Service Manual
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are
marked by
in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
We suggest to handle such parts after the static electricity prevention.
It is forbidden to touch the PCB parts by bare hands during the repairing process.
1.Specifications
2.Parts Identifcation
3.Wiring Diagram
4.Parts List
5.Troubleshooting Guide
WARNING
IMPORTANT SAFETY NOTICE
PEG1610038CE
Version:2301
Air Purifier
India Market
Malaysia Market
Vietnam Market
Indonesia Market
Thailand Market
Philippines Market
F-PXM35A
2~4
6~8
9~14
1
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic nanoe F-PXM35A
Summary of Contents for Panasonic nanoe F-PXM35A
- Page 1 PEG1610038CE Version:2301 Service Manual Air Purifier India Market Malaysia Market Vietnam Market Indonesia Market Thailand Market Philippines Market F-PXM35A WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
-
Page 3: Parts Identification
2.Parts Identification F-PXM35A Main Body Section (2pcs) (3pcs) (4pcs) (Sensor PCB) Display PCB Unit (3pcs) (3pcs) Fan Section (2pcs) (2pcs) (3pcs) For Style Reference Remark: The double same letter which displayed behind the Lead Assy. Means they were linked together. -
Page 4: Fan Section
2.Parts Identification F-PXM35A Fan Section Nanoe Unit (3pcs) (2pcs) Wiring Section Lead Assy(A) Lead Assy(A) Lead Assy(B) Lead Assy(C) Cord Assy Lead Assy(B) Motor Lead Assy... - Page 5 2.Parts Identification F-PXM35A Packing Section (2pcs)
-
Page 6: Wiring Diagram
3.Wiring Diagram F-PXM35A Display P.C.B CN102 CN101 LED110 LED115 LED113 LED117 LED116 LED108 LED111 SW102 SW101 SW104 LED103 LED107 LED104 LED114 LED109 SW103 LED105 LED106 LED102 LED101 LND101 Odor Sensor LEAD ASSY(C) CN201 HV LEAD LEAD ASSY(B) GND LEAD NANOE UNIT LEAD LEAD ASSY(A) CORD ASSY POWER PCB ASSY... -
Page 7: Parts List
4.Parts List F-PXM35A Main Body Section Part No. Part Name Q'ty Remark FFE33001601S Front Panel Print Blue Model,For India Market FFE33001602S Front Panel Print Silver Model,For India Market FFE33001502S Front Panel Print For Malaysia,Vietnam,Indonesia,Thailand,Philippines Market FFE41801718S HEPA Filter Assy For India,Malaysia,Indonesia Market FFE41802307S HEPA Filter Assy For Thailand Market FFE41801804S HEPA Filter Assy... - Page 8 4.Parts List F-PXM35A Main Body Section Part No. Part Name Q'ty Remark FFE34011601S Sw Panel Blue Model,For India Market (14) FFE34031701S Sw Panel Blue Model,For Malaysia,Vietnam Market (14) FFE34011602S Sw Panel Silver Model,For India Market (14) FFE34041701S Sw Panel Silver Model,For Malaysia,Indonesia,Thailand,Philippines Market FFE16101601S Cord Assy For India Market (15)
- Page 9 4.Parts List F-PXM35A Fan Section Parts No. Parts Name Q'ty Remark FFE09071102S Peltier Lead FFE15001302S Nanoe Unit FFE09061102S High Voltage Lead FFE48041301S Nanoe PCB Assy FFE12221001S Lead Assy (C) FFE01211203S Nanoe Attachment FFE02091101S Nanoe Silencer FFE02081102S Nanoe Cover XTB4+14CFJ Bind Tap Screw Packing Section Parts No.
- Page 10 Corrective Maintenance Fault Phenomena:1,Air Volume Indicator Light Flashing 2,Machine out of operation Cause:1,Motor's rotating speed is abnormal. 2,Motor out of operation Substitute Part: Motor,Power Circuit Assembly Abnormal Check if the motor lead wire terminals disconnect Reconnect the motor lead wire terminal with the power circuit assembly on the power circuit assembly Normal...
- Page 11 Display P.C.B CN102 CN101 LED113 LED110 LED115 LED117 LED116 LED108 LED111 SW102 SW101 SW104 LED103 LED104 LED107 LED114 LED109 SW103 LED105 LED106 LED102 LED101 LND101 Odor Sensor LEAD ASSY(C) CN201 HV LEAD LEAD ASSY(B) GND LEAD NANOE UNIT LEAD LEAD ASSY(A) CORD ASSY POWER PCB ASSY MOTOR...
- Page 12 Setting method of checking mode Body Plug in the power supply. Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation...
- Page 13 Setting method of checking mode Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Body Use the alcoho spray to odor sensor to confirm the status Operation of the odor sensor Body Operation Indicating...
- Page 14 Setting method of checking mode Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Body Press Operation Body Operation Indicating confirmation Mode check is complete and unplug the power supply.
- Page 15 Setting method of checking mode Setting method of checking mode is used to check the working status of all features of the machine. Indicator Light's Notes 1,Function icon (Black is light off, color is light on ) 2,Rectangular bar is air pollution indicator (Display color includes blue, red.
