42” lcd television
Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTENTS
Getting Started ............................................................... 3
Specifications ........................................................................................................... 5
Opening the Package ................................................................................................ 9
Installation................................................................................................................ 9
Important Safety Guidelines................................................................................... 10
Television Antenna Connection Protection ............................................................ 13
Product Browse ...................................................................................................... 15
Display.......................................................................................................... 15
Note: wall-mounted ...................................................................................... 16
TV Info Explained ........................................................................................ 19
Source PC & AV Explained .......................................................................... 19
Media Box .................................................................................................... 21
Media Box Rear View Connector Definitions .............................................. 22
Picture Quality of All Connections from Ok to Best .................................... 24
Quick Installation ................................................................................................... 26
Installation batteries of remote control ......................................................... 26
Connecting the Display with Media Box...................................................... 26
Connecting the Display with Media Box...................................................... 27
Connecting the AC Power Cord.................................................................... 29
Connecting AV1 / AV2 Port .......................................................................... 30
Connecting Component HD Port .................................................................. 31
Connecting HDMI-1, HDMI-2 Port.............................................................. 32
Connecting ATSC Tuner ............................................................................... 34
Connecting Line Out Port ............................................................................. 34
Connecting VGA Port ................................................................................... 35
Connecting to TV Speaker............................................................................ 36
