TRASH PUMP
SAFETY AND OPERATING MANUAL
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATING THE UNIT
LMCG260EH
LMWPTG30
PROUDLY
A STEELFORT PRODUCT
NZ OWNED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMCG260EH and is the answer not in the manual?

Questions and answers

Related Manuals for LawnMaster LMCG260EH

Summary of Contents for LawnMaster LMCG260EH

  • Page 1 TRASH PUMP SAFETY AND OPERATING MANUAL PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATING THE UNIT LMCG260EH LMWPTG30 PROUDLY A STEELFORT PRODUCT NZ OWNED...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS OPERATOR SAFETY Safety Rules FEATURES & TECHNICAL DATA OPERATION & ASSEMBLY Water Pump Connecting Operating Condition Engine Oil/Fuel Prime The Pump Starting & Stopping Pump MAINTENANCE Maintenance Schedule Engine Oil Changing Oil Double Filter Foam & Paper Filter Spark Plug Spark Arrester Adjustment...

  • Page 3: Operator Safety

    LawnMaster product. DO NOT operate this waste pump until you have read ALL safety, operation, and maintenance Instructions listed in this manual.

  • Page 4: Hot Surface

    • DO NOT operate pump with covers, shrouds, or • Fix the pump in case moving or being caught in guards removed. mud or water, especially when it settles down • DO NOT wear loose-fitting clothing, dangling to the pound or ditches nearby. drawstrings or items that could become caught.

  • Page 5: Features & Technical Data

    FEATURES & TECHNICAL DATA Throttle Control Fuel Cap Water Outlet Choke Lever Water Inlet Plug Water Inlet Fuel Switch Rack Water Outlet Plug Starter Dipstick Air Filter Muffler Oil Drain Remote On/Off Switch A STEELFORT PRODUCT...
  • Page 6 Model LMWPTG30 Engine Model GB225 Type Petrol Engine Rated Power (kW) Oil Type SAE 10W-30 Fuel Capacity (L) Oil Capacity (L) Net Gross Weight (kg) 38-40 Inlet Diameter (mm) Outlet Diameter (mm) Max. Flow (m3/h) Max. Head (m) Measured Sound Pressure Level dB (A) Measurement Uncertainty dB (A) Guaranteed Sound Power Level dB (A) Max Self Height (m)

  • Page 7: Operation & Assembly

    OPERATION & ASSEMBLY WATER PUMP CONNECTING Check all the following parts after unpacking. Then connect them as follows. 1. Outlet mouth 2. Rubber sealing gasket 8 3. Joint tube Connecting the filter 4. Joint tube connecting 5. Clamp 6. Outlet pipe CAUTION Input pipe must be the unfolded hard pipe but not too long, length should be the direct proportion with the...

  • Page 8: High Altitude

    The exhaust of the pump engine contains carbon monoxide, an odorless, colorless, poison gas. Using pump indoors CAN KILL YOU! NEVER use inside any building or any kind of enclosure, EVEN IF doors and windows are open. HIGH ALTITUDE This pump engine may require a high altitude carburetor kit to ensure correct operation at high altitudes.

  • Page 9: Engine Fuel

    ENGINE FUEL • Empty the fuel tank before storing or transporting this engine. With the engine stopped, check the fuel level gauge. • Keep fire extinguisher handy and be prepared if Refill the fuel tank if necessary. a fire starts. CAUTION NEVER use engine or carburetor cleaner products in Pressure can build up in the fuel tank.

  • Page 10: Stopping The Pump

    • Turn the throttle lever to high speed to run the engine under standard speed. Check the item before operating the pump. Turn start switch to ‘ON” position Slide the choke lever to the left and the fuel STOPPING THE PUMP lever to the right to allow fuel to flow to the engine Turn the throttle lever to low speed to run...

  • Page 11: Maintenance Schedule

    Service the water pump in a clean, dry and dusty area. Follow the service intervals indicated in the chart below. Service your water pump more frequently when operating in adverse conditions. Contact your local LawnMaster service dealer for your water pump maintenance needs. EACH TIME...

  • Page 12: General Maintenance

    GENERAL MAINTENANCE Place the engine on a level surface. Clean area around dipstick and drain plug. ENGINE OIL Remove oil dipstick. Remove the oil drain plug and allow the oil to SAE 1 0W-30 is recommended for general, all- drain completely. temperature use.

  • Page 13: Spark Plug

    There has no other service and/or adjustment need for your engine. Unapproved adjustments or tampering can damage your engine and your electrical devices and will void your warranty. Contact your local LawnMaster dealer for such needs. WARNING Tampering with the factory set governor will damage your engine and void your warranty.

  • Page 14: Trouble Analysis & Troubleshooting

    Engine works low speed speed If problems still not be solved according to above problem shooting or other problem caused during operation, contact your local authorised LawnMaster dealer for help. Unauthorised disassemble on the pump will void your warranty. A STEELFORT PRODUCT...

  • Page 15: Storage & Transportation

    Only genuine spare parts can be used for repairs and this must be carried out by an authorised LawnMaster Services Dealer to maintain warranty.
  • Page 16 FIND US www.lawnmaster.co.nz lawnmasternz Steelfort Steelfort Auckland 500 Rangitikei Street, Private Bag 11045 880 Great South Road, Penrose Palmerston North, 4412, New Zealand Auckland, 1061, New Zealand 06 350 1350 09 573 1324...
