pic. 6). DETAIL OF SWIM JET NOZZLE MAXIMUM FLOW MINIMUM FLOW PIC. 6 Swim jet ELEGANCE 70 /...
- Page 10 Piezo switchboard with DO 1 piece *Elegance 70–230 V = 1ND03-01-001; Elegance 70–400 V = 1ND03-01-002; Elegance 80 = 1ND03-01-005, Elegance 95 = 1ND03-01-038; **Elegance 70–230 V = 1BP11-01-013, Elegance 70–400 V = 1BP11-01-011, Elegance 80 and 95 = 1BP11-01-010 FIG.
- Page 11 All these parts should be installed in a waterproof plastic enclosure with an ingress protection rating of IP55. FIG. 8 FIG. 9 Motor I.N. - control fuse, - starting motor, - electropneumatic switching unit, - contactor, - current protector Swim jet ELEGANCE 70 /...
- Page 12 Yellow Pink - motor circuit switch - motor protector - control fuse - contactor - 24 V DC power supply - remote control receiver - time relay - piezo button - counterflow motor / Swim jet ELEGANCE 70...
- Page 13 - motor circuit switch - motor protector - control fuse - contactor - 24 V DC power supply - remote control receiver - time relay - piezo button - counterflow motor Swim jet ELEGANCE 70 /...
- Page 14 SWIMMING POOLS WITH LINER SWIMMING POOLS SWIMMING POOLS WITH LINER Model A033 Modelo A034 Modelo A034 Modelo A035 Pool Wall Pool Wall Pool Wall Pool Wall LINER LINER DIMENSION Model STP-2200S 1110 STP-3000S 1110 STP-4000S 1110 PIC. 10 / Swim jet ELEGANCE 70...
- Page 15 Switching the receiver (actor) to pairing mode – RFSA-61M 1) The module must be powered – the green Un light is on 2) Press and hold the PRG button (for about 2 seconds) – the red light starts flashing regularly Swim jet ELEGANCE 70 /...
- Page 16 Attach the front piece of the cover and snap it closed. Setting the CRM-161 timer Automatic counterflow shutdown after 2 hours Range of 10 hours Fine adjustment - .2 FUNC k – Impulse relay with a delay / Swim jet ELEGANCE 70...
- Page 17 Once the product’s useful life has ended, please ensure its ecological liquidation by a specialised company. Complaints and Service Claims are governed by the relevant acts on consumer protection. In the event of any irreparable defects, please contact your supplier in writing. Date ..............Supplier Swim jet ELEGANCE 70 /...
- Page 18 Contents of box 1 Contents of box 2 Contents of box 3 Content of box „C“ Head of the swim jet – outer part Head of the swim jet – inner part Mounting ring with seals / Swim jet ELEGANCE 70...
- Page 19 Shaft bushings Air suction hose termination. Passage of the switching Connection of the switching hose to the hose through the end of the protective hose electropneumatic switch Piezoelectric button with a reducer and pressure nut Swim jet ELEGANCE 70 /...
- Page 20 Thank you for using ALBIXON products ALBIXON export@albixon.com www.ALBIXON.com Note that the photos used in the manual are illustrative only. Printing and typesetting errors reserved.
