Page 1: Table Of Contents
GAS WOK COOKERS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page INJECTOR CHANGE AND GAS SETTING Page GAS CONNECTION IMAGES Page SPARE PART LIST- EXPLODING DRAWING... -
Page 2: Ageneral Information
GAS WOK COOKERS Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
*The Professional Gas wok cookers ,that provides high efficiency has been designed to be used in industrial kitchens. Dimensions Weight Packaging Product Code Model (mm) (kg) Dimensions (mm) EMP.PLS.7WK010 1 Burner Gas Ranges 400x730x300 480X860X620 EMP.PLS.7WK020 2 Burner Gas Ranges 800x730x300 900X850X620 EMP.PLS.7WK030 3 Burner Gas Ranges... -
Page 4: A3 Transportation
GAS WOK COOKERS TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
GAS WOK COOKERS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty. -
Page 6: Doperation
GAS WOK COOKERS OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Lighter Position B : Full Flame C : Half Flame D : Lighter *Operating; According to type of use,make gas entrance connection from behınd the machine.Because the machine is operated with LPG and NG. ... -
Page 7: Ecleaning & Maintenance
GAS WOK COOKERS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE CLEANING AND MAINTENANCE AFTER EVERY USE Turn off the gas connection before cleaning. Clean the outer surface of the appliance with a wet cloth and chrome shiner. ... -
Page 8: Ftroubleshooting
GAS WOK COOKERS TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the gas connection is done or not. If there is no gas entrance to pilot,the THE APPLIANCE DOESN’T OPERATE appliance is not operated. If the hoses that have gas entrance lose gas due to slit,hole.etc.,the appliance is not operated. -
Page 9: Ginjector Change And Gas Setting
GAS RANGE BURNER - INJECTOR CHANGE CHART NG / LPG 30/50 mbar 30/50 mbar mm Ø 3,00 Ø 3,00 Ø 1,80 Ø 1,80 EMP.PLS.7WK010 mm Ø 3,00 Ø 3,00 Ø 1,80 Ø 1,80 EMP.PLS.7WK020 mm Ø 3,00 Ø... -
Page 10: Hgas Connection Images
GAS WOK COOKERS GAS CONNECTION IMAGES Kasap Tip Dik Buzdolapları Image 2 Image 1 Image 3... - Page 11 GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.7WK010...
- Page 12 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.PLS.7WK010 PRODUCT NAME P.CODE TICKET M.AKS-OZL-MTL-006 LIGHTER GUARD M.GAZ--PIEZ-KRM PIOZE LIGHTER Ø:18 M.GAZ-CKM-PIEZ-001 CABLE 500MM M.GAZ-CKM-KBL-004 LIGHTER WASHER YSC-KNX.PG7-LZ-0557 BUTTON M.AKS-DGM-EMP-024 BUTTON BUFFER M.AKS-DGM-EMP-016 BUTTON SOCKET 8 MM M.AKS-DGM-SKT-001...
-
Page 13: Ispare Part List-Exploding Drawing
GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.7WK020... - Page 14 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: Kasap Tip Dik Buzdolapları EMP.PLS.7WK020 PRODUCT NAME P.CODE TICKET M.AKS-OZL-MTL-006 LIGHTER GUARD M.GAZ--PIEZ-KRM PIOZE LIGHTER Ø:18 M.GAZ-CKM-PIEZ-001 CABLE 500MM M.GAZ-CKM-KBL-004 LIGHTER WASHER YSC-KNX.PG7-LZ-0557 BUTTON M.AKS-DGM-EMP-024 BUTTON BUFFER M.AKS-DGM-EMP-016 BUTTON SOCKET 8 MM M.AKS-DGM-SKT-001 FRONT PANEL YSC-KNX.PG7-LZ-0446...
- Page 15 GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.7WK030...
- Page 16 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.7WK030 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE TICKET M.AKS-OZL-MTL-006 LIGHTER GUARD M.GAZ--PIEZ-KRM PIOZE LIGHTER Ø:18 M.GAZ-CKM-PIEZ-001 CABLE 500MM M.GAZ-CKM-KBL-004 LIGHTER WASHER YSC-KNX.PG7-LZ-0557 BUTTON M.AKS-DGM-EMP-024 BUTTON BUFFER M.AKS-DGM-EMP-016 BUTTON SOCKET 8 MM M.AKS-DGM-SKT-001 FRONT PANEL YSC-KNX.PG7-LZ-0447...
- Page 17 GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.9WK010...
- Page 18 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.9WK010 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE BURNER GRILL M.AKS-DKM-WOK-001 BURNER M.GAZ-BRL-BEK-007 INJECTOR M8*0.75 Ø 1.80 MM. M.GAZ-ENJ-NG-006 INJECTOR M8*0.75 Ø 3.00 MM. M.GAZ-ENJ-NG-009 THREE WRONG PILOTS (0.35) M.GAZ.TES-SRI-003 M8*1200 THERMOELEMENT NO:18 M.GAZ-TRL-003 M4 Spark Plug M.GAZ-CKM-KBJI-003...
- Page 19 GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.9WK020...
- Page 20 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.PLS.9WK020 Kasap Tip Dik Buzdolapları PRODUCT NAME P.CODE M.AKS-DKM-WOK-001 BURNER GRILL JP.M.AKS-DKM-KZN-013 40 CM X 7 CM CHIMNEY M.TRN-KNX-PG7-004 M.GAZ-TES-SRI-021 ELBOW 16*1.5/1/4 M.GAZ-BRL-BEK-007 BURNER M.GAZ-ENJ-NG-006 INJECTOR M8*0.75 Ø 1.80 MM. M.GAZ-ENJ-NG-009 INJECTOR M8*0.75 Ø...
- Page 21 GAS WOK COOKERS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.PLS.9WK030...
- Page 22 GAS WOK COOKERS SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.PLS.9WK030 PRODUCT NAME P.CODE BURNER GRILL M.AKS-DKM-WOK-001 40 CM X 7 CM CHIMNEY JP.M.AKS-DKM-KZN-013 M.TRN-KNX-PG7-004 ELBOW 16*1.5/1/4 M.GAZ-TES-SRI-021 BURNER M.GAZ-BRL-BEK-007 INJECTOR M8*0.75 Ø 1.80 MM. M.GAZ-ENJ-NG-006 INJECTOR M8*0.75 Ø 3.00 MM. M.GAZ-ENJ-NG-009 THREE WRONG PILOTS (0.35) M.GAZ.TES-SRI-003...
