ELECTRIC COOKER / HOT PLATE
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
Page
6
Page
7
Page
8
Page
9
Page
18
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.9KE030 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.9KE030

Summary of Contents for EMPERO EMP.9KE030

  • Page 1: Table Of Contents

    ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    EMP.7KE010 400x730x285 480x800x590 EMP.7KE020 800x730x285 830x800x590 EMP.7KE030 1200x730x285 1230x800x590 EMP.9KE010 400x900x285 430x1000x590 EMP.9KE020 800x900x285 830x1000x590 EMP.9KE030 1200x900x285 1230x1000x590 TECHNICAL INFORMATION Product Cable Power Model Electric Inlet (mm²) Code (KW) EMP.7KE010 Electric Cooker/2 Hot Plate 200 V. AC N PE 3x2,5 EMP.7KE020...

  • Page 4: A3 Transportation

    ELECTRIC COOKER / HOT PLATE TRANSPORTATION Kasap Tip Dik Buzdolapları * This appliance can not be moved by hand from area to area. Therefore Use a hauling truck (forklift or pallet jack) to move the appliance. ( The lifting arms of the of forklift or pallet jack must reach up to more than half part of t appliance underneath.) UNPACKING *Please unpack the package according to the security codes and ordinances of current...

  • Page 5: Csafety Instructions

    ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...

  • Page 6: Doperation

    ELECTRIC COOKER / HOT PLATE OPERATION Kasap Tip Dik Buzdolapları *Control Panel; A : Heat setting button B : Indicator lamp *Operating;  Plug in the appliance.  Put the pot that wanted cook or heat on the hot plate. ...

  • Page 7: Ecleaning & Maintenance

    ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE  CLEANING AND MAINTENANCE AFTER EVERY USE  Always turn off the appliance and disconnect from the power supply before cleaning.  Clean the outer surface of the appliance with a wet cloth and chrome shiner. ...

  • Page 8: Ftroubleshooting

    ELECTRIC COOKER / HOT PLATE TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. Check if it is operated at required heat THE APPLIANCE DOESN’T COOK WELL or not.

  • Page 9: Gspare Part List-Exploding Drawing

    ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.7KE010-9KE010...
  • Page 10 ELECTRIC COOKER / HOT PLATE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.7KE010 NUMBER PRODUCT NAME PRODUCT CODE PLATE (4 KW) Y.EMP.7KE010.001 PLATFORM Y.EMP.7KE010.002 WARNING LAMP Y.EMP.7KE010.003 SWITCH Y.EMP.7KE010.004 PANEL Y.EMP.7KE010.005 SWITCH (0-6) Y.EMP.7KE010.006 TERMINAL BLOCK Y.EMP.7KE010.007 TERMINAL BLOCK BASE Y.EMP.7KE010.008 BASE FRAME Y.EMP.7KE010.009...
  • Page 11 ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KE010 NUMBER PRODUCT NAME PRODUCT CODE PLEYT (4KW) Y.EMP.9KE010.001 TABLA Y.EMP.9KE010.002 İKAZ LAMBASI Y.EMP.9KE010.003 DÜĞME Y.EMP.9KE010.004 PANEL Y.EMP.9KE010.005 ŞALTER (0-6) Y.EMP.9KE010.006 KLEMENS Y.EMP.9KE010.007 KLEMENS ALTLIĞI Y.EMP.9KE010.008 ŞASE Y.EMP.9KE010.009...
  • Page 12 ELECTRIC COOKER / HOT PLATE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.7KE020-9KE020...
  • Page 13 ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KE020 NUMBER PRODUCT NAME PRODUCT CODE PLATE (4KW) Y.EMP.9KE020.001 PLATFORM Y.EMP.9KE020.002 WARNING LAMP Y.EMP.9KE020.003 SWITCH Y.EMP.9KE020.004 PANEL Y.EMP.9KE020.005 SWITCH (0-6) Y.EMP.9KE020.006 TERMINAL BLOCK Y.EMP.9KE020.007 TERMINAL BLOCK Y.EMP.9KE020.008 BASE BASE FRAME...
  • Page 14 ELECTRIC COOKER / HOT PLATE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.7KE020 NUMBER PRODUCT NAME PRODUCT CODE PLATE (4KW) Y.EMP.7KE020.001 PLATFORM Y.EMP.7KE020.002 WARNING LAMP Y.EMP.7KE020.003 SWITCH Y.EMP.7KE020.004 PANEL Y.EMP.7KE020.005 SWITCH (0-6) Y.EMP.7KE020.006 TERMINAL BLOCK Y.EMP.7KE020.007 TERMINAL BLOCK Y.EMP.7KE020.008 BASE BASE FRAME...
  • Page 15 ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING EMP.7KE030-9KE030...
  • Page 16 ELECTRIC COOKER / HOT PLATE SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.7KE030 NUMBER PRODUCT NAME PRODUCT CODE Y.EMP.7KE030.001 PLATE (4KW) Y.EMP.7KE030.002 PLATFORM Y.EMP.7KE030.003 WARNING LAMP Y.EMP.7KE030.004 SWITCH Y.EMP.7KE030.005 PANEL Y.EMP.7KE030.006 SWITCH (0-6) Y.EMP.7KE030.007 TERMINAL BLOCK TERMINAL BLOCK Y.EMP.7KE030.008 BASE Y.EMP.7KE030.009...
  • Page 17 ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KE030 NUMBER PRODUCT NAME PRODUCT CODE Y.EMP.9KE030.001 PLATE (4KW) Y.EMP.9KE030.002 PLATFORM Y.EMP.9KE030.003 WARNING LAMP Y.EMP.9KE030.004 SWITCH Y.EMP.9KE030.005 PANEL Y.EMP.9KE030.006 SWITCH (0-6) Y.EMP.9KE030.007 TERMINAL BLOCK TERMINAL BLOCK Y.EMP.9KE030.008...

  • Page 18: Helectric Circuit Schema

    ELECTRIC COOKER / HOT PLATE ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.7KE010-9KE SW1.SW2 R1.R2 L1.L2 Terminal 6 Kademeli şalter Sinyal lambası Pleyt rezistans 2000 W 230V...
  • Page 19 ELECTRIC COOKER / HOT PLATE Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA EMP.7KE020-9KE SW1.SW2.SW3.SW4 R1.R2.R3.R4 L1.L2.L3.L4 Pleyt rezistans 2000 6 Kademeli şalter Şalter sinyal lambası Terminal W 230V...
  • Page 20 ELECTRIC COOKER / HOT PLATE ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları EMP.7KE030-9KE SW1.SW2. R1.R2.R3.R4 R5.R6 SW5.SW6 L1.L2.L3.L4 L5.L6 SW3.SW4 Plate Plate resistance 6 Gradual 6 Gradual Signal resistance Signal Lamp Terminal 2000 W Switch Switch Lamp 2000 W 230V 230V...
