- Page 1 Lighting made better. User Manual 4” Slim Baffle Selectable Nightlight SKU: DL_SLBF4_INL-WH-2760K support@sunco.com (844) 334-9938...
- Page 2 What’s in the Box? Baffle w/ Nightlight Light Fixture Junction Box Installation Template Wire Nuts Get Your Gear Cable Connector Hole Saw Ladder Wire Strippers...
- Page 3 Before You Start Safety Information To reduce the risk of fire, electric shock, or physical injury: • Turn off circuit breaker before installing this fixture. • Suitable for damp locations at temperature ranging • Professional installation required. Safety gear from 4°F to 113°F. Not for use where directly exposed recommended.
- Page 4 Installation Guide STEP 1 a. Turn off circuit breaker before installation. b. Cut out 4.33” housing size on Installation Template (C), 4.33” then tape onto ceiling in desired location. c. Cut ceiling hole using Installation Template (C) as a guide. STEP 2 a.
- Page 5 Installation Guide (Cont.) STEP 3 a. Thread cable connector through J-Box knockout, secure wires with screws, then connect cable connector on opposite side. b. Connect supply wires with junction wires using wire nuts (C): - Black to Black (Live) -White to White (Neutral) - Bare Copper to Bare Copper (Ground) c.
- Page 6 Installation Guide (Cont.) STEP 5 a. Attach fixture to junction box using connector (1). b. Tighten connector by hand (2). STEP 6 a. To toggle between downlight and nightlight mode, toggle wall switch within 2 seconds. Note: lf using multiple lights and they are not synced, turn off lights for more than 5 seconds.
-
Page 7: Product Details
Product Details Recommended Dimmers Brand Model LUTRON P-PKG1WB-WH LUTRON MACL-153M-WH LUTRON PD-6WCL-WH LUTRON AYCL-153P-WH LUTRON DVCL-153P-WH LEVITON D26HD-2RW KASA SMART HS220 KASA SMART HS220P3 Specifications Voltage Average Lifetime 120V 50000 Hours Wattage Lumens 600LM Frequency Moisture Rating 60Hz Damp Rated Beam Angle 120°... -
Page 8: Common Troubleshooting
Common Troubleshooting We’ve got you covered! Our troubleshooting If you still need some assistance, feel free to section is here to shed some light and provide contact us. Our team of lighting experts are happy you with easy-to-follow solutions for any problem. to help brighten your day. - Page 9 Light Distribution Angle AVERAGE BEAM ANGLE (50%): 134.1 DEG C0/180 137.6° C90/270 130.7° UNIT:cd Luminous Intensity Distribution 1 Lighting distribution angle refers to the spread of certain degree in up-lighting. An asymmetric light emitted from a light source. It is an important lighting distribution angle, also known as beam factor to consider when selecting a fixture or angle, creates a pattern that focuses light in a...
- Page 10 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
