    GAS COOKER Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page INJECTOR CHANGE AND GAS SETTING Page GAS CONNECTION IMAGES Page SPARE PART LIST- EXPLODING DRAWING Page...

  • Page 2: Ageneral Information

    GAS COOKER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Gas Cooker ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.9KG010 400x900x285 430x1000x590 EMP.9KG020 800x900x285 830x1000x590 EMP.9KG030 1200x900x285 1230x1000x590 EMP.7KG010...

  • Page 4: A3 Transportation

    GAS COOKER TRANSPORTATION * This appliance can not be moved by hand from area to area. Therefore Use a hauling truck Kasap Tip Dik Buzdolapları (forklift or pallet jack) to move the appliance. ( The lifting arms of the of forklift or pallet jack must reach up to more than half part of t appliance underneath.

  • Page 5: Csafety Instructions

    GAS COOKER Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty.

  • Page 6: Doperation

    GAS COOKER OPERATION Kasap Tip Dik Buzdolapları *Control Panel A : ON/OFF B : IGNİTİON C : FULL FLAME POSİTİON D : HOLF FLAME POSİTİON *Operating; • According to type of use,make gas entrance connection from behınd the appliance.Because the machine is operated with LPG and NG. •...

  • Page 7: Ecleaning & Maintenance

    GAS COOKER Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Turn off the gas connection before cleaning. • Clean the outer surface of the appliance with a wet cloth and chrome shiner. • Do not use abrasive cleaning chemicals as these can leave harmful residues.

  • Page 8: Ftroubleshooting

    GAS COOKER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the gas connection is done or not. If there is no gas entrance to pilot,the THE APPLIANCE DOESN’T OPERATE appliance is not operated. If the hoses that have gas entrance lose gas due to slit,hole.etc.,the appliance is not operated.

  • Page 9: Ginjector Change And Gas Setting

    GAS COOKER Kasap Tip Dik Buzdolapları INJECTOR CHANGE AND GAS SETTING GAS RANGE BURNER-INJECTOR CHANGE CHART Small Middle Pilot Injector  Injector  Injector  Injector  Injector  Group 2,15 1,35 0,41 2,15 0,41 1,35 0,85 0,22 mbar 0,85 0,72 0,20 mbar...

  • Page 10: Hgas Connection Images

    GAS COOKER GAS CONNECTION IMAGES Kasap Tip Dik Buzdolapları Image 1 Image 2...
  • Page 11 GAS COOKER Kasap Tip Dik Buzdolapları GAS CONNECTION IMAGES Image3 Image4...

  • Page 12: Ispare Part List-Exploding Drawing

    GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.9KG010...
  • Page 13 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KG010 PRODUCT NAME P.CODE BASE FRAME Y.EMP.9KG010.001 FEET Y.EMP.9KG010.002 BURNER BRACKET Y.EMP.9KG010.003 CASTING GRILL-SMALL Y.EMP.9KG010.004 FLEX HOSE 80CM Y.EMP.9KG010.005 INJECTOR GROUP Y.EMP.9KG010.006 BURNER 8,5KW Y.EMP.9KG010.007 BUTTON BUFFER Y.EMP.9KG010.008 BUTTON Y.EMP.9KG010.009...
  • Page 14 GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.7KG010...
  • Page 15 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:EMP.7KG010 PRODUCT NAME P.CODE BASE FRAME Y.EMP.7KG010.001 FEET Y.EMP.7KG010.002 BURNER BRACKET Y.EMP.7KG010.003 CASTING GRILL Y.EMP.7KG010.004 PILOT Y.EMP.7KG010.005 INJECTOR GROUP Y.EMP.7KG010.006 BURNER 6 KW Y.EMP.7KG010.007 BUTTON BUFFER Y.EMP.7KG010.008 BUTTON Y.EMP.7KG010.009 GAS TAP Y.EMP.7KG010.010 GAS TANK...
  • Page 16 GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.9KG020...
  • Page 17 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KG020 PRODUCT NAME P.CODE BASE FRAME Y.EMP.9KG020.001 FEET Y.EMP.9KG020.002 BURNER BRACKET Y.EMP.9KG020.003 CASTING GRILL-SMALL Y.EMP.9KG020.004 FLEX HOSE 80CM Y.EMP.9KG020.005 INJECTOR GROUP Y.EMP.9KG020.006 BURNER 8,5KW Y.EMP.9KG020.007 BUTTON BUFFER Y.EMP.9KG020.008 BUTTON Y.EMP.9KG020.009 GAS TAP...
  • Page 18 GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.7KG020...
  • Page 19 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:EMP.7KG020 PRODUCT NAME P.CODE BASE FRAME Y.EMP.7KG020.001 FEET Y.EMP.7KG020.002 BURNER BRACKET Y.EMP.7KG020.003 CASTING GRILL Y.EMP.7KG020.004 PILOT Y.EMP.7KG020.005 INJECTOR GROUP Y.EMP.7KG020.006 BURNER 6 KW Y.EMP.7KG020.007 BUTTON BUFFER Y.EMP.7KG020.008 BUTTON Y.EMP.7KG020.009 GAS TAP Y.EMP.7KG020.010 GAS TANK...
  • Page 20 GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.9KG030...
  • Page 21 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.9KG030 PRODUCT NAME P.CODE BASE FRAME Y.EMP.9KG030.001 FEET Y.EMP.9KG030.002 BURNER BRACKET Y.EMP.9KG030.003 CASTING GRILL-SMALL Y.EMP.9KG030.004 FLEX HOSE 80CM Y.EMP.9KG030.005 INJECTOR GROUP Y.EMP.9KG030.006 BURNER 8,5KW Y.EMP.9KG030.007 BUTTON BUFFER Y.EMP.9KG030.008 BUTTON Y.EMP.9KG030.009 GAS TAP...
  • Page 22 GAS COOKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.7KG030...
  • Page 23 GAS COOKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE:EMP.7KG030 PRODUCT NAME P.CODE BASE FRAME Y.EMP.7KG030.001 FEET Y.EMP.7KG030.002 BURNER BRACKET Y.EMP.7KG030.003 CASTING GRILL Y.EMP.7KG030.004 PILOT Y.EMP.7KG030.005 INJECTOR GROUP Y.EMP.7KG030.006 BURNER 6 KW Y.EMP.7KG030.007 BUTTON BUFFER Y.EMP.7KG030.008 BUTTON Y.EMP.7KG030.009 GAS TAP Y.EMP.7KG030.010 GAS TANK...
