Summary of Contents for Albixon HIDROLIFE
- Page 1 Salt electrolysis HIDROLIFE INSTALLATION AND USER GUIDE Portable Worldwide WIFI and color remote MODBUS from 3g display (TFT) control salt/l Upgrade Self possible clean water VERZE 11. 02. 2020 / REVIZE: 11. 02. 2020...
- Page 2 Hydrochloric acid container (optional, for models with pH control, not supplied with unit) See section 5 - Other pool equipment Filtration of the Module RF or RF/WIFI or WIFI General Installation Free chlorine control Guide Relay FILTER PUMP 110-230 V / Salt electrolysis Hidrolife...
- Page 3 (clear liquid). After each cleaning the probes must be calibrated. Also: the probes should never dry out and must be kept wet if stored (when emptying the pool for winterizing, make sure to store the measuring head in water). Salt electrolysis Hidrolife /...
- Page 4 To avoid accidents, children should not handle this product unless supervised by an adult. Children should be supervised at all times when in or near a spa, pool or jacuzzi. HANDLING AND DOSING DANGEROUS CHEMICALS Chemicals should be handled with extreme precaution. When preparing acid, always add acid to water, never add water to acid, because very dangerous gasses may be produced. / Salt electrolysis Hidrolife...
- Page 5 Thread for an easy installation Diameter tube connection 63 mm Dimension cell 355 x 305 x 305 mm Cell cable size (3 x 4) x 1,5 m Gas sensor Incorporated in the cell Maximum pressure 4 kg/cm Maximum temperature 45°C Salt electrolysis Hidrolife /...
- Page 6 10 MS / 100 MS 1°C Material Ag/Cl Gold Copper / gold Stainless steel Probe holder ABS 50/63mm Supplementary equipment Includes 2 m of flexible tube/valve Cable Plug BNC with protection BNC with protection Connectors Connectors Connectors Dimensions / Salt electrolysis Hidrolife...
- Page 7 Notes Salt electrolysis Hidrolife /...
- Page 8 Thank you for using ALBIXON products ALBIXON export@albixon.com www.ALBIXON.com Note that the photos used in the manual are illustrative only. Printing and typesetting errors reserved.
